P7KDMP300MP3 Player

1 Thank you for purchasing Diasonic MP3 Player. Please read this instruction manual carefully before use. If you find any defect during the use of this unit, please contact A/S Center [Tel 031-474- 0852; Head Office]. Precautions: ● Do not repair, disassemble or modify the unit at your own discretion. ● The memory content may be changed or lost due to misuse, static electricity or electric shock during the repair or battery change. Be sure to make a note of important content. ● Diasonic assumes no responsibility for any damage caused by change or loss of memory content. ● Do not drop the unit in the water or keep it in any damp environment. ● This instruction manual is subject to change without notice for the purpose of product improvement. Copyright ● The MP3 files created for MP3 conversion shall not be used for any commercial or public purposes. Any violation of the prohibition may be a breach of copyright laws. ● Any unauthorized reproduction of recorded files for any other purposes than personal use is strictly prohibited by the relevant laws and regulations. Note This instruction manual is required for the effective use of Diasonic MP3 Player. Pay special attention not to lose the manual as it is not provided separately from the unit. Preface 2 Warning ● Keep the batteries out of reach of the children. If a child swallowed a battery, please consult a doctor immediately. ● Do not have the battery shorted, disassembled, heated or put in fire. This may cause leakage, heat, explosion or fire. ● If the battery leakage gets in your eyes, wash it off with clean water, and seek immediate medical treatment. If not, you may lose your sight. ● If the LCD is damaged, do not touch the liquid. If the liquid contacts your eyes or skin, wash it off with clean water, and seek immediate medical treatment. ● If you use the rechargeable batteries, read the user’s manuals for batteries and chargers carefully before use. ● Read this instruction manual carefully before use. Using earphones Road safety ● Do not use earphones while driving, cycling or operating any motorized vehicle. It may cause a traffic hazard and is illegal in some areas. It can also be dangerous to play your earphones at high volume while walking, especially at pedestrian crossings. Preventing hearing damage ● Avoid using earphones at high volume. Hearing experts advise against continuous, loud and extended play. ● If you experience a ringing in your ears, reduce the volume or discontinue use. Safety Precautions INFORMATION TO THE USER This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one more of the following measures: -. Reorient or relocate the receiving antenna. -. Increase the separation between the equipment and receiver. -. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -. Consult the dealer or an experienced radio/TV technician for help. CAUTION Any changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operations. 3 Precautions 1. Functions and Features 2. Parts and Components 3. Quick Operation Guide 4. Setting PC Environment 5. Downloading Files 6. Deleting Files 7. Formatting Files 8. Managing Folders and Files 9. FM Radio 10. Mode Menu 11. Main Menu 12. Recording in RECORD Range 13. Interface with External Devices 14. Setting the Menu in MP3 / RECORD Range 15. Buttons 16. Icons Specifications Warranty Contents 4 ● Be careful not to drop the unit or subject it to heavy impact. It may cause trouble. ● Do not put the unit in the hip pocket. The LCD part may be damaged when you sit down. ● Do not leave the unit in any location exposed to direct sunlight or near any heat source. ● To remove dust, clean the unit with soft cloth. Do not use liquid solvent (thinner, benzene, etc.) or wet cloth. ● To be noted, the LCD panel is made of glass. Do not press the screen hard. ● Do not use any hard materials or use excessive force to press the keys. The keys may be damaged. Precautions 5 ● Diasonic MP3 Player is a high performance portable digital audio player. This multi- functional next-generation portable digital audio player supports playing of MP3 and WMA (64Kbps or more) digital compressed music files and recording of music files via external equipment. ● Stylish, luxury and compact design and robust exterior Stylish and compact design, half-mirror type window and front aluminum case enable a luxury-style, highly portable and light MP3 player. ● Hi-fidelity MP3 Player Adopting various functions (equalizer / repeat play), the unit gives all the merits of MP3 players. It also provides rich and sensitive sound quality. ● Direct encoding recording Adopting voice recorder functions to the MP3 player, the unit supports voice recording and direct MP3 encoding recording through the external device. The unit can also be used as a portable data storage or portable hard disk. ● Bit rate variation You can select various bit rates for voice recording or line-in recording …
