OR7OPTMS302Mini Wireless Optical Mouse

From: [email protected] Sent: Wednesday, November 03 To: Steve Cheng Cc: Helen Zhao; Mike Kuo; Scott Wang Subject: RE: GloblinkModel: GM-302, GM-303 AN03T3360 Hi Steve, In response to your questions as followed: Question #1: Yes, it is plastic housing change only. Question #2: Refer to the attached schematic. Please help to check the project status of CAB application for the same products ? It is also a urgent situation to us. Thank you. Best regards, Liana Hsiung (&#29066;&#36899;&#26525;) =================== &#31243;&#26234;&#31185;&#25216;&#32929;&#20221;&#26377;&#38480;&#20844;&#21496; Compliance Certification Services Inc. (Hsintien Lab.) No.165, Chunghsen Road, Hsintien City, Taipei Hsien, Taiwan TEL:+886-2-2217-0894*10 FAX:+886-2-2217-1029 [email protected] =================== Steve Cheng <[email protected]> 2003/11/02 03:26 AM &#25910;&#20214;&#20154;&#65306; "'[email protected]'" <[email protected]>, Helen Zhao <[email protected]> &#21103;&#26412;&#25220;&#36865;&#65306; Mike Kuo <[email protected]>, Scott Wang <[email protected]> &#20027;&#26088;&#65306; RE: ??? ??? RE: CAB Application: GloblinkModel: GM-302, GM-303 Hi Liana, Subject: Question #1: External photos shown two different housing shapes, is it plastic housing change only? Question #2: Schematic is not readable. Please re-supply a clear copy. Best Regards Steve Cheng Compliance Certification Services 561F Monterey Road Morgan Hill, CA 95037 Tel:(408)463-0885 x:119 Fax:(408)463-0888 [email protected] http:\\www.ccsemc.com

Compliance Certification Services Inc. Report No: C30805407 Date of Issue: September 30, 2003 Page 1 Total Page: 4 Rev. 00 PHOTOGRAPHS OF EUT (GM-302) Compliance Certification Services Inc. Report No: C30805407 Date of Issue: September 30, 2003 Page 2 Rev. 00 (GM-303)

FCC ID LABEL FORMAT AND LOCATION Applicant: Globlink Technology Inc. FCC ID: OR7OPTMS302 FCC ID: OR7OPTMS302 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID LABEL AREA

Compliance Certification Services Inc. Report No: C30805407 Date of Issue: September 30, 2003 Page 3 Rev. 00 Compliance Certification Services Inc. Report No: C30805407 Date of Issue: September 30, 2003 Page 4 Rev. 00

Compliance Certification Services Inc. Report No: C30805407-RP FCC ID : OR7OPTMS302 Date of Issue: September 30, 2003 Page 1 Total Page: 19 Rev. 00 FCC CFR 47 PART 15 SUBPART C TEST REPORT For Globlink Technology Inc. Mini Wireless Optical Mouse Model: GM-302; GM-303 Trade Name: Globlink Issued for Globlink Technology Inc. 27Fl., 101 Feenliau Street, Nei-hu (114), Taipei, Taiwan Issued by Compliance Certification Services Inc. Hsintien Lab. No. 165, Chunghsen Road, Hsintien City Taipei Hsien, Taiwan TEL: (02) 2217-0894 FAX: (02) 2217-1029 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Lab. Code: 200617-0 Compliance Certification Services Inc. Report No: C30805407-RP FCC ID : OR7OPTMS302 Date of Issue: September 30, 2003 Page 2 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION......................................................................................3 2. EUT DESCRIPTION............................................................................................................4 3. TEST METHODOLOGY.....................................................................................................5 3.1 EUT CONFIGURATION...............................................................................................5 3.2 EUT EXERCISE...........................................................................................................5 3.3 GENERAL TEST PROCEDURES.................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS.......................................6 3.5 DESCRIPTION OF TEST MODES................................................................................6 4. INSTRUMENT CALIBRATION..........................................................................................7 5. FACILITIES AND ACCREDITATIONS..............................................................................7 5.1 FACILITIES.................................................................................................................7 5.2 EQUIPMENT................................................................................................................7 5.3 LABORATORY ACCREDITATIONS AND LISTINGS.................................................7 5.4 TABLE PF ACCREDITATIONS AND LISTINGS.........................................................8 6. SETUP OF EQUIPMENT UNDER TEST............................................................................9 6.1 SETUP CONFIGURATION OF EUT.............................................................................9 6.2 SUPPORT EQUIPMENT...............................................................................................9 7. FCC PART 15.227 REQUIREMENTS................................................................................10 7.1 26 DB BANDWIDTH..................................................................................................10 7.2 RADIATED EMISSIONS............................................................................................12 7.3 POWERLINE CONDUCTED EMISSIONS..................................................................18 APPENDIX 1 - PHOTOGRAPHS OF TEST SETUP...............................................................19 Compliance Certification Services Inc. Report No: C30805407-RP FCC ID : OR7OPTMS302 Date of Issue: September 30, 2003 Page 3 Rev. 00 1. TEST RESULT CERTIFICATION Applicant: Globlink Technology Inc. 27Fl., 101 Feenliau Street, Nei-hu (114), Taipei, Taiwan Equipment Under Test: Mini Wireless Optical Mouse Trade Name: Globlink Model: GM-302; GM-303 Model Difference N/A Report Number: C30805407-RP Date of Test: August 21~ August 25, 2003 APPLICABLE STANDARDS STANDARD TEST RESULT FCC Part 15 Subpart C No non-compliance noted The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (1992) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.227. The test results of this report relate only to the tested sample identified in this report. Approved by: Reviewed by: David Wang Vince Chiang Manager of Hsintien Laboratory Section Manager of Hsintien Laboratory Compliance Certification Services Inc. Compliance Certification Services Inc. Compliance Certification Services Inc. Report No: C30805407-RP FCC ID : OR7OPTMS302 Date of Issue: September 30, 2003 Page 4 Rev. 00 2. EUT DESCRIPTION Product Mini Wireless Optical Mouse Trade Name Globlink Model GM-302; GM-303 Power Supply DC From Battery AAA size X 2 pcs. Operate Frequency 27.12 MHz Transmit Power N/A Modulation Technique Frequency Shift Keying (FSK) Number of Channels 1 Channel Operating Mode Point-to-Point Antenna Designation Internal loop, which is built in EUT Note: The product is a composite system which includes Transmitter and Receiver. This submittal(s) (test report) is intended for FCC ID: OR7OPTMS302 filing to comply with Section 15.227 of the FCC Part 15 Subpart C Rules. The composite system (digital device) is compliance with Subpart B is authorized under a DoC procedure. Model Name Difference Tested (Checked) Original GM-302 Additional GM-303 Cosmetic change in shape Compliance Certification Services Inc. Report No: C30805407-RP FCC ID : OR7OPTMS302 Date of Issue: September 30, 2003 Page 5 Rev. 00 3. TEST METHODOLOGY The tests documented in this report were performed in accordance with ANSI C63.4 and FCC CFR 47 Part 15 Subpart C. 3.1 EUT CONFIGURATION The EUT configuration for testing is installed on RF field strength measurement …
