P7KDTX-03FM CAR TRANSMITTER

DTX-03 User Manual V.1.0 FM CAR TRANSMITTER for iPod 1. Part Description & Components 1) Main Body 2) Accessory MODE DC 12V JACK (CIGARATTE LIGHT POWER CABLE) iPod ® Adaptor POWER ON-OFF FF REW PLAY/PAUSE VIDEO OUT JACK LINE IN JACK ● iPod ® ADAPTOR -iPod with video, Pod® 4G, iPod® 3G, iPod® mini, iPod®nano ● CIGARATTE LIGHT POWER CABLE (12V~24V) ● LINE IN CABLE (OPTION) ● VIDEO CABLE (OPTION) 2. Basic Functions ●Listen to iPod ® tunes or Other Audio Equipments through FM transmitter ●iPod with Video’s Playback on GPS/TV/PMP, while listening to iPod ® tunes through FM Transmitter in the car ● iPod ® Control using the Buttons on the Cup Holder ● Full FM Frequency Adjustment (88.1~107.9MHz) ● State of the art Ergonomic Design for iPod secure placement ● Charge iPod ® ● Support iPod ® Compatible Remote Controller 3. How to use FM CAR TRANSMITTER 1. Install proper provided iPod ® Adaptor to FM Car Transmitter 2. Connect FM Car Transmitter to Car Cigarette Jack using provided Cigarette Power Light Cable 3. Turn on Radio and tune to FM Channel, which is not currently used for broadcasting in your location 4. Using , button, match the Frequency Channel of the unit to that of FM Radio 5. You can listen to the iPod ® Music through FM Transmitter Note 1. If you want to listen to Another Audio Machine, connect the line-in jack of the unit to that of the Audio Machine via line-in cable. 2. Once all is set, LCD screen will appear as “iPod”after several seconds. You can operate iPod ® using the button of the unit once LCD is changed into iPod ® Mode. 3. You may need to change the frequency occasionally owing to the distortion and interference which may happen while driving. 4. The whole or part of the manual should not be copied or translated for distribution, without written approval of the Diasonic Technology. * iPod® is a registered trademark owned by Apple computer in the U.S. and other countries Patent Pending 4. Preset Set PRESET Channel Set If you the PLAY/PAUSE button for more than two (2) seconds, the Channel will be displayed in the LCD PRESET Channel Shift Select the Targeted Channel using PLAY/PAUSE Button while navigating among Stored 5 Channels with , button 5. iPod Mode You can change the mode between iPod ® and FM, should you push the mode button. Once install the iPod on the FM Car Transmitter , LCD will show “iPod” and you can control iPod in case you push any key of the unit. Please refer that this unit support iPod® Compatible Remote Controller. PLAY/PAUSE : Start to play or Stop Music : Once you push this button normally, you can listen to the next song. And in case of pressing the button and hold down for about 2 seconds, you can skip the files faster than normal. : Once you push this button normally, you can listen to the previous song. And in case of pressing the button and hold down for about 2 seconds, you can reversely skip the files faster than normal. Note 1. The mode will be changed into FM Mode, once you remove iPod ® from the unit. 2. The operation of iPod ® could be changed in accordance with iPod ® model or its Firmware Version. 6. VIDEO OUT SET It’s possible to watch the Movie/Image View of iPod with video by Video Out using video out cable. 1. Tune iPod ® with video as follows. Video Mode Video Setting TV Out On 2. Connect the Unit to the automotive LCD Display such as GPS, TV using video cable. 3. Playback the movie of iPod with video and you can watch them onto the Automotive LCD Display. 4. You can listen to the iPod ® Music through FM Transmitter. TV/GPS’s Video female connector Video cable’s male connector AV-in ※ You cannot listen to the iPod ® Music via Automotive LCD Display. 7. POWER ON/OFF 1. If you start a car , the unit will automatically powered-on via Car Charger and iPod ® starts being charged on the condition of the iPod installation onto the unit 2. If you push the Power normally, the unit will be turned on under Power- Off Mode. 3. Should you press the button and hold down for more than 2 seconds, the unit will be turned down. Important Notice ● Do not repair, dismantle or reconstruct the unit without the help of a technical support representative. ● Do not operate the nit while driving for your safety. ● Do not keep the unit in the hot places, direct sunlight or heating device. ● Do grasp securely the unit body whenever you connect/disconnect the cable ● FM Transmitters WARNING : Outdated some European Country’s Laws (The Wireless and Telegraphy Act, 1949) designed to stop pirate radio stations and people interfering with government frequencies do not allow FM Transmitters such as the AudiaX to be used in the some European Country. We will sell you one, but only if you warrant that you do not intend to use it in breach of any law. 8. FAQs ● Why should I get a noise when listening? -Please make sure whether or not the Frequency of the unit and automobile is same. -Please try to tune at the different FM Frequency. -Please correctly connect iPod ® and Line-in Cable. ● Why should I get some distortion through Line-in Jack? -Please adjust appropriate volume level of the iPod ® or another Audio Machine through Line-in Cable. ● I cannot watch the Movie to my iPod machine. -Please make sure that the machine has movie function and whether or not iPod with video is set on TV Out. ● I cannot operate iPod ® Remote Controller. What could be wrong? -Ensure this is iPod ® Compatible Remote Controller. ● FM Car Transmitter cannot be turned on. What can I do? -Please check on whether or not Car Charger’s Fuse(250V,2A) is working. Specification Frequency: WORLD /88.1~107.9MHz ; JAPAN / 76.0~96.0MHz Car Charger Vin : 12V~24V Operating Temperature: -10~50°C Audio Input: 50~400mV Audio Characteristics: 100Hz~5K (-3dB) Safety Approval: FCC , CE , E-MARK Warranty FM CAR TRANSMITTER MODEL: DTX-03 The Term of Guarantee: 1 year Date of Purchase: . . Name Address Purchaser Telephone Name Address Seller Telephone Free repair regulation We offer free repair service for produc…

Text truncated - open the document above for the full version.

#321-43, Suksu-dong, Manan-gu, Anyang-City, Kyungki-do, Korea December 8, 2006 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA In re : DIASONIC TECHNOLOGY CO., LTD. FCC ID : P7KDTX-03 Request for Confidentiality Gentlemen: In accordance with 0.459 of CFR 47, DIASONIC TECHNOLOGY CO., LTD. hereby requests confidentiality of the Block diagram(Block Diagrm_P7KDTX-03.pdf), Schematics(Schematic_ P7KDTX-03.pdf), Parts list(Part List_ P7KDTX-03.pdf) and Operational description(Operational Description_ P7KDTX-03.pdf). These documents contain detailed system and equipment description and related information about the product which DIASONIC TECHNOLOGY CO., LTD. considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, DIASONIC TECHNOLOGY CO., LTD. considers that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Jin-Geun, Moon / General Manager

#321-43, Suksu-dong, Manan-gu, Anyang-City, Kyungki-do, Korea December 8, 2006 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA In re: DIASONIC TECHNOLOGY CO., LTD. FCC ID: P7KDTX-03 Request for Short-Term Confidentiality To Whom It May Concern: In accordance with 0.457 and 0.459 of CFR 47, DIASONIC TECHNOLOGY CO., LTD requests short- term confidentiality of following sections of this application for a period of 45 days after grant is issued. Test setup photos(Test Photo_P7KDTX-03.pdf) External photos(Ext Photo_ P7KDTX-03.pdf) Internal photos(Int Photo_ P7KDTX-03.pdf)) User’s manual(User Manual_ P7KDTX-03.pdf)) These documents contain detailed system and equipment descriptions and related information about the product, which DIASONIC TECHNOLOGY CO., LTD considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, DIASONIC TECHNOLOGY CO., LTD. feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Sincerely, Jin-Geun, Moon / General Manager

KDB Inquiry Tracking Number - 754497

683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 http://www.digitalemc.com Tel: +82-31-321-2664 Fax: +82-31-321-1664 Copyright ○ c 2006, DIGITAL EMC Co., Ltd. 1. How does the device Operate? This device use DC 12V from cigarette lighter jack of a car. User can use connector of the unit for Ipod or use line-in jack to input audio signal from other audio equipments. This device use RS300A FM Stereo transmitter IC. RS300A consists of a stereo modulator for generating stereo composite signals and a FM transmitter for broadcasting FM signal on the air. 2. Provide information on the device and its antenna. Internal Wire Antenna is soldered permanently to the PCB. Any external antennas can not be attached to this device. 3. How is it installed? This device installed on the cup holder of the cars. The power is supplied from the cigarette lighter jack of a car. 4. What test procedure was used? The power line conducted emission test was not performed because this device is powered from a car cigarette jack only. The field strength of emissions was measured in accordance with FCC Part §15.239 and ANSI C 63.4:2003. The EUT was placed on a 0.8m high wooden table inside a shielded semi-anechoic chamber for pre-scanning test. An antenna was placed at 3m distance from EUT and measurements of frequencies and amplitudes of field strengths were recorded for reference during final measurements. For final radiated testing, measurements were performed at 3m OATS. 5. If tested in a car, how was it configured? The test was not performed in a car. The tests were performed on OATS. 6. Was the tuning range properly verified? The test lab should indicate in the report that the tuning controls were manually adjusted to verify the maximum tuning range. The user manual specifies that the operating frequency range is 88.1 ~ 107.9 MHz. This operating frequency range was verified manually before the tests using frequency changing button of the unit. 7. Was the bandwidth properly tested with the maximum audio input? The test lab should describe the audio input signal (use a typical audio file from a typical device) - DO NOT use 1kHz tone from signal generator as specified under ETSI EN 301 357-1) The input audio signal was delivered from Ipod or MP3 player. And the input audio signal level was maximum volume level of the Ipod and MP3 player. 8. Does the device operate in a vehicle? Please state that this was verified. Yes, this device can be used in a car.

FCCID: P7KDTX-03 View 1 FCCID: P7KDTX-03 View 2 FCCID: P7KDTX-03 View 3

FCC ID: P7KDTX-03 FCC ID SAMPLE LABEL & LOCATION MODEL NAME: DTX-03 LABELLING REQUIREMENTS PER §2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase FCCID: P7KDTX-03 Model name: DTX-03

FCCID: P7KDTX-03 View 1 (Internal) FCCID: P7KDTX-03 View 2 FCCID: P7KDTX-03 View 3 FCCID: P7KDTX-03 View 4 FCCID: P7KDTX-03 View 5 FCCID: P7KDTX-03 View 6 FCCID: P7KDTX-03 View 7

DEMC#DR50110612B-rev FCC ID: P7KDTX-03 Copyright ○ c 2006, DIGITAL EMC Co., Ltd. Page 1 of 25 DIGITAL EMC CO., LTD. 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 Tel: +82-31-321-2664 Fax: +82-31-321-1664 http://www.digitalemc.com CERTIFICATION OF COMPLIANCE Dates of Tests: December 1 ~ 7, 2006 February 5, 2007 Diasonic Technology Co., Ltd. #321-43, Suksu-dong, Manan-ku, Anyang-city, Kyungki-do, Korea. Test Report S/N: DR50110612B-rev Test Site : DIGITAL EMC CO., LTD. FCC ID APPLICANT FCC Classification : Low Power Communication Device Transmitter Device name : FM Car Transmitter Manufacturer : Diasonic Technology Co., Ltd. Model / Brand name : DTX-03 / CT BANK Test Device Serial number : Identical prototype FCC Rule Part(s) : FCC Part 15 Subpart C ANSI C-63.4-2003 Frequency Range : 88.1 ~ 107.9 MHz Data of issue : February 7, 2006 I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. P7KDTX-03 Diasonic Technology Co., Ltd. DEMC#DR50110612B-rev FCC ID: P7KDTX-03 Copyright ○ c 2006, DIGITAL EMC Co., Ltd. Page 2 of 25 TABLE OF CONTENTS 1. GENERAL INFORMATION ---------------------------------------------------------------------------- 2. INFORMATION ABOUT TEST ITEM ---------------------------------------------------------------- 3. TEST REPORT --------------------------------------------------------------------------------------------- 3.1 SUMMARY OF TESTS ------------------------------------------------------------------------------ 3.2 TEST REQUIREMENTS ----------------------------------------------------------------------------- 3.2.1 FIELD STRENGTH OF FUNDAMENTAL AND EMISSIONS WITHIN PERMITTED BAND. -- 3.2.2 RADIATED EMISSIONS ----------------------------------------------------------------------------------- 3.2.3 AC CONDUCTED EMISSION ---------------------------------------------------------------------------- 3.2.4 OCCUPIED CHANNEL BANDWIDTH ----------------------------------------------------------------- 3.2.5 ANTENNA REQUIREMENT ------------------------------------------------------------------------------ APPENDIX I MEASUREMETN UNCERTAINTY -------------------------------------------------- APPENDIX II TEST EQUIPMENT USED FOR TESTS --------------------------------------------- 3 4 7 7 8 8 9 14 15 20 21 23 DEMC#DR50110612B-rev FCC ID: P7KDTX-03 Copyright ○ c 2006, DIGITAL EMC Co., Ltd. Page 3 of 25 1. General Information This report contains the result of tests performed by: DIGITAL EMC CO., LTD. Address : 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 http://www.digitalemc.com E-mail : [email protected] Tel: +82-31-321-2664 Fax: +82-31-321-1664 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. This laboratory is accredited by NVLAP and NVLAP Lab. Code is 200559-0. Test operator: engineer February 7, 2007 Won –Jung, LEE Data Name Signature Report Reviewed By: manager February 7, 2007 Harvey Sung Data Name Signature Ordering party: Company name : Diasonic Technology Co., Ltd. Address : #321-43, Suksu-dong, Manan-ku Zip code : 430-040 City/town : Anyang-city, Kyungki-do Country : Korea Date of order : September 4, 2006 Attention : Jin-Geun, Moon DEMC#DR50110612B-rev FCC ID: P7KDTX-03 Copyright ○ c 2006, DIGITAL EMC Co., Ltd. Page 4 of 25 2. Information about test item P7KDTX-03 2.1 Equipment information Equipment model name DTX-03 Type of equipment FM Car Transmitter Frequency band 88.1 ~ 107.9 MHz Type of antenna Internal Wire Antenna Power DC 12 V 2.2 Tested environment Temperature : 15 ~ 35 ( o C) Relative humidity content : 20 ~ 75 % Air pressure : 86 ~ 103 kPa Details of power supply : DC 12.0 V (powered by power supply) 2.3 Tested frequency Frequency TX RX Low frequency 88.1 MHz - Middle frequency 98.0 MHz High frequency 107.9 MHz - Note 1. The operating frequency range was verified manually using frequency changing button. DEMC#DR50110612B-rev FCC ID: P7KDTX-03 Copyright ○ c 2006, DIGITAL EMC Co., Ltd. Page 5 of 25 P7KDTX-03 2.4 Setup of Configuration of EUT - Case 1.(With iPOD) - Case 2.(With iPod and MP3P) Note. When the EUT connected with iPOD and MP3 simultaneously, the EUT only transmits DATA from MP3P (LINE IN). - Support Equipment Equipment Model name Serial Number Manufacturer DATA Cable Power Cable iPod A1136 4J547WX0SZ9 Apple Computer N/A N/A Sansa(MP3P) M250 N/A SanDisk Stereo cable N/A - - - - - - DEMC#DR50110612B-rev FCC ID: P7KDTX-03 Copyright ○ c 2006, DIGITAL EMC Co., Ltd. Page 6 of 25 P7KDTX-03 2.5 Cabling Configuration EUT Shield Length (m) Connection VIDEO OUT None 1.2 Termination DC IN None 1.0 DC power supply LINE IN None 1.0 MP3P 2.6 EMI Suppression Device(s)/Modifications EMI suppression device(s) added and/or modifications made during testing Î None DEMC#DR50110612B-rev FCC ID: P7KDTX-03 Copyright ○ c 2006, DIGITAL EMC Co., Ltd. Page 7 of 25 3. Test Report 3.1 Summary of tests FCC Part Section(s) Parameter Limit Test Condition Status (note 1) 15.239 Field Strength of Fundamental and Emissions within permitted band. < 250 uV/m @ 3m Radiated C 15.209 Radiated Emission < FCC 15.209 limits Radiated C 15.207 AC Conducted Emissions < FCC 15.207 limits Line Conducted NA 15.239 Occupied channel bandwidth < 200kHz Radiated C 15.203 Antenna Requirement FCC 15.203 - C Note 1: C=Complies NC=Not Complies NT=Not Tested NA=Not Applicable Note 2: Conducted emission test is not applied, because the power of the EUT is supplied from a Car battery. Note 3: The sample was tested according to the following specification: FCC Parts 15.239; ANSI C-63.4-2003 DEMC#DR50110612B-rev FCC ID: P7KDTX-03 Copyright ○ c 2006, DIGITAL EMC Co., Ltd. Page 8 of 25 3.2 TEST requirements 3.2.1 Field…

Text truncated - open the document above for the full version.

FCC ID: P7KDTX-03 View 1 FCC ID: P7KDTX-03 View 2
