FCC ID: OVFKWC-KX21 Kyocera Wireless Corp. 1 December 2, 2005 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular and PCS Transceiver Certification To Whom It May Concern: Kyocera Wireless Corporation (KWC) herein submits the Application for Equipment Authorization (FCC Form 731) and Exhibits for Certification of a Cellular & PCS Transceiver, FCC ID: OVFKWC-KX21. Applicant: Kyocera Wireless Corporation 10300 Campus Point Drive San Diego, CA 92121-1522 Manufacture: Kyocera Wireless Corporation 10300 Campus Point Drive San Diego, CA 92121 The equipment is for mobile station cellular and PCS system use. The OVFKWC-KX21 is in full compliance with all parts of EIA/TIA/IS-98-B&D Mobile Station-Land Station Compatibility Specification, issue July 2000 and March 2001, and also in full compliance with all parts of ANSI J-STD-08, Recommended Minimum Performance Requirements for 1.8 to 2 GHz Code Division Multiple Access (CDMA) Personal Stations, issue July 1996. Information concerning how the ESN protection requirements are met is provided in Exhibit 10. Please contact me at Tel: (858) 882-2406 or Email: [email protected] if there are any questions or if any additional information is needed. Kyocera Wireless Corporation Lin Lu Principal Engineer

FCC ID: OVFKWC-KX21 Kyocera Wireless Corp. 1 December 2, 2005 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Request of Confidentiality for FCC ID: OVFKWC-KX21 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), Kyocera Wireless Corp (KWC) hereby requests confidential and treatment of information accompanying this Application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also requesting Short-Term Confidentiality as outlined in Public Notice DA 04-1705. This provision will give KWC Temporary Confidentiality of commercially sensitive information prior to product launch. The requested Confidential and Temporary Confidential exhibits are listed in table 1 below: Table 1. Confidential and Short-Term Confidential Exhibit Description 1 Operation Descriptions 2 Block diagrams 3 Schematics Confidential 4 Parts Lists 5 Instruction Manual 7 External Photos Short-Term Confidential 8 Internal Photos The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. Sincerely, Lin Lu Lin Lu Engineer, Principal Kyocera Wireless Corp.

FCC ID: OVFKWC-KX21 External Photos Page 1 of 3 Model: KX21 Exhibit 7: OVFKWC-KX21 External Photos TOP AND BOTTOM VIEWS (CLOSED) TOP VIEW (OPEN) FCC ID: OVFKWC-KX21 External Photos Page 2 of 3 Model: KX21 BOTTOM VIEW (OPEN) SIDE VIEW (CLOSED) FCC ID: OVFKWC-KX21 External Photos Page 3 of 3 Model: KX21 SIDE VIEW (OPEN)

FCC ID: OVFKWC-KX21 Label Information Page 1 of 1 Model: KX21 Exhibit 6: OVFKWC-KX21 ID Label Label Format Label Location

FCC ID: OVFKWC-KX21 Internal Photos Page 1 of 5 Model: KX21 Exhibit 8: OVFKWC-KX21 Internal Photos FCC ID: OVFKWC-KX21 Internal Photos Page 2 of 5 Model: KX21 FCC ID: OVFKWC-KX21 Internal Photos Page 3 of 5 Model: KX21 FCC ID: OVFKWC-KX21 Internal Photos Page 4 of 5 Model: KX21 FCC ID: OVFKWC-KX21 Internal Photos Page 5 of 5 Model: KX21

FCC ID: OVFKWC-KX21 SAR Report Page 1 of 23 Model: KX21 SAR Test Report on Dual-Band Tri-mode AMPS/CDMA Cellular Phone FCC Part 22 & 24 Certification FCC ID: OVFKWC-KX21 MODEL: KX21 DATE: December 2, 2005 STATEMENT OF COMPLIANCE Kyocera Wireless Corp declares under its sole responsibility that the product, FCC ID: OVFKWC- KX21 to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines. It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted: NONE. Date of Test: November 22-28, 2005 Test performed by: Kyocera Wireless Corp 10300 Campus Point Drive San Diego, CA 92121 Report Prepared by: Fernando Calimbahin, Engineer Report Reviewed by: Lin Lu, Principal Engineer FCC ID: OVFKWC-KX21 SAR Report Page 2 of 23 Model: KX21 Table of Contents 1 INTRODUCTION.........................................................................................................................................................................................3 2 EQUIPMENT UNDER TEST (EUT)...............................................................................................................................................................3 3 PRODUCT DESCRIPTION.........................................................................................................................................................................4 4 ACCESSORIES:..........................................................................................................................................................................................5 5 SAR TEST RESULT SUMMARY..................................................................................................................................................................5 5.1 MAXIMUM RESULTS FOUND DURING SAR EVALUATION.........................................................................................................................5 5.2 HEAD CONFIGURATION..........................................................................................................................................................................6 5.3 BODY WORN CONFIGURATION (WITH KWC BODY WORN ACCESSORIES)................................................................................................6 5.4 MEASUREMENT UNCERTAINTY..............................................................................................................................................................6 6 TEST CONDITIONS....................................................................................................................................................................................7 6.1 AMBIENT CONDITIONS...........................................................................................................................................................................7 6.2 RF CHARACTERISTICS OF THE TEST SITE...................................................................................................................................................7 6.3 TEST SIGNAL, FREQUENCIES AND OUTPUT POWER................................................................................................................................7 6.4 DEVICE TEST CONDITIONS.....................................................................................................................................................................7 7 DESCRIPTION OF THE TEST EQUIPMENT..............................................................................................................................................8 7.1 DOSIMETRIC SYSTEM..............................................................................................................................................................................8 7.2 ADDITIONAL EQUIPMENT NEEDED IN VALIDATION.................................................................................................................................8 7.3 TISSUE STIMULANTS..............................................................................................................................................................................8 7.4 PHANTOMS DESCRIPTION.......................................................................................................................................................................9 7.5 ISOTROPIC E-FIELD PROBE....................................................................................................................................................................9 8 SYSTEM VALIDATION.............................................................................................................................................................................10 9 DESCRIPTION OF THE TEST PROCEDURE...........................................................................................................................................11 9.1 TEST POSITIONS...................................................................................................................................................................................11 9.1.1 Initial Ear Position.....................................................................................................................................................................11 9.1.2 Cheek Position............................................................................................................................................................................12 9.1.3 Tilt Position................................................................................................................................................................................12 9.1.4 Body Worn Configuration................................…

Text truncated - open the document above for the full version.

Appendix A: Validation Test Plots FCC ID: OVFKWC-KX21 Validation Test PlotsPage 1 of 6Model: KX21 Date/Time: 11/22/2005 12:32:38 AM Test Laboratory: Kyocera 835MHz Validation @ 20.00dBm, Probe #3036, DAE #530, Dipole #454 Communication System: CW, Frequency: 835 MHz, Duty Cycle: 1:1 Medium: HSL900,Medium parameters used: f = 835 MHz; σ = 0.92 mho/m; ε r = 43; ρ = 1000 kg/m 3 Phantom: SAM 12,Phantom section: Flat Section DASY4 Configuration: Probe: ES3DV2 - SN3036, ConvF(5.99, 5.99, 5.99), Calibrated: 10/25/2005 Sensor-Surface: 4mm (Mechanical Surface Detection), Electronics: DAE4 Sn530,Calibrated: 1/4/2005 Measurement SW: DASY4, V4.4 Build 3 Postprocessing SW: SEMCAD, V1.8 Build 159 Temperature: Room T = 21.8 +/− 1 deg C, Liquid T = 22.0 +/− 1 deg C Validation Flat/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 34.8 V/m; Power Drift = -0.014 dB Peak SAR (extrapolated) = 1.51 W/kg SAR(1 g) = 1.01 mW/g; SAR(10 g) = 0.656 mW/g Maximum value of SAR (measured) = 1.09 mW/g 0 dB = 1.09mW/g FCC ID: OVFKWC-KX21 Validation Test PlotsPage 2 of 6Model: KX21 Date/Time: 11/23/2005 1:22:46 AM Test Laboratory: Kyocera 835MHz Validation @ 20.00dBm, Probe #3036, DAE #530, Dipole #454 Communication System: CW, Frequency: 835 MHz, Duty Cycle: 1:1 Medium: HSL900,Medium parameters used: f = 835 MHz; σ = 0.9 mho/m; ε r = 42.1; ρ = 1000 kg/m 3 Phantom: SAM 12,Phantom section: Flat Section DASY4 Configuration: Probe: ES3DV2 - SN3036, ConvF(5.99, 5.99, 5.99), Calibrated: 10/25/2005 Sensor-Surface: 4mm (Mechanical Surface Detection), Electronics: DAE4 Sn530,Calibrated: 1/4/2005 Measurement SW: DASY4, V4.4 Build 3 Postprocessing SW: SEMCAD, V1.8 Build 159 Temperature: Room T = 21.8 +/− 1 deg C, Liquid T = 22.0 +/− 1 deg C Validation Flat/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 35.8 V/m; Power Drift = 0.004 dB Peak SAR (extrapolated) = 1.54 W/kg SAR(1 g) = 1.04 mW/g; SAR(10 g) = 0.675 mW/g Maximum value of SAR (measured) = 1.12 mW/g 0 dB = 1.12mW/g FCC ID: OVFKWC-KX21 Validation Test PlotsPage 3 of 6Model: KX21 Date/Time: 11/23/2005 12:27:53 PM Test Laboratory: Kyocera 1900MHz Validation @ 20.00dbm, Probe #3036, DAE #530, Dipole #5d005 Communication System: CW 1900, Frequency: 1900 MHz, Duty Cycle: 1:1 Medium: HSL1800,Medium parameters used (interpolated): f = 1900 MHz; σ = 1.37 mho/m; ε r = 40.4; ρ = 1000 kg/m 3 Phantom: SAM 12,Phantom section: Flat Section DASY4 Configuration: Probe: ES3DV2 - SN3036, ConvF(4.64, 4.64, 4.64), Calibrated: 10/25/2005 Sensor-Surface: 4mm (Mechanical Surface Detection), Electronics: DAE4 Sn530,Calibrated: 1/4/2005 Measurement SW: DASY4, V4.4 Build 3 Postprocessing SW: SEMCAD, V1.8 Build 159 Temperature: Room T = 21.8 +/− 1 deg C, Liquid T = 22.0 +/− 1 deg C 1900Mhz/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 61.0 V/m; Power Drift = 0.011 dB Peak SAR (extrapolated) = 7.75 W/kg SAR(1 g) = 4.33 mW/g; SAR(10 g) = 2.27 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 4.91 mW/g 0 dB = 4.91mW/g FCC ID: OVFKWC-KX21 Validation Test PlotsPage 4 of 6Model: KX21 Date/Time: 11/24/2005 1:22:30 AM Test Laboratory: Kyocera 1900MHz Validation @ 20.00dbm, Probe #3036, DAE #530, Dipole #5d005 Communication System: CW 1900, Frequency: 1900 MHz, Duty Cycle: 1:1 Medium: HSL1800,Medium parameters used (interpolated): f = 1900 MHz; σ = 1.42 mho/m; ε r = 40.8; ρ = 1000 kg/m 3 Phantom: SAM 12,Phantom section: Flat Section DASY4 Configuration: Probe: ES3DV2 - SN3036, ConvF(4.64, 4.64, 4.64), Calibrated: 10/25/2005 Sensor-Surface: 4mm (Mechanical Surface Detection), Electronics: DAE4 Sn530,Calibrated: 1/4/2005 Measurement SW: DASY4, V4.4 Build 3 Postprocessing SW: SEMCAD, V1.8 Build 159 Temperature: Room T = 21.8 +/− 1 deg C, Liquid T = 22.0 +/− 1 deg C 1900Mhz/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 59.6 V/m; Power Drift = 0.000 dB Peak SAR (extrapolated) = 7.71 W/kg SAR(1 g) = 4.28 mW/g; SAR(10 g) = 2.23 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 4.85 mW/g 0 dB = 4.85mW/g FCC ID: OVFKWC-KX21 Validation Test PlotsPage 5 of 6Model: KX21 Date/Time: 11/28/2005 7:47:18 AM Test Laboratory: Kyocera 1900MHz Validation @ 20.00dbm, Probe #3036, DAE #530, Dipole #5d005 Communication System: CW 1900, Frequency: 1900 MHz, Duty Cycle: 1:1 Medium: HSL1800,Medium parameters used (interpolated): f = 1900 MHz; σ = 1.42 mho/m; ε r = 41; ρ = 1000 kg/m 3 Phantom: SAM 12,Phantom section: Flat Section DASY4 Configuration: Probe: ES3DV2 - SN3036, ConvF(4.64, 4.64, 4.64), Calibrated: 10/25/2005 Sensor-Surface: 4mm (Mechanical Surface Detection), Electronics: DAE4 Sn530,Calibrated: 1/4/2005 Measurement SW: DASY4, V4.4 Build 3 Postprocessing SW: SEMCAD, V1.8 Build 159 Temperature: Room T = 21.8 +/− 1 deg C, Liquid T = 22.0 +/− 1 deg C 1900Mhz/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 59.8 V/m; Power Drift = 0.004 dB Peak SAR (extrapolated) = 7.63 W/kg SAR(1 g) = 4.27 mW/g; SAR(10 g) = 2.24 mW/g Info: Interpolated medium parameters used for SAR evaluation. 0 dB = 4.84mW/g FCC ID: OVFKWC-KX21 Validation Test PlotsPage 6 of 6Model: KX21

Appendix B1: SAR Distribution Plots (Head) FCC ID: OVFKWC-KX21 SAR Distribution Plots HeadPage 1 of 16Model: KX21 Date/Time: 11/21/2005 10:23:31 PM Test Laboratory: Kyocera KX21 #Y63V AMPS ch799 Left Cheek with Extended Battery Communication System: AMPS, Frequency: 848.97 MHz, Duty Cycle: 1:1 Medium: HSL900,Medium parameters used (interpolated): f = 848.97 MHz; σ = 0.904 mho/m; ε r = 42.7; ρ = 1000 kg/m 3 Phantom: SAM 12,Phantom section: Left Section DASY4 Configuration: Probe: ES3DV2 - SN3036, ConvF(5.99, 5.99, 5.99), Calibrated: 10/25/2005 Sensor-Surface: 4mm (Mechanical Surface Detection), Electronics: DAE4 Sn530,Calibrated: 1/4/2005 Measurement SW: DASY4, V4.4 Build 3 Postprocessing SW: SEMCAD, V1.8 Build 159 Temperature: Room T = 21.8 +/− 1 deg C, Liquid T = 22.0 +/− 1 deg C AMPS Ch799 LC/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 33.7 V/m; Power Drift = -0.023 dB Peak SAR (extrapolated) = 1.82 W/kg SAR(1 g) = 1.34 mW/g; SAR(10 g) = 0.934 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 1.43 mW/g 0 dB = 1.43mW/g FCC ID: OVFKWC-KX21 SAR Distribution Plots HeadPage 2 of 16Model: KX21 Date/Time: 11/21/2005 11:20:26 PM Test Laboratory: Kyocera KX21 #Y63V AMPS ch799 Left Tilt with Extended Battery Communication System: AMPS, Frequency: 848.97 MHz, Duty Cycle: 1:1 Medium: HSL900,Medium parameters used (interpolated): f = 848.97 MHz; σ = 0.904 mho/m; ε r = 42.7; ρ = 1000 kg/m 3 Phantom: SAM 12,Phantom section: Left Section DASY4 Configuration: Probe: ES3DV2 - SN3036, ConvF(5.99, 5.99, 5.99), Calibrated: 10/25/2005 Sensor-Surface: 4mm (Mechanical Surface Detection), Electronics: DAE4 Sn530,Calibrated: 1/4/2005 Measurement SW: DASY4, V4.4 Build 3 Postprocessing SW: SEMCAD, V1.8 Build 159 Temperature: Room T = 21.8 +/− 1 deg C, Liquid T = 22.0 +/− 1 deg C AMPS Ch799 LT/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 33.1 V/m; Power Drift = -0.159 dB Peak SAR (extrapolated) = 1.22 W/kg SAR(1 g) = 0.935 mW/g; SAR(10 g) = 0.660 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.995 mW/g 0 dB = 0.995mW/g FCC ID: OVFKWC-KX21 SAR Distribution Plots HeadPage 3 of 16Model: KX21 Date/Time: 11/22/2005 5:37:00 AM Test Laboratory: Kyocera KX21 #Y63V AMPS ch799 Right Cheek Communication System: AMPS, Frequency: 848.97 MHz, Duty Cycle: 1:1 Medium: HSL900,Medium parameters used (interpolated): f = 848.97 MHz; σ = 0.92 mho/m; ε r = 43; ρ = 1000 kg/m 3 Phantom: SAM 12,Phantom section: Right Section DASY4 Configuration: Probe: ES3DV2 - SN3036, ConvF(5.99, 5.99, 5.99), Calibrated: 10/25/2005 Sensor-Surface: 4mm (Mechanical Surface Detection), Electronics: DAE4 Sn530,Calibrated: 1/4/2005 Measurement SW: DASY4, V4.4 Build 3 Postprocessing SW: SEMCAD, V1.8 Build 159 Temperature: Room T = 21.8 +/− 1 deg C, Liquid T = 22.0 +/− 1 deg C AMPS Ch799 RC/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 30.8 V/m; Power Drift = 0.012 dB Peak SAR (extrapolated) = 1.56 W/kg SAR(1 g) = 1.12 mW/g; SAR(10 g) = 0.761 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 1.20 mW/g 0 dB = 1.20mW/g FCC ID: OVFKWC-KX21 SAR Distribution Plots HeadPage 4 of 16Model: KX21 Date/Time: 11/22/2005 2:17:40 PM Test Laboratory: Kyocera KX21 #Y63V AMPS ch383 Right Tilt with Extended Battery Communication System: AMPS, Frequency: 836.49 MHz, Duty Cycle: 1:1 Medium: HSL900,Medium parameters used (interpolated): f = 836.49 MHz; σ = 0.92 mho/m; ε r = 43; ρ = 1000 kg/m 3 Phantom: SAM 12,Phantom section: Right Section DASY4 Configuration: Probe: ES3DV2 - SN3036, ConvF(5.99, 5.99, 5.99), Calibrated: 10/25/2005 Sensor-Surface: 4mm (Mechanical Surface Detection), Electronics: DAE4 Sn530,Calibrated: 1/4/2005 Measurement SW: DASY4, V4.4 Build 3 Postprocessing SW: SEMCAD, V1.8 Build 159 Temperature: Room T = 21.8 +/− 1 deg C, Liquid T = 22.0 +/− 1 deg C AMPS Ch383 RT/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 26.9 V/m; Power Drift = 0.005 dB Peak SAR (extrapolated) = 1.04 W/kg SAR(1 g) = 0.740 mW/g; SAR(10 g) = 0.526 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.786 mW/g 0 dB = 0.786mW/g FCC ID: OVFKWC-KX21 SAR Distribution Plots HeadPage 5 of 16Model: KX21 FCC ID: OVFKWC-KX21 SAR Distribution Plots HeadPage 6 of 16Model: KX21 Date/Time: 11/21/2005 6:46:24 PM Test Laboratory: Kyocera KX21 #Y63V CDMA-800 ch777 Left Cheek Communication System: CDMA-800, Frequency: 848.31 MHz, Duty Cycle: 1:1 Medium: HSL900,Medium parameters used (interpolated): f = 848.31 MHz; σ = 0.904 mho/m; ε r = 42.7; ρ = 1000 kg/m 3 Phantom: SAM 12,Phantom section: Left Section DASY4 Configuration: Probe: ES3DV2 - SN3036, ConvF(5.99, 5.99, 5.99), Calibrated: 10/25/2005 Sensor-Surface: 4mm (Mechanical Surface Detection), Electronics: DAE4 Sn530,Calibrated: 1/4/2005 Measurement SW: DASY4, V4.4 Build 3 Postprocessing SW: SEMCAD, V1.8 Build 159 Temperature: Room T = 21.8 +/− 1 deg C, Liquid T = 22.0 +/− 1 deg C CDMA-800 Ch777 LC/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 33.8 V/m; Power Drift = 0.006 dB Peak SAR (extrapolated) = 1.93 W/kg SAR(1 g) = 1.38 mW/g; SAR(10 g) = 0.943 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 1.48 mW/g 0 dB = 1.48mW/g FCC ID: OVFKWC-KX21 SAR Distribution Plots HeadPage 7 of 16Model: KX21 Date/Time: 11/21/2005 7:18:53 PM Test Laboratory: Kyocera KX21 #Y63V CDMA-800 ch383 Left Tilt Communication System: CDMA-800, Frequency: 836.49 MHz, Duty Cycle: 1:1 Medium: HSL900,Medium parameters used (interpolated): f = 836.49 MHz; σ = 0.904 mho/m; ε r = 42.7; ρ = 1000 kg/m 3 Phantom: SAM 12,Phantom section: Left Section DASY4 Configuration: Probe: ES3DV2 - SN3036, ConvF(5.99, 5.99, 5.99), Calibrated: 10/25/2005 Sensor-…

Text truncated - open the document above for the full version.

Appendix B2: SAR Distribution Plots (Body) FCC ID: OVFKWC-KX21 SAR Distribution Plots BodyPage 1 of 10Model: KX21 Date/Time: 11/22/2005 5:43:37 PM Test Laboratory: Kyocera KX21 #Y63V AMPS ch383 Flat with 25mm Air Space Communication System: AMPS, Frequency: 836.49 MHz, Duty Cycle: 1:1 Medium: M900,Medium parameters used (interpolated): f = 836.49 MHz; σ = 0.936 mho/m; ε r = 54.4; ρ = 1000 kg/m 3 Phantom: SAM 12,Phantom section: Flat Section DASY4 Configuration: Probe: ES3DV2 - SN3036, ConvF(5.85, 5.85, 5.85), Calibrated: 10/25/2005 Sensor-Surface: 4mm (Mechanical Surface Detection), Electronics: DAE4 Sn530,Calibrated: 1/4/2005 Measurement SW: DASY4, V4.4 Build 3 Postprocessing SW: SEMCAD, V1.8 Build 159 Temperature: Room T = 21.8 +/− 1 deg C, Liquid T = 22.0 +/− 1 deg C AMPS Ch383 FLAT/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 22.0 V/m; Power Drift = 0.087 dB Peak SAR (extrapolated) = 0.710 W/kg SAR(1 g) = 0.540 mW/g; SAR(10 g) = 0.398 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.569 mW/g 0 dB = 0.569mW/g FCC ID: OVFKWC-KX21 SAR Distribution Plots BodyPage 2 of 10Model: KX21 Date/Time: 11/22/2005 6:21:51 PM Test Laboratory: Kyocera KX21 #Y63V AMPS ch383 Flat with Black Pouch Communication System: AMPS, Frequency: 836.49 MHz, Duty Cycle: 1:1 Medium: M900,Medium parameters used (interpolated): f = 836.49 MHz; σ = 0.936 mho/m; ε r = 54.4; ρ = 1000 kg/m 3 Phantom: SAM 12,Phantom section: Flat Section DASY4 Configuration: Probe: ES3DV2 - SN3036, ConvF(5.85, 5.85, 5.85), Calibrated: 10/25/2005 Sensor-Surface: 4mm (Mechanical Surface Detection), Electronics: DAE4 Sn530,Calibrated: 1/4/2005 Measurement SW: DASY4, V4.4 Build 3 Postprocessing SW: SEMCAD, V1.8 Build 159 Temperature: Room T = 21.8 +/− 1 deg C, Liquid T = 22.0 +/− 1 deg C AMPS Ch383 FLAT/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 22.0 V/m; Power Drift = -0.003 dB Peak SAR (extrapolated) = 0.613 W/kg SAR(1 g) = 0.480 mW/g; SAR(10 g) = 0.356 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.507 mW/g 0 dB = 0.507mW/g FCC ID: OVFKWC-KX21 SAR Distribution Plots BodyPage 3 of 10Model: KX21 FCC ID: OVFKWC-KX21 SAR Distribution Plots BodyPage 4 of 10Model: KX21 Date/Time: 11/22/2005 7:59:08 PM Test Laboratory: Kyocera KX21 #Y63V CDMA-800 ch383 Flat with 25mm Air Space Communication System: CDMA-800, Frequency: 836.49 MHz, Duty Cycle: 1:1 Medium: M900,Medium parameters used (interpolated): f = 836.49 MHz; σ = 0.936 mho/m; ε r = 54.4; ρ = 1000 kg/m 3 Phantom: SAM 12,Phantom section: Flat Section DASY4 Configuration: Probe: ES3DV2 - SN3036, ConvF(5.85, 5.85, 5.85), Calibrated: 10/25/2005 Sensor-Surface: 4mm (Mechanical Surface Detection), Electronics: DAE4 Sn530,Calibrated: 1/4/2005 Measurement SW: DASY4, V4.4 Build 3 Postprocessing SW: SEMCAD, V1.8 Build 159 Temperature: Room T = 21.8 +/− 1 deg C, Liquid T = 22.0 +/− 1 deg C CDMA-800 Ch383 FLAT/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5…
