OVFKWC-K24BK24 Dual Band Tri-mode Cellular Phone w/ Bluetooth

ii User Guide for the Kyocera K323 Phone This manual is based on the production version of the Kyocera K323 phone. Software changes may have occurred after this printing. Kyocera reserves the right to make changes in technical and product specifications without prior notice. The products and equipment described in this documentation are manufactured under license from QUALCOMM Incorporated under one or more of the following U.S. patents: 4,901,307 5,109,390 5,267,262 5,416,797 5,506,865 5,544,196 5,657,420 5,101,501 5,267,261 5,414,796 5,504,773 5,535,239 5,600,754 5,778,338 5,228,054 5,337,338 5,710,784 5,056,109 5,568,483 5,659,569 5,490,165 5,511,073 The Kyocera Wireless Corp. (“KWC”) products described in this manual may include copyrighted KWC and third party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for KWC and third party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in the KWC products may not be modified, reverse engineered, distributed or reproduced in any manner not permitted by law. Furthermore, the purchase of the KWC products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents or patent applications of KWC or any third party software provider, except for the normal, non-exclusive royalty-free license to use that arises by operation of law in the sale of a product. Kyocera is a registered trademark of Kyocera Corporation. Doodler, Brick Attack and Race 21 are trademarks of Kyocera Wireless Corp. QUALCOMM is a registered trademark of QUALCOMM Incorporated. Openwave is a trademark of Openwave Systems Incorporated. eZiText is a registered trademark of Zi Corporation. TransFlash is a trademark of SanDisk Corporation. Get It Now is a service mark of Verizon Wireless. All other trademarks are the property of their respective owners. All other trademarks are the property of their respective owners. Copyright © 2006 Kyocera Wireless Corp. All rights reserved. Ringer Tones Copyright © 2000-2002 Kyocera Wireless Corp. 82-N8863-1EN, Rev. x3 DRAFT FCC/IC Notice This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. To maintain compliance with FCC RF exposure guidelines, if you wear a handset on your body, use the Kyocera Wireless Corp. (KWC) supplied and approved standard case CV90-M2293-01, premium case CV90-M2294-01 , and holster CV90-M2288-01. Other accessories used with this device for body- worn operations must not contain any metallic components and must provide at least 15 mm separation distance including the antenna and the user’s body. THIS MODEL PHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. User Guide for the Kyocera K323 Phoneiii The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg.* Tests for SAR are conducted using standard operating positions specified by the FCC with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output. Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit established by the government-adopted requirement for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model. Body-worn measurements differ among phone models, depending upon availability of accessories and FCC requirements. While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirement for safe exposure. The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF emission guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section http://www.fcc.gov/oet/fccid after searching on the FCC ID: OVFKWC-K24B. Additional information on SAR can be found on the Cellular Telecommunications and Internet Association (CTIA) web-site at http://www.wow-com.com. * In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/ kg (W/kg) averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give additional protection for the public and to account for any variations in measurements. Caution The user is cautioned that changes or modifications not expressly approved by the p…

Text truncated - open the document above for the full version.

FCC ID: OVFKWC-K24B May 10, 2006 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Request of Confidentiality for FCC ID: OVFKWC-K24B To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), Kyocera Wireless Corp (KWC) hereby requests confidential and treatment of information accompanying this Application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also requesting Short-Term Confidentiality as outlined in Public Notice DA 04-1705. This provision will give KWC Temporary Confidentiality of commercially sensitive information prior to product launch. The requested Confidential and Temporary Confidential exhibits are listed in table 1 below: Table 1. Confidential and Short-Term Confidential Exhibit Description 1 Operation Descriptions 2 Block diagrams 3 Schematics 4 Parts Lists 8A Internal Photo under the shield Confidential 12 Tune Up Procedure 5 Instruction Manual 7 External Photos 8 Internal Photos Short-Term Confidential 13 Test Set Up Photo The Exhibit 8A contains internal photos showing the RF components are under the shield and the opening of this area would cause the device unusable; therefore this information is not customarily released to the public. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. Sincerely, Christy Le Christy Le Regulatory Engineer Kyocera Wireless Corp. Kyocera Wireless Corp. 1

1 Chris Harvey From: Christy Le [[email protected]] Sent: Friday, May 12, 2006 5:21 PM To: Chris Harvey Cc: [email protected] Subject: RE: Kyocera Wireless Corp. , FCC ID: OVFKWC-K24B, Assessment NO.: AN06T5757, Notice#1 Attachments: Exhibit 8_OVFKWC-K24B_ Internal Photos.pdf Exhibit VFKWC-K24B_ Inter Chris, Attached is a revised Internal Photo. Please review and let me know if you have any questions. Thanks, Christy At 02:38 PM 5/12/2006 -0400, Chris Harvey wrote: >Christy, you must respond to the Internal Photo issue from #3 below, as >this is a long standing policy from the FCC for devices that are >provided to the General Public. > >Best regards, > >Chris Harvey > >-----Original Message----- >From: Christy Le [mailto:[email protected]] >Sent: Friday, May 12, 2006 2:30 PM >To: [email protected] >Cc: Christy Le >Subject: Re: Kyocera Wireless Corp. , FCC ID: OVFKWC-K24B, Assessment NO.: >AN06T5757, Notice#1 > >Hi Chris, > > Attached is the response for Notice#1 part 1. >For Internal Photos, please let me know what action should I take? >However, I am applying for a separate application for BT portion and >will be done by 1pm. >Thanks, >Christy > >At 03:54 AM 5/12/2006 -0700, [email protected] wrote: > >Christy, > > > >I have reviewed the above referenced TCB application and find that > >the following items need to be addressed before the review can be completed: > > > >1. The FCC has released CDMA2000 SAR Measurement guidance. Please > >show evidence of compliance with determining the worst case RC/SO > >combination keeping in mind that the FCC recommendation is SO55 > >loopback for Rev 6 systems or higher. > > > >2. Please provide Schematic Diagrams for this handset (only Bluetooth > >Schematics were provided) > > 2 > >3. The Internal Photos have several component markings that have been > >blacked-out. Please either confirm that all production samples will > >also be blacked-out or provide photos where the numbers are legible. > > > >4. This device contains a Bluetooth transmitter. It appears as though > >a separate application to cover this Bluetooth portion of this FCC ID > >may have been filed under AN06T5756, but the exhibits provided so far > >are not for the Bluetooth portion. Since the Bluetooth portion has a > >different Equipment Class (DSS) from the rest of the handset (PCE) > >the separate application must be filed. Please confirm if AN06T5756 > >has been submitted to cover the Bluetooth portion of this application. > > > >The items indicated above must be submitted before processing can > >continue on the above referenced application. Failure to provide the > >requested information within 30 days of the original e-mail date may > >result in application dismissal and forfeiture of the filing fee. > >Also, please note that partial responses increase processing time and > >should not be submitted. Any questions about the content of this > >correspondence should be directed to the e-mail address listed below the name of the sender. > > > >Best regards, > >Chris Harvey > >[email protected]

1 Chris Harvey From: Christy Le [[email protected]] Sent: Tuesday, May 16, 2006 12:39 PM To: Chris Harvey Cc: [email protected]; 'Mike Kuo'; christy Le Subject: RE: Kyocera Wireless Corp. , FCC ID: OVFKWC-K24B, Assessment NO.: AN06T5757, Notice#1 Attachments: OVFKWC-K24B_Request for confidentiality.pdf; Exhibit 8_OVFKWC-K24B_ Internal Photos.pdf; Exhibit 8A_OVFKWC-K24B_ Internal Photos under the shield.pdf OVFKWC-K24B_Req uest for confid... Exhibit VFKWC-K24B_ Inter Exhibit OVFKWC-K24B_ Inte Chris, Thank you for your confirmation. Attached are 3 revised documentations: 1. Request for Confidentiality 2. Exhibit 8_Internal Photos 3. Exhibit 8A_Internal Photo under the Shield Please review and advise if you have any questions. Thanks, Christy At 07:11 AM 5/16/2006 -0400, Chris Harvey wrote: >Yes, I see that 3 photo exhibits are required. > >External Photo - allowed to be short-term confidentiality Internal >Photo with shields ON - allowed to be short-term confidentiality >Internal Photo with shields removed - allowed to be Long-Term >Confidentiality (removing RF Shield will likely destroy device) > >I hope this is clear. > >Best regards, > >Chris Harvey > > >-----Original Message----- >From: Christy Le [mailto:[email protected]] >Sent: Monday, May 15, 2006 7:03 PM >To: Chris Harvey >Cc: [email protected]; 'Mike Kuo' >Subject: RE: Kyocera Wireless Corp. , FCC ID: OVFKWC-K24B, Assessment NO.: >AN06T5757, Notice#1 > >Hi Chris, > > It is very nice to talk to you over the phone. I will register to >a photographic class so that I could take a better picture next time >:o) Please confirm that the internal picture (no blacked out) with chip >set under the shield will be submit in different exhibit with long term >confidentiality. >Thanks, >Christy > >At 08:51 AM 5/13/2006 -0400, Chris Harvey wrote: > >Christy, since the Chip Set is under the shield, you are allowed to 2 > >ask for confidentiality of the photos that show the components under > >the RF Shield that requires destroying the device to remove. > >Therefore, if you choose, you can separate the regular internal > >photos from the confidential internal photos and update the > >Confidentiality letter to include the specific internal photos. > > > >Please let me know if this is the way you would prefer to proceed or > >if you have any questions. > > > >Best regards, > > > >Chris Harvey > > > >-----Original Message----- > >From: Christy Le [mailto:[email protected]] > >Sent: Friday, May 12, 2006 5:21 PM > >To: Chris Harvey > >Cc: [email protected] > >Subject: RE: Kyocera Wireless Corp. , FCC ID: OVFKWC-K24B, Assessment NO.: > >AN06T5757, Notice#1 > > > >Chris, > > > > Attached is a revised Internal Photo. Please review and let me > > know >if > >you have any questions. > >Thanks, > >Christy > > > >At 02:38 PM 5/12/2006 -0400, Chris Harvey wrote: > > >Christy, you must respond to the Internal Photo issue from #3 > > >below, as > >this > > >is a long standing policy from the FCC for devices that are > > >provided to >the > > >General Public. > > > > > >Best regards, > > > > > >Chris Harvey > > > > > >-----Original Message----- > > >From: Christy Le [mailto:[email protected]] > > >Sent: Friday, May 12, 2006 2:30 PM > > >To: [email protected] > > >Cc: Christy Le > > >Subject: Re: Kyocera Wireless Corp. , FCC ID: OVFKWC-K24B, > > >Assessment >NO.: > > >AN06T5757, Notice#1 > > > > > >Hi Chris, > > > > > > Attached is the response for Notice#1 part 1. > > >For Internal Photos, please let me know what action should I take? > > >However, I am applying for a separate application for BT portion >and > > >will be done by 1pm. > > >Thanks, > > >Christy > > > > > >At 03:54 AM 5/12/2006 -0700, [email protected] wrote: > > > >Christy, > > > > 3 > > > >I have reviewed the above referenced TCB application and find > > > >that the following items need to be addressed before the review > > > >can be >completed: > > > > > > > >1. The FCC has released CDMA2000 SAR Measurement guidance. > > > >Please show evidence of compliance with determining the worst > > > >case RC/SO >combination > > > >keeping in mind that the FCC recommendation is SO55 loopback for > > > >Rev 6 systems or higher. > > > > > > > >2. Please provide Schematic Diagrams for this handset (only > > > >Bluetooth Schematics were provided) > > > > > > > >3. The Internal Photos have several component markings that have > > > >been blacked-out. Please either confirm that all production > > > >samples will >also > > > >be blacked-out or provide photos where the numbers are legible. > > > > > > > >4. This device contains a Bluetooth transmitter. It appears as > > > >though a separate application to cover this Bluetooth portion of > > > >this FCC ID may have been filed under AN06T5756, but the exhibits > > > >provided so far are >not > > > >for the Bluetooth portion. Since the Bluetooth portion has a > > > >different Equipment Class (DSS) from the rest of the handset > > > >(PCE) the separate application must be filed. Please confirm if > > > >AN06T5756 has been > >submitted > > > >to cover the Bluetooth portion of this application. > > > > > > > >The items indicated above must be submitted before processing can > >continue > > > >on the above referenced application. Failure to provide the > > > >requested information within 30 days of the original e-mail date > > > >may result in application dismissal and forfeiture of the filing > > > >fee. Also, please >note > > > >that partial responses increase processing time and should not be > > > >submitted. Any questions about the content of this correspondence >should > > > >be directed to the e-mail address listed below the name of the sender. > > > > > > > >Best regards, > > > >Chris Harvey > > > >[email protected]

1 Chris Harvey From: Christy Le [[email protected]] Sent: Tuesday, May 16, 2006 10:11 PM To: [email protected] Cc: [email protected]; christy Le Subject: Re: Kyocera Wireless Corp. , FCC ID: OVFKWC-K24B, Assessment NO.: AN06T5757, Notice#2 Attachments: OVFKWC-K24B_Request for confidentiality.pdf; Exhibit 8A_OVFKWC-K24B_ Internal Photos under the shield.pdf OVFKWC-K24B_Req uest for confid... Exhibit OVFKWC-K24B_ Inte Hi Chris, Attached is the revised for internal photo under the shield and confidential letter. Please let me know if you have any questions. Thanks, Christy At 12:21 PM 5/16/2006 -0700, [email protected] wrote: >Christy, thank you for the exhibits. I have reviewed these and have the >following continued request. > >The photo under the shield is still not clear or the resolution is too low >to clearly see the components. Please provide clearer photo. > >The Letter of Confidentiality must clearly justify the need to keep the >internal photos confidential as the FCC does not routinely allow >confidentiality of internal photos. The justification must explain >clearly how this consumer device internal component construction is not >accessible to the end user (if applicable, special tools, unsolder RF >shield would destroy device, etc.). Please revise the letter of >confidentiality to clearly justify keeping the internal photos confidential. > >The items indicated above must be submitted before processing can continue >on the above referenced application. Failure to provide the requested >information within 30 days of the original e-mail date may result in >application dismissal and forfeiture of the filing fee. Also, please note >that partial responses increase processing time and should not be >submitted. Any questions about the content of this correspondence should >be directed to the e-mail address listed below the name of the sender. > >Best regards, > >Chris Harvey >[email protected]

Mike Kuo From: C.K. Li [[email protected]] Sent: Friday, July 14, 2006 9:03 AM To: Mike Kuo Subject: Re: Short term confidential extension Attachments: Request for short term confidentiality_071406.pdf; ATT563562.txt  7/18/2006 Mike, Letter attached. We understand that the listed information have been released to the public after July 02 2006. This is to request FCC to withdraw the information from the public and grant additional 45 days of Short term confidential extension. Thanks, CK At 07:04 PM 7/13/2006 -0700, you wrote: Hi C.K. : Please provide a cover letter to request short term confidential to be extended and indicates in the cover letter that Kyocera has acknowledged that those requested files have been available to the public after July 02. Best Regards Mike Kuo Compliance Certification Services 561F Monterey Road Morgan Hill CA 95037 Tel: (408)463-0885 x: 105 Fax: (408)463-0888 e-mail:[email protected] http://www.ccsemc.com

FCC ID: OVFKWC-K24B Kyocera Wireless Corp. 1 July 14, 2006 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Request of Short Term Confidentiality for FCC ID: OVFKWC-K24B To Whom It May Concern: Pursuant to Section 0.459 of the Commission’s Rules and Public Notice DA 04, Kyocera Wireless Corp (KWC) hereby requests for second 45 days Short-Term Confidential treatment of some information accompanying this Application. This provision will give KWC Temporary Confidentiality of commercially sensitive information prior to product launch. The requested Temporary Confidential exhibits are listed in table 1 below: Description Instruction Manual External Photos Internal Photos Short-Term Confidential Setup Photos Sincerely, C K Li C. K. Li Engineer, Senior Staff/Manager Kyocera Wireless Corporation

FCC ID: OVFKWC-K24B Exhibit 7: OVFKWC-K24B External Photos TOP VIEWS CLOSED AND OPEN External Photos Page 1 of 3 Model: K323 FCC ID: OVFKWC-K24B BOTTOM VIEWS CLOSED AND OPEN External Photos Page 2 of 3 Model: K323 FCC ID: OVFKWC-K24B FLIP CLOSED SIDE VIEWS FLIP OPEN SIDE VIEWS External Photos Page 3 of 3 Model: K323

FCC ID: OVFKWC-K24B Exhibit 6: OVFKWC-K24B ID Label Label Format Label Location Label Information Page 1 of 1 Model: K323

FCC ID: OVFKWC-K24B Exhibit 8: OVFKWC-K24B Internal Photos Bluetooth Antenna Internal Photos Page 1 of 4 Model: K323 FCC ID: OVFKWC-K24B Bluetooth Circuitry Internal Photos Page 2 of 4 Model: K323 FCC ID: OVFKWC-K24B Internal Photos Page 3 of 4 Model: K323 FCC ID: OVFKWC-K24B Internal Photos Page 4 of 4 Model: K323

FCC ID: OVFKWC-K24B SAR Test Report on Dual-Band Tri-mode AMPS/CDMA Cellular Phone with Bluetooth FCC Part 22 & 24 Certification FCC ID: OVFKWC-K24B MODEL: K323 DATE: May 10, 2006 STATEMENT OF COMPLIANCE Kyocera Wireless Corp declares under its sole responsibility that the product, FCC ID: OVFKWC- K24B to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines. It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted: NONE. Date of Test: April 12 –May 1, 2006 Test performed by: Kyocera Wireless Corp 10300 Campus Point Drive San Diego, CA 92121 Report Prepared by: Christy Le, Regulatory Engineer Report Reviewed by: C.K., Li Engineer, Sr. Staff/ Manager SAR Report Page 1 of 28 Model: K323 FCC ID: OVFKWC-K24B Table of Contents 1 INTRODUCTION..............................................................................................................................................................3 2 EQUIPMENT UNDER TEST (EUT)...............................................................................................................................3 3 PRODUCT DESCRIPTION.............................................................................................................................................4 4 ACCESSORIES:................................................................................................................................................................4 5 SAR TEST RESULT SUMMARY...................................................................................................................................5 5.1 MAXIMUM RESULTS FOUND DURING SAR EVALUATION..............................................................................................5 5.2 HEAD CONFIGURATION.................................................................................................................................................5 5.3 BODY WORN CONFIGURATION (WITH KWC BODY WORN ACCESSORIES) .....................................................................5 5.4 MEASUREMENT UNCERTAINTY.....................................................................................................................................5 6 TEST CONDITIONS.........................................................................................................................................................6 6.1 AMBIENT CONDITIONS..................................................................................................................................................6 6.2 RF CHARACTERISTICS OF THE TEST SITE.......................................................................................................................6 6.3 TEST SIGNAL, FREQUENCIES AND OUTPUT POWER.......................................................................................................6 6.4 DEVICE TEST CONDITIONS............................................................................................................................................6 7 DESCRIPTION OF THE TEST EQUIPMENT.............................................................................................................7 7.1 DOSIMETRIC SYSTEM....................................................................................................................................................7 7.2 ADDITIONAL EQUIPMENT NEEDED IN VALIDATION........................................................................................................7 7.3 TISSUE STIMULANTS.....................................................................................................................................................7 7.4 PHANTOMS DESCRIPTION..............................................................................................................................................8 7.5 ISOTROPIC E-FIELD PROBE............................................................................................................................................8 8 SYSTEM VALIDATION..................................................................................................................................................9 9 DESCRIPTION OF THE TEST PROCEDURE...........................................................................................................10 9.1 TEST POSITIONS..........................................................................................................................................................10 9.1.1 Initial Ear Position.............................................................................................................................................10 9.1.2 Cheek Position....................................................................................................................................................11 9.1.3 Tilt Position........................................................................................................................................................11 9.1.4 Body Worn Configuration..................................................................................................................................12 9.2 SCAN PROCEDURES.....................................................................................................................................................12 9.3 SAR AVERAGING METHODS.......................................................................................................................................12 10 MEASUREMENT UNCERTAINTY.........................................................................................................................13 11 TEST DATA..........................................................................................................…

Text truncated - open the document above for the full version.

FCC ID: OVFKWC-K24B Appendix A: Validation Test Plots Validation Test Plots Page 1 of 1 Model: K323 Date/Time: 4/14/2006 12:20:57 AM Test Laboratory: Kyocera 835Mhz Validation, Probe 1664, DAE 602, Dipole 495 Communication System: CW, Frequency: 835 MHz, Duty Cycle: 1:1 Medium: HSL900,Medium parameters used: f = 835 MHz; σ = 0.901 mho/m; ε r = 42; ρ = 1000 kg/m 3 Phantom: SAM 12,Phantom section: Flat Section DASY4 Configuration: Probe: ET3DV6 - SN1664, ConvF(6.77, 6.77, 6.77), Calibrated: 6/15/2005 Sensor-Surface: 4mm (Mechanical And Optical Surface Detection), Electronics: DAE4 Sn602,Calibrated: 8/30/2005 Measurement SW: DASY4, V4.6 Build 19 Postprocessing SW: SEMCAD, V1.8 Build 160 Temperature: Room T = 21.8 +/− 1 deg C, Liquid T = 22.0 +/− 1 deg C 20 dbm validation/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 35.2 V/m; Power Drift = 0.012 dB Peak SAR (extrapolated) = 1.46 W/kg SAR(1 g) = 0.961 mW/g; SAR(10 g) = 0.621 mW/g Maximum value of SAR (measured) = 1.03 mW/g 0 dB = 1.03mW/g Page 1 of 1 5/8/2006file://C:\Documents%20and%20Settings\cle\Desktop\835Mhz%20Validation%20@%2020... Date/Time: 4/21/2006 12:41:53 AM Test Laboratory: Kyocera 835Mhz Validation, Probe 1664, DAE 602, Dipole 495 Communication System: CW, Frequency: 835 MHz, Duty Cycle: 1:1 Medium: HSL900,Medium parameters used: f = 835 MHz; σ = 0.901 mho/m; ε r = 42.1; ρ = 1000 kg/m 3 Phantom: SAM 12,Phantom section: Flat Section DASY4 Configuration: Probe: ET3DV6 - SN1664, ConvF(6.77, 6.77, 6.77), Calibrated: 6/15/2005 Sensor-Surface: 4mm (Mechanical And Optical Surface Detection), Electronics: DAE4 Sn602,Calibrated: 8/30/2005 Measurement SW: DASY4, V4.6 Build 19 Postprocessing SW: SEMCAD, V1.8 Build 160 Temperature: Room T = 21.8 +/− 1 deg C, Liquid T = 22.0 +/− 1 deg C 20 dbm validation/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 35.8 V/m; Power Drift = -0.019 dB Peak SAR (extrapolated) = 1.43 W/kg SAR(1 g) = 0.970 mW/g; SAR(10 g) = 0.636 mW/g Maximum value of SAR (measured) = 1.04 mW/g 0 dB = 1.04mW/g Page 1 of 1 5/8/2006file://C:\Documents%20and%20Settings\cle\Desktop\835Mhz%20Validation%20@%2020... Date/Time: 4/22/2006 1:13:58 AM Test Laboratory: Kyocera 835Mhz Validation, Probe 1664, DAE 602, Dipole 495 Communication System: CW, Frequency: 835 MHz, Duty Cycle: 1:1 Medium: HSL900,Medium parameters used: f = 835 MHz; σ = 0.902 mho/m; ε r = 42.3; ρ = 1000 kg/m 3 Phantom: SAM 12,Phantom section: Flat Section DASY4 Configuration: Probe: ET3DV6 - SN1664, ConvF(6.77, 6.77, 6.77), Calibrated: 6/15/2005 Sensor-Surface: 4mm (Mechanical And Optical Surface Detection), Electronics: DAE4 Sn602,Calibrated: 8/30/2005 Measurement SW: DASY4, V4.6 Build 19 Postprocessing SW: SEMCAD, V1.8 Build 160 Tempera…
