P5FSPC936Atomic Wall Clock with Wireless Indoor / Outdoor Temperature

Instructions & Warranty Thank you for your purchase of this quality clock. The utmost care has gone into the design and manufacture of your clock. Please read these instructions and store them in a safe place for future reference. The receiver unit has a clear, easy-to-read display that shows indoor temperature and humidity, outdoor temperature, time, month, date, day. The remote sensor transmits the outdoor temperature. To receive the outdoor temperature, place the sensor anywhere within 30 meters; the 433.92MHz technology means no wire installation is required. The Atomic Clock will always be accurate to within one second as it receives daily WWVB updates. Daylight Saving Time also automatically updates so there is no need to re-set the clock manually! IMPORTANT: If the Atomic Clock does not receive the WWVB signal immediately, wait overnight and it will be set in the morning. The clock has a built in receiver that automatically synchronizes itself with the WWVB radio signal broadcast by the US Government’s National Institute of Standards & Technology (NIST) in Fort Collins, Colorado. FEATURES: Atomic Clock 1. CLOCK DISPLAY: - Displays time in hours and minutes; calendar display of day, month and year; indoor temperature and humidity; outdoor temperature; signal strength indicator; daylight saving (DST); and time zone. 2. Set BUTTON: - In TIME mode, press and hold the SET button to enter the time setting mode. - Press the SET button to confirm the setting and enter the next setting. 3. Channel BUTTON: - In the normal mode, press the button to switch the between channel 1, 2 and 3 to receive the 433.92MHz signal; press and hold the button for 3 seconds will pairing with the outdoor remote sensor. 4. + BUTTON: - In the TIME setting mode, press it to increase the setting values. Hold the button for 3 seconds, the display will change rapidly. 5. -/wave BUTTON: - In the TIME setting mode, press the button to decrease the setting values. Hold the button for 3 seconds, the display will change rapidly. - In the normal mode, press and hold the button for 3 seconds for receive the RCC signal immediately. - During the RCC receiving period, press the button again to stop the RCC reception. 6. 12/24 BUTTON: - In normal mode, press the button to switch 12/24 time display format. 7. °C/°F BUTTON: - In normal mode, press the button to switch temperature unit °C/°F. DST 1 2 4 6 3 5 7 8 9 10 Set + 12/24 Channel -/wave °C/°F Reset 8. Reset BUTTON: - In case of malfunction, press RESET button to reset all values to default values. 9. WALL MOUNT 10. BATTERY COMPARTMENT AND DOOR: - Use 2 AA size batteries. Remote Transmitter 1. LED INDICATOR: - LED Flashes when the remote unit transmits a reading 2. CHANNEL SLIDE SWITCH: - Assign the transmitter to channel 1, 2 or 3 to receive 433.92MHz signal 3. RESET BUTTON: - Press it to restart the transmitter and return all values to default values. 4. BATTERY COMPARTMENT: - Use 2 AA Size batteries. 5. BATTERY DOOR 6. WALL MOUNT 7. TABLE STAND SETTING UP THE TRANSMITTER: 1. Remove the battery door and insert 2 AA batteries into the battery compartment and follow the polarities marked. 2. Slide the switch to Channel 1. Press the RESET button to set the transmitter. 3. Press the CHANNEL button at the back of the clock to set channel 1. 4. Lock the transmitter battery door with the screw. 5. Place the units away from metal objects and electrical appliances to minimize interference. Position the receiver within the effective transmission range 30 meters in usual circumstances. 6. If Channel 1 signal is not received properly, change the transmitter slide button to Channel 2 or 3. Press CHANNEL button of the clock to 2 or 3 respectively. Press and hold the CHANNEL button for three seconds. The unit will start to find the new channel. NOTE: 1. To receive the transmitter signal, the channels of receiver and transmitter must match each other. 2. Once the channel is assigned to transmitter, you can only change it by removing the batteries or resetting the unit. SETTING UP THE ATOMIC CLOCK: 1. Remove the battery door from the back of the weather station and insert 2 AA batteries. Insert them according to the marked polarity. 2. Replace the battery door. 3. Press the RESET button on the back of the clock to set and synchronize the transmitter automatically. SIGNAL STRENGTH INDICATOR: The signal indicator displays signal strength in 4 levels. Wave segment flashing means time signals are being received. NOTE: 1. The unit will automatically search for the time signal at 2:00 (3:00, 4:00, 5:00,6:00 is also available if the signal was not received at 2:00) 2. Closed area such as airport, basement, tower block or factory is not recommended. SPC936 SUGGESTION: Make sure you read the instructions before operating this clock. We have developed this sophisticated instrument for the best reception performance; however, the signal transmitted from USA Atomic Clock transmitter will be affected in certain situations. We advise you to note the following instructions: 1. It is strongly recommended to start this clock at night and let the clock receive the signal automatically past midnight. 2. Always place the unit away from interfering sources such as TV set, computer, etc. 3. Avoid placing the unit on or next to metal plates. 4. Areas with access to windows is recommended for better reception. 5. Do not start reception in moving articles such as vehicles or trains. DAYLIGHT SAVING TIME (DST): The clock has programmed to automatically switch when the daylight saving time is in effect. Your clock will show DST during the summer time if you turn on the DST. TIME ZONE SETTING: The default time zone is PACIFIC. If your location is not in the Pacific, set the time zone by pressing -/wave button to change the Pacific Time/ Mountain Time/ Central Time/ Eastern Time zone in the normal time mode and will disappear after setting. TIME AND CALENDAR SETTING: Time and calendar can be set manually. As soon as…

Text truncated - open the document above for the full version.

1 Photographs - EUT Constructional Details Test Model No.: SPC936

Size: 29 x 27mm FCC ID: P5FSPC936 FCC ID: P5FSPC936

1 Photographs - EUT Constructional Details Test Model No.: SPC936

SGS-CSTC Standards Technical Services Ltd. No. 1 Workshop, M-10, Middle section, Science & Technology Park, Nanshan District, Shenzhen, Guangdong, China 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 Email: [email protected] Report No.: SZEM120800438401 Page: 1 of 19 Authorized Signature: Jack Zhang EMC Laboratory Manager The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. ′′This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.′′ 1 Cover Page FCC REPORT Application No.: SZEM1208004384RF Applicant: Digital Gallery Global Limited Manufacturer: Digital Gallery Global Limited Product Name: Atomic Wall Clock with Wireless Indoor / Outdoor Temperature Model No.(EUT): SPC936 FCC ID: P5FSPC936 Standards: 47 CFR Part 15, Subpart C (2011) Date of Receipt: 2012-08-03 Date of Test: 2012-08-09 to 2012-08-15 Date of Issue: 2012-08-22 Test Result: PASS * . * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Ltd. Report No.: SZEM120800438401 Page: 2 of 19 “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only.” 2 Test Summary Test Item Test Requirement Test method Result Antenna Requirement 47 CFR Part 15, Subpart C Section 15.203 ANSI C63.10(2009) PASS Field Strength of the Fundamental Signal 47 CFR Part 15, Subpart C Section 15.231 (e) ANSI C63.10(2009) PASS Spurious Emissions 47 CFR Part 15, Subpart C Section 15.231 (e)/15.209 ANSI C63.10(2009) PASS 20dB Bandwidth 47 CFR Part 15, Subpart C Section 15.231 (c) ANSI C63.10(2009) PASS Dwell Time 47 CFR Part 15, Subpart C Section 15.231 (e) ANSI C63.10(2009) PASS SGS-CSTC Standards Technical Services Ltd. Report No.: SZEM120800438401 Page: 3 of 19 “This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the s…

Text truncated - open the document above for the full version.

1 Photographs - EUT Test Setup (Test Model No.: SPC936) 1.1 Radiated Emission
