OWMHC-DIGICODE

Installation Instructions Garage Door Opener Radio Controls Model 5010 (300 mHz) \ 5012 (310 mHz) Single Button Transmitters Model 5020 (300 mHz) \ 5022 (310 mHz) Dual Button Transmitters Model 5190-01 (300 mHz) \ 5190-02 (310 mHz) Receivers WARNING: •• Disconnect operator power before any installation or repair •• Always wear safety glasses Your Digi-Code radio controls are designed specifically to remotely control a garage door opener from within an automobile and to give years of trouble free service without adjustment. Because all radio controls are set with the even numbered switches in the “ON” position when they leave the factory, it is recommended that a different code be selected and set at the time of installation. Please refer to the “Setting the Code Switch” section for instructions. The radio frequency (RF) portion of the controls, however, are tuned to standard frequencies and are thoroughly tested at the factory. This permits the addition or replacement of either the transmitter or the receiver by specifying the Model number and the RF frequency designated on the identification label. RF adjustments are not needed nor should any be attempted. RECEIVER INSTALLATION The receiver is designed to mount directly to the operator. It can be remotely installed if the operator terminal strip is not accessible, or if the power for the receiver is not obtainable from the operator. To direct mount the receiver, simply loosen the terminal screws on the operator and insert the two-way lugs from the receiver under the screw heads along the wall button wires, and tighten the screws ( See Figure #1) Place the antenna (a 10 inch black wire ) in a vertical position as far from any metal as possible. For remote installation the receiver may be mounted near the operator head on a joist or the ceiling by using the mounting tab. Order Model 5192-06 adapter, which permits connection between the operator terminal and the two-way lugs on the receiver. Slip on connectors at one end of the adapter connect to the flat side of each spade lug on the receiver, and the spade connectors at the other end connect to the operator terminal. Connect wires as follows: (a) White wire to terminal “1” or “24v” (b) Black wire to terminal “2” or “Relay” (c) Red wire to terminal “3” or “Common” ( Radio Power ) (d) Connect push button wires to terminal “1” and “2” (See Figure #2) Where power for the radio receiver is not available from the operator order a Model 5192-01 power transformer adapter for connection between the operator and the remote receiver. SETTING THE ( “RECEIVER” ) CODE SWITCH - TO WORK WITH MODEL 5010 AND MODEL 5012 SINGLE BUTTON TRANSMITTERS Use your finger to slide the “code switch hatch” from the receiver for access to the code switch. On the transmitter the entire front lower half of the case ( “ the battery hatch” ) is removeable. Use a coin or the curved end of the visor clip to disengage the lower half of the transmitter front. This will expose both the code switch and the battery compartment (See Figure #3). Model – 5010 (300mHz) or 5012 (310mHz) Set both code switches to the code of your choice, being sure both are set the same since a different setting of just one switch will prevent operation. The digital code is determined by the position of the 10 small switches numbered 1 through 10 located in the receiver and the transmitter. Any combination of “on” or “off” positions can be selected by using a pencil or a pen. (Note: The switches are in the “on” position when the switch is depressed toward the number.) See Figure #3 above. Once the codes have been set, check operation and reinsert the hatches. SETTING THE ( “RECEIVER” ) CODE SWITCHES - TO WORK WITH MODEL 5020 AND MODEL 5022 DUAL BUTTON TRANSMITTERS Use your finger to slide the “code switch hatch” from the receiver for access to the code switch. On the transmitter the entire front lower half of the case ( “ the battery hatch” ) is removeable. Use a coin or the curved end of the visor clip to disengage the lower half of the transmitter front. This will expose both the code switch and the battery compartment. See Figure #3 (Receiver) above and Figure #4 (Dual Button Transmitter) below. Figure #4 Model – 5020 (300mHz) or 5022 (310mHz) Before setting the receiver code switches, you will need to set the transmitter code switch on your model 5020 or 5022. We strongly suggest that you change the code from the factory setting to provide security for your own system, and to eliminate interference with neighboring systems. SETTING THE TRANSMITTER CODE SWITCH – MODEL’S 5020 & 5022 On the transmitter the entire front lower half of the case ( “ the battery hatch” ) is removeable. Use a coin or the curved end of the visor clip to disengage the lower half of the transmitter front. This will expose both the code switch and the battery compartment Once you have done this, locate the code switch and set code switch positions 1 through 9 to your personal code scheme ( THE 10 TH POSITION SWITCH MUST BE SET IN THE CLOSED POSITION “ON” ). We strongly urge that several coding schemes be avoided: ALL ON; 2,4,6,8,10, ON. These positions are similar to our or other manufacturers test positions, or are frequently used. SETTING RECEIVER #1 (WORKS WITH LEFT BUTTON ON TRANSMITTER) Use your finger to slide the “code switch hatch” from the receiver for access to the code switch. Set the receiver code switch positions 1 through 9 to match the transmitter code switch. Then make sure that the 10 th position switch on receiver #1 is set in the closed position “ON”. The left button on the transmitter should now operate this receiver. Once the codes have been set, check operation and reinsert the hatches. SETTING RECEIVER #2 (WORKS WITH RIGHT BUTTON ON TRANSMITTER) Use your finger to slide the “code switch hatch” from the receiver for access to the code switch. Set the receiver code switch positions 1 through 9 to match the transmitter code switch. Then make sure that the 10…

Text truncated - open the document above for the full version.

ATTESTATION Model 5100 and 5102 Superregenerative Receivers, F.C.C. ID OWMHC-DIGICODE Attestation Statement: Please see the Measurement Report contained elsewhere in this Application For Certification for the Attestation Statement.

307 Robbins Dr. • Troy, Michigan 48083 • Tel: 248 589-3645 • Fax: 248 588-6801 Date: February 28, 2000 Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315 Dear Sir/Madam: We hereby make application for Grant of Certification on the following garage door opener superregenerative receivers - model #’s 5100 & 5102. The model 5100 receiver operates on a fixed frequency of 300mHz and the model 5102 receiver operates on a fixed frequency of 310 mHz. All of these receivers are compliant with Part 15 of the FCC rules and regulations. These products will be marketed and sold by: Digi-Code Inc., 307 Robbins Dr., Troy, Michigan 48083. These products will be manufactured by: KDS Controls, 307 Robbins Dr., Troy, Michigan 48083. Model’s 5100 & 5102 will be marked with FCC ID # OWMHC-DIGICODE Thank you for your assistance in this matter. Please contact us immediately if you have any additional questions or concerns. Sincerely, Richard J. Caceres President

307 Robbins Dr. • Troy, Michigan 48083 • Tel: 248 589-3645 • Fax: 248 588-6801 Description of Operation Model CR-5100 and Model CR-5102 Remote Control Receivers: These receivers are self-contained superregenerative remote control devices designed and manufactured for the purpose of remote radio control of garage door openers and other like devices. The physical size of these devices is approximately 6” x 4” x 1”. Model CR-5100 operates on a fixed frequency of 300 mHz and Model CR-5102 operates on a fixed frequency of 310 mHz. These devices are powered by a small 24 VAC transformer or by the control device to which each is connected. A dry contact relay output is provided for interface control purposes. This relay contact remains in the closed position when a proper radio signal is being received. Personal radio coding of each device is provided by a small 10 position switch which is mounted on the printed circuit board. Access to this switch is provided when the access cover on the receiver is removed. 10 switch positions provide 1,024 personal code selections. All models are compliant with F.C.C. Part 15 Rules.

A A B B C C D D E E 44 33 22 11 10V 25V25V a b GND RY D.ZAPATA CR-5100/5102 FILM FILM FILM NOTES: ALL RESISTORS IN OHMS, 1/4 WATT, 5% UNLESS SPECIFIED ALL CAPACITORS IN uF UNLESS SPECIFIED Q1 & Q2 HAVE BEC PIN-OUT 1/2W 1/2W 50V FILM 35V 14-3050 U3 OI 24 VAC RECEIVER, 3 TAB T1 T2 T3 SW 1-10 2-14-00 CN# 1155 FFC-ID OWMHC-DIGICODE Wednesday, February 16, 2000 Custom Tuesday, November 16, 1999 00 Digi-Code Drawn: Engineer: Document Number Rev. Size:Cage Code: Scale: Sheet of Rev Date:Orig Date: C1 3.9pF C2 5.6pF C18 .01 C3 .001 C4 .001 R3 330 R8 4.7k R6 3.3k R30 100 R2 4.7k R1 1.8k R5 220 R7 10k Q1 L1 C5 3pF ANT? ANTENNA Q2 C6 .001 C7 100pF L2 .22uH R9 470 C8 3.9pF R10 4.7k C9 .022 R11 10k R12 10k U1A LM358 - + 2 3 1 R13 2.2M C10 10 + C19 33pF R15 10k R14 4.7k R16 1M C12 10 + U1A LM358 - + 6 5 7 8 4 R22 270k R23 2.7M R24 2.7M R25 5.1M R26 10M C13 .0022 C14 .001 R27 330k R21 10k Q4 C11 100 + D1 1N4002 K1 U2 CCD 1 2 3 4 5 6 7 89 10 11 12 13 14 15 16 R18 68k R20 220 R19 220 R28 MOV Q3 C15 47 + C16 100 + C17 .01 R17 100k D2 1N4002 J2
