OR7GTM9300-9301Optical Track Ball Tenkey

RF Wireless Keypad with Optical Trackball User’s Manual This device combines the functions of wireless numerical keypad and trackball mouse that can provide Notebook users a best and convenient solution anywhere. It is also suitable for PC users for its one-touch access to calculator, Internet and E-mail as an extension function. 1 Features and Specifications z 27.12MHz wireless technology z 4096 IDs free from interference z Patented optical trackball z Advanced power saving management z Power recharging through USB charging cable z Mouse left and right keys z Windows 98SE/Me/2000/XP/2003/X64 compatible z FCC & CE approvals z Dimension: 103.5L x 119W x 32.5mmH Package Contents - Keypad with trackball - USB receiver - USB extension Y-cable - 2 AAA rechargeable batteries - Carrying pouch - User’s manual 2 Installation 1. Plug USB receiver to Notebook or PC’s USB port. The LED light turns on automatically. 2. Insert two AAA rechargeable batteries. Please ensure they are in the right direction. 3. Press and release the “Connect” button on the receiver to turn off the LED light. LED Light Fig. 1 Connect Button Insert Batteries Connect Button On/off Switch 3 4. Press and release the “Connect Button” on the keypad, LED light on the receiver will turn on, indicating that the setup has been completed. Keypad is now ready to use. Operating the Keypad 1. Put Keypad on tabletop, the optical ball is used for moving screen cursor. 2. Right and left key beneath/above the Trackball two models can be used for right- and left-handed users. For Right-handed user Optical Trackball Left key Number Lock LED 4 For Left-handed user 3. While the “Num Lock” key is ON (Num Lock LED is flashing). The keypad works as numerical one and its key function is defined as below: Num Lock / * BkSp 7 8 9 - 4 5 6 + Right key Left key 5 1 2 3 0 00 . Enter 4. While the Num Lock is OFF (Num Lock LED is vanished). The keypad’s key function is defined as below: 5. Num Lock BkSp HOME - + END PgDn INS ShiftDEL Enter 6. There are 3 compound keys for use while the NumLock off. 6 „ Shift+END → € (European dollar symbol) „ Shift+Enter → e-mail (Open the e-mail) „ Shift+ ＋ → Internet (Open the website) 7. When the numeric key or screen cursor remains moving slow or no movement at all, the low battery status indicated. Please plug USB receiver to USB female port of Y-cable and plug USB male of Y-cable to Notebook or PC’s USB port, and then insert recharging male to KM-9300/9301. 8. We suggest to turn off Keypad power (power switch on the back of keypad) when it is not in usage status for saving power. 7 Note: FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 April 29, 2005 RE: Globlink Technology Inc. FCC ID: OR7GTM9300-9301 I have a few comments on this Application. Depending on your responses, kindly understand there may be additional comments. 1.) The Manual is missing the required compliance information. This includes the two-part statement of 15.19(a)(3), and the information to the user of 15.21. Please review. A: Page 7 of the manual has gone. Revised one has been uploaded. 2.) Kindly review the Operational Description. What is an “angel limit”? A: There is no angel limit for this antenna. We have informed the customer and uploaded the revised one. 3.) The Test Report does not indicate a loop antenna was used for measuring fundamental emissions at 27MHz. Please re-measure. A: Thanks for your reminding, we have changed the test report format in case the same mistake happened again. 4.) Please provide evidence of compliance at the band edges at 26.96 and 27.28MHz as required by 15.27(b) and 15.209(b). A: Please reference the plot on page 7 of revised test report. William H. Graff President and Director of Engineering mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.
