User Manual Classroom Audio System 1POWER2 1 2 Teacher INPUT lightspeed-tek.com 800.732.8999 1 2 Teach er 1 2 Te acher INPU T VOL SECTION 1: OVERVIEW SYSTEM COMPONENTS AND UNPACKING The standard configuration of the Redcat® Access will contain: Wall Charger & Charging Cables Flexmike® Classroom Microphone 1 2 Teacher INPUT lightspeed-tek.com 800.732.8999 1 2 Teach er 1 2 Tea cher INPU T VOL 1POWER2 Redcat® Access Receiver/Amplifier with Table Stand and Power Supply TOP PANEL CONTROLS AND CONNECTIONS FRONT PANEL INDICATORS 1POWER2 1 22 1. MIC VOLUME: Controls the volume level of the microphones. 2. TONE CONTROL: Adjusts the audio level for optimum sound quality. MICROPHONE VOLUME MINMAXBASSTREBLE TONE 1 2 1. POWER ON INDICATOR: The power LED will glow blue when power is applied. 2. MIC 1 & MIC 2: Mic link and registration indicators a. Flashing amber indicates registration is in process. b. Solid green indicates a link has been established. SIDE PANEL CONTROLS AND CONNECTIONS 1. REGISTRATION: Press this button if there is a new microphone to be registered. 2. AUDIO INPUT VOLUME CONTROL & INPUT JACK: 3.5mm stereo connector for connecting classroom audio sources to the Redcat Access (RCA). Controls the volume level of the audio input from the connected audio source.. 3. AUDIO OUTPUT VOLUME CONTROL & OUTPUT JACK: 3.5mm stereo connector for connecting to an assisted listening device (ALD) or to a computer for recording. Controls the volume level of the audio output. 4. POWER SWITCH: This switch is used to turn the RCA on or off. The front panel blue LED lights when power is on 5. DC POWER INPUT JACK: Plug the power supply (16V/2.0A) into this jack. REGISTER AUDIO IN MIN MAX AUDIO (ALD) OUT MIN MAX ON/OFF DC INPUT 16V/2.0A 2 1 4 5 3 REAR PANEL CONTROLS AND CONNECTIONS 1. CARRYING INSET: Cutaway grip for moving or carrying the Redcat Access. 2. CABLE MANAGEMENT AND STRAIN RELIEF Testing Purposes Only 1 2 FLEXMIKE CONTROLS AND CONNECTIONS 1 2 Teacher INPUT lightspeed-tek.com 800.732.8999 1 2 Teach er 1 2 Tea cher INPU T VOL 1 2 Teacher INPUT lightspeed-tek.com 800.732.8999 1 2 Teach er 1 2 Tea cher INPU T VOL 1. POWER/MUTE SWITCH: press and hold to power on, press to mute, press and hold to power off. 2. MIC 1 STATUS: lighted to indicate microphone is registered as MIC 1 • Blue: solid = normal operation; flashing = linking in process • Red: solid = muted; flashing = muted while linking in process 3. MIC 2 STATUS: lighted to indicate microphone is registered as MIC 2 (same behavior as MIC 1 status light above) 4. *EARBUD CONNECTION: connect the 3.5mm earbud jack for monitoring (*for use with Flexcat Pods only) 5. CHARGING/LOW BATTERY INDICATOR: lights red when charging, green when fully charged. When in operation, turns red to indicate low battery. 6. MICROPHONE VOLUME UP/DOWN 7. AUDIO INPUT: connect audio source to send to Redcat Access 8. LANYARD INTERFACE: insert the lanyard into this hook to wear the Flexmike. 9. BATTERY DOOR: remove the battery door to replace the rechargeable battery pack 10. REGISTRATION: (inside battery compartment - not shown) only used when adding or replacing Flexmike. 1 2 Teacher INPUT lightspeed-tek.com 800.732.8999 1 2 Teach er 1 2 Tea cher INPU T VOL 1 10 9 8 7 6 5 4 3 2 The Redcat Access is shipped with a table stand connected and ready for use. Alternatively, the table stand can be used as the wall mount bracket. Advantages of either include: SECTION 2: SET-UP & USE 1. DETERMINE SET-UP LOCATION 1A. TO SET-UP ON TABLE-TOP Tabletop (recommended): • Virtually no setup time • Greater flexibility to move to different locations First, consider that the Redcat Access should be placed within 7 feet of an electrical outlet and on a surface about 3-6 feet off the ground. Next, find a location as far away as possible from the teacher who will be using the mic. The best place is against the wall opposite where the teacher will be speaking. If this is not possible, other good locations are along either wall next to the teacher or in a corner. Avoid placing the RCA next to where the teacher instructs. Putting the Redcat Access in close proximity to the teacher’s mic can result in feedback. Wall-mount: • More permanent setup • Greater security Avoid! Good placementBest placement 1B. TO SET-UP MOUNTED ON A WALL First, consider that the RCA should be placed within 7 feet of an electrical outlet and about 6-8 feet off the ground. Next, find a location as far away as possible from the teacher who will be using the mic. The best place is centered on the long wall opposite the teacher. If this is not possible, other good locations are on the wall next to the teacher. Avoid placing the RCA on any wall close to where the teacher usually stands to instruct the class. Having the teacher’s mic too close to the RCA can result in feedback. Good placement Best placement Avoid! 1B. TO SET-UP MOUNTED ON A WALL CONT’D 1. Level template and tape to wall 2. Mark position of drill holes on wall 3. Drill pilot holes 4. Insert anchors 5. Insert screws through the RCA feet into the anchors 6. If using optional security bracket, mount on wall using the provided screws and anchors 7. Slide the Redcat Access onto the wall mounted feet Drill Template for wall-mounting the REDCAT System Drill holes Instructions Determine the best location for the REDCAT, refer to the user manual provided with this product. For wall mounting, the REDCAT should be mounted 7 to 8 feet from the floor. 1. Start by leveling this template and taping to the desired location on the wall. 2. Mark the hole locations using a sharp pencil. (7 locations) 3. Drill pilot holes 4. Insert anchors 5. Insert screws through the feet and tighten to the wall 6. Insert screws through the security tab bracket and tighten to the wall. 7. Slide the REDCAT onto its mounted feet. If the safety tab is installed, it should snap into place preventing system removal. Materials Required Drill Bit: Size appropriate for the anchors or screws being used. Anc…
