C:\windows\TEMP\probonholdemail.doc TIMCOTIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] 7 June 2002 FCC SUBJECT: VERTU LTD. FCC ID: P7QNPM-7 To Whom It May Concern: This application was dismissed because of a statement in Exhibit 6, I could not find an exhibit 6 but I did locate a typographical error on Page 8 of 25 of the equipment test report that indicated the incorrect average for the power output. This has been corrected. The following grant note was added to the grant: This device contains 900 MHz GSM functions that are not operational in U.S. Territories. This approval is only applicable for 1900 MHz PCS operations. Sincerely, Sid Sanders

COMPLIANCE DOCUMENTATION 1 (6) CONFIDENTIAL Photographs of P7QNPM-7 Mobile Phone March 2002 Exhibit 1: Front External View of Vertu P7QNPM-7 COMPLIANCE DOCUMENTATION 2 (6) CONFIDENTIAL Photographs of P7QNPM-7 Mobile Phone March 2002 Exhibit 2: Back External View of Vertu P7QNPM-7, shown with Whip Antenna Extended. COMPLIANCE DOCUMENTATION 3 (6) CONFIDENTIAL Photographs of P7QNPM-7 Mobile Phone March 2002 Exhibit 3: View of Vertu P7QNPM-7, battery cover removed to show TYPE DESIGNATION LABEL, and SIM card holder.

COMPLIANCE DOCUMENTATION 4 (6) CONFIDENTIAL Photographs of P7QNPM-7 Mobile Phone March 2002 Exhibit 4: RF Circuitry Top View of Printed wire Board, with RF shielding cans removed to show RF Circuitry. RF Antenna Module, whip extended, showing Printed integral Antenna Circuit. COMPLIANCE DOCUMENTATION 5 (6) CONFIDENTIAL Photographs of P7QNPM-7 Mobile Phone March 2002 Exhibit 5: Bottom View of Printed Wire Board with screaning can removed to show baseband circuitry. COMPLIANCE DOCUMENTATION 6 (6) CONFIDENTIAL Photographs of P7QNPM-7 Mobile Phone March 2002 Exhibit 6: Back internal view showing interconnecting printed flexy circuit and peripherals.

PC Site Oulu Exhibit 11: SAR Report DTX04125-EN Applicant: Vertu Ltd FCC ID:P7QNPM-7 Copyright  2002 Nokia Corporation 1 (14) SAR Compliance Test Report Test report no.: Not numbered Date of report: 2002-03-07 Number of pages: 62 Contact person: Olli Kautio Responsible test engineer: Pertti Mäkikyrö Testing laboratory: Nokia Corporation Elektroniikkatie 10 P.O. Box 50 FIN-90571 OULU Finland Tel. +358-7180-08000 Fax. +358-7180-47222 Client: Vertu Ltd Summit Avenue Farnborough Hamshire GU14 0NG Tel. +44-1252-866000 Fax. +44-1252-866001 Tested devices: P7QNPM-7 BH2-AL01 Supplement reports: - Testing has been carried out in accordance with: IEEE P1528-200X Draft 6.4 Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Body Due to Wireless Communications Devices: Experimental Techniques Documentation: The documentation of the testing performed on the tested devices is archived for 15 years at PC Site Oulu Test results: The tested device complies with the requirements in respect of all parameters subject to the test. The test results and statements relate only to the items tested. The test report shall not be reproduced except in full, without written approval of the laboratory. Date and signatures: 2002-03-07 For the contents: Pertti Mäkikyrö Engineering Manager, EMC Miia Nurkkala Test Engineer PC Site Oulu Exhibit 11: SAR Report DTX04125-EN Applicant:Vertu Ltd FCC ID:P7QNPM-7 Copyright  2002 Nokia Corporation 2 (14) CONTENTS 1.SUMMARY FOR SAR TEST REPORT ..........................................................................................................................3 1.1 MAXIMUM RESULTS FOUND DURING SAR EVALUATION.................................................................................................................. 3 1.1.1Head Configuration.......................................................................................................................................................... 3 1.1.2Body Worn Configuration............................................................................................................................................... 3 1.1.3Measurement Uncertainty ............................................................................................................................................. 3 2.DESCRIPTION OF TESTED DEVICE .............................................................................................................................4 2.1 PICTURE OF PHONE........................................................................................................................................................................... 4 2.2 D ESCRIPTION OF THE ANTENNA........................................................................................................................................................ 4 2.3 B ATTERY OPTIONS............................................................................................................................................................................. 5 2.4 B ODY WORN ACCESSORIES.............................................................................................................................................................. 5 3.TEST CONDITIONS ........................................................................................................................................................5 3.1 AMBIENT CONDITIONS...................................................................................................................................................................... 5 3.2 RF CHARACTERISTICS OF THE TEST SITE............................................................................................................................................. 5 3.3 T EST SIGNAL, FREQUENCIES, AND OUTPUT POWER.......................................................................................................................... 5 4.DESCRIPTION OF THE TEST EQUIPMENT.................................................................................................................6 4.1 SYSTEM ACCURACY VERIFICATION.................................................................................................................................................... 6 4.2 T ISSUE SIMULANTS............................................................................................................................................................................ 7 4.2.1Head Tissue Simulant ...................................................................................................................................................... 7 4.2.2Muscle Tissue Simulant................................................................................................................................................... 7 4.3 P HANTOMS........................................................................................................................................................................................ 8 4.4 I SOTROPIC E-FIELD PROBE ET3DV6 ................................................................................................................................................ 8 5.DESCRIPTION OF THE TEST PROCEDURE ................................................................................................................9 5.1 TEST POSITIONS................................................................................................................................................................................. 9 5.1.1Against Phantom Head ................................................................................................................................................... 9 5.1.2Body Worn Configuration............................................................................................................................................. 10 5.2 S CAN PROCEDURES...............................…

Text truncated - open the document above for the full version.

FCC ID: P7QNPM-7 MFA p0220005, d0220021 TRANSMITTER CERTIFICATION of FCC ID: P7QNPM-7 MODEL: MMII to FEDERAL COMMUNICATIONS COMMISSION Rule Part(s) 24E DATE OF REPORT: June 7, 2002 ON THE BEHALF OF THE APPLICANT: Vertu Ltd. AT THE REQUEST OF : P.O. E38-4355478 Vertu Ltd. Nokia House, Building 3, Floor 1, Summit Avenue Farnborough, Hampshire GU14 ONG, UK Attention of: Mark Pope, Manager - Test and Type Approvals +44 1252 867587; FAX: -865680 [email protected] SUPERVISED BY: Morton Flom, P. Eng. FCC ID: P7QNPM-7 MFA p0220005, d0220021 LIST OF EXHIBITS (FCCCERTIFICATION(PCS TRANSMITTERS) - REVISED 9/28/98) APPLICANT: Vertu Ltd. FCC ID: P7QNPM-7 BY APPLICANT: 1. LETTER OF AUTHORIZATION x 2. IDENTIFICATION DRAWINGS, 2.1033(c)(11) xID LABEL xLOCATION OF LABEL xCOMPLIANCE STATEMENT xLOCATION OF COMPLIANCE STATEMENT 3. PHOTOGRAPHS, 2.1033(c)(12) x 4. CONFIDENTIALITY REQUEST: 0.457 and 0.459 x 5. DOCUMENTATION: 2.1033(c) (3) USER MANUAL x (9) TUNE UP INFO x (10) SCHEMATIC DIAGRAM x (10) CIRCUIT DESCRIPTION x BLOCK DIAGRAM x PARTS LIST x ACTIVE DEVICES x 6. SAR Report by Nokia Finland x BY M.F.A. INC. A. TESTIMONIAL & STATEMENT OF CERTIFICATION B. STATEMENT OF QUALIFICATIONS FCC ID: P7QNPM-7 MFA p0220005, d0220021 THE APPLICANT HAS BEEN CAUTIONED AS TO THE FOLLOWING: 15.21 INFORMATION TO USER. The users manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.27(a) SPECIAL ACCESSORIES. Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer, without additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. FCC ID: P7QNPM-7 MFA p0220005, d0220021 TABLE OF CONTENTS RULEDESCRIPTIONPAGE . Test Report 1 2.1033(c) General Information Required 2 2.1033(c)(14) Rule Summary 5 . Standard Test Conditions and Engineering Practices 6 2.1046(a) ERP Carrier Power (Radiated) 7 2.1051, 2.1049(c), 24, 24.238(b). . Transmitter Conducted Measurements 9 2.1053(a) Field Strength of Spurious Radiation 16 2.1055(a)(1), 24.235. .Frequency Stability (Temperature Variation) 21 2.1055(b)(1) Frequency Stability (Voltage Variation) 24 2.202(g) Necessary Bandwidth and Emission Bandwidth 25 FCC ID: P7QNPM-7 MFA p0220005, d0220021 PAGE NO.1of25. Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a) TEST REPORT b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d0220021 d) Client: Vertu Ltd. Nokia House, Building 3, Floor 1, Summit Avenue Farnborough, Hampshire GU14 ONG, UK e) Identification: MMII FCC ID: P7QNPM-7 Description: Cell phone f) EUT Condition: Not required unless specified in individual tests. g) Report Date: June 7, 2002 EUT Received: February 18, 2002 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supervised by: Morton Flom, P. Eng. n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduced, except in full, without written permission from this laboratory. p) Special Notes: Results contained herein apply to cases made for either Stainless Steel, Platinum or Gold. The following accessories were used during the test program: ACV-A Charger BLZ-2 Battery HSV-A Headset BH2-AL01 Belt Holster DLV-A Data Cable DTV-A Desk Stand FCC ID: P7QNPM-7 MFA p0220005, d0220021 PAGE NO.2of25. LIST OF GENERAL INFORMATION REQUIRED FOR CERTIFICATION IN ACCORDANCE WITH FCC RULES AND REGULATIONS, VOLUME II, PART 2 AND TO 24E Sub-part 2.1033 (c)(1): NAME AND ADDRESS OF APPLICANT: Vertu Ltd. Nokia House, Building 3, Floor 1, Summit Avenue Farnborough, Hampshire GU14 ONG, UK MANUFACTURER: Applicant (c)(2): FCC ID: P7QNPM-7 MODEL NO: MMII (c)(3): INSTRUCTION MANUAL(S): PLEASE SEE ATTACHED EXHIBITS (c)(4): TYPE OF EMISSION: 256KGXW (c)(5): FREQUENCY RANGE, MHz : 1850.2 to 1909.8 (c)(6): POWER RATING, Watts: 1.0715 EIRP Switchable x Variable N/A FCC GRANT NOTE: BC - The output power is continuously variable from the value listed in this entry to 5%-10% of the value listed. (c)(7): MAXIMUM POWER RATING, Watts :1 FCC ID: P7QNPM-7 MFA p0220005, d0220021 PAGE NO.3of25. Subpart 2.1033(continued) (c)(8): VOLTAGES & CURRENTS IN ALL ELEMENTS IN FINAL R. F. STAGE, INCLUDING FINAL TRANSISTOR OR SOLID STATE DEVICE: COLLECTOR CURRENT, A = per manual COLLECTOR VOLTAGE, Vdc = per manual SUPPLY VOLTAGE, Vdc = 3.6 (c)(9): TUNE-UP PROCEDURE: PLEASE SEE ATTACHED EXHIBITS (c)(10): CIRCUIT DIAGRAM/CIRCUIT DESCRIPTION: Including description of circuitry & devices provided for determining and stabilizing f…

Text truncated - open the document above for the full version.

FCC ID: P7QNPM-7 MFA p0240008, d0270002 NAME OF TEST: Unwanted Emissions (Transmitter Conducted) g0250007: 2002-May-01 Wed 11:50:00 STATE: 1:Low Power FREQUENCY TUNED, MHz FREQUENCY EMISSION, MHz LEVEL, dBm LEVEL, dBc MARGIN, dB 1850.200000 3700.352500 -75.5 -77.8 -62.5 1880.000000 3759.948500 -75.8 -78.1 -62.8 1909.800000 3819.440500 -75.4 -77.7 -62.4 1850.200000 5550.534500 -74.1 -76.4 -61.1 1880.000000 5639.910500 -75.5 -77.8 -62.5 1909.800000 5729.268000 -73.2 -75.5 -60.2 1850.200000 7400.959000 -69 -71.3 -56 1880.000000 7520.218000 -68.8 -71.1 -55.8 1909.800000 7639.234500 -68.9 -71.2 -55.9 1850.200000 9251.010500 -68.3 -70.6 -55.3 1880.000000 9399.953000 -69.4 -71.7 -56.4 1909.800000 9548.993500 -69.8 -72.1 -56.8 1850.200000 11101.250500 -68.9 -71.2 -55.9 1880.000000 11279.999500 -69.3 -71.6 -56.3 1909.800000 11458.755000 -69.1 -71.4 -56.1 1850.200000 12951.519000 -63.6 -65.9 -50.6 1880.000000 13160.049000 -63.9 -66.2 -50.9 1909.800000 13368.559800 -64.3 -66.6 -51.3 1850.200000 14801.672500 -63.3 -65.6 -50.3 1880.000000 15039.774400 -63.4 -65.7 -50.4 1909.800000 15278.224800 -63.3 -65.6 -50.3 1850.200000 16651.863300 -63.5 -65.8 -50.5 1880.000000 16920.208800 -60.9 -63.2 -47.9 1909.800000 17188.171400 -63.1 -65.4 -50.1 1850.200000 18501.858900 -62.3 -64.6 -49.3 1880.000000 18800.084300 -58.2 -60.5 -45.2 1909.800000 19098.091700 -56.9 -59.2 -43.9 1850.200000 20352.221200 -56.2 -58.5 -43.2 1880.000000 20679.767900 -54.7 -57 -41.7 1909.800000 21007.737500 -56.6 -58.9 -43.6 FCC ID: P7QNPM-7 MFA p0240008, d0270002 NAME OF TEST: Unwanted Emissions (Transmitter Conducted) g0250006: 2002-May-01 Wed 11:38:00 STATE: 2:High Power FREQUENCY TUNED, MHz FREQUENCY EMISSION, MHz LEVEL, dBm LEVEL, dBc MARGIN, dB 1850.200000 3700.626000 -55.3 -84.3 -42.3 1880.000000 3760.196000 -55.3 -84.3 -42.3 1909.800000 3819.358000 -55.1 -84.1 -42.1 1850.200000 5550.706000 -54.8 -83.8 -41.8 1880.000000 5640.006500 -55 -84 -42 1909.800000 5729.376000 -54.6 -83.6 -41.6 1850.200000 7400.738000 -49.2 -78.2 -36.2 1880.000000 7520.202500 -48.9 -77.9 -35.9 1909.800000 7639.409500 -48.6 -77.6 -35.6 1850.200000 9251.234000 -48.8 -77.8 -35.8 1880.000000 9399.788500 -48 -77 -35 1909.800000 9549.066500 -50 -79 -37 1850.200000 11101.424000 -48.2 -77.2 -35.2 1880.000000 11280.177000 -47.9 -76.9 -34.9 1909.800000 11458.936000 -48.1 -77.1 -35.1 1850.200000 12951.383600 -44.5 -73.5 -31.5 1880.000000 13159.953500 -44.1 -73.1 -31.1 1909.800000 13368.789300 -44.2 -73.2 -31.2 1850.200000 14801.755000 -43.3 -72.3 -30.3 1880.000000 15039.924300 -43.9 -72.9 -30.9 1909.800000 15278.589300 -44.3 -73.3 -31.3 1850.200000 16651.740800 -43.1 -72.1 -30.1 1880.000000 16920.088800 -43.3 -72.3 -30.3 1909.800000 17188.184900 -42.5 -71.5 -29.5 1850.200000 18502.190500 -43.1 -72.1 -30.1 1880.000000 18800.061000 -37.9 -66.9 -24.9 1909.800000 19097.948100 -37.7 -66.7 -24.7 1850.200000 20352.120900 -36.8 -65.8 -23.8 1880.000000 20679.762900 -35.2 -64.2 -22.2 1909.800000 21007.632700 -36.1 -65.1 -23.1

FCC ID: P7QNPM-7 MFA p0260005, d0270001 NAME OF TEST: Emission Masks (Occupied Bandwidth) g0260092: 2002-Jun-26 Wed 13:09:00 STATE: 2:High Power RES BW 1 MHz VBW 10 kHz SWP 20.0 msec ATTEN 30 dBREF 29.1 dBm 10 dB/ POS P K CENTER 1.880 00 GHz SPAN 2.00 MHz OFFSET 10.3 dB MKR 1.879 898 GHz 29.20 dBm POWER: HIGH MODULATION: GSM PCS BAND REFERENCE LEVEL PERFORMED BY: Doug Noble, B.A.S. E.E.T.
