OTM-80062-27M-TXRemote Controller for Toy

A4 size ( Black & White ) - English - FRONTBACK 5F60A8D A4 size ( Black & White ) - English - FRONTBACK 5F60A8D A4 size ( Black & White ) - English - FRONTBACK 5F60A8D Contents RC Vehicle (Vehicle) x 1 RC Transmitter (Transmitter) x 1 Antenna for RC Transmitter x 1 Instruction Manual x 1 9.6V Rechargeable Battery Pack x 1 Charger x 1 9V Battery x 1 Battery Precaution 1. The 9.6V rechargeable battery pack must be charged before use by utilizing the battery charger included 2. Do not charge the battery pack for more than 6 hours 3. Do not charge the battery pack if there is any sign of leakage, corrosion, or exposed wires 4. Do not cover the battery pack while charging 5. Do not install or recharge the battery pack when it is hot, wait for it to cool 6. Do not dispose of the battery in fire 7. Do not dismantle the battery or charger; do not cut the battery or charger cables 8. The battery pack will be warm after charging and hot after use in a vehicle 9. The supply terminals are not to be short-circuited 10. Rechargeable batteries are to be removed from the toy before being charged 11. Rechargeable batteries are only to be charged under adult supervision 12. Batteries should only be replaced by an adult 13. The transformer (charger) is not a toy 14. Compatible with charge-only type (700mAh Max.) rechargeable battery packs. Other types of batteries may burst causing injury and/or damage. This power unit is intended to be orientated in a vertical or floor mount position. This charger is intended to be used for charging 9.6V rechargeable battery pack with a capacity of 700mAh Max. It cannot be used for charging non-rechargeable batteries. Regularly examine battery charger for any damage to its cord, plug, enclosure and other parts. In the event of such damage, it must not be used to charge battery pack until such damage has been repaired. Note that the 9V battery is non-rechargeable and is not to be recharged. Only batteries of the same or equivalent type as recommended are to be used. Please replace when transmission is poor. 15. Exhausted batteries are to be removed from the product. How to Play 1. Switch ON the Vehicle 2. Use the Forward / Backward joystick (Fig.3) to drive the Vehicle forward and backward 3. Use the Left / Right joystick (Fig.3) to control the Vehicle turning left or right 4. If the vehicle does not run in straight line, adjust the Direction Adjustment on the vehicle chassis (Fig. 1) 5. Operate vehicle on a smooth surface for optimum performance 6. Remember to switch OFF the power of the vehicle and transmitter when finished playing 7. The optimum control range is up to 10m in an outdoor environment Performance Tips 1. Do not drive on grass, dirt, sand, dust, carpet or in water 2. Do not drive in windy or rainy weather 3. Avoid direct impact with obstacles 4. Switch OFF the power when not in use to prevent damage to the vehicle and transmitter due to leakage of electrolyte from batteries 5. Remove all batteries from the vehicle and transmitter when not in use for long periods of time 6. Keep fingers, hair and loose clothing away from wheels 7. Outdoor use is recommended in order to get optimum control range 8. Clean the battery compartment to make sure it is free from dust 9. The operating range can be affected by a variety of factors: a) Low voltage of batteries in transmitter or vehicle b) Interference from other items that emit radio frequency signals Caution 1. Do not attempt to disassemble the vehicle or transmitter 2. Do not operate the vehicle simultaneously with other remote control items that have the same in same location, this will interfere with the vehicle and may cause loss of control 3. Make sure the batteries are installed with correct polarities (+/-) as shown inside the battery compartment 4. Remove the package and take out all accessories before giving the vehicle and transmitter to child to play FCC label compliance statement: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna - Increase the separation between the equipment and receiver - Connect the equipment into an outlet on a circuit different from that to which the receiver is needed - Consult the dealer or an experienced radio/TV technician for help Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. RSS-310 Compliance Statement: This radio communication device complies with all the requirements of Industry Canada Standard RSS-310. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Declaration of Conformity The product is in conformity with the requirement of EU Directive 1999/5/EC Environmental notes: The product should not be disposed of with household waste at the end of t…

Text truncated - open the document above for the full version.

External Photo Front View of the product Rear View of the product Battery compartment Battery Cover

Internal Photo Internal View of the product Inner Circuit Top View Inner Circuit Bottom View Antenna

BUREAU VERITAS TESTREPORTNo.: (5213)116-1511 To: TESTREPORT ,-------------,----------------------, FolderNo.: [email protected] lonsonkidztech.net KIDZTECHTOYSMANUFACTURING LIMITED To: KodTang1LonsonCheungAttn: Attn: Room1201,12/F,Inter-ContinentalPlaza, 94 GranvilleRoad,TSTEast,HongKong Address: Address: Fax: Fax:85227218838 E-mail: E-mail: FactoryName:SHANTOUCHENGHAIJIN JUNTOYSCO. LTD. Location: 1/10RC Car - Mustang ModelNo.: 5F60A801 80062 Product: SampleNo:(5213)116-1511 May 2,2013TestOate(s): FCCPart 15 - 2011TestRequested: TestMethod: ANSIC63.4- 2009 FCC10: The resultsgivenin this reportare relatedto the testedspecimenof the describedelectricalapparatus. OTM-80062-27M-TX AuthorizedSignature: CONCLUSION:The submittedsamplewas foundto COMPLYwithrequirementof FCCPart15 SubpartC. BUREAUVERITASHONGKONGL1MITED- KowloonBay Office 1/FPacificTradeCentre, 2 Kai HingRoad,KowloonBay, Kowloon,HONGKONG Tel:+85223310888 Fax: +85223310889 www.cps.bureauveritas.com 11usreportISIntendedfor yourevclusne useAn~copymgor replicationof thisreport10or for an~otherpersonorenuty.or use of ournameor trademarkISpermittedonbwnhourpnorwnnenpemussionOurreportISlmutedto the testsamplesIdentified heremTheresultsset forthIntlusreportare notnecessanlvmdicanveorrepresenranveof thestansucalqualityorcbaractensucsof the101fromwfuch3 lestsamplewastakenoranysimilaror IdenticalproductunlessspecificallyandexpresslynotedOurreport includesall of the testsrequestedb~ youandthe resultsthereofYoushallhavethJrt~daysfromreceiptofthisreportto request additionaltestingof the samplesor to notlf~us of anyerrorsor onussicnsrelatingto ourreport.provided.however.suchnotice shallbe In \\rumgandshallspecificallyaddressthe Issueyou\\ Ish to raiseA failuretoraisesuchIssueWithinthe prescribedtime shallconstituteyourunqualifiedacceptanceof the completenessofthisreport.the testsconductedandthe correctnessof the report contents Page1of16 TEST REPORT No.: (5213)116-1511 BUREAU VERITAS HONG KONG LIMITED – Kowloon Bay Office 1/F Pacific Trade Centre, 2 Kai Hing Road, Kowloon Bay, Kowloon,HONG KONG Tel: +852 2331 0888 Fax: +852 2331 0889 www.cps.bureauveritas.com This report is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. Our report is limited to the test samples identified herein. The results set forth in this report are not necessarily indicative or representative of the statistical quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof. You shall have thirty days from receipt of this report to request additional testing of the samples or to notify us of any errors or omissions relating to our report, provided, however, such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Page 2 of 16 Test Result Summary EMISSION TEST Test requirement: FCC Part 15 - 2011 Test Condition Test Method Test Result Pass Failed Radiated Emission Test, 9kHz to 1GHz ANSI C63.4 Report Revision & Sample Re-submit History: -- TEST REPORT No.: (5213)116-1511 BUREAU VERITAS HONG KONG LIMITED – Kowloon Bay Office 1/F Pacific Trade Centre, 2 Kai Hing Road, Kowloon Bay, Kowloon,HONG KONG Tel: +852 2331 0888 Fax: +852 2331 0889 www.cps.bureauveritas.com This report is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. Our report is limited to the test samples identified herein. The results set forth in this report are not necessarily indicative or representative of the statistical quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof. You shall have thirty days from receipt of this report to request additional testing of the samples or to notify us of any errors or omissions relating to our report, provided, however, such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Page 3 of 16 Test Laboratory & Test Instruments List Radiated and Conducted emissions measurements are investigated and taken pursuant to the procedures of ANSI C63.4 – 2009. An Open Area Test Site and Full Anechoic Chamber (FCC Listed Site, Registration No. 642151) are set up for investigation and located at: BUREAU VERITAS HONG KONG LIMITED, EMC CENTRE No. 2106-2107, 21/F., Westin Centre, 26 Hung To Road, Kwun Tong, Kowloon, Hong Kong Test Instrument List Radiated Emission EQUIPMENT MANUFACTURER MODEL NO. SERIAL NO. CALIBRATION DUE EMI TEST RECEIVER R&S ESCI 100379 28-JAN-2014 LOOP ANTENNA ETS-LINDGREN 6502 00102266 14-AUG-2013 BILOG ANTENNA SCHAFFNER CBL6112D 25229 12-SEP-2013 OPEN AREA TEST SITE BVCPS N/A N/A 09-JUL-2013 ANECHOIC CHAMBER ALBATROSS M-CDC 80374004499B 05-FEB-2014 COAXIAL CABLE SUHNER RG214 N/A 24-SEP-2013 Remarks: - N/A: Not Applicable or Not Available The measurement instrumentation uncertainty would be taking into consideration on each of the test result TEST REPORT No.: (5213)116-1511 BUREAU VERITAS HONG KONG LIMITED – Kowloon Bay Office 1/F Pacific Trade Centre, 2 Kai Hing Road, Kowloon Bay, Kowloon,HONG KONG Tel: +852 2331 0888 Fax: +852 2331 0889 www.cps.bureauveritas.com This repor…

Text truncated - open the document above for the full version.

Test Set Up Photo
