OPPMA4070B

AGILE MMDS UPCONVERTER MA4061 12W POWER AMPLIFIER MA4070B INSTALLATION AND OPERATION GUIDE FOR SYSTEM OPERATORS WaveCom Electronics Inc MA4061/MA4070 Manual; MAN1L2301 Rev02 (Oct 2001) Approved: R. L. ii Proprietary to WaveCom Electronics Inc. All rights reserved. No part of this publication may by reproduced in any form or by any means or used to make any derivative work (such as translation, transformation or adaptation) without written permission from WaveCom Electronics Inc. WaveCom Electronics Inc. reserves the right to revise this publication and to make changes in content from time to time without obligation on the part of WaveCom Electronics Inc. to provide notification of such revision or change. WaveCom Electronics Inc. provides this guide without warranty of any kind, either implied or expressed, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. WaveCom Electronics Inc. may make improvements or changes in the product(s) described in this manual at any time. MA4061/MA4070 Manual; MAN1L2301 Rev02 (Oct 2001); Approved: R. L. Specifications subject to change without notice — Printed in Canada WaveCom Electronics Inc MA4061/MA4070 Manual; MAN1L2301 Rev02 (Oct 2001) Approved: R. L. iii Thank-you for purchasing this product and welcome to WaveCom! You have chosen an innovative solution from a leading technology design center in the ongoing TV & data delivery revolution. No doubt you’ve been thinking that the future of your television delivery system includes new technologies like Digital TV, Internet Over Cable, Wireless Cable. By selecting WaveCom, you are benefiting from the same design powerhouse that since 1988 has created custom RF and digital products for technology leaders like Nortel Networks, Diva Systems and Cisco Systems. WaveCom designs and manufactures: ✔ ✔✔ ✔Agile CATV Modulators ✔ ✔✔ ✔256 QAM Upconverters ✔ ✔✔ ✔Digital Video Modulators ✔ ✔✔ ✔Frequency Translators ✔ ✔✔ ✔Spread Spectrum Devices ✔ ✔✔ ✔Off-Air Demodulators ✔ ✔✔ ✔Video-On-Demand Products ✔ ✔✔ ✔Wireless Cable MMDS ✔ ✔✔ ✔Wireless Cable LMDS ✔ ✔✔ ✔Frequency Stackers ✔ ✔✔ ✔MMDS Transceivers ✔ ✔✔ ✔Satellite Receivers and more! Designs to fill the market needs of the CATV industry – both foreign and domestic. For additional product or corporate information, contact us: On the web at: www.WaveCom.ca By sending email to: [email protected] By telephone: (306) 955-7075 By fax: (306) 955-9919 By snail mail: WaveCom Electronics Inc. 222 Cardinal Cres. Saskatoon, SK Canada S7L 6H8 WaveCom's Corporate Mandate is to be a leading worldwide designer and manufacturer of state-of-the- art communications equipment and components. Through the remarkable success of our customers and business partners, WaveCom innovations are achieving this goal. WaveCom Electronics Inc MA4061/MA4070 Manual; MAN1L2301 Rev02 (Oct 2001) Approved: R. L. iv SAFETY PRECAUTIONS 1. Before installing and operating this equipment, read all Safety, Installation and Operating sections. Retain this manual for future reference. 2. Follow all instructions — Failure to do so may result in damage to the unit or severe personal injury. 3. Servicing should not be attempted by the user. There are no user serviceable parts inside. Refer all servicing to factory qualified personnel. 4. Shock Hazard — An electrical shock hazard exists when the chassis cover is removed as is required to set internal controls. Always disconnect power from the unit before removing the cover. 5. Cleaning — Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning. Warning Do not work on the system or connect or disconnect cables during periods of lightning activity. LES PRÉCAUTIONS DE SÉCURITÉ 1. Avant d'installer ou d'opérer cet équipement, lisez, toutes les sections de sécurités, d'installations et d'opérations. Gardez ce manuel comme source de référence. 2. Suivez toutes instructions - si non, vous risquez d'endommager la machine ou de vous blesser sérieusement. 3. N'essayez, pas de réparer cet équipement vous même. Référez toutes revisions nécessaire au personnel qualifié de la manufacture. 4. Risque de choc - Il y a un risque de décharge électrique qui existe quand la couverture du châssis est enlevée, comme est nécessaire pour ajuster les contrôlcs internes. Il faut toujours couper l'électricité avant d'enlever le couvercle pour faire aucun ajustage. 5. Le nettoyage - n'utilisez pas de nettoyeurs aérosols ou liquides. Utilisez un tissu humide pour nettoyer. Attention Ne pas travailler sur le système ni brancher ou débrancher les câbles pendant un orage du foudre. ☛ Caution: To comply with FCC RF exposure requirements in section 1.1307, any antenna which is connected to an MA4061/MA4070 requires a minimum distance of 1.5 meters between it and all persons. ☛ Important Installation Instructions WaveCom Electronics Inc MA4061/MA4070 Manual; MAN1L2301 Rev02 (Oct 2001) Approved: R. L. v INDEX 1.0 GENERAL INFORMATION ........................................................................................................7 1.1 System Overview ..................................................................................................................................... 7 1.2 MA4061B Module Features .................................................................................................................... 7 1.3 MA4070B Module Features .................................................................................................................... 7 1.4 System Features ....................................................................................................................................... 7 1.5 Specifications........................................................................................................................................... 8 2.0 INSTALLATION...........................................................................................................................9 2.1 Unp…

Text truncated - open the document above for the full version.

AGILE MMDS UPCONVERTER MA4061 POWER AMPLIFIER MA4070B INSTALLATION AND OPERATION GUIDE FOR SYSTEM OPERATORS WaveCom Electronics Inc MA4061/MA4070 Manual; MAN1L2301 Rev03 (Mar 2002) Approved: R. L. ii Proprietary to WaveCom Electronics Inc. All rights reserved. No part of this publication may by reproduced in any form or by any means or used to make any derivative work (such as translation, transformation or adaptation) without written permission from WaveCom Electronics Inc. WaveCom Electronics Inc. reserves the right to revise this publication and to make changes in content from time to time without obligation on the part of WaveCom Electronics Inc. to provide notification of such revision or change. WaveCom Electronics Inc. provides this guide without warranty of any kind, either implied or expressed, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. WaveCom Electronics Inc. may make improvements or changes in the product(s) described in this manual at any time. MA4061/MA4070 Manual; MAN1L2301 Rev03 (Mar 2002); Approved: R. L. Specifications subject to change without notice — Printed in Canada WaveCom Electronics Inc MA4061/MA4070 Manual; MAN1L2301 Rev03 (Mar 2002) Approved: R. L. iii Thank-you for purchasing this product and welcome to WaveCom! You have chosen an innovative solution from a leading technology design center in the ongoing TV & data delivery revolution. No doubt you’ve been thinking that the future of your television delivery system includes new technologies like Digital TV, Internet Over Cable, Wireless Cable. By selecting WaveCom, you are benefiting from the same design powerhouse that since 1988 has created custom RF and digital products for technology leaders like Nortel Networks, Diva Systems and Cisco Systems. WaveCom designs and manufactures: ✔ ✔✔ ✔Agile CATV Modulators ✔ ✔✔ ✔256 QAM Upconverters ✔ ✔✔ ✔Digital Video Modulators ✔ ✔✔ ✔Frequency Translators ✔ ✔✔ ✔Spread Spectrum Devices ✔ ✔✔ ✔Off-Air Demodulators ✔ ✔✔ ✔Video-On-Demand Products ✔ ✔✔ ✔Wireless Cable MMDS ✔ ✔✔ ✔Wireless Cable LMDS ✔ ✔✔ ✔Frequency Stackers ✔ ✔✔ ✔MMDS Transceivers ✔ ✔✔ ✔Satellite Receivers and more! Designs to fill the market needs of the CATV industry – both foreign and domestic. For additional product or corporate information, contact us: On the web at: www.WaveCom.ca By sending email to: [email protected] By telephone: (306) 955-7075 By fax: (306) 955-9919 By snail mail: WaveCom Electronics Inc. 222 Cardinal Cres. Saskatoon, SK Canada S7L 6H8 WaveCom's Corporate Mandate is to be a leading worldwide designer and manufacturer of state-of-the- art communications equipment and components. Through the remarkable success of our customers and business partners, WaveCom innovations are achieving this goal. WaveCom Electronics Inc MA4061/MA4070 Manual; MAN1L2301 Rev03 (Mar 2002) Approved: R. L. iv SAFETY PRECAUTIONS 1. Before installing and operating this equipment, read all Safety, Installation and Operating sections. Retain this manual for future reference. 2. Follow all instructions — Failure to do so may result in damage to the unit or severe personal injury. 3. Servicing should not be attempted by the user. There are no user serviceable parts inside. Refer all servicing to factory qualified personnel. 4. Shock Hazard — An electrical shock hazard exists when the chassis cover is removed as is required to set internal controls. Always disconnect power from the unit before removing the cover. 5. Cleaning — Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning. Warning Do not work on the system or connect or disconnect cables during periods of lightning activity. LES PRÉCAUTIONS DE SÉCURITÉ 1. Avant d'installer ou d'opérer cet équipement, lisez, toutes les sections de sécurités, d'installations et d'opérations. Gardez ce manuel comme source de référence. 2. Suivez toutes instructions - si non, vous risquez d'endommager la machine ou de vous blesser sérieusement. 3. N'essayez, pas de réparer cet équipement vous même. Référez toutes revisions nécessaire au personnel qualifié de la manufacture. 4. Risque de choc - Il y a un risque de décharge électrique qui existe quand la couverture du châssis est enlevée, comme est nécessaire pour ajuster les contrôlcs internes. Il faut toujours couper l'électricité avant d'enlever le couvercle pour faire aucun ajustage. 5. Le nettoyage - n'utilisez pas de nettoyeurs aérosols ou liquides. Utilisez un tissu humide pour nettoyer. Attention Ne pas travailler sur le système ni brancher ou débrancher les câbles pendant un orage du foudre. ☛ Caution: To comply with FCC RF exposure requirements in section 1.1307, any antenna which is connected to an MA4061/MA4070 requires a minimum distance of 1.5 meters between it and all persons. ☛ Important Installation Instructions WaveCom Electronics Inc MA4061/MA4070 Manual; MAN1L2301 Rev03 (Mar 2002) Approved: R. L. v INDEX 1.0 GENERAL INFORMATION ....................................................................................................... 7 1.1 System Overview ..................................................................................................................................... 7 1.2 MA4061B Module Features..................................................................................................................... 7 1.3 MA4070B Module Features..................................................................................................................... 7 1.4 System Features ....................................................................................................................................... 7 1.5 Specifications ........................................................................................................................................... 8 2.0 INSTALLATION .......................................................................................................................... 9 2.1 Unpac…

Text truncated - open the document above for the full version.

222 Cardinal Cres., Saskatoon, Saskatchewan, Canada S7L 6H8 ph: (306) 955-7075 fax: (306) 955-9919 we bs it e : www.WaveCom.ca RE: WaveCom MA4070BFCC ID# OPPMA4070B 1) The internal photo’s cannot be held confidential. Supply a corrected confidential letter. Our test agency, Nemko Canada Inc., provided the following statement from FCC: "Internal photographs are not normally held confidential because anyone who purchases the device can take it apart and see what it looks like. Exceptions are if a company restricts the marketing of a device so it is not sold directly to the general public or it takes a special tool to disassemble it, we will grant confidentiality to the internal photos. Cable set-top boxes were marketed this way at one time and most of them qualified for confidentiality of their internal photos. Another option is for the internal circuitry to be "potted" or covered in epoxy that cannot be easily removed. In that case we would hold the internal photos confidential. Also, if a company professionally installs the products and they are not sold directly to, or viewable by, the general public the internal photos could be made Confidential." A corrected Request for Nondisclosure is supplied. We think that item 9 of the request will justify holding the internal photos confidential. If the request for confidentiality of is not granted, then updated internal photos will be supplied. 2) The measured output power is 31.5 dBm. The specification sheet indicates output power up to 12 Watts. Please correct or provide data. A revised specification sheet is provided. 3) What was the input level of the input signal? Was it tested at the maximum input of 36 dBmV? The input level of input signal was –0.5 dBm (48.3 dBmV). This was sufficient to drive the output to 31.5 dBm. 4) Verify that the antennas listed will be the only antennas used with the device. Confirmed with WaveCom’s Vice-President, Systems Division. 5) Provide frequency stability tests. Frequency stability is not applicable to this equipment as it is a power amplifier with no internal frequency conversions. Verified by our test agency, Nemko Canada Inc. 222 Cardinal Cres., Saskatoon, Saskatchewan, Canada S7L 6H8 ph: (306) 955-7075 fax: (306) 955-9919 we bs it e : www.WaveCom.ca 6) Redo the RF safety compliance exhibits if appropriate with any change in output power or antenna gain. Based on the above, no changes were required.

T HE W AVE C OM MA4070B P OWER A MPLIFIER M ODULE WAVECOMELECTRONICSINC. 222 C ARDINALCRESCENT SASKATOON, SK, CANADA S7L 6H8 TEL: (306) 955-7075 FAX: (306) 955-9919 Website: www.WaveCom.ca E-mail: [email protected] Distributed by: Specifications subject to change without notice — Printed in Canada The MA4070Bis a solid state, fixed gain power amplifier for MMDS applications. The MA4070 has an instantaneous bandwidth of 100 MHz in the 2.5 to 2.7 GHz frequency band. High linearity permits the MA4070B to operate with high level digital (64 QAM) signals, or with analog video signals. The MA4070B is a modular plug-in designed for use with the WaveCom MA4000 Series. Each MA4000 card chassis with common MA4010 power supply can contain up to 2 - MA4070B power amplifiers and 2 - MA4061B MMDS Upconverters for a complete two channel transmitter in a 4U rack mount configuration. This advanced cost effective power amplifier offers high performance, flexibility and space efficiency. BRO1L2401 - Rev05(0202) Card Features: • RF High, RF Low, and High Reverse Power alarms • Linear transmit power for 64 QAM modulation • May be operated as high with video • Amplifier may be disabled via front panel or remote control • Fully protected against reverse power • High reliability, state of the art design using microstrip MMIC and surface mount technology; conservative component derating and 100% burn in help ensure reliable operation • Low power consumption System Features: • Local control via LCD and 4 soft touch push buttons • Remote control and monitoring via front panel configured RS232/RS485 • Durable design is reflected in the stainless steel chassis, active cooling, and lexan labels • International internal switching power supply (100 to 240 VAC) 222 CARDINALCRESCENT, SASKATOON, SKS7L 6H8 T EL: (306) 955-7075 FAX: (306) 955-9919 E-MAIL: [email protected] W EBSITE: WWW.WAVECOM.CA BRO1L2401 - Rev05(0202) Specifications subject to change without notice. - Printed in Canada. SPECIFICATIONS—WAVECOMMA4070B Power Amplifier Module RF Output Frequency2500 to 2600 MHz (any 100 MHz band available from 2500 to 2700 MHz) Output PowerFCC emission mask approved for 31.5 dBm Gain34 dB ±2 dB, fixed Gain Stability±0.5 dB (10 to 40°C) Gain Flatness±0.3 dB over 6 MHz Mute Level-60 dBc Spurious Inband-55 dBc Out of band-55 dBc Sync Pulse Compression2 IRE max (analog video, 7 W) Spectral Sideband Regrowth-35 dBc max. (64 QAM, 2 W) Input Impedance50 ohm Output ConnectorN female Front Panel IndicatorsDC power RF High RF Low High Reverse Power Miscellaneous Remote Control InterfaceRS232/RS485 Remote Control ConnectorRJ45 (in and out) Operating Temperature10 to 40°C (50 to 104°F) MA4010 Power Supply (included with MA4000 chassis)100 to 240 VAC; 50/60 Hz Shipping Weight MA4000 chassis with MA4010 PS18 lbs. (8.2 kg) MA4070B Power Amplifier Module (each)6.2 lbs. (2.8 kg) Dimensions (MA4000 chassis)19" (w) x 13.7" (d) x 7" (h) (48.3 x 34.8 x 17.8 cm) Mounting (MA4000 chassis)Standard 19" rack - 4U (7.0") Other Features Local and Remote Control RF Output Disable Via Local or Remote Control

RF Exposure Label Revision: 01 Date: 02 October 2001 Equipment: WaveCom MA4070B 12W Power Amplifier Module FCC ID: OPPMA4070B 10.2 cm x 2.5 cm label, 11 point Helvetica Regular Condensed Antenna RF Exposure Label close up Antenna RF Exposure Label from 3 feet distance Antenna RF Exposure Label full view

RF Safety Exhibit Revision: 03 Date: 24 October 2001 Equipment: WaveCom MA4070B 12W Power Amplifier FCC ID: OPPMA4070B For radio transmitters in the 2500 to 2686 MHz band, paragraph 1.1310 limits maximum permissible exposure (MPE) to 1 mW/cm 2 for uncontrolled environments. The maximum safe distance from the antenna at which MPE is met or exceeded is calculated from the equation relating field strength in V/m, transmit power in Watts, transmit antenna gain, and separation distance in meters: Basis of calculations: Safe Distance meters for 1mW/cm 2 MPE = (P Watts x Antenna Gain dBi x 30)^0.5 / 61.4 V/m Transmitted Power Antenna Type Antenna Gain Safe Distance (Watts) (dBm) (dBi) (meters) 1.41 31.5 omni 10 0.3353 1.41 31.5 omni 15 0.5962 1.41 31.5 cardioid horizontal 20 1.0602 1.41 31.5 cardioid vertical 20 1.0602 Installation Requirements: The MA4070B is used with a user-supplied antenna. A self-adhesive RF exposure label is supplied with each MA4070B unit for the user to affix to their antenna. Installation of the MA4070B and affixing of the RF exposure label to the antenna is described in the user manual, which is supplied with each MA4070B. See section 2.2.2 on page 9 of “Installation and Operation Guide for System Operators” user manual. The following statement is included in the users manual and on the label to be attached to the antenna: “CAUTION: To comply with FCC RF exposure requirements in section 1.1307, a minimum separation distance of 1.5 meters is required between this antenna and all persons.”

RF Safety Exhibit Revision: 04 Date: 22 February 2002 Equipment: WaveCom MA4070B Power Amplifier FCC ID: OPPMA4070B For radio transmitters in the 2500 to 2686 MHz band, paragraph 1.1310 limits maximum permissible exposure (MPE) to 1 mW/cm 2 for uncontrolled environments. The maximum safe distance from the antenna at which MPE is met or exceeded is calculated from the equation relating field strength in V/m, transmit power in Watts, transmit antenna gain, and separation distance in meters: Basis of calculations: Safe Distance meters for 1mW/cm 2 MPE = (P Watts x Antenna Gain dBi x 30)^0.5 / 61.4 V/m Transmitted Power Antenna Type Antenna Gain Safe Distance (Watts) (dBm) (dBi) (meters) 1.41 31.5 omni 10 0.3353 1.41 31.5 omni 15 0.5962 1.41 31.5 cardioid horizontal 20 1.0602 1.41 31.5 cardioid vertical 20 1.0602 Installation Requirements: The MA4070B is used with a user-supplied antenna. A self-adhesive RF exposure label is supplied with each MA4070B unit for the user to affix to their antenna. Installation of the MA4070B and affixing of the RF exposure label to the antenna is described in the user manual, which is supplied with each MA4070B. See section 2.2.2 on page 9 of “Installation and Operation Guide for System Operators” user manual. The following statement is included in the users manual and on the label to be attached to the antenna: “CAUTION: To comply with FCC RF exposure requirements in section 1.1307, a minimum separation distance of 1.5 meters is required between this antenna and all persons.”

RF Exposure Label Revision: 02 Date: 22 February 2002 Equipment: WaveCom MA4070B Power Amplifier Module FCC ID: OPPMA4070B 10.2 cm x 2.5 cm label, 11 point Helvetica Regular Condensed Antenna RF Exposure Label close up Antenna RF Exposure Label from 3 feet distance Antenna RF Exposure Label full view

Master: Generic FCC Date: October 16, 2001 Test Report:1W04319 Applicant:WaveCom Electronics Inc. 222 Cardinal Crescent Saskatoon, Saskatchewan S7L 6H8 Equipment Under Test:MA4070B Power Amplifier (EUT) FCC ID:OPPMA4070B In Accordance With:FCC Part 21 & Part 74 Tested By:Nemko Canada Inc. 3325 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: G. Westwell, Wireless Technologist Date:October 16, 2001 Total Number of Pages:17 Authorized Copy:Soft Copy Nemko Canada Inc.FCC PART 21 & PART 74 PROJECT NO.: 1W04319 EQUIPMENT: MA4070B Power Amplifier FCC ID: OPPMA4070B Page 2 of 17 Table of Contents Section 1. Summary of Test Results......................................................................................3 Section 2. General Equipment Specification........................................................................5 Section 3. RF Power Output..................................................................................................6 Section 4. Occupied Bandwidth............................................................................................7 Section 5. Spurious Emissions at Antenna Terminals........................................................10 Section 6. Field Strength of Spurious Emissions................................................................13 Section 7. Block Diagrams...................................................................................................15 Section 8. Test Equipment List...........................................................................................17 Nemko Canada Inc.FCC PART 21 & PART 74 PROJECT NO.: 1W04319 EQUIPMENT: MA4070B Power Amplifier FCC ID: OPPMA4070B Page 3 of 17 Section 1.Summary of Test Results General All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 21 & Part 74. THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. TESTED BY: DATE: October 16, 2001 Russell Grant, Wireless Group Manager Nemko Canada Inc., a testing laboratory, is accredited by the Standards Council of Canada. The tests included in this report are within the scope of this accreditation. The results apply only to the samples tested. Nemko Canada Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Canada Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. Nemko Canada Inc.FCC PART 21 & PART 74 PROJECT NO.: 1W04319 EQUIPMENT: MA4070B Power Amplifier FCC ID: OPPMA4070B Page 4 of 17 Summary Of Test Data Name Of TestPara. No.Result RF Power Output2.1046Complies Audio Frequency Response2.1047N/A Audio Low-Pass Filter Response2.1047N/A Modulation Limiting2.1047N/A Occupied Bandwidth2.1049Complies Spurious Emissions at Antenna Terminals 2.1051Complies Field Strength of Spurious Emissions2.1053Complies Frequency Stability2.1055N/A(1) Transient Frequency Behavior——N/A Footnotes For N/A’s:(1)This equipment is an amplifier and does not use any frequency generating circuits. IndoorTemperature:22 °C Humidity:56 % OutdoorTemperature:21 °C Humidity:50 % . Nemko Canada Inc.FCC PART 21 & PART 74 PROJECT NO.: 1W04319 EQUIPMENT: MA4070B Power Amplifier FCC ID: OPPMA4070B Page 5 of 17 Section 2.General Equipment Specification Manufacturer: WaveCom Electronics Inc. Model No.: MA4070B Serial No.: 218776 Date Received In Laboratory: October 3, 2001 Nemko Identification No.: Item #1 Frequency: 2500 – 2686 MHz Output Power: 31.5 dBm, 1.41 Watts Emission Designator: D7W Modulation: 64 QAM Nemko Canada Inc.FCC PART 21 & PART 74 PROJECT NO.: 1W04319 EQUIPMENT: MA4070B Power Amplifier FCC ID: OPPMA4070B Page 6 of 17 Section 3.RF Power Output Para. No.: 2.1046 Test Performed By: Russell GrantDate of Test: October 12, 2001 Minimum Standard:± 1 dB Test Results:Complies Measurement Data:Rated:31.5 dBm Measured:31.5 dBm Nemko Canada Inc.FCC PART 21 & PART 74 PROJECT NO.: 1W04319 EQUIPMENT: MA4070B Power Amplifier FCC ID: OPPMA4070B Page 7 of 17 Section 4.Occupied Bandwidth Para. No.: 2.1049 Test Performed By: Russell GrantDate of Test: October 15, 2001 Minimum Standard:21.908(a), 74.936(c) Test Results:Complies Measurement Data:See attached plots. Nemko Canada Inc.FCC PART 21 & PART 74 PROJECT NO.: 1W04319 EQUIPMENT: MA4070B Power Amplifier FCC ID: OPPMA4070B Page 8 of 17 Nemko Canada Inc.FCC PART 21 & PART 74 PROJECT NO.: 1W04319 EQUIPMENT: MA4070B Power Amplifier FCC ID: OPPMA4070B Page 9 of 17 Nemko Canada Inc.FCC PART 21 & PART 74 PROJECT NO.: 1W04319 EQUIPMENT: MA4070B Power Amplifier FCC ID: OPPMA4070B Page 10 of 17 Section 5.Spurious Emissions at Antenna Terminals Para. No.: 2.1051 Test Performed By: Russell GrantDate of Test: October 12, 2001 Minimum Standard:21.908(a), 74.936(c) Test Results:Complies Measurement Data:See attached plots. Nemko Canada Inc.FCC PART 21 & PART 74 PROJECT NO.: 1W04319 EQUIPMENT: MA4070B Power Amplifier FCC ID: OPPMA4070B Page 11 of 17 Tx 2503 MHz Nemko Canada Inc.FCC PART 21 & PART 74 PROJECT NO.: 1W04319 EQUIPMENT: MA4070B Power Amplifier FCC ID: OPPMA4070B Page 12 of 17 Tx 2683 MHz Nemko Canada Inc.FCC PART 21 & PART 74 PROJECT NO.: 1W04319 EQUIPMENT: MA4070B Power Amplifier FCC ID: OPPMA4070B Page 13 of 17 Section 6.Field Strength of Spurious Emissions Para. No.: 2.1053 Test Performed By: Russell GrantDate of Test: October 12, 2001 Minimum Standard:21.908(a), 74.936(c) Test Results:Complies Measurement Data:See attached tabulated data. Nemko Canada Inc.FCC PART 21 & PART 74 PROJE…

Text truncated - open the document above for the full version.
