SG800 Signal Amplifier Installation Manual Page 1 of 2 Copyright 2002, Seamless Group, Inc., All rights reserved. Made in North America Note: Before installing the SG800 Signal Amplifier, please read the entire contents of this manual. Parts List Item Qty Description 1 1 SG800 Inteligain TM Signal Amplifier 2 1 1.5 Meter (59”) RF Cable 3 1 2 Meter (78”) DC Power Cable 4 1 Connector Adapter FME Female to TNC Male 5 1 Connector Adapter FME Male to TNC Male 3A Fuse PHONEANTENNA 1 2 3 54 3A Fuse PHONEANTENNA 1 2 3 54 Tools and Other Materials Required Item Description 1 Electric drill (as required for signal amplifier mounting holes) 2 Screw driver 3 Qty 4 screws (length and type as required for signal amplifier mounting) 4 Wire cutters / strippers 5 Qty 2 wire connection insulators or insulating material (as required for DC power cable connection to 12V DC system) WARNINGS! ∇ Directly wired vehicle antennae, mounted a minimum distance of 50 cm (19.5”) away from any person, are recommended. ∇ Mounting a signal amplifier in the engine cavity or on the underside of the vehicle will void the manufacturer’s warranty. ∇ Subjecting the amplifier to voltages greater than 30 Volts DC will damage the amplifier and void the manufacturers warranty. ∇ Any vehicle with an electrical system of greater than 30 Volts DC should use a step-down voltage regulator to bring the voltage within the DC operating power range of the amplifier (10 to 30V dc). ∇ Under no circumstances should the amplifier be powered up without a properly connected 50 ohm 800 MHz cellular antenna or the amplifier may be damaged and the manufacturer’ warranty will be void. ∇ An antenna of not more than 5dBd gain shall be used with the amplifier or the manufacturer’s warranty will be void. ∇ Use of cellular amplifiers with antennae of higher gains is in violation of FCC regulations for which the offender will be fully liable. It is recommended that only certified automotive installation technicians install this product in a vehicle. Installation by any other person is at the risk of the vehicle owner and operator. Installation Selecting a Suitable Location To Mount The Signal Amplifier Locate a suitable place to mount and conceal the signal amplifier. Suggested mounting locations include: under the dashboard, under a seat, or in the trunk. For peak performance the signal amplifier should be mounted as close to the phone handset as SG800 Signal Amplifier Installation Manual Page 2 of 2 Copyright 2002, Seamless Group, Inc., All rights reserved. Made in North America possible. The amplifier’s location should be easily accessible and mounted away from moving parts, as well as excessive heat and moisture. Installation Cautions ∇ Use caution to avoid drilling through or near fuel lines or fuel tanks; brake lines; or electrical wiring. ∇ Do not mount the signal amplifier or its associated wiring in a location that may interfere with the safe operation of the vehicle. Installation Of The Signal Amplifier Signal Amplifier 1.5 M Cable Color/ Black Black (12 V DC) Antenna * 1 Antenna Cable * 1 * 1 Optional items must be purchased separately . Phone/Cradle or RF output device * 1 1 2 3 Signal Amplifier 1.5 M Cable Color/ Black Black (12 V DC) Antenna * 1 Antenna Cable * 1 * 1 Optional items must be purchased separately . Phone/Cradle or RF output device * 1 1 2 3 Typical Installation For Under The Seat Mounting 1. For safety, disconnect the vehicle’s negative “− −− −“ battery terminal to remove power from the vehicle. 2. Drill holes and mount the signal amplifier (ITEM 1) in the selected location. 3. Connect the coloured striped black wire of the supplied 2 Meter (78”) power cable (ITEM 3) for the signal amplifier to a positive connection on the vehicle’s electrical system. Choose a 10 to 30 Volt DC circuit that is: fuse protected; and ignition switched. (Often referred to as the “Accessory output”) 4. Attach the solid black wire of the supplied 2 Meter (78”) power cable (ITEM 3) to a vehicle electrical ground point. 5. Attach one end of the antenna cable* 1 to the antenna. The other end is connected to the cellular phone handset via a cradle or an RF output cable *1 to the signal amplifier’s ANTENNA output connector. Use the supplied FME to TNC adapters (ITEM 4 or 5) if necessary. 6. Connect the amplifier’s PHONE input connector to the cellular phone handset via a cradle or an RF output cable using the provided 1.5 Meter (59”) RF cable (ITEM 2) and adapter (ITEM 4 or 5) if necessary. 7. Reconnect the vehicle’s negative “− −− −“ Battery terminal. Limited Warranty Seamless Group Inc. warrants that this product is free from any defects in material or workmanship for a period of one year. If a defect in material or workmanship is found, Seamless Group Inc. agrees to repair or replace the product at its own discretion, free of charge to the original purchaser. Please return the product along with proof of purchase to the original authorized dealer. This warranty is null and void if the product has been modified, abused, tampered with, subjected to abnormal conditions, or transferred to someone other than the original purchaser. All brands and trademarks are the property of their respective owners. Designed and manufactured in North America

SG800 Signal Amplifier Installation Manual Page 1 of 1 Copyright 2002, Seamless Group, Inc., All rights reserved. Rev A D00000413 Made in North America Note: Before installing the SG800 Signal Amplifier, please read the entire contents of this manual. Parts List Item Qty Description 1 1 SG800 Inteligain TM Signal Amplifier 2 1 1.5 Meter (59”) RF Cable 3 1 2 Meter (78”) DC Power Cable 4 1 Connector Adapter FME Female to TNC Male 5 1 Connector Adapter FME Male to TNC Male 3A Fuse PHONEANTENNA 1 2 3 54 3A Fuse PHONEANTENNA 1 2 3 54 Tools and Other Materials Required Item Description 1 Electric drill (as required for signal amplifier mounting holes) 2 Screw driver 3 Qty 4 screws (length and type as required for signal amplifier mounting) 4 Wire cutters / strippers 5 Qty 2 wire connection insulators or insulating material (as required for DC power cable connection to 12V DC system) WARNINGS!
An antenna of not more than 5dBd gain shall be used with the amplifier or the manufacturer’s warranty will be void. Use of cellular amplifiers with antennae of higher gains is in violation of FCC regulations for which the offender will be fully liable.
Ensure that the external antenna connected to the SG800 amplifier is mounted at least 0.5 meter away from any seating position in the automobile to ensure that the FCC Maximum Possible Exposure (MPE) guidelines are satisfied. At a distance of 0.5 meter from the externally mounted 5dBd antenna connected to the SG800, the uncontrolled MPE power density will be 0.33mW/cm 2 (FCC guideline 0.55mW/ cm 2 ).
Mounting a signal amplifier in the engine cavity or on the underside of the vehicle will void the manufacturer’s warranty.
Subjecting the amplifier to voltages greater than 30 Volts DC will damage the amplifier and void the manufacturers warranty.
Any vehicle with an electrical system of greater than 30 Volts DC should use a step-down voltage regulator to bring the voltage within the DC operating power range of the amplifier (10 to 30V dc).
Under no circumstances should the amplifier be powered up without a properly connected 50 ohm 800 MHz cellular antenna or the amplifier may be damaged and the manufacturer’ warranty will be void. It is recommended that only certified automotive installation technicians install this product in a vehicle. Installation by any other person is at the risk of the vehicle owner and operator. Installation Selecting a Suitable Location To Mount The Signal Amplifier Locate a suitable place to mount and conceal the signal amplifier. Suggested mounting locations include: under the dashboard, under a seat, or in the trunk. For peak performance the signal amplifier should be mounted as close to the phone handset as possible. The amplifier’s location should be easily accessible and mounted away from moving parts, as well as excessive heat and moisture. SG800 Signal Amplifier Installation Manual Page 2 of 2 Copyright 2002, Seamless Group, Inc., All rights reserved. Rev A D00000413 Made in North America Installation Cautions
Use caution to avoid drilling through or near fuel lines or fuel tanks; brake lines; or electrical wiring.
Do not mount the signal amplifier or its associated wiring in a location that may interfere with the safe operation of the vehicle. Installation Of The Signal Amplifier Signal Amplifier 1.5 M Cable Color/ Black Black (12 V DC) Antenna * 1 Antenna Cable * 1 * 1 Optional items must be purchased separately . Phone/Cradle or RF output device * 1 1 2 3 Signal Amplifier 1.5 M Cable Color/ Black Black (12 V DC) Antenna * 1 Antenna Cable * 1 * 1 Optional items must be purchased separately . Phone/Cradle or RF output device * 1 1 2 3 Typical Installation For Under The Seat Mounting 1. For safety, disconnect the vehicle’s negative “
“ battery terminal to remove power from the vehicle. 2. Drill holes and mount the signal amplifier (ITEM 1) in the selected location. 3. Connect the coloured striped black wire of the supplied 2 Meter (78”) power cable (ITEM 3) for the signal amplifier to a positive connection on the vehicle’s electrical system. Choose a 10 to 30 Volt DC circuit that is: fuse protected; and ignition switched. (Often referred to as the “Accessory output”) 4. Attach the solid black wire of the supplied 2 Meter (78”) power cable (ITEM 3) to a vehicle electrical ground point. 5. Attach one end of the antenna cable* 1 to the antenna. The other end is connected to the cellular phone handset via a cradle or an RF output cable *1 to the signal amplifier’s ANTENNA output connector. Use the supplied FME to TNC adapters (ITEM 4 or 5) if necessary. 6. Connect the amplifier’s PHONE input connector to the cellular phone handset via a cradle or an RF output cable using the provided 1.5 Meter (59”) RF cable (ITEM 2) and adapter (ITEM 4 or 5) if necessary. 7. Reconnect the vehicle’s negative “
“ Battery terminal. Limited Warranty Seamless Group Inc. warrants that this product is free from any defects in material or workmanship for a period of one year. If a defect in material or workmanship is found, Seamless Group Inc. agrees to repair or replace the product at its own discretion, free of charge to the original purchaser. Please return the product along with proof of purchase to the original authorized dealer. This warranty is null and void if the product has been modified, abused, tampered with, subjected to abnormal conditions, or transferred to someone other than the original purchaser. All brands and trademarks are the property of their respective owners. Designed and manufactured in North America

_______________________________________________________________________ Confidential Page 1 February 21, 2002 5-55 Henlow Bay, Winnipeg, Manitoba, R3Y 1G4 Phone: 204-489-3200 Fax: 204-489-8300 February 21, 2002 Exhibit of Confidentiality To Whom It May Concern: Arrista Technologies would like the following submitted exhibits treated as confidential material: 1. Amplifier Schematic 2. Block Diagram Amplifier 3. Amplifier Parts Listing 4. Internal Photos of the Amplifier 5. Operational Description The amplifier design, specifically, the gain control circuitry is of novel design and a US patent has been filed on it. As there is no other amplifier design that incorporates the gain control function the way the SG800 does, we believe that we have a competitive advantage over competing designs out in the market place. Roman Wroczynski Director of Product Development Arrista Technologies Inc Tel: (204) 489-3200 Fax: (204) 489-8300 [email protected]

_______________________________________________________________________ Confidential Page 1 February 25, 2002 5-55 Henlow Bay, Winnipeg, Manitoba, R3Y 1G4 Phone: 204-489-3200 Fax: 204-489-8300 February 25, 2002 Exhibit of Confidentiality To Whom It May Concern: Arrista Technologies would like the following submitted exhibits treated as confidential material: 1. Amplifier Schematic 2. Block Diagram Amplifier 3. Amplifier Parts Listing 4. Internal Ph otos of the Amplifier Amendment 1 5. Operational Description The amplifier design, specifically, the gain control circuitry is of novel design and a US patent has been filed on it. As there is no other amplifier design that incorporates the gain control function the way the SG800 does, we believe that we have a competitive advantage over competing designs out in the market place. Roman Wroczynski Director of Product Development Arrista Technologies Inc Tel: (204) 489-3200 Fax: (204) 489-8300 [email protected]

Copyright  2002 Arrista Technologies Inc. This document contains confidential information. Appendix SG800 Panel Pictures Arrista Technologies Inc. 5-55 Henlow Bay, Winnipeg, MB, CA Copyright  2002 Arrista Technologies Inc. This document contains confidential information. Figure 1. Antenna Side Panel Copyright  2002 Arrista Technologies Inc. This document contains confidential information. Figure 2. Cell Phone Side Panel

Caution: This product is designed to be used with an external antenna with maximum gain of 5 dBd or less. The use of an antenna of higher gain is strictly prohibited and violates FCC regulations. 10 point Helvetica, Bold 8 point Helvetica 1.5" 2.5" FCC ID: P35ARR-800-P207 Made In Canada 0.125" 0.125" 0.125"0.125" 10 point Helvetica 8 point HelveticaPatent Pending 8 point Helvetica 0.5" Specifications Label Stock: 3M Tamper-Indicating Label Material for Thermal Transfer Printing 7866 Facestock: 2.0 mil Gloss White Polyester Destruct Pattern: “VOID” Adhesive: 1.0 mil #300 “Hi-Strength” Acrylic Liner: 3.2 mil 55# Densified Kraft Company: Arrista Technologies Inc. Component Name: Warning Label Component Number: C00000275 Revision: B Date: January 3, 2001

________________________________________________________________________ Confidential Page 1 February 15, 2002 5-55 Henlow Bay, Winnipeg, Manitoba R3Y 1G4 Phone: 204-489-3200 Fax: 204-489-8300 SG800 Internal Photos Figure 1. Front Side View ________________________________________________________________________ Confidential Page 2 February 15, 2002 5-55 Henlow Bay, Winnipeg, Manitoba R3Y 1G4 Phone: 204-489-3200 Fax: 204-489-8300 Figure 2. PCB Bottom View ________________________________________________________________________ Confidential Page 3 February 15, 2002 5-55 Henlow Bay, Winnipeg, Manitoba R3Y 1G4 Phone: 204-489-3200 Fax: 204-489-8300 Figure 3. PCB Top View

________________________________________________________________________ Confidential Page 1 February 15, 2002 5-55 Henlow Bay, Winnipeg, Manitoba R3Y 1G4 Phone: 204-489-3200 Fax: 204-489-8300 RF Human Exposure Analysis Users may be concerned with the power levels achieved using booster amplifiers in-line with the handset, cradle and automobile antenna. Global standards organizations (including the FCC) have dictated that the maximum mean power flux density exposure level in the 30 MHz to 300 GHz frequency range shall not be above 10 W/m 2 or 1 mW/cm 2 . The far field on-axis power flux density (W/m 2 ) is calculated using the following formula: S = G P T / 4πR 2 , Where: G = Numerical gain of the antenna P T = Power delivered to the antenna in watts R = Distance from the antenna in meters The following table shows the maximum output power of the booster amplifier combined with an antenna with 5dBd gain. This is the maximum antenna gain permissible as documented in the user/installation manual. The resulting radiated power density is compared to MPE limits for both uncontrolled and controlled environments. ________________________________________________________________________ Confidential Page 2 February 15, 2002 5-55 Henlow Bay, Winnipeg, Manitoba R3Y 1G4 Phone: 204-489-3200 Fax: 204-489-8300 Table 1. MPE Calculations Output power of the amplifier: 2W maximum (1.3W +/-0.3W specified by manufacturer) Antenna Gain: Maximum antenna gain allowed as described in user/installation manual. 5dBd Operational Frequency: 824-849MHz Minimum distance (Controlled): From radiating source for personnel aware of radiofrequency equipment and who are able to limit their exposure time. (Installation Technicians) 0.5m Antenna mounted on vehicle exterior Minimum distance (Uncontrolled): From radiating source for personnel unaware of radiofrequency equipment and who are not able to limit their exposure time. (General Public) 0.5m Antenna mounted on vehicle exterior Estimated RF Power Density: 0.33mW/cm 2 Maximum Permissible Exposure (MPE): Controlled 6 min avg exposure 2.75mW/cm 2 Uncontrolled 30 min avg exposure 0.55mW/ cm 2 Complies with MPE Limits Yes Yes
