PANBT420Bluetooth Low Energy Dongle

user manual BLE USB DONGLE 1.Install BLE‐CC254X‐1.4.0.exe 2.Associate Driver with USB Dongle After the software installation is complete, the USB Dongle driver must be associated with the device in order to use the demo application. To associate the USB Dongle driver, first you must connect the USB Dongle to the PC’s USB port, or to a USB hub that connects to the PC. The first time that the dongle is connected to the PC, a message will most probably pop‐up, indicating that Windows does not recognize the device. When prompted whether to use Windows Update search for software, select “No, not this time” and press the “Next” button. On the next screen, select the option “Install from a list or specific location (Advanced)”, and press the “Next” button: On the next screen, click the checkbox labeled “Include this location in the search:”, and click the “Browse” button. Select the following directory (assuming the default installation path was used): C:\Texas Instruments\BLE‐CC254x‐1.4.0\Accessories\Drivers Click the “Next” button. This should install the driver. It will take a few seconds for the file to load. If the installation was successful, you should see the screen to the below. Click the “Finish” button to complete the installation. 3. Determining the COM Port Once the driver is installed, you need to determine which COM port Windows has assigned to the USB Dongle. A list of all hardware devices should appear. Under the section “Ports (COM & LPT)”, the device “TI CC2540 Low‐Power RF to USB CDC Serial Port” should appear. Next to the name should be the port number (for example, the CC2540USB Dongle uses COM8 ). Take note of this port number, as it will be needed in order to use BTool. You may close the device manager at this point. 4. Using BTool To start the application go into your programs by choosing Start > Programs > Texas Instruments > BLECC254x‐1.4.0 > BTool. On Start‐up you should be able to set the Serial Port Settings. Set the “Port” value to the COM port. For the other settings, use the default values. Press “OK” to connect to the USB Dongle. When connected you should see the screen presented. The screen indicates that you now have a serial port connection to the USB Dongle. The screen is divided up into a few sections: the left sidebar contains information on the USB Dongle status. The left side of the sub‐window contains a log of all messages sent from the PC to the USB Dongle and received by the PC from the USB Dongle. The right side of the sub‐window contains a GUI for control of the USB Dongle. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC Test Report Report No. : EP422023 SPORTON International Inc. PAGE NUMBER : B1 OF B6 TEL : 886-3-327-3456 ISSUED DATE : Apr. 07, 2014 FAX : 886-3-327-0973 APPENDIX B. Photographs of EUT FCC Test Report Report No. : EP422023 SPORTON International Inc. PAGE NUMBER : B2 OF B6 TEL : 886-3-327-3456 ISSUED DATE : Apr. 07, 2014 FAX : 886-3-327-0973

Model:BT- 420 FCC ID:PANBT420 Made in China Model:BT- 420 FCC ID:PANBT420 Made in China

FCC Test Report Report No. : EP422023 SPORTON International Inc. PAGE NUMBER : B3 OF B6 TEL : 886-3-327-3456 ISSUED DATE : Apr. 07, 2014 FAX : 886-3-327-0973 FCC Test Report Report No. : EP422023 SPORTON International Inc. PAGE NUMBER : B4 OF B6 TEL : 886-3-327-3456 ISSUED DATE : Apr. 07, 2014 FAX : 886-3-327-0973 FCC Test Report Report No. : EP422023 SPORTON International Inc. PAGE NUMBER : B5 OF B6 TEL : 886-3-327-3456 ISSUED DATE : Apr. 07, 2014 FAX : 886-3-327-0973 Balan Filter 1 Balan Filter 2 FCC Test Report Report No. : EP422023 SPORTON International Inc. PAGE NUMBER : B6 OF B6 TEL : 886-3-327-3456 ISSUED DATE : Apr. 07, 2014 FAX : 886-3-327-0973

FCC Test Report Report No. : FR422023 SPORTON INTERNATIONAL INC. Page No. : 1 of 37 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 FCC Test Report Equipment : Bluetooth Low Energy Dongle Brand Name : CC&C Model No. : BT-420 FCC ID : PANBT420 Standard : 47 CFR FCC Part 15.247 Operating Band : 2400 MHz – 2483.5 MHz FCC Classification : DTS Applicant Manufacturer : CC&C Technologies, Inc. 8F, No.150, Jian Yi Rd, Zhonghe District, New Taipei City, 235, Taiwan The product sample received on Mar. 10, 2014 and completely tested on Mar. 14, 2014. We, SPORTON, would like to declare that the tested sample has been evaluated in accordance with the procedures given in ANSI C63.10-2009 and shown compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Wayne Hsu / Assistant Manager FCC Test Report Report No. : FR422023 SPORTON INTERNATIONAL INC. Page No. : 2 of 37 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Table of Contents 1 GENERAL DESCRIPTION .................................................................................................................... 5 1.1 Information.............................................................................................................................................. 5 1.2 Support Equipment ................................................................................................................................. 7 1.3 Testing Applied Standards ..................................................................................................................... 7 1.4 Testing Location Information .................................................................................................................. 7 1.5 Measurement Uncertainty ...................................................................................................................... 8 2 TEST CONFIGURATION OF EUT ........................................................................................................ 9 2.1 The Worst Case Modulation Configuration ............................................................................................ 9 2.2 The Worst Case Power Setting Parameter ............................................................................................ 9 2.3 The Worst Case Measurement Configuration ...................................................................................... 10 2.4 Test Setup Diagram ............................................................................................................................. 11 3 TRANSMITTER TEST RESULT .......................................................................................................... 13 3.1 AC Power-line Conducted Emissions .................................................................................................. 13 3.2 6dB Bandwidth ..................................................................................................................................... 16 3.3 RF Output Power .................................................................................................................................. 18 3.4 Power Spectral Density ........................................................................................................................ 20 3.5 Transmitter Bandedge Emissions ........................................................................................................ 22 3.6 Transmitter Unwanted Emissions......................................................................................................... 25 4 TEST EQUIPMENT AND CALIBRATION DATA ................................................................................ 36 APPENDIX A. TEST PHOTOS APPENDIX B. PHOTOGRAPHS OF EUT FCC Test Report Report No. : FR422023 SPORTON INTERNATIONAL INC. Page No. : 3 of 37 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Summary of Test Result Conformance Test Specifications Report Clause Ref. Std. Clause Description Measured Limit Result 1.1.3 15.203 Antenna Requirement Antenna connector mechanism complied FCC 15.203 Complied 3.1 15.207 AC Power-line Conducted Emissions [dBuV]: 0.2018130MHz 44.34 (Margin 9.20dB) - AV 53.70 (Margin 9.84dB) - QP FCC 15.207 Complied 3.2 15.247(a) 6dB Bandwidth LE: 712 kHz ≥500kHz Complied 3.3 15.247(b) RF Output Power (Maximum Peak Conducted Output Power) Power [dBm] LE: 1.38 Power [dBm] LE:30 Complied 3.4 15.247(e) Power Spectral Density PSD [dBm/100kHz] LE: -15.77 PSD [dBm/3kHz]: 8 Complied 3.5 15.247(d) Transmitter Bandedge Emissions Restricted Bands [dBuV/m at 3m]: 2483.760 MHz 57.19 (Margin 16.81dB) - PK 45.70 (Margin 8.30dB) - AV Non-Restricted Bands: > 20 dBc Restricted Bands: FCC 15.209 Complied 3.6 15.247(d) Transmitter Unwanted Emissions Restricted Bands [dBuV/m at 3m]: 797.270 MHz 38.73 (Margin 7.27dB) - PK Non-Restricted Bands: > 20 dBc Restricted Bands: FCC 15.209 Complied FCC Test Report Report No. : FR422023 SPORTON INTERNATIONAL INC. Page No. : 4 of 37 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Revision History Report No. Version Description Issued Date FR422023 Rev. 01 Initial issue of report Apr. 07, 2014 2500-2690 FCC Test Report Report No. : FR422023 SPORTON INTERNATIONAL INC. Page No. : 5 of 37 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 1 General Description 1.1 Information 1.1.1 Product Details The equipment is Bluetooth Low Energy Dongle. There are two types of Balan Filter. The only difference is the source. For more detailed features description, please refer to the manufacturer’s specifications or user’s manual. 1.1.2 RF General Information RF General Information Frequency Range (MHz) Bluetooth Version Ch. Frequency (MHz) Channel Number RF Output Power (dBm) 2…

Text truncated - open the document above for the full version.

FCC Test Report Report No. : FR422023 SPORTON INTERNATIONAL INC. Page No. : A1 of A7 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Appendix A. Test Photos FCC Test Report Report No. : FR422023 SPORTON INTERNATIONAL INC. Page No. : A2 of A7 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 1 Photographs of Conducted Emissions Test Configuration FRONT VIEW REAR VIEW FCC Test Report Report No. : FR422023 SPORTON INTERNATIONAL INC. Page No. : A3 of A7 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 SIDE VIEW FCC Test Report Report No. : FR422023 SPORTON INTERNATIONAL INC. Page No. : A4 of A7 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 2 Photographs of Radiated Emissions Test Configuration For radiated emissions 9kHz~30MHz FRONT VIEW REAR VIEW FCC Test Report Report No. : FR422023 SPORTON INTERNATIONAL INC. Page No. : A5 of A7 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 For radiated emissions 30MHz~1GHz FRONT VIEW REAR VIEW FCC Test Report Report No. : FR422023 SPORTON INTERNATIONAL INC. Page No. : A6 of A7 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 For radiated emissions above 1GHz FRONT VIEW REAR VIEW FCC Test Report Report No. : FR422023 SPORTON INTERNATIONAL INC. Page No. : A7 of A7 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 EUT take a close-up FRONT VIEW REAR VIEW
