5.7-5.8 GHz Base Station Transceiver BTR5857 INSTALLATION AND OPERATION GUIDE FOR SYSTEM OPERATORS VCom Inc. BTR5857 Manual; ML_BTR5857_02 (Mar 2004) Approved: G.C. ii Thank-you for purchasing this product and welcome to VCom! You have chosen an innovative broadband wireless solution from a leading technology design center in the ongoing TV & data delivery revolution. No doubt you’ve been thinking that the future of your television delivery system includes new technologies such as Digital TV, Internet Over Cable, Wireless Cable. By selecting VCom, you are benefiting from the same design powerhouse that since 1988 has created custom RF and digital products for technology leaders such as AT&T, Cisco Systems, Cogeco, Comcast, and Cox Communications. VCom designs and manufactures: ✔ ✔✔ ✔Agile CATV Modulators ✔ ✔✔ ✔256 QAM Upconverters ✔ ✔✔ ✔Digital Video Modulators ✔ ✔✔ ✔Frequency Translators ✔ ✔✔ ✔Spread Spectrum Devices ✔ ✔✔ ✔Off-Air Demodulators ✔ ✔✔ ✔Video-On-Demand Products ✔ ✔✔ ✔Wireless Cable MMDS ✔ ✔✔ ✔Wireless Cable LMDS ✔ ✔✔ ✔Frequency Stackers ✔ ✔✔ ✔Subscriber Transceivers ✔ ✔✔ ✔Satellite Receivers and more! Designs to fill the market needs of the CATV industry – both foreign and domestic. For additional product or corporate information, contact us: On the web at: www.vcom.com By sending email to: [email protected] By telephone: (306) 955-7075 By fax: (306) 955-9919 By snail mail: VCom Inc. 150 Cardinal Place Saskatoon, SK Canada S7L 6H7 VCom's Corporate Mandate is to be a leading worldwide designer and manufacturer of state- of-the-art communications equipment and components. Through the remarkable success of our customers and business partners, VCom innovations are achieving this goal. VCom Inc. BTR5857 Manual; ML_BTR5857_02 (Mar 2004) Approved: G.C. iii Proprietary to VCom Inc. All rights reserved. No part of this publication may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation or adaptation) without written permission from VCom Inc. VCom Inc. reserves the right to revise this publication and to make changes in content from time to time without obligation on the part of VCom Inc. to provide notification of such revision or change. VCom Inc. provides this guide without warranty of any kind, either implied or expressed, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. VCom Inc. may make improvements or changes in the product(s) described in this manual at any time. BTR5857 Manual; ML_BTR5857_02 (Mar 2004); Approved: G.C. Specifications subject to change without notice — Printed in Canada VCom Inc. BTR5857 Manual; ML_BTR5857_02 (Mar 2004) Approved: G.C. iv SAFETY PRECAUTIONS 1. Before installing and operating this equipment, read all Safety, Installation and Operating sections. Retain this manual for future reference. 2. Follow all instructions — Failure to do so may result in damage to the unit or severe personal injury. 3. The user should not attempt servicing. There are no user serviceable parts inside. Refer all servicing to factory qualified personnel. 4. Cleaning — Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning. Warning Do not work on the system or connect or disconnect cables during periods of lightning activity. LES PRÉCAUTIONS DE SÉCURITÉ 1. Avant d'installer ou d'opérer cet équipement, lisez, toutes les sections de sécurités, d'installations et d'opérations. Gardez ce manuel comme source de référence. 2. Suivez toutes instructions - si non, vous risquez d'endommager la machine ou de vous blesser sérieusement. 3. N'essayez, pas de réparer cet équipement vous même. Référez toutes revisions nécessaire au personnel qualifié de la manufacture. 4. Le nettoyage - n'utilisez pas de nettoyeurs aérosols ou liquides. Utilisez un tissu humide pour nettoyer. Attention Ne pas travailler sur le système ni brancher ou débrancher les câbles pendant un orage du foudre. VCom Inc. BTR5857 Manual; ML_BTR5857_02 (Mar 2004) Approved: G.C. v INFORMATION TO USER This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for Class B Digital Device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna • Increase the separation between the equipment and receiver • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected • Consult the dealer or an experienced radio/TV technician for help CAUTION: Any changes or modifications not expressly approved by VCom Inc. could void the user’s authority to operate the equipment. CAUTION: This device must be professionally installed. WARNING: In order to comply with the FCC radiofrequency exposure limits of 1.1310, this equipment must be installed in such a way as to provide a minimum separation distance of 1.5m from the transmitting antenna to persons nearby. The installer of this radio equipment must ensure that the antenna is located or pointed such that it does not emit RF fields in excess of Health Canada’s limits for the ge…

Text truncated - open the document above for the full version.

T HE VC OM BTR5857 B ASE S TATION T RANSCEIVER The VCom BTR5857is a low cost 5.7 to 5.8 GHz Base Station Outdoor Unit (ODU) for use with VCom TRI5758 in broadband fixed wireless systems. The BTR5857 cost and performance makes it ideal for both point-to-point and point-to-multipoint systems. The BTR5857 combines a low noise downconverter, high power upconverter and high rejection duplexer to offer a quick and easy to install base station ODU for BWIN TM BASED ON DOCSIS TM . br_btr5857_03 (Mar 2004) Product Features: • Up to +15 dBm output power with 64QAM; +20 dBm with QPSK • Digital temperature compensation - guarantees specifications over full operating temperature band • High reliability, state-of-the-art design using microstrip, MMIC and surface mount technology • Can be used with an external antenna or an integrated antenna for point-to-point systems • Automatic transmit RF mute (transmits only when an IF signal is present) VCom Inc. (formerly WaveCom Electronics Inc.) 150 Cardinal Place Saskatoon, Sk, Canada S7L 6H7 TEL: (306) 955-7075 FAX: (306) 955-9919 Website: www.vcom.com E-mail: [email protected] Distributed by: Specifications subject to change without notice — Printed in Canada br_btr5857_03 (Mar 2004) The DOCSIS TM acronym belongs to CableLabs® 150 C ARDINALPLACE, SASKATOON, SKS7L 6H7 T EL: (306) 955-7075 FAX: (306) 955-9919 E-MAIL: [email protected]: WWW.VCOM.COM Specifications subject to change without notice. - Printed in Canada. S PECIFICATIONS —VC OM BTR5857 Base Station Transceiver T RANSMITSPECIFICATIONS IF Input Frequency516-540 MHz Bandwidthone or more RF carriers (4 x 6 MHz) RF Output Frequency Range5775-5799 MHz (Low Band Option) 5799-5823 MHz (High Band Option) Frequency Response (any 6 MHz band)± 0.3 dB Rated Output Power at Antenna Port+15 dBm (64QAM); +20 dBm (QPSK) Spectral MaskCompliant with ETSI EN 301 021 v1.5.1, section 5.3.3, system type D Phase Noise<-85 dBc/Hz @ 10 KHz Gain30 dB (± 1 dB over temp) IFLevel for RF Activation18 ± 2 dBmV RECIEVE RF Input Frequency Range5727-5751 MHz (Low Band Option) 5751-5775 MHz (High Band Option) Frequency Response (any 6 MHz band)±0.3 dB IF Output Frequency Range18-42 MHz Noise Figure at Antenna Port<6 dB including duplexer loss Gain38 dB (± 2 dB over temp) Phase Noise<-85 dBc/Hz @ 10 KHz GENERAL Frequency Setting and Stability over Temperature± 15 kHz Frequency Setting and Stability over 10 years± 25 kHz IF ConnectorF female, 75 ohms RF ConnectorN female, 50 ohms Return Loss10 dB Power Requirement12 to 28 VDC (+21 V to +28 V nominal) Power Consumption12W maximum Operating Temperature RangeETS 300 019 Class 4.1 (-30 to +40°C ambient) full specifications ETS 300 019 Class 4.1E (-45 to +45°C ambient) operational Antenna Beamwidth90°, Omnidirectional available Antenna ComplianceETSI EN 302 085 Spurious EmissionsETSI EN 301 390, FCC Part 15, Industry Canada RSS-210 EMC ComplianceETSI EN 300 385 MountingStandard - Pole (1” to 1.75” (25mm to 44mm) diameter) with polarization , azimuth, elevation adjustment. Optional - wall mount Dimensions12” x 12” x 2.5” (305 mm x 305 mm x 64 mm) maximum Weight5.5 lbs. (2.5 kg) SYSTEMCONFIGURATIONS BTR5857-T5775_5799-R5727_5751Outdoor 5.7 GHz Base Station Transceiver Low Band (Transmit: 5775-5799 MHz, Receive: 5727-5751 MHz) BTR5857-T5799_5823-R5751_5775Outdoor 5.7 GHz Base Station Transceiver High Band (Transmit: 5799-5823 MHz, Receive: 5751-5775 MHz)

TA-5705H-14-90 Sector 5725-5875 MHz 0 90 180 2700-3-6-10 -15 -20 -30 dB 0 90 180 2700-3-6-10 -15 -20 -30 dB Typical mid band values. (For details , contact factory) E-PlaneH-Plane The TA-5705H-14-90 is a horizontally polarized 90 degree sectoral antenna. The antenna consists of a printed dipole array enclosed in an aluminum base with a UV stabilized radome for superior weatherability. The antenna is at DC ground to aid in lightning protection. 2.25 in. (57mm) 6 lb. (2.72 kg) 125 mph (200 km/h) 96 lb. (43.5 kg) 0+/-16 degrees 0.75 - 2.0 in. (19 - 51 mm) Depth: Weight (incl. Clamps): Rated Wind Velocity: Hor. Thrust at rated wind: Mechanical Tilt: Mounting (OD): Mechanical Specifications Length:24.5 in. (622 mm) Width:9.0 in. (229 mm) Plated Copper on PCB Irridited aluminum Gray UV stabilized ASA Aluminum and stainless steel Radiating Elements: Reflector: Radome: Clamps: Materials 5725-5875 MHz 16.5 dBi min. 1.5:1 25 dB min. Horizontal 5 Watts 5 degrees 90 degrees 20 dB min. 50 ohms nominal N female Frequency Range: Gain: VSWR: Front to Back Ratio: Polarization: Power Rating: H-Plane Beamwidth: E-Plane Beamwidth: Cross Pol. Discrimination: Impedance: Termination: Electrical Specifications TIL-TEK Antennaswww.tiltek.com(613) 258-5928Form 2002-5705H-14-90 Specifications subject to change without notice 2003-10-02

TA-5204-14-90 Sector 5250-5350 & 5725-5850 MHz 0 90 180 2700-3-6-10 -15 -20 -30 dB 0 90 180 2700-3-6-10 -15 -20 -30 dB Typical mid band values. (For details , contact factory) H-PlaneE-Plane The TA-5204-14-90 is a vertically polarized 90 degree sectoral antenna. The antenna consists of a printed dipole array enclosed in an aluminum base with a UV stabilized radome for superior weatherability. The antenna is at DC ground to aid in lightning protection. 2.0 in. (51 mm) 6 lb. (2.72 kg) 125 mph (200 km/h) 72 lb. (32.6 kg) 0+/-16 degrees 0.75 - 2.0 in. (19 - 51 mm) Depth: Weight (incl. Clamps): Rated Wind Velocity: Hor. Thrust at rated wind: Mechanical Tilt: Mounting Pipe: Mechanical Specifications Length:26.5 in. (673 mm) Width:6.25 in. (159 mm) Plated Copper on PCB Irridited aluminum Gray UV stabilized ASA Aluminum and HDG steel Radiating Elements: Reflector: Radome: Clamps: Materials 5250-5350 & 5725-5850 MHz 16 dBi min. 1.5:1 25 dB min. Vertical 5 Watts 90 degrees 5 degrees 20 dB min. 50 ohms nominal N female Frequency Range: Gain: VSWR: Front to Back Ratio: Polarization: Power Rating: H-Plane Beamwidth: E-Plane Beamwidth: Cross Pol. Discrimination: Impedance: Termination: Electrical Specifications TIL-TEK Antennaswww.tiltek.com(613) 258-5928Form 2002-5204-14-90 Specifications subject to change without notice 2001-12-18

RF Exposure Label Revision: 01 Date: 04 September 2003 Equipment: VCom BTR5857 Base Station Transceiver FCC ID: OPPBTR5857 Label dimensions: 10.2 cm x 2.5 cm Label font: 11 point Helvetica Regular Condensed Antenna RF Exposure Label close up Antenna RF Exposure Label from 3 feet distance

Prediction of MPE limit at a given distance Fixed Mounted Horizontal Antenna Equation from page 18 of OET Bulletin 65, Edition 97-01where: S = power density P = power input to the antennaG = power gain of the antenna in the direction of interest relative to an isotropic radiatorR = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal: 20.00 (dBm) Maximum peak output power at antenna input terminal: 100 (mW) Antenna gain(typical): 16.5 (dBi) Maximum antenna gain: 44.66835922 (numeric) Prediction distance: 20 (cm) Prediction frequency: 5800 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 1 (mW/cm^2) Power density at prediction frequency: 0.888649 (mW/cm^2) Maximum allowable antenna gain: 17.01269855 (dBi) Margin of Compliance: 0.512698554 2 4 R PG S π =

Prediction of MPE limit at a given distance Fixed Mounted Vertical Antenna Equation from page 18 of OET Bulletin 65, Edition 97-01where: S = power density P = power input to the antennaG = power gain of the antenna in the direction of interest relative to an isotropic radiatorR = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal: 20.00 (dBm) Maximum peak output power at antenna input terminal: 100 (mW) Antenna gain(typical): 16 (dBi) Maximum antenna gain: 39.81071706 (numeric) Prediction distance: 20 (cm) Prediction frequency: 5800 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 1 (mW/cm^2) Power density at prediction frequency: 0.792009 (mW/cm^2) Maximum allowable antenna gain: 17.01269855 (dBi) Margin of Compliance: 1.012698554 2 4 R PG S π =

Prediction of MPE limit at a given distance Fixed Mounted Horizontal Antenna Equation from page 18 of OET Bulletin 65, Edition 97-01where: S = power density P = power input to the antennaG = power gain of the antenna in the direction of interest relative to an isotropic radiatorR = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal: 20.00 (dBm) Maximum peak output power at antenna input terminal: 100 (mW) Antenna gain(typical): 16.5 (dBi) Maximum antenna gain: 44.66835922 (numeric) Prediction distance: 20 (cm) Prediction frequency: 5800 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 1 (mW/cm^2) Power density at prediction frequency: 0.888649 (mW/cm^2) Maximum allowable antenna gain: 17.01269855 (dBi) Margin of Compliance: 0.512698554 2 4 R PG S π =

Prediction of MPE limit at a given distance Fixed Mounted Vertical Antenna Equation from page 18 of OET Bulletin 65, Edition 97-01where: S = power density P = power input to the antennaG = power gain of the antenna in the direction of interest relative to an isotropic radiatorR = distance to the center of radiation of the antenna Maximum peak output power at antenna input terminal: 20.00 (dBm) Maximum peak output power at antenna input terminal: 100 (mW) Antenna gain(typical): 16 (dBi) Maximum antenna gain: 39.81071706 (numeric) Prediction distance: 20 (cm) Prediction frequency: 5800 (MHz) MPE limit for uncontrolled exposure at prediction frequency: 1 (mW/cm^2) Power density at prediction frequency: 0.792009 (mW/cm^2) Maximum allowable antenna gain: 17.01269855 (dBi) Margin of Compliance: 1.012698554 2 4 R PG S π =

Master: PT15C-FHT Date: February 7, 2002 Test Report: 4W07803 Applicant: VCom Inc. 150 Cardinal Place Saskatoon, SK Canada S7L 6H7 Equipment Under Test: BTR5857 (EUT) FCC ID: OPPBTR5857 In Accordance With: FCC Part 15, Subpart E U-NII Devices Tested By: Nemko Canada Inc. 303 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: Sim Jagpal, Resource Manager Date: 11 March 2004 Total Number of Pages: 41 Nemko Canada Inc. FCC PART 15, SUBPART E U-NII Devices PROJECT NO.:4W07803 EQUIPMENT: BTR5857 Page 2 of 41 Table of Contents Section 1. Summary of Test Results ...................................................................................3 Section 2. General Equipment Specification......................................................................5 Section 3. Powerline Conducted Emissions........................................................................6 Section 4. Emission Bandwidth .........................................................................................11 Section 5. Peak Conducted Transmit Power....................................................................16 Section 6. Peak Power Spectral Density ...........................................................................21 Section 7. Peak Excursion Measurement .........................................................................26 Section 8. Undesirable Emissions......................................................................................31 Section 9. Block Diagrams .................................................................................................39 Section 10. Test Equipment List ..........................................................................................41 Nemko Canada Inc. FCC PART 15, SUBPART E U-NII Devices PROJECT NO.:4W07803 EQUIPMENT: BTR5857 Page 3 of 41 Section 1. Summary of Test Results General All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with Part 15, Subpart E, for U-NII devices. Radiated tests were conducted is accordance with ANSI C63.4-1992. Radiated emissions are made on an open area test site. A description of the test facility is on file with the FCC. THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. TESTED BY: _______________________________ DATE: 11 March 2004 Glen Westwell, Wireless Specialist TESTED BY: _______________________________ DATE: 11 March 2004 Kevin Carr, EMC/EMI/Wireless Specialist Nemko Canada Inc., a testing laboratory, is accredited by the Standards Council of Canada. The tests included in this report are within the scope of this accreditation. The results apply only to the samples tested. Nemko Canada Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Canada Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko Canada Inc. FCC PART 15, SUBPART E U-NII Devices PROJECT NO.:3W07146 EQUIPMENT: BTR5857 Page 4 of 34 Summary Of Test Data Name Of Test Para. No. Result Powerline Conducted Emissions 15.207(a) Complies Emission Bandwidth 15.403(c) Complies Peak Conducted Transmit Power 15.407(a)(3) Complies Peak Power Spectral Density 15.407(a)(3) Complies Peak Excursion Measurement 15.407(a)(6) Complies Undesirable Emissions 15.407(b)(3)(5) Complies Test Conditions: Indoor Temperature: 22°C Humidity: 27% Outdoor Temperature: 10°C Humidity: 49% Nemko Canada Inc. FCC PART 15, SUBPART E U-NII Devices PROJECT NO.:4W07803 EQUIPMENT: BTR5857 Page 5 of 41 Section 2. General Equipment Specification Manufacturer: VCom Inc. Model No.: BTR5857 Serial No.: 304061 Date Received In Laboratory: Sept 5, 2003 Nemko Identification No.: 1 Frequency Band: 5725-5825MHz Operating Frequency(ies) of DUT: 5802-5817MHz MHz Transmit Power (Rated): 64QAM: +15.0dBm QPSK: +20dBm Modulation: 64 QAM @ 5.056941Msym/Sec QPSK @ 5.213043Msym/Sec Antenna Gain(s): 5204-14-90V = 16dBi 5705H-14-90 = 16.5dBi EUT Set Up for Conducted Tests. DUT RF OUT, 5802-5817MHz IF IN, 519-534MHz Signal Gen AC/DC BTR5857 Power Meter H.P.E4418B Nemko Canada Inc. FCC PART 15, SUBPART E U-NII Devices PROJECT NO.:4W07803 EQUIPMENT: BTR5857 Page 6 of 41 Section 3. Powerline Conducted Emissions Para. No.: 15.207 (a) Test Performed By: Kevin Carr Date of Test: 3 Oct. 2003 Test Results: Complies Measurement Data: See attached graph(s). Nemko Canada Inc. FCC PART 15, SUBPART E U-NII Devices PROJECT NO.:4W07803 EQUIPMENT: BTR5857 Page 7 of 41 Nemko Canada Inc. FCC PART 15, SUBPART E U-NII Devices PROJECT NO.:4W07803 EQUIPMENT: BTR5857 Page 8 of 41 Nemko Canada Inc. FCC PART 15, SUBPART E U-NII Devices PROJECT NO.:4W07803 EQUIPMENT: BTR5857 Page 9 of 41 Nemko Canada Inc. FCC PART 15, SUBPART E U-NII Devices PROJECT NO.:4W07803 EQUIPMENT: BTR5857 Page 10 of 41 Powerline Conducted Emissions Set-up Photo: Nemko Canada Inc. FCC PART 15, SUBPART E U-NII Devices PROJECT NO.:4W07803 EQUIPMENT: BTR5857 Page 11 of 41 Section 4. Emission Bandwidth Para. No.: 15.403(c) Test Performed By: Glen Westwell Date of Test: 3 Mar. 2004 Test Results: Complied Measurement Data: See Attached Plots. Emission Bandwidth (EBW) Frequency 5802MHz 5811MHz 5817MHz QPSK 6.13MHz 6.13MHz 6.17MHz QAM 5.95MHz 5.92MHz 5.95MHz Nemko Canada Inc. FCC PART 15, SUBPART E U-NII Devices PROJECT NO.:4W07803 EQUIPMENT: BTR5857 Page 12 of 41 QAM Nemko Canada Inc. FCC PART 15, SUBPART E U-NII Devices PROJECT NO.:4W07803 EQUIPMENT: BTR5857 Page 13 of 41 Nemko Canada Inc. FCC PART 15, SUBPART E U-NII Devices PR…

Text truncated - open the document above for the full version.

Nemko Canada Inc. FCC PART 15, SUBPART E U-NII Devices PROJECT NO.:4W07803 EQUIPMENT: BTR5857 Page 10 of 41 Powerline Conducted Emissions Set-up Photo:

Nemko Canada Inc. FCC PART 15, SUBPART E U-NII Devices PROJECT NO.:4W07803 EQUIPMENT: BTR5857 Page 37 of 41 Radiated Test Set-Up, Pre-Scan Nemko Canada Inc. FCC PART 15, SUBPART E U-NII Devices PROJECT NO.:4W07803 EQUIPMENT: BTR5857 Page 38 of 41 Radiated Emissions, OATS
