P2DBTU9XUFD + Bluetooth

Applicant: Fu Kuang Hui Electronics Co., Ltd. (Shen-Zhen) FCC ID: P2DBTU9X USB Bluetooth/Flash Disk User’s manual V1.0 USB Bluetooth/Flash Disk User’s manual -1- Content 1. Introduction 1.1 USB Bluetooth/Flash Disk 1.2 What’s in the box? 1.3 Function 1.4 Specification 1.5 System requirements 2. Installation 2.1 Install “BlueManager” and “USB Bluetooth/Flash Disk” 3. Regarding manual of USB Bluetooth/Flash Disk USB Bluetooth/Flash Disk User’s manual -2- 1. Introduction 1.1 USB Bluetooth/Flash Disk Thank you for purchasing USB Bluetooth/Flash Disk that is the solution for the seamless integration of Bluetooth technology and portable mass storage into one device. It utilizes short-distance radio link technology, replaces the traditional cable connections to enable wireless connections between desktop and laptop computers, cellular phones, scanners, digital cameras, printers, and other devices. You can now easily transfer files between two computers, dial up to the Internet using the host computer’s modem or a cell phone, or even share a network connection without literally attaching your cables to a device. USB Bluetooth/Flash Disk is a portable USB hard drive used store and transport data safely and easily between computers through USB interface. Installation of the USB Bluetooth/Flash Disk is easy. This user’s guide will guide you through the process of making wireless connection between your devices. USB Bluetooth/Flash Disk User’s manual -3- 1.2 What’s in the box? Check if the following items are included in the package. If there are any items missing, please contact your dealer. ÿ Bluetooth USB adapter ÿ USB extension cable ÿ Use’s manual ÿ Driver CD 1.3 Function ÿ Automatic discovery another Bluetooth device’s resources and services. ÿ File transfer: Transfer file from one Bluetooth device to another. ÿ Wireless device synchronization: Exchange information among computers, mobile phones and PDAs. ÿ Dial-up networking: Access Internet wirelessly through a modem on another Bluetooth device or a cellular phone. ÿ Bluetooth Serial Port: Establishes a Bluetooth wireless connection between two devices. ÿ LAN Access: Allow Bluetooth-enabled devices to access the services of a LAN using Point-to-Point Protocol USB Bluetooth/Flash Disk User’s manual -4- ÿ Mass storage device: Store data to integrated Flash memory through USB interface. 1.4 Specification ÿ Compliant with the Bluetooth TM V1.1 specification, Class 2 ÿ Fully Bluetooth TM Version 1.1 qualified ÿ Powered by USB bus directly ÿ Full speed USB interface, compliant with USB 1.1 ÿ LED indicator when the device is in use. ÿ Built-in Antenna ÿ Frequency band: 2.4GHZ ISM band ÿ Maximum date rate: 1Mbps ÿ 10 meter working distance ÿ Integrated Flash memory (32MB~512MB) ÿ Read and Write Speed: Read: 1.1MB/S; Write: 700KB/S ÿ Support Windows98SE/2000/ME/XP operating system or higher USB Bluetooth/Flash Disk User’s manual -5- 1.5 System requirements ÿ IBM PC or compatible PC with USB port; ÿ Notebook or laptop； ÿ Windows 98/Me/2000/XP。 2. Installation (Attention: You need to install the BlueManager Software before plugging in the USB Bluetooth/Flash Disk) 2.1 Install “BlueManager” and “USB Bluetooth/Flash Disk” 1. Insert the driver CD and run “BlueManager.exe” then the following picture will show up on your desktop: USB Bluetooth/Flash Disk User’s manual -6- Fig-1 2. System will install software automatically; 3. In the dialog of “License Agreement”please click [Y es]; 4. In the dialog of “Choose Destination Location”, select directory of files and click [Next]; 5. In the dialog of“Select Program Folder”，click [Next]; During installation, some system prompts out warning message as below Fig-2. (Because Bluetooth is not a standard built-in device on most operation system yet. Please click “[Continue（C）] till pass authentication） USB Bluetooth/Flash Disk User’s manual -7- Fig-2 6. Then system will prompt to reboot computer. Please select [Yes, I want to restart my computer now..]，and finish to reboot computer. USB Bluetooth/Flash Disk User’s manual -8- Fig-3 7. After rebooting, system will run “Blue manager” automatically. 8. Then please insert “USB Bluetooth/Flash Disk” into USB port, and system will find new hardware and install its driver automatically (Attention： 1. If your system is Windows XP, please select [Install automatically (Recommend)(I)] from dialog of “Find New Hardware Wizard”；Click Next to install automatically. Refer to Fig-4） USB Bluetooth/Flash Disk User’s manual -9- Fig-4 2. If your system is Windows98, the system will find new mass storage device, please cancel it then run “ufddriver/setup. exe” in driver CD to install the mass storage device’s driver ) 9. After completed BlueManager installation. You will find LED of device will flash; There are series of Bluetooth virtual added in computer hardware; “Bluetooth LAN Connection Client” and “GPRS Bluetooth Connection” are created in network connection; Shortcut of “BlueManager” and “GPRS Bluetooth connection.” USB Bluetooth/Flash Disk User’s manual -10- 3. Regarding manual of USB Bluetooth/Flash Disk Application range of USB Bluetooth/Flash Disk includes: 1、 Use USB Bluetooth/Flash Disk to fulfill wireless connecting between PC and Bluetooth cell phone. 2、 Use USB Bluetooth/Flash Disk to fulfill wireless connecting between two PCs, exchanging data and sharing Internet and so on. 3、 Use USB Bluetooth/Flash Disk to fulfill wireless connecting with other Bluetooth devices, such as Bluetooth printer. Please read “Application Guide” in CD about operation of above functions. Regarding the connection and operation with other Bluetooth device, please refer to manual of other Bluetooth devices. USB Bluetooth/Flash Disk User’s manual -11- FCC INFORMATION The Federal Communication Commission Radio Frequency Interference Statement includes the following paragraph: The equipment has been tested and found to comply with the limits for a Class B Digital Device, pursuant to part 15 of the FC…

Text truncated - open the document above for the full version.

Applicant: Fu Kuang Hui Electronics Co., Ltd. (Shen-Zhen) FCC ID: P2DBTU9X

Applicant: Fu Kuang Hui Electronics Co., Ltd. (Shen-Zhen) FCC ID: P2DBTU9X (1) EUT top view (2) EUT bottom view

Applicant: Fu Kuang Hui Electronics Co., Ltd. (Shen-Zhen) FCC ID: P2DBTU9X Proposed Label Location on EUT EUT Bottom View/Proposed FCC ID Location FCC ID: P2DBTU9X

Applicant: Fu Kuang Hui Electronics Co., Ltd. (Shen-Zhen) FCC ID: P2DBTU9X (3) EUT inside whole view (4) Main board component side (5) Main board solder side

Applicant: Fu Kuang Hui Electronics Co., Ltd. (Shen-Zhen) FCC ID: P2DBTU9X Operational Description 1. Purpose: The purpose of this document is to describe key component operations on Bluetooth. The BTU** Series are the advanced USB Flash Disk (UFD) with Bluetooth communication system. ( UFD is a developed mobile storage device. It stores data in flash memory ICs. UFD can be re-used for 100,000 times and data retention for 10 years. Transfer rate is 15 times faster than floppy disk. The UFD is an easy-to- use, reliable, security mobile mass storage device. ) 2. Key components: ALPS ELECTRIC CO., LTD. Bluetooth Module: UGPZ2-109A; Alcor Micro Corp USB HUB: AU9254 and mass storage microprocessor AU6680; K9FXXXXUOM, SAMSUNG Flash Memory, Matsushita narrow-pitch 20 pin high reliability connectors 3. Operation Principle: UGPZ2-109A, Bluetooth Module contains CSR BC2-EXT (BC212013/BC212015), which has complete radio part and base band controller section (16bits RISC processor, ram and flash memory). Protocol software is already downloaded into integrated Flash memory and interfaces to HCI layer of upper layer protocol stack on an appropriate host system. It provides a fully compliant Bluetooth system for data and voice communications. USB flash disk function resort to mass storage micro processor AU6680 via USB HUB: AU9254 transmit data with PC Operation at 2.7 ~ 3.3V supply. Operation clock is provided by 12MHz oscillator. 4. Key Features: . Supports huge capacity (16MB/32MB/64MB/128MB/256MB) . USB1.0/1.1 compliant, supporting plug-and-play. . No auxiliary power supply necessary, powered by USB bus directly. . Built-in write protection switch protect data from delete and virus attack. . Read speed: 1.1 MB/S . Write speed: 700KB/s . Data can be preserved more than 10 years . Storage media: Flash Memory . Compact size . Two modules, UFD module and Bluetooth module combine the BTU* series products. . The Bluetooth module in this product is a standard Bluetooth System, which comply with Bluetooth Specification Version 1.1; . No driver necessary for UFD in Windows Me/2000/XP, Mac OS9, Linux Kernel 2.4x Operating System. . A special application software for Bluetooth system, which used to drive and manage the Bluetooth devices. . Supports “portable QQ” functions via a special application program (Optional). . Supports USB Flash Disk bootable function if the motherboard supports booting from USB devices (Optional item). 5. Electrical Specifications: Fully compliant with USB 1.1 specification and UHCI, OHCI standards Data transfer-rate: Read: 1.1 Megabytes per second approximately. Write: 700 Kilobytes per second approximately. Power Supply: UFD is powered by USB bus directly, the power should be within 4.75V, 500mA to 5.25V, 500mA. Fully compatible with Windows98 (A driver is required). Fully compatible with Windows Me, Windows2000, Windows XP, Linux kernel 2.4 and the driver is needless. Power consumption: less than 0.5Watt. 6. Physical Layer specifications: 7. Tx Specifications: 8. Rx Specifications:

55 44 33 22 11 D D C C B B A A Optionalcircuits , MAIN PCB SIDE MEM PCB SIDE To Bluetooth Module UFD(6680)+BLUETOOTH A BTU9X MAIN CIRCUIT B 12 Friday, May 16, 2003 TitleSize Document Number Rev Date: Sheet of SD7 UFD_D- ALE XTAL_I RE WE UFD_D+ Bluetooth_D- SD2SD4 CLE SD6 XTAL_O SD5 WE CLE SD4 GNDA Bluetooth_D- UFD_D- UFD_D+ PWR_H GND SD2 CE0 SD3 LED_BLT CE2 VCC5V XTAL1 XTAL1 XTAL_O ALE RB SD6 GNDAVCCA XTAL_I UFD_D+ VCC SD1CE3 VCC3.3 CE2 Bluetooth_D+ VCC CE1 VCC3.3 SD3 WP VDD GND CE1 UFD_D- SD0 RERB SD0SD5 PWR_H SD7CE3 GND_POWER GND SD1CE0 LED_BLT Bluetooth_D+ USB4_DM JP1JP4 USB4_DP JP2JP3 USB3_DM USB4_DP USB3_DMUSB3_DP USB3_DPUSB4_DM JP3JP1JP2JP4 VCC3.3 VCC3.3 VCC3.3 VDD VDD VCC VCCA VCC VCC3.3 VCC5V VDD VCC VCC5V VDD C171 uF R22 1.5K R315K R7 1K D1 EL-15-22 42 31 JP1 R5 47K C80.1UF Y112M L4 70 Ohm@100MHz_0805 R1 39 R1315K R24 39 Ohm JP2 R61.5K C21 1uF C15 39P R25 330 C90.1UF L122uH R10 39 R19 39 L5 30 Ohm@100M_0603 SW1 SW KEY-SPDT R2015K C1147P L2 30 Ohm@100M_0603 CN1USB 42315 GNDD-D+VCCSHIELD C1247P C60.1UF C1447P C16 0.1uF R1415K C19 0.1uF U1 AU9254 23645 1314 151617181920 89 101112 2128272625242322 71 USB2_DPUSB3_DMUSB4_DPUSB3_DPUSB4_DMDP1_PWRUPGANGPOWER DP1_OVRCUR SUSPEND DP2_OVRCUR EMPTY_PIN AGND/GNDO XTAL1 DP2_PWRUPBUS_PWRUPVCC5O/VCC5IKGND5O/GND5IKVCC3V XTAL2 USB1_DP USB1_DM USB_DP USB_DM DP3_OVRCURDP4_OVRCUR DP3_PWRUP DP4_PWRUPUSB2_DM C24.7UF C1347P R8 10K C30.1UF R91K R415K CN2 ARC Male_598.0100.210 13579 1113151719 2468101214161820 U3 6680_DICE 123456789 10111213141516171819202122 23242526272829303132333435363738394041424344 VCCAGNDAXTAL1XTAL2VCC2FMVCC5VVCCIORSTNXUSB_DPUSB_DMGNDIOGPO1XFMXWPFMXWRFMALEFMCLEFMXCHIP1FMXCHIP2FMXRDFMRDXBZYGPO5XRESERVED GPO4X FMXCHIP3FMXCHIP4 VCCK GNDK RESERVEDRESERVEDRESERVEDRESERVEDRESERVEDRESERVED GPO3X FMIO4FMIO5FMIO6FMIO7FMIO0FMIO1FMIO2FMIO3 GPO0XGPO2X C180.1UF C10 39P L3 30 Ohm@100M_0603 R18 0 Ohm C1 10UF C41UF R1515K C2010uF CN3 5P CON 12345 12345 R17 1M C22 1uF R12 39 R2115K R11 39 C50.1UF JP4 R2 39 U2 7S04 2 4 53 1 AY VGND NC C70.1UF R23 39 Ohm JP3 R1615K 55 44 33 22 11 D D C C B B A A UFD(6680)+BLUETOOTH A BTU9X MEM CIRCUIT B 22 Friday, May 16, 2003 TitleSize Document Number Rev Date: Sheet of RE CLE CE0 SD0 RB SD4 WE CLEWERB WP SD1 CLE SD5 SD6SD3 ALE SD4 SD5 RB SD3 CE2 ALE WE SD5 CE0 SD1 SD4 SD2 SD7 SD2 RE WP WP SD7 SD6 SD3 RE WPALE RE WE SD7SD0 WP SD4 CE3 SD5 SD5 SD1 ALE CLE SD7 SD4 SD2 SD6 SD0 RE CE3 SD6 SD0 RB CE1 SD3CLE SD1 ALE SD2 SD2 SD1 SD0 CE2 CE1 WERB SD7 SD3 SD6 VDD VDD VDD VDD VDD Default VDD VDD VDD VDD VDD VDD C230.1UF C28 0.1UF FLASHU4 123456789 101112131415161718192021222324 484746454443424140393837363534333231302928272625 N/CN/CN/CN/CN/CSER/BRECEN/CN/CVDDVSSN/CN/CCLEALEWEWPN/CN/CN/CN/CN/C N/CN/CN/CN/C I/O7I/O6I/O5I/O4 N/CN/CN/C VDD VSS N/CN/CN/C I/O3I/O2I/O1I/O0 N/CN/CN/CN/C C260.1UF FLASHU5 123456789 101112131415161718192021222324 484746454443424140393837363534333231302928272625 N/CN/CN/CN/CN/CSER/BRECEN/CN/CVDDVSSN/CN/CCLEALEWEWPN/CN/CN/CN/CN/C N/CN/CN/CN/C I/O7I/O6I/O5I/O4 N/CN/CN/C VDD VSS N/CN/CN/C I/O3I/O2I/O1I/O0 N/CN/CN/CN/C CN5 ARC Female 561.0630.210 13579 1113151719 2468101214161820 C31 0.1UF C30 0.1UF C250.1UF C29 0.1UF FLASHU6 123456789 101112131415161718192021222324 484746454443424140393837363534333231302928272625 N/CN/CN/CN/CN/CSER/BRECEN/CN/CVDDVSSN/CN/CCLEALEWEWPN/CN/CN/CN/CN/C N/CN/CN/CN/C I/O7I/O6I/O5I/O4 N/CN/CN/C VDD VSS N/CN/CN/C I/O3I/O2I/O1I/O0 N/CN/CN/CN/C FLASHU7 123456789 101112131415161718192021222324 484746454443424140393837363534333231302928272625 N/CN/CN/CN/CN/CSER/BRECEN/CN/CVDDVSSN/CN/CCLEALEWEWPN/CN/CN/CN/CN/C N/CN/CN/CN/C I/O7I/O6I/O5I/O4 N/CN/CN/C VDD VSS N/CN/CN/C I/O3I/O2I/O1I/O0 N/CN/CN/CN/C C240.1UF C270.1UF

The test report consists 39 pages in total. It may be duplicated completely for legal use with the allowance of the applicant. It shall not be reproduced except in full, without the written approval of Ke Mei Ou Laboratory Corporation. The test result in the report only applied to the tested sample. FCC TEST REPORT Under: FCC 15 Subpart C, Paragraph 15.247 Prepared For: Fu Kuang Hui Electronics Co., Ltd. (Shen-Zhen) The Second Industrial Park of Xia Village, Gongming Baoan District, Shenzhen city, Guangdong Province, China September 23, 2003 FCC ID: P2DBTU9X EUT: UFD + Bluetooth Model: BTU9X Report Type: Original Report Test Engineer: Peter Lin Test Date: August 26, 2003 Review By: Apollo Liu / Manager FEDERAL COMMUNICATIONS COMMISSION Registration Number: 125782 Ke Mei Ou Laboratory Co., Ltd. 7A, Jiaxiangge, Jiahuixincheng, No.3027, Shennan Rd., Futian, Shenzhen, Guangdong, P.R.China. Zip Code: 518033 Tel: + 86 755 83642690 Fax: + 86 755 83297077 www.kmolab.com Fu Kuang Hui Electronics Co., Ltd. (Shen-Zhen) FCC ID: P2DBTU9X FCC ID Report Report #: KSZ2003081402J Page 2 of 2 TABLE OF CONTENTS 1. General Information...........................................................................................................................................................4 1. 1 Notes...............................................................................................................................................................................4 1. 2 Testing Laboratory..........................................................................................................................................................4 1. 3 Details of Applicant........................................................................................................................................................4 1. 4 Application Details.........................................................................................................................................................4 1. 5 Test Item.........................................................................................................................................................................4 1. 6 Test Standards.................................................................................................................................................................5 2. Technical Test.......................................................................................................................................................................6 2. 1 Summary of Test Results................................................................................................................................................6 3. EUT Modifications..............................................................................................................................................................7 4. Technical Characteristics Test............................................................................................................................................8 4. 1 Conducted Emission Test................................................................................................................................................8 4.1.1 Test Equipment.............................................................................................................................................................8 4.1.2 Test Procedure..............................................................................................................................................................8 4.1.3 Test Setup.....................................................................................................................................................................8 4.1.4 Configuration of The EUT............................................................................................................................................9 4.1.5 EUT Operating Condition...........................................................................................................................................10 4.1.6 Conducted Power Line Emission Limits....................................................................................................................10 4.1.7 Conducted Power Line Test Result.............................................................................................................................10 4. 2 Radiated Emission Test.................................................................................................................................................12 4.2.1 Test Equipment...........................................................................................................................................................12 4.2.2 Test Procedure............................................................................................................................................................12 4.2.3 Radiated Test Setup....................................................................................................................................................12 4.2.4 Configuration of The EUT..........................................................................................................................................13 4.2.5 EUT Operating Condition...........................................................................................................................................13 4.2.6 Radiated Emission Limit............................................................................................................................................13 4.2.7 Radiated Emission Test Result....................................................................................................................................14 4. 3 Channel Separation Test...................................................................................................…

Text truncated - open the document above for the full version.

Applicant: Fu Kuang Hui Electronics Co., Ltd. (Shen-Zhen) FCC ID: P2DBTU9X Conducted emission test view Radiated emission test view
