OWWF110655SZorida Ace 3S

User Manual Home Mobile Signal Booster Ace 3S Boost Your Bars (972) 870-5666 [email protected] Package Content Introduction Pre-Installation Instructions LED Indicator Lights APP Assisted Installation Quick Troubleshooting Guide Technical Specifications Authorized Accessories List FCC and IC Statements Return and Warranty Policies 01 02 03 08 09 20 22 23 24 26 CONTENTS Package Content 01 Warning: Un-authorized antennas, cables, and/or coupling devices are prohibited by new FCC rules, Please contact FCC for details: 1(888)-CALL-FCC. Zorida Ace 3S Outdoor Antenna Indoor Panel Antenna 50ft SMAM-SMAM Outdoor Cable 20ft SMAM-SMAM Outdoor Cable Booster Power Supply are all provided Accessories for main parts Introduction Thanks again for purchasing Zorida cell phone Booster. The Ace 3S is a collection of precision-engineered products that improve cellular reception inside of homes and businesses by amplifying incoming and outgoing cell phone signals. The exclusive cloud-based signal monitoring mobile application of the Zorida cell booster allows users to remotely monitor the real-time status of Zorida cell phone signal boosters anytime, anywhere directly through their mobile devices. If there are any issues while installing a Zorida Ace 3S cell phone signal booster, please contact the Zorida technical support team through the following options Online Support: Create a ticket or chat via Signal Supervisor App (972) 870-5666 (M-F from 9am – 5 pm CST) [email protected] Pre-Installation Instructions We strongly recommend you to read the user guide completely before you install. Zorida 3S booster provides App assisted installation. 1.App Assisted Installation From Page 08~19. It’s more convenient and many work could be done by ONE person, and the most important is that the obtained signal can be very precise. 02 The app helps you find the best signal outside 03 Then why has Zorida spent extra big efforts and costs to design APP and LCD signal meters to help you install? Out of the various reasons, the most important reason is that we would like you, our valuable client, to get the maximum output power from the booster system in order to get optimal signal reception for all your mobile devices. As it is known and a big thanks, FCC makes signal boosters legal in 2014 so that every body can install and benefit from the signals; But FCC regulations do limit the gain and output power of all consumer boosters to low values in order to avoid any interference to the cell towers; Furthermore FCC stipulates that any improper install should trigger immediately further reduction of the booster’s already-limited gain and power to protect the towers. Therefore, you can understand how important you need to find the perfect outside signal from the tower and how important to squeeze every last gain and power from the booster, even 1dB more power is so precious when you suffer from no signals. 04 General Working Principle: Please do spend some time to read it fully, as it is crucial to get full bars for your rooms. Before we start any of the two ways, please allow us to spend 3 pages to make you understand how the booster system works for you. Vice versa, inside antenna receives phone signal and sends to the booster, The booster then amplifies and sends it to outside antenna, Outside antenna sends signal to the cell tower. Then you can make phone calls and do internet streaming. The outdoor Antenna receives outside signal from the nearby cell tower and sends it to Zorida Booster. The indoor antenna receives amplified signal and sends it throughout your rooms The booster amplifies the signal and sends to indoor antenna. Installation mode: Wall Mount 05 Working Principle in Formula Outside Signal Outdoor Antenna Gain Outdoor Cable Loss Booster Gain Indoor Antenna Gain System Output Power Out of the Formula: Outside Signal: To be received by outdoor antenna from cell tower Outdoor Antenna Gain: The gain of outdoor antenna Outdoor Cable Loss: The loss of the outdoor cable Booster Gain: The actual working gain of the booster Indoor Antenna Gain: The gain of indoor antenna For example: -65dBm + 11dBi - 4.5dB + 60dB + 2dBi = 3.5dBm (System Output Power) Since the figures in Black color are fixed when you finish the purchase, thus the RED figures of 1. Outside Signal 2. Booster Gain will play a vital role in reaching the best output power during the installation, especially when we know the FCC limits the booster system values. So the user guide is focused on: 1. Getting the best outside signal. 2. Keeping the maximum booster gain. = 06 More notes on how to keep the maximum booster gain Please note: This separation is not an absolute mandate. The idea is to isolate the outdoor antenna from the indoor antenna. 1) Increase the distance between the outdoor and indoor antenna, generally the same vertical distance generates more loss than horizontal, and to follow easily, a Typical Required Distance Between Outdoor and Indoor Antenna Over 30 feet (10 meters) straight line distance. 2) Use barriers between the indoor and outdoor antenna. The self-oscillation from the outdoor antenna to the indoor antenna will reduce the gain, so the principle to keep the maximum booster gain is to avoid the lself-oscillation from the outdoor antenna to the indoor antenna. ＞10M/30ft 07 LED Indicator Lights Power Bluetooth not connectedBlue light is always on connectedblue light flashes at 3S intervals Alarm(ISO) normal input conditionIndicator light blue light always on output status ISO=114dBblue light flashes for 3 seconds ISO=1521dB blue light flashes for 1 second ISO≥22 dB normal power off blue light is always on Light off red light flashes for 1S Power Alarm(ISO) Bluetooth Bands contained in the Gauges on Signal Supervisor GaugeBandUplinkDownlink LTE700 CELL800 12/17698-716MHz728-746MHz 13776-787MHz746-757MHz 5824-849MHz869-894MHz Please focus on the gauge that contains the band you are using. Flow Chart of App Assisted Installation App Ass…

Text truncated - open the document above for the full version.

SHENZHEN HUAPTEC CO., LTD To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: SHENZHEN HUAPTEC CO., LTD 3rd FL,E BLDG,Sogood Science Park,SanWei community Hangcheng Street,Bao’anDistrict, Shenzhen, China Regarding: Request application for FCC ID: OWWF110655S According to: FCC KDB 935210 D02 Signal Boosters Certification v04r02 For consumer booster device, Section III.C requirement: (2) NPS and other compliance/safeguard features have been implemented (3) NPS and other compliance/safeguard features are defaulted to “ON” configuration (in operation) (4) NPS and other compliance/safeguard features cannot be field reconfigured, disabled or removed (5) Consumer booster is not user programmable, does not need fine tuning or adjustment, does not require professional installation (6) Future software upgrade will not cause non-compliance We SHENZHEN HUAPTEC CO., LTD declared our product (Product name: Zorida Ace 3S, FCC ID: OWWF110655S) comply above requirement. Sincerely, Name（printed）: Yanwei Wang Title: - Signature: On behalf of company: SHENZHEN HUAPTEC CO., LTD

Tune Up

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 1 of 8 FCC ID: OWWF110655S Appendix - External Photos for GZCR2405000446AT Test Model No.: F05GZ-3S-BT SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-01 Rev 1.1 Page: 2 of 8 EUT Constructional Details (EUT Photos) Shell 1 (F05GZ-3S-BT) SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-01 Rev 1.1 Page: 3 of 8 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-01 Rev 1.1 Page: 4 of 8 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-01 Rev 1.1 Page: 5 of 8 Shell 2 (F05GB-3S-BT) SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-01 Rev 1.1 Page: 6 of 8 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-01 Rev 1.1 Page: 7 of 8 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-01 Rev 1.1 Page: 8 of 8 - End of the Appendix -

Page 1 of 2 Page 2 of 2 The device is impracticable to label it with the 15.19(a) statement.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 1 of 3 FCC ID: OWWF110655S Appendix - Internal Photos for GZCR2405000446AT Test Model No.: F05GZ-3S-BT SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 2 of 3 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 3 of 3 - End of the Appendix -

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR240500044603 Page: 1 of 10 FCC ID: OWWF110655S Ricky Liu Manager RF EXPOSURE EVALUATION REPORT Application No.: GZCR2405000446AT Applicant: Shenzhen Huaptec Co., Ltd Address of Applicant: 3rd FL, E BLDG, Sogood Science Park, SanWei Community, Hangcheng Street, Bao'an District, Shenzhen, China Manufacturer: Shenzhen Huaptec Co., Ltd Address of Manufacturer: 3rd FL, E BLDG, Sogood Science Park, SanWei Community, Hangcheng Street, Bao'an District, Shenzhen, China Factory: Shenzhen Huaptec Co., Ltd Address of Factory: 3rd FL, E BLDG, Sogood Science Park, SanWei Community, Hangcheng Street, Bao'an District, Shenzhen, China Product Name: Zorida Ace 3S Model No.: F05GZ-3S-BT, F05GB-3S-BT   Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Trade Mark: Zorida Standard(s) : 47 CFR Part 2.1091 47 CFR Part 1.1310, Part 1.1307 Date of Receipt: 2024-05-08 Date of Evaluation: 2024-06-17 Date of Issue: 2024-06-18 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR240500044603 Page: 2 of 10 Revision Record VersionChapterDateRemark 01GZCR2405000446032024-06-18Original Authorized for issue by: Kevin Zhang/Project Engineer Jerry Chan/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR240500044603 Page: 3 of 10 2Evaluation Summary ItemStandardRequirementMethodResult RF Exposure 47 CFR Part 2.1091 47 CFR Part 1.1310 47 CFR Part 1.1307 47 CFR Part 1.131047 CFR Part 1.1310PASS Note: E.U.T./ EUT means Equipment Under Test Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section.  Declaration of EUT Family Grouping: Model No.: F05GZ-3S-BT, F05GB-3S-BT According to the declaration from the applicant, the electrical circuit design, layout, components used and internal wiring were identical for all models, with only differences on model No.and outer shell. Details as below. Model No.Outer Shell F05GZ-3S-BTShell 1 F05GB-3S-BTShell 2 Antenna Kitting Information: Antenna KittingModelAntenna Gain and Cable lossRemark 698-849MHz8dBi Log-periodic antenna080012030 1710-1915MHz9dBi Outdoor antenna 728-894MHz8dBi Panel antenna080011023 1930-2155MHz9dBi Indoor antenna 600-2000MHz-8.4dB Coaxial-cable (15m)3D-FB 2000-2500MHz-9.1dB For outdoor use 600-2000MHz-3.8dB Coaxial-cable (6m)3D-FB 2000-2500MHz-4.5dB For indoor use Therefore, only one mode F05GZ-3S-BT was tested in this report. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR240500044603 Page: 4 of 10 3Contents Page 1 Covers Page................................................................................................................................................1 2Evaluation Summary..................................................................................................................................3 3Contents......................................................................................................................................................4 4General Information....................................................................................................................................5 4.1Details of E.U.T...................................................................................................................................5 4.2Evaluation Location...........................................................................................................................6 4.3Test Facility........................................................................................................................................6 4.4Deviation from Standards.................................................................................................................6 4.5Abnormalities from Standard Conditions........................................................................................6 5RF Exposure................................................................................................................................................7 5.1Requirement.......................................................................................................................................7 5.2Method................................................................................................................................................7 5.3Conclusion..........................................................................................................................................8 6EUT Constructional Details (EUT Photos).............................................................................................10 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR240500044603 Page: 5 of 10 4General Information 4.1Details of E.U.T. Power Supply: AC 100-240V, 50/60Hz by AC/DC adapter Model: RJ23-W120150US Input: 100-240V, 50/60Hz 0.8A Output: 12V--1.5A Test Voltage:AC 120V Cable: DC output cable (unshielded, 2m) Operating Temperature:-25 to +55 °C Uplink:698MHz to 716MHz Lower 700MHz Downlink:728MHz to 746MHz Uplink:776MHz to 787MHz Upper 700MHz Downlink:746MHz to 757MHz Uplink:824MHz to 849MHz Operating Frequency: Cellular Downlink:869MHz to 894MHz RF Port:2 (N-F) Interface: Power Jack:1 Uplink: ≥17dBm Output Power: (Conducted)Downlink: ≤11dBm Uplink: ≤65dB Max. Gain: Downlink: ≤65dB Antenna Type: External Dedicated Antenna Antenna Gain: Refer to clause 2 in this report Software Version: F05GZ-3S-BT_V1.0 Booster Type: Fixed Consumer Signal Booster Bluetooth: Refer to Bluetooth Module FCC ID: 2ATPO-PB03 Remark: The information in this section is pro…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500044602 Page: 1 of 41 FCC ID: OWWF110655S Ricky Liu Manager TEST REPORT Application No.: GZCR2405000446AT Applicant: Shenzhen Huaptec Co., Ltd Address of Applicant: 3rd FL, E BLDG, Sogood Science Park, SanWei Community, Hangcheng Street, Bao'an District, Shenzhen, China Manufacturer: Shenzhen Huaptec Co., Ltd Address of Manufacturer: 3rd FL, E BLDG, Sogood Science Park, SanWei Community, Hangcheng Street, Bao'an District, Shenzhen, China Factory: Shenzhen Huaptec Co., Ltd Address of Factory: 3rd FL, E BLDG, Sogood Science Park, SanWei Community, Hangcheng Street, Bao'an District, Shenzhen, China Product Name: Zorida Ace 3S Model No.: F05GZ-3S-BT, F05GB-3S-BT   Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Trade Mark: Zorida Standard(s) : 47 CFR Part 2 47 CFR Part 20 47 CFR Part 22 47 CFR Part 27 Date of Receipt: 2024-05-08 Date of Test: 2024-05-17 to 2024-06-13 Date of Issue: 2024-06-18 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500044602 Page: 2 of 41 Revision Record VersionChapterDateRemark 01GZCR2405000446022024-06-18Original Authorized for issue by: Kevin Zhang/Project Engineer Jerry Chan/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500044602 Page: 3 of 41 2Test Summary Item (FCC Rule 47 CFR) Item & Method (KDB 935210 D03 v04r04 Subclause) Result 20.21(e)(3) Frequency Bands 7.1 Authorized frequency band verificationPASS 20.21(e)(8)(i)(D) Power Limits 20.21(e)(8)(i)(B) Bidirectional Capability 7.2 Maximum power PASS 20.21(e)(8)(i)(C)(2) Booster Gain Limits 20.21(e)(8)(i)(B) Bidirectional Capability 7.3 Maximum booster gain computation PASS 20.21(e)(8)(i)(F) Intermodulation Limits 7.4 Intermodulation product PASS 20.21(e)(8)(i)(E) Out of Band Emission Limits 7.5 Out-of-band emissions PASS 2.1051 Spurious emissions at antenna terminals 7.6 Conducted spurious emissions PASS 20.21(e)(8)(i)(A) Noise Limits 20.21(e)(8)(i)(H) Transmit Power Off Mode 7.7 Noise limitPASS 20.21(e)(8)(i)(I) Uplink Inactivity 7.8 Uplink inactivityPASS 20.21(e)(8)(i)(C)(1) Booster Gain Limits 20.21(e)(8)(i)(H) Transmit Power Off Mode 7.9 Variable booster gainPASS 2.1049 Occupied bandwidth 7.10 Occupied bandwidthPASS 20.21(e)(8)(ii)(A) Anti-Oscillation 20.21(e)(5) Anti-Oscillation 7.11 Oscillation detectionPASS 2.1053 Field strength of spurious radiation 7.12 Radiated spurious emissionsPASS 20.21(e)(4) Self-monitoring /PASS SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500044602 Page: 4 of 41 Item (FCC Rule 47 CFR) Item & Method (KDB 935210 D03 v04r04 Subclause) Result 20.21(e)(8)(i)(G) Booster Antenna Kitting /PASS 20.21(e)(8)(i)(H) Transmit Power Off Mode / PASS 20.21(e)(8)(ii)(B) Gain Control / PASS 20.21(e)(8)(ii)(C) Interference Avoidance for Wireless Subsystems / PASS 20.21(e)(8)(i)(B) Bidirectional Capability 20.21(e)(3) Frequency Bands 7.13 Spectrum block filtering PASS Note: E.U.T./ EUT means Equipment Under Test Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section. 20.21(e)(4) Self-monitoring There is no specific test for this functionality but it is instead indirectly addressed by the noise and gain limits tests. 20.21(e)(8)(i)(G) Booster Antenna Kitting Generic testing requirements are not established; rather technical documentation is used describing all antennas, cables, and/or coupling devices that may be used with a consumer booster and how those meet the requirements. The related information stated in the user manual. 20.21(e)(8)(i)(H) Transmit Power Off Mode There is no specific test for this functionality but it is instead addressed through a combination of the variable noise, variable gain, and oscillation detection tests. 20.21(e)(8)(ii)(B) Gain Control Conformance to the requirement to include AGC circuitry is verified in 7.1 and 7.2. 20.21(e)(8)(ii)(C) Interference Avoidance for Wireless Subsystems Before testing please submit a proposed test plan in a KDB inquiry for FCC review and acceptance. But this consumer boosters device not using unlicensed (part 15) or other frequency bands for wireless transmissions between donor and server subsystems for its internal operations, the requirement is not applicable. 20.21(e)(8)(i)(B) Bidirectional Capability This item is only for wideband consumer booster utilizing spectrum block filtering.The device not use spectrum block filtering and the test is not applicable. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500044602 Page: 5 of 41  Declaration of EUT Family Grouping: Model No.: F05GZ-3S-BT, F05GB-3S-BT According to the declaration from the applicant, the electrical circuit design, layout, components used and internal wiring were identical for all models, with only differences on model No.and outer shell. Details as below. Model No.Outer Shell F05GZ-3S-BTShell 1 F05GB-3S-BTShell 2 Antenna Kitting Information: Antenna KittingModelAntenna Gain and Cable lossRemark 698-849MHz8dBi Log-periodic antenna080012030 1710-1915MHz9dBi Outdoor antenna 728-894MHz8dBi Panel antenna080011023 1930-2155MHz9dBi Indoor antenna 600-2000MHz-8.4dB Coaxial-cable (15m)3D-FB 2000-2500MHz-9.1dB For outdoor use 600-2000MHz-3.8dB Coaxial-cable (6m)3D-FB 2000-2500MHz-4.5dB For indoor use Therefore, only one mode F05GZ-3S-BT was tested in this report. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR240500044602 Page: 6 of 41 3Contents Page 1 Covers Page..........................................................................…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 1 of 118 FCC ID: OWWF110655S Appendix - Test Data and Result for report GZCR240500044602 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 2 of 118 1 Authorized frequency band verification Authorized frequency band verification DL Lower & Upper 700MHz Band f0 =736.2MHz Cellular Band f0 =879.2MHz SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 3 of 118 Authorized frequency band verification UL Lower 700MHz Band f0 =702.7MHz Upper 700MHz Band f0 =777.0MHz SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 4 of 118 Authorized frequency band verification UL Cellular Band f0 =840.6MHz Remark: The frequency point f0 with the highest power level fall in the CMRS band under test with reset the spectrum analyser span to 2  the width of the CMRS band under test and adjust the tuned frequency of the signal generator to sweep 2  the width of the CMRS band using the sweep function. EUT is compiled the KDB 935210 D03 Signal Booster Measurements v04r04 Authorized frequency band verification test requirement. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 5 of 118 2 Maximum power Maximum Output Power Path Band Signal Type Input Signal Level (dBm) Maximum Output Power Verdict Conducted (dBm) Limit (dBm) EIRP (dBm) Limit (dBm) DL 700MHz AWGN Pre-AGC -56.3 5.4 ≤17 9.6 ≤17 PASS GSM Pre-AGC -56.4 5.5 9.7 PASS Cellular AWGN Pre-AGC -56.9 4.9 9.1 PASS GSM Pre-AGC -58.0 5.0 9.2 PASS UL Lower 700MHz AWGN Pre-AGC -40.0 18.6 ≥17 & ≤30 18.2 ≤30 PASS GSM Pre-AGC -38.8 20.2 19.8 PASS Upper 700MHz AWGN Pre-AGC -41.8 18.5 18.1 PASS GSM Pre-AGC -39.3 19.3 18.9 PASS Cellular AWGN Pre-AGC -41.6 18.1 17.7 PASS GSM Pre-AGC -56.3 19.3 18.9 PASS Remark: 1. The test frequency f 0 was determined in Authorized frequency band verification test in this report. 2. ERIP = Conducted Output Power + Antenna Gain – Cable loss, refer to clause 2 for the details about the declared antenna gain and cable loss. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 6 of 118 Maximum transmitter test input levels Path Band Signal Type Input Power (dBm) Conducted output power (dBm) Verdict DL 700MHz AWGN -46.0 5.1 PASS GSM -47.0 5.1 PASS Cellular AWGN -48.0 4.6 PASS GSM -48.0 4.8 PASS UL Lower 700MHz AWGN -30.0 18.4 PASS GSM -29.0 20.1 PASS Upper 700MHz AWGN -31.0 18.3 PASS GSM -30.0 19.1 PASS Cellular AWGN -31.0 17.8 PASS GSM -30.0 19.1 PASS Remark: The EUT went into shutdown mode at the maximum input level indicated in 5.5 of KDB 935210 D03. Above test data was measured at input level 1dB less than that found to cause the shutdown, where the input power is much greater than 10dB above AGC. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 7 of 118 3 Maximum booster gain computation Maximum Gain Path Band Signal Type Input Signal Level (dBm) Conducted Output Power (dBm) Gain (dB) Limit (dB) Verdict DL 700MHz AWGN Pre-AGC -56.8 5.4 62.2 ≤63.4 PASS GSM Pre-AGC -57.2 5.5 62.7 PASS Cellular AWGN Pre-AGC -58.6 4.9 63.5 ≤64.9 PASS GSM Pre-AGC -58.5 5.0 63.5 PASS UL Lower 700MHz AWGN Pre-AGC -40.6 18.6 59.2 ≤63.4 PASS GSM Pre-AGC -39.8 20.2 60.0 PASS Upper 700MHz AWGN Pre-AGC -41.5 18.5 60.0 ≤64.3 PASS GSM Pre-AGC -41.0 19.3 60.3 PASS Cellular AWGN Pre-AGC -41.3 18.1 59.4 ≤64.9 PASS GSM Pre-AGC -40.6 19.3 59.9 PASS SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 8 of 118 Equivalent Uplink and Downlink Gain Band Signal Type Uplink Gain (dB) Downlink Gain (dB) |UL vs DL Gain| (dB) Limit (dB) Verdict Lower 700MHz AWGN 59.2 62.2 3.0 ≤9 PASS GSM 60.0 62.7 2.7 PASS Upper 700MHz AWGN 60.0 62.2 2.2 PASS GSM 60.3 62.7 2.4 PASS Cellular AWGN 59.4 63.5 4.1 PASS GSM 59.9 63.5 3.6 PASS SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 9 of 118 4 Intermodulation product Intermodulation product Path Band Input Signal Worst Test Level (dBm) Limit (dBm) Verdict DL 700MHz two CW signals Pre-AGC -55.9 ≤-19 PASS 10dB above AGC -55.5 PASS Cellular two CW signals Pre-AGC -40.5 ≤-19 PASS 10dB above AGC -39.3 PASS UL Lower 700MHz two CW signals Pre-AGC -22.9 ≤-19 PASS 10dB above AGC -22.7 PASS Upper 700MHz two CW signals Pre-AGC -25.2 ≤-19 PASS 10dB above AGC -24.4 PASS Cellular two CW signals Pre-AGC -32.0 ≤-19 PASS 10dB above AGC -31.9 PASS SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 10 of 118 Intermodulation product DL 700MHz Band_Pre-AGC 700MHz Band_10dB above AGC SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 11 of 118 Intermodulation product DL Cellular Band_Pre-AGC Cellular Band_10dB above AGC SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 12 of 118 Intermodulation product UL Lower 700MHz Band_Pre-AGC Lower 700MHz Band_10dB above AGC SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 13 of 118 Intermodulation product UL Upper 700MHz Band_Pre-AGC Upper 700MHz Band_10dB above AGC SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 14 of 118 Intermodulation product UL Cellular Band_Pre-AGC Cellular Band_10dB above AGC SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 15 of 118 5 Out-of-band emissions Out-of-band emissions Path Band Input Signal Limit (dBm) Verdict DL 700MHz GSM Lower Edge Pre-AGC ≤-19 PASS 10dB above AGC PASS Upper Edge Pre-AGC PASS 10dB above AGC PASS 1.25MHz AWGN Lower Edge Pre-AGC ≤-19 PASS 10dB above AGC PASS Upper Edge Pre-AGC PASS 10dB above AGC PASS 4.1MHz AWGN Lower Edge Pre-AGC ≤-19 PASS 10dB above AGC PASS Upper Edge Pre-AGC PASS 10dB above AGC PASS Cellular GSM Lower Edge Pre-AGC ≤-19 PASS 10…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 33 of 118 Out-of-band emissions UL_Lower 700MHz Band GSM signal input_Lower band edge_Pre-AGC SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 34 of 118 Out-of-band emissions UL_Lower 700MHz Band GSM signal input_Lower band edge_10dB above AGC SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 35 of 118 Out-of-band emissions UL_Lower 700MHz Band GSM signal input_Upper band edge_Pre-AGC SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 36 of 118 Out-of-band emissions UL_Lower 700MHz Band GSM signal input_Upper band edge_10dB above AGC SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 37 of 118 Out-of-band emissions UL_Lower 700MHz Band 1.25MHz AWGN signal input_Lower band edge_Pre-AGC 1.25MHz AWGN signal input_Lower band edge_10dB above AGC SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 38 of 118 Out-of-band emissions UL_Lower 700MHz Band 1.25MHz AWGN signal input_Upper band edge_Pre-AGC 1.25MHz AWGN signal input_Upper band edge_10dB above AGC SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 39 of 118 Out-of-band emissions UL_Lower 700MHz Band 4.1MHz AWGN signal input_Lower band edge_Pre-AGC 4.1MHz AWGN signal input_Lower band edge_10dB above AGC SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 40 of 118 Out-of-band emissions UL_Lower 700MHz Band 4.1MHz AWGN signal input_Upper band edge_Pre-AGC 4.1MHz AWGN signal input_Upper band edge_10dB above AGC SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 41 of 118 Out-of-band emissions UL_Upper 700MHz Band GSM signal input_Lower band edge_Pre-AGC SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 42 of 118 Out-of-band emissions UL_Upper 700MHz Band GSM signal input_Lower band edge_10dB above AGC SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 43 of 118 Out-of-band emissions UL_Upper 700MHz Band GSM signal input_Upper band edge_Pre-AGC SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 44 of 118 Out-of-band emissions UL_Upper 700MHz Band GSM signal input_Upper band edge_10dB above AGC SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 45 of 118 Out-of-band emissions UL_Upper 700MHz Band 1.25MHz AWGN signal input_Lower band edge_Pre-AGC 1.25MHz AWGN signal input_Lower band edge_10dB above AGC SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 46 of 118 Out-of-band emissions UL_Upper 700MHz Band 1.25MHz AWGN signal input_Upper band edge_Pre-AGC 1.25MHz AWGN signal input_Upper band edge_10dB above AGC SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 47 of 118 Out-of-band emissions UL_Upper 700MHz Band 4.1MHz AWGN signal input_Lower band edge_Pre-AGC 4.1MHz AWGN signal input_Lower band edge_10dB above AGC SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-05 Rev 1.1 Page: 48 of 118 Out-of-ban…

Text truncated - open the document above for the full version.
