ORVLES-360TBody Worn Low Power Radio Service Transmitter

FCC ID: ORVLES-360T MFA p9980015, d99b0060 Date:November 17, 1999 Federal Communications Commission Via: Electronic Filing Attention:Authorization & Evaluation Division Applicant:LightSPEED Technologies, Inc. Equipment:LES-360T LES-36OR FCC ID:ORVLES-360T FCC Rules:95G Gentlemen: On behalf of the Applicant, enclosed please find Application Form 731, Engineering Test Report and all pertinent documentation, the whole for approval of the referenced equipment as shown. Filing fees are attached. We trust the same is in order. Should you need any further information, kindly contact the writer who is authorized to act as agent. Sincerely yours, William H. Graff, Director of Engineering enclosure(s) cc: Applicant WHG/cvr FCC ID: ORVLES-360T MFA p9980015, d99b0060 LIST OF EXHIBITS (FCC CERTIFICATION (TRANSMITTERS) - REVISED 9/28/98) APPLICANT:LightSPEED Technologies, Inc. FCC ID:ORVLES-360T BY APPLICANT: 1. LETTER OF AUTHORIZATION 2. IDENTIFICATION DRAWINGS, 2.1033(c)(11) LABEL LOCATION OF LABEL COMPLIANCE STATEMENT LOCATION OF COMPLIANCE STATEMENT 3. PHOTOGRAPHS, 2.1033(c)(12) 4. DOCUMENTATION: 2.1033(c) (3)USER MANUAL (9)TUNE UP INFO (10)SCHEMATIC DIAGRAM (10) CIRCUIT DESCRIPTION 5. PART 90.203(e) & (g) ATTESTATION BY M.F.A. INC. A.TESTIMONIAL & STATEMENT OF CERTIFICATION B.STATEMENT OF QUALIFICATIONS FCC ID: ORVLES-360T MFA p9980015, d99b0060 Sub-part 2.1033(c): EQUIPMENT IDENTIFICATION FCC ID: ORVLES-360T NAMEPLATE DRAWING ATTACHED, EXHIBIT 1. LOCATION AS PER LABEL DRAWING(S) DATE OF REPORT November 17, 1999 SUPERVISED BY:William H. Graff, Director of Engineering FCC ID: ORVLES-360T MFA p9980015, d99b0060 THE APPLICANT HAS BEEN CAUTIONED AS TO THE FOLLOWING: 15.21INFORMATION TO USER. The users manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.27(a)SPECIAL ACCESSORIES. Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer, without additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. FCC ID: ORVLES-360T MFA p9980015, d99b0060 TABLE OF CONTENTS RULEDESCRIPTIONPAGE .Test Report1 2.1033(c)General Information Required2 2.1033(c)(14) Rule Summary5 .Standard Test Conditions and Engineering Practices6 2.1046(a) Carrier Output Power (Conducted)7 2.1053(a) Field Strength of Spurious Radiation9 2.1049(c)(1) Emission Masks (Occupied Bandwidth)12 2.1047(a) Audio Frequency Response16 2.1047(b) Modulation Limiting18 2.1055(a)(1) Frequency Stability (Temperature Variation)20 2.1055(b)(1)Frequency Stability (Voltage Variation)23 2.202(g) Necessary Bandwidth and Emission Bandwidth24 FCC ID: ORVLES-360T MFA p9980015, d99b0060 PAGE NO.1 of 24. Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a)TEST REPORT b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85224 c) Report Number:d99b0060 d) Client:LightSPEED Technologies, Inc. 15812 S.W. Upper Boones Ferry Rd. Lake Oswego, OR 97035 e) Identification:LES-360T FCC ID: ORVLES-360T Description:Body Worn LPRS Transmitter f) EUT Condition:Not required unless specified in individual tests. g) Report Date:November 17, 1999 EUT Received:1999-Aug-09 h, j, k):As indicated in individual tests. i) Sampling method:No sampling procedure used. l) Uncertainty:In accordance with MFA internal quality manual. m) Supervised by: William H. Graff, Director of Engineering n) Results:The results presented in this report relate only to the item tested. o) Reproduction:This report must not be reproduced, except in full, without written permission from this laboratory. FCC ID: ORVLES-360T MFA p9980015, d99b0060 PAGE NO.2 of 24. LIST OF GENERAL INFORMATION REQUIRED FOR CERTIFICATION IN ACCORDANCE WITH FCC RULES AND REGULATIONS, VOLUME II, PART 2 AND TO 95G Sub-part 2.1033 (c)(1):NAME AND ADDRESS OF APPLICANT: LightSPEED Technologies, Inc. 15812 S.W. Upper Boones Ferry Rd. Lake Oswego, OR 97035 MANUFACTURER: REOR ELECTRONICS Co. LTD. No. 857, Chung-Cheng Road Chung-Ho, Taipei, TAIWAN (c)(2):FCC ID:ORVLES-360T MODEL NO:LES-360T (c)(3):INSTRUCTION MANUAL(S): PLEASE SEE ATTACHED EXHIBITS (c)(4):TYPE OF EMISSION:20K0F3E (c)(5):FREQUENCY RANGE, MHz:216.025 to 216.9875 (c)(6):POWER RATING, Watts: 0.050 SwitchableVariablexN/A (c)(7):MAXIMUM POWER RATING, Watts:0.1 FCC ID: ORVLES-360T MFA p9980015, d99b0060 PAGE NO.3 of 24. M. Flom Associates, Inc. is accredited by the American Association for Laboratory Association (A2LA) as shown in the scope below. "This laboratory is accredited by the American Association for Laboratory Accreditation (A2LA) and the results shown in this report have been determined in accordance with the labor…

Text truncated - open the document above for the full version.
