P7KDDR6000RDigital Voice Recorder

- 1 - DIGITAL Voice RECORDER & AUDIO PLAYER FM Radio DDR-6000R User Manual Thank you for purchasing Diasonic DDR-6000R, a digital voice recorder and audio player. Please read this manual before using the product. It is recommended to keep this manual near the product for convenient use. 그림 추가 (제품 빗면 그림) - 2 - INFORMATION TO THE USER Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Modifications not expressly approved by the manufacturer could void the user's authority to operated the equipment under FCC rules. This device complies with Part 15 of the FCC Results. Operation is subject to the following two conditions: 1 This Device may not cause harmful interface, and 2 This device must accept any interference received, including interference that may cause undesired operation. Preface Thank you for purchasing DDR-6000R manufactured by Diasonic Technology. Please read this manual before using the product. Store this manual in a separate place as this manual contains important information for the operation of the product. In case the user loses the manual, Diasonic Technology does not separately provide a manual. All manuals are provided with the product. Notes ● Do not repair, disassemble, or remodel the product. ● Incorrect use of the product by the user or a third party or static electricity or electric shock loaded on the product may cause loss of or change in the data saved in the product during repair services or replacement of the battery. ● DIASONIC Technology is not responsible for damage caused by change or loss of the data in the product. ● Do not heat up or short the main body or the battery. ● Do not put the battery on a hot item or disassemble the battery in a high-temperature place. Toxic contents of the battery may harm user’s eyes or skin. ● In case the contents of the battery leaks and is exposed to the user, wash the exposed body part - 3 - with clean water and see the doctor. ● Do not soak the device in water or leave it in a humid place. ● Contents of the user manual are subject to change without prior notice for performance improvement. ● Using the earphones for a long time may compromise user’s hearing ability. Copyrights ● DIASONIC Technology has all copyrights of this user manual. Reproduction, distribution, and commercial use of a part of or the entire user manual without prior consent of DIASONIC Technology are strictly prohibited by laws. All information contained in this manual has been carefully studied and written and is subject to change without prior notice for functional and performance improvement. DIASONIC Technology will not take any responsibility for issues arising due to differences between the product and information contained in the user manual. ● Use of MP3 files is limited to the personal purposes not including commercial or service purposes. Servicing or providing MP3 files for commercial purposes will be against the copyright act of Korea. ● Reproduction of files is prohibited for other than personal purposes by law. - 4 - Table of Contents - 5 - Safety Notes ● Do not store the device in any place with following conditions: - High temperature (60 or higher)°C - Exposure to the direct sun rays or a heating device - Inside the car with closed windows (especially, in the summer) - Humid place such as the bathroom ● When removing dust, use soft cloth. Do not use liquid agent (such as thinner or benzene) or wet cloth. ● Do not place a debit card or a bus pass near the speakers. The magnetic interference may occur, which will damage the card. ● Do not place the device near a magnet. The speakers may not function. ● Diasonic Technology is not responsible for any damage caused by the use of this device or damage claim made by a third party. ● Diasonic Technology is not responsible for the loss of data caused by other actions than repair services by Diasonic Technology personnel. ● Do not repair, disassemble, or remodel the device. ● Do not use the product in a place where use of electronic devices is prohibited. ● Do not use this device while driving. ● Do not heat up or short the main body or the battery. ● When using an auxiliary device, leave a gap between the auxiliary device and the main device. ● Incorrect use of the product by the user or a third party or static electricity or electric shock loaded on the product may cause loss of or change in the data saved in the product during repair services or replacement of the battery. - 6 - Features and Characteristics Diasonic Digital Voice Recorder is a next-generation portable digital recorder equipped with the state-of-the-art technologies. With this digital voice recorder, the user can record and play voice with the best quality in various recording ways – SHQ, HQ, and SP. The device supports various playing methods (including speakers and earphones) as well as diverse file formats including MP3 and WMA. The device can also receive and record FM radio broadcasting. ● Sophisticated, Durable Design So…

Text truncated - open the document above for the full version.

#321-43, Suksu-dong, Manan-gu, Anyang-City, Kyungki-do, Korea July 29, 2006 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : DIASONIC TECHNOLOGY CO., LTD. FCC ID : P7KDDR6000R Request for Confidentiality Gentlemen: In accordance with 0.459 of CFR 47, DIASONIC TECHNOLOGY CO., LTD. hereby requests confidentiality of the block diagram and brief circuit description. These documents contain detailed system and equipment description and related information about the product which DIASONIC TECHNOLOGY CO., LTD. considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, DIASONIC TECHNOLOGY CO., LTD. considers that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Jin-Geun, Moon / General Manager

FCC ID: P7KDDR6000R Copyright Ⓒ 2006, DIGITAL EMC Co., Ltd. View 1 FCC ID: P7KDDR6000R Copyright Ⓒ 2006, DIGITAL EMC Co., Ltd. View 2

FCC ID: P7KDDR6000R FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase (SEE NEXT PAGE) FCC ID: P7KDDR6000R APPENDIX - 1 FCC ID: P7KDDR6000R

FCC ID: P7KDDR6000R Copyright ○ Ⓒ 2006, DIGITAL EMC Co., Ltd. View 1 FCC ID: P7KDDR6000R Copyright ○ Ⓒ 2006, DIGITAL EMC Co., Ltd. View 2

DEMC#DR50110606N FCC ID: P7KDDR6000R Copyright c 2006, DIGITAL EMC Co., Ltd. Page 1 of 14 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 Tel: +82-31-321-2664 Fax: +82-31-321-1664 http://www.digitalemc.com CERTIFICATE OF COMPLIANCE FCC Part 15B Certification Dates of Tests: June 14 ~ 26, 2006 Test Report S/N:DR50110606N Test Site : DIGITAL EMC CO., LTD. FCC ID. APPLICANT FCC Classification :Part 15 Class B Computing Device Peripheral Device name :Digital Voice Recorder Manufacturer :Diasonic Technology Co., Ltd. #321-43, Suksu-dong, Manan-ku, Anyang-city, Kyungki-do, Korea. Model name(Brand Name) :DDR-6000R (Voice Bank) Test Device Serial number :Identical prototype FCC Rule Part(s) :FCC Part 15 Subpart B; ANSI C 63.4-2003 Data of issue :June 27, 2006 I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. P7KDDR6000R Diasonic Technology Co., Ltd. DEMC#DR50110606N FCC ID: P7KDDR6000R Copyright c 2006, DIGITAL EMC Co., Ltd. Page 2 of 14 TABLE OF CONTENTS 1. GENERAL INFORMATIONS -------------------------------------------------------------------------- 2. INFORMATIONS ABOUT TEST ITEM ------------------------------------------------------------- 3. TEST REPORT --------------------------------------------------------------------------------------------- 3.1 SUMMARY OF TESTS ------------------------------------------------------------------------------ 3.2 TRANSMITTER REQUIREMENTS --------------------------------------------------------------- 3.2.1 RADIATED EMISSION ------------------------------------------------------------------------ 3.2.2 CONDUCTED EMISSION --------------------------------------------------------------------- APPENDIX TEST EQUIPMENT USED FOR TESTS ----------------------------------------------- 3 4 5 5 6 6 9 13 DEMC#DR50110606N FCC ID: P7KDDR6000R Copyright c 2006, DIGITAL EMC Co., Ltd. Page 3 of 14 1. General Informations This report contains the result of tests performed by: DIGITAL EMC CO., LTD. Address : 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 http://www.digitalemc.com E-mail : [email protected] Tel: +82-31-321-2664 Fax: +82-31-321-1664 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. This laboratory is accredited by NVLAP for NVLAP Lab. Code : 200559-0. Test operator: Assistant Manager June 27, 2006 Seung-Bum, Cho Data Name Signature Report Reviewed By: Technical Director June 27, 2006 Harvey Sung Data Name Signature Ordering party: Company name : Diasonic Technology Co., Ltd. Address : #321-43, Suksu-dong, Manan-ku, City/town : Anyang-city, Kyungki-do Country : Korea. Zip code : 430-040 Date of order : June 09, 2006 DEMC#DR50110606N FCC ID: P7KDDR6000R Copyright c 2006, DIGITAL EMC Co., Ltd. Page 4 of 14 2. Informations about test item P7KDDR6000R 2.1 Equipment information Kind of Equipment Digital Voice Recorder Model No.(Brand Name) DDR-6000R (Voice Bank) Add Model No.(Brand Name) DDR-6000(Voice Bank) ; Deletion of FM Receiver Serial No. None Memory Size 128MB, 256MB, 512MB, 1GB, 2GB Type of Sample Tested Pre-Production Rating Power Supply (Used AC/DC adapter) Model No : U045020D12 Manufacture : Ten Pao Industrial Co., Ltd. Input : AC120V, 60Hz, 6.5W Output : DC4.5V, 200mA High Frequency 32.768kHz, 12MHz Tested Power Supply 1 Phase 120Vac, 60Hz 2.2 Ancillary Equipment Equipment Model No. Serial No. Manufacturer PC Y8Y 408KIEV102124 LG LCD Monitor CT-150 R20110001B COMTEC Printer SRP-770 SRP7708060035 SAMSUNG Mouse SMOP5000WX 04010159128 CHIC TECHNOLOGY Keyboard SEM-DT35US N/A GREAT PLEASURE ELECTRONICS 2.3 EMI Suppression Device(s)/Modifications None DEMC#DR50110606N FCC ID: P7KDDR6000R Copyright c 2006, DIGITAL EMC Co., Ltd. Page 5 of 14 3. Test Report 3.1 Summary of tests FCC Part Section(s) Parameter Status (note 1) Transmitter requirements 15.109 Radiated Emission C 15.107 Conducted Emissions C Note 1: C= Complies NC=Not Complies NT=Not Tested NA=Not Applicable The sample was tested according to the following specification: FCC Parts 15B; ANSI C-63.4-2003 DEMC#DR50110606N FCC ID: P7KDDR6000R Copyright c 2006, DIGITAL EMC Co., Ltd. Page 6 of 14 3.2 Transmitter requirements 3.2.1 Radiated Emission Procedure: The EUT was placed on a 0.8m high wooden table inside a shielded enclosure. An antenna was placed near the EUT and measurements of frequencies and amplitudes of field strengths were recorded for reference during final measurements. For final radiated testing, measurements were performed in a OATS. Measurements were performed with the EUT oriented in 3 orthogonal axis and rotated 360 degrees to determine worst-case orientation for maximum emissions. The spectrum analyzer is set to: Frequency Range = 27 MHz ~ 10 th harmonic. RBW = 120 kHz ( 30MHz ~ 1 GHz) = 1 MHz (1 GHz ~ 10 th harmonic ) VBW RBW Trace = max hold Detector function = peak / Quasi-peak / average Sweep = auto Measurement Result: Complies - Refer to the Next page Minimum Standard: 10m measurement according to CISPR 22 Frequency (MHz) Limit (uV/m) @ 10m 30 ~ 230 30 230 ~ 1000 37 DEMC#DR50110606N FCC ID: P7KDDR6000R Copyright c 2006, DIGITAL EMC Co., Ltd. Page 7 of 14 Radiated Emissions Measurement Data: Remark: the other emission is less than 30dB. Test mode : Play Mode DEMC#DR50110606N FCC ID: P7KDDR6000R Copyright c 2006, DIGITAL EMC Co., Ltd. Page 8 of 14 Radiated Emissions Measurement Data: Remark: the other emission is less than 30dB. Test mode : USB download Mode DEMC#DR50110606N FCC ID: P7KDDR6000R Copyright c 2006, DIGITAL EMC Co., Ltd. Page 9 of 14 3.2.2 Conducted Emission. Procedure: The conducted emissions are measured in the shielded room with a spectrum analyzer in peak hold. While …

Text truncated - open the document above for the full version.

FCC ID: P7KDDR6000R Copyright ○ Ⓒ 2006, DIGITAL EMC Co., Ltd. View 1 FCC ID: P7KDDR6000R Copyright ○ Ⓒ 2006, DIGITAL EMC Co., Ltd. View 2
