P7KDDR4100DIGITAL VOICE RECORDER

Diasonic Technology Co Ltd

Click to zoom

Application Details

Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Date of Grant: Jan 06, 2005
Application Purpose: Original Equipment
Date of Application: Jan 06, 2005
Equipment Note: DIGITAL VOICE RECORDER
Company: Diasonic Technology Co Ltd
Country: South Korea

Documents & Files

Select a file to view

Users Manual

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Cover Letter(s)

#321-43, Suksu-dong, Manam-ku, Anyang-city, Kyunggi do, KOREA 430-040 Dec 20, 2004 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : DIASONIC TECHNOLGY CO.,LTD. FCC ID : P7KDDR4100 Request for Confidentiality Gentlemen: In accord ance with 0.459 of CFR 47, Diasonic Technology Co., Ltd. hereby requests confidentiality of the Block diagram, Schematics, Parts list and Operational Description of the attached test report. These documents contain detailed system and equipment description and related information about the product which Diasonic Technology Co., Ltd. considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Diasonic Technology Co., Ltd. considers that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Jin Geun Moon R&D Manager

External Photos

ID Label/Location Info

FCC ID: P7KDDR4100 FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase (SEE NEXT PAGE) FCC ID: P7KDDR4100 APPENDIX - 1 FCC ID: P7KDDR4100 Model No.: DDR-4100 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Internal Photos

Test Report

DEMC#DR50110412P FCC ID: P7KDDR4100 Copyright ○ c 2004, DIGITAL EMC Co., Ltd. Page 1 of 18 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 Tel: +82-31-321-2664 Fax: +82-31-321-1664 http://www.digitalemc.com CERTIFICATE OF COMPLIANCE FCC Part 15B Certification Dates of Tests: November 24~27, 2004 Test Report S/N:DR50110412P Test Site : DIGITAL EMC CO., LTD. FCC ID. APPLICANT FCC Classification :Part 15 Class B Computing Device Peripheral Device name :Digital Voice Recorder Manufacturer : Diasonic Technology Co., Ltd. #321-43, Suksu-dong, Manan-ku, Anyang-city, Kyungki-do, Korea Model name(Brand Name) : DDR-4100(Voice Bank) Add Model Name(Brand Name) : RIR-500H(Talk Master II), RIR-500S(Talk Master II), PRY M04 LX (PoGo), PRY M06 LX(PoGo), PRY M08 LX (PoGo) Test Device Serial number : Identical prototype FCC Rule Part(s) : FCC Part 15 Subpart B; ANSI C-63.4-2001 Data of issue : December 27, 2004 I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. P7KDDR4100 Diasonic Technology Co., Ltd. DEMC#DR50110412P FCC ID: P7KDDR4100 Copyright ○ c 2004, DIGITAL EMC Co., Ltd. Page 2 of 18 TABLE OF CONTENTS 1. GENERAL INFORMATION’S -------------------------------------------------------------------------- 2. INFORMATION’S ABOUT TEST ITEM ------------------------------------------------------------- 3. TEST REPORT --------------------------------------------------------------------------------------------- 3.1 SUMMARY OF TESTS ------------------------------------------------------------------------------ 3.2 TRANSMITTER REQUIREMENTS --------------------------------------------------------------- 3.2.1 RADIATED EMISSION ------------------------------------------------------------------------ 3.2.2 CONDUCTED EMISSION --------------------------------------------------------------------- ANNEX TEST EQUIPMENT USED FOR TESTS --------------------------------------------------- 3 4 5 5 6 6 9 16 DEMC#DR50110412P FCC ID: P7KDDR4100 Copyright ○ c 2004, DIGITAL EMC Co., Ltd. Page 3 of 18 1. General information’s This report contains the result of tests performed by: DIGITAL EMC CO., LTD. Address : 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 http://www.digitalemc.com E-mail : [email protected] Tel: +82-31-321-2664 Fax: +82-31-321-1664 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. This laboratory is accredited by NVLAP for NVLAP Lab. Code : 200559-0. Test operator: engineer December 29, 2004 Seung-Bum, Cho Data Name Signature Report Reviewed By: manager December 29, 2004 Sang-Uk,Han Data Name Signature Ordering party: Company name : Diasonic Technology Co., Ltd. Address : #321-43, Suksu-dong, Manan-ku, City/town : Anyang-city, Kyungki-do Country : Korea. Zip code : 430-040 Date of order : November 20, 2004 Att. : Mr. Jin-Geun, Moon DEMC#DR50110412P FCC ID: P7KDDR4100 Copyright ○ c 2004, DIGITAL EMC Co., Ltd. Page 4 of 18 2. Information’s about test item P7KDDR4100 2.1 Equipment information Kind of Equipment Digital Voice Recorder Model Number(Brand Name) DDR-4100(Voice Bank) Add Model Number (Brand Name) RIR-500H(Talk Master II), RIR-500S(Talk Master II), PRY M04 LX (PoGo), PRY M06 LX(PoGo), PRY M08 LX (PoGo) Serial No. None Memory Size 64M/ 128M/ 256M/512MB/1GB Type of Sample Tested Pre-Production Rating Power Supply -Adaptor(SR-0550U) Manufacture : SEORIM ELECTRONICS CO.,LTD INPUT: AC120V, 60Hz OUTPUT:DC5V / 550mA - Battery : Rechargeable Li-polymer cell 3.7V 1000mA High Frequency 32.768KHz Tested Power Supply 1 Phase 120Vac, 60Hz 2.2 Ancillary Equipment Equipment Model No. Serial No. Manufacturer PC Y8Y 311KI19443 LG Monitor CT-150 R20110001B COMTEC Printer 2225C 3245S12493 H.P Keyboard SEM-DT35 2209CPXAA SAMSUNG Mouse SMOP5000WX 0401059135 SAMSUNG Joystick J-ZA10 YED21700090 LOGITECH 2.3 EMI Suppression Device(s)/Modifications None DEMC#DR50110412P FCC ID: P7KDDR4100 Copyright ○ c 2004, DIGITAL EMC Co., Ltd. Page 5 of 18 3. Test Report 3.1 Summary of tests FCC Part Section(s) Parameter Status (note 1) Transmitter requirements 15.109 Radiated Emission C 15.107 Conducted Emissions C Note 1: C= Complies NC=Not Complies NT=Not Tested NA=Not Applicable The sample was tested according to the following specification: FCC Parts 15B; ANSI C-63.4-2001 DEMC#DR50110412P FCC ID: P7KDDR4100 Copyright ○ c 2004, DIGITAL EMC Co., Ltd. Page 6 of 18 3.2 Transmitter requirements 3.2.1 Radiated Emission Procedure: The EUT was placed on a 0.8m high wooden table inside a shielded enclosure. An antenna was placed near the EUT and measurements of frequencies and amplitudes of field strengths were recorded for reference during final measurements. For final radiated testing, measurements were performed in a OATS. Measurements were performed with the EUT oriented in 3 orthogonal axis and rotated 360 degrees to determine worst-case orientation for maximum emissions. The spectrum analyzer is set to: Frequency Range = 27 MHz ~ 10 th harmonic. RBW = 120 kHz ( 30MHz ~ 1 GHz) = 1 MHz (1 GHz ~ 10 th harmonic ) VBW ≥ RBW Trace = max hold Detector function = peak / Quasi-peak / average Sweep = auto Measurement Result: Complies - Refer to the Next page Minimum Standard: FCC Part 15.109 Frequency (MHz) Limit (uV/m) @ 3m 30 ~ 88 100 ** 88 ~ 216 150 ** 216 ~ 960 200 ** Above 960 500 TEST EQUIPMENT USED: 02, 22, 30, 31, 33, 34, 39, 40, 41, 47, 49 DEMC#DR50110412P FCC ID: P7KDDR4100 Copyright ○ c 2004, DIGITAL EMC Co., Ltd. Page 7 of 18 Radiated Emissions Measurement Data : Remark: the other emission is less than 30dB. Test mode : Play Mode DEMC#DR50110412P FCC ID: P7KDDR4100 Copyright ○ c 2004, DIGITAL EMC Co., Ltd. Page 8 of 18 Radiated Emissions Measur…

Text truncated - open the document above for the full version.

Test Setup Photos
