PANCL8723BUWLAN and BT Combo Dongle

IEEE 802.11b/g/n WLAN and BT combo dongle CL-8723BU USER’S GUIDE VERSION 1.2 © All rights reserved. All trade names are registered trademarks of respective manufacturers listed. This manual may not be copied in any media or form without the written consent of original maker. Information To User .......................................................... I 1. Introduction ............................................................... 1 2. Wireless LAN Basics ....................................................... 3 3. IP ADDRESS ................................................................. 4 4. Install Driver/Utility ...................................................... 5 4.1 Windows XP/Vista/Win7 / 8 / 8.1 / 10........................ 5 5. Wireless Network Configuration ....................................... 7 5.1 Utility Icon ........................................................ 7 5.2 Client Mode (Default Setting)................................... 7 6. Technical Specifications ............................................... 15 7. Troubleshooting ......................................................... 16 8. Glossary ................................................................... 17 The channel identifiers, channel center frequencies, and regulatory domains of each 22-MHz- wide channel are shown in following Table. Channel Identifier Frequency (MHZ) Regulatory Domains Japan ETSI North America Israel Mexico 1 2412 ● ● ● 2 2417 ● ● ● 3 2422 ● ● ● ● 4 2427 ● ● ● ● 5 2432 ● ● ● ● 6 2437 ● ● ● ● 7 2442 ● ● ● ● 8 2447 ● ● ● ● 9 2452 ● ● ● ● 10 2457 ● ● ● ● 11 2462 ● ● ● ● 12 2467 ● ● 13 2472 ● ● 14 2484 ● 1 Thank you for your purchase of the WLAN Adapter. Featuring wireless technology, this wireless networking solution has been designed for both large and small businesses, and it is scalable so that you can easily add more users and new network features depending on your business scale. FEATURES Support Microsoft Win7 / 8 / 8.1 / 10(32bit/64bit). Operating distance of up to 150 meters in free space. 150/120/90/60/54/48/36/30/24/22/18/12/11/6/5.5/2/1 Mbps selectable Data Rate. 64/128-bit WEP , WPA (Wi-Fi Protected Access), WPA2 2.400GHz ~ 2.4835GHz unlicensed ISM Frequency Band. Modulation Method : IEEE 802.11b : DSSS (Direct Sequence Spread Spectrum). IEEE 802.11g / 802.11n : OFDM (Orthogonal Frequency Division Multiplexing). Easy operation and setting up. SYSTEM REQUIREMENTS Windows System : Win7 / 8 / 8.1 / 10(32bit/64bit). System must have a device driver installed. It allows you to communicate with WLAN 11n USB Client Adapter. 2 BEFORE YOU START 1. Confirm Box Contents ◆ WLAN 11n USB Client Adapter ◆ Quick Start Guide ◆ Driver CD CONNECTING YOUR WLAN 11n USB Client Adapter Quick Start Guide Connect your WLAN 11n USB Client Adapter. Install driver. GETTING TO KNOW WIRELESS LAN ADAPTER LED LED turns on when WLAN link to WLAN adaptor or AP. LED is blinking when WLAN Adapter is active. 3 Wireless LAN network defined by IEEE 802.11b/g standard committee could be configured as : Ad Hoc wireless LAN. Infrastructure wireless LAN. Ad Hoc network is a group of wireless LAN cards, this group is called a BSS (Basic Service Set). This group can use their wireless LAN cards to communicate with each other, but can not connect to the Internet. Ad Hoc Wireless Network Infrastructure Wireless Network The most obvious difference between Infrastructure wireless network and Ad Hoc wireless network in Infrastructure wireless network can access the resource in the Internet through Access Point. Depending on your requirement, you can easily set up your system network to be a “Ad Hoc” or “Infrastructure” wireless network. Generally speaking, if in your network, there is an Access Point in it, we recommend you to set your network as an “Infrastructure”, so it can connect to the Internet. 4 The installation & driver CD will automatically activate the autorun installation program after you insert the disk into your CD drive. Step 1 : Insert the installation CD into your CD- ROM. Win UAC Dialog is shown. Click Yes to continue. Step 2 : Preparing Setup dialog is shown Step 3 : Wizard is ready to install driver and utility. Click Next to begin the installation Installing & configuring WLAN driver and utility 5 Installing Cisco 802.1x module Step 4 : Click Finish to complete installation. The installation will affect after windows rebooting 6 WLAN 11n USB Client Adapter uses its own management software. All functions controlled by users are provided by this application. When you insert the WLAN Adapter into your laptop or desktop, a icon should appear in the Windows System Tray automatically. 5.1 Utility Icon ▓ Client mode utility running but no WLAN Adapter plugged ▓ Client mode utility running and WLAN Adapter scan available network. ▓ Client mode utility running and WLAN Adapter can not scan any AP 5.2 Client Mode (Default Setting) Wireless Device Control : ▓ Show Tray Icon – Show icon or not show icon in system tray. ▓ Radio Off – To stop wireless signal. ▓ Disable Adapter – To stop wireless device. ▓ Virtual WiFi allowed – To enable Soft AP 7 5.2.1 GENERAL SETTING Once device is set, double click on that icon and the configuration window will pop up as shown. It shows the current connected network. The signal strength and link quality are displayed also. The bar graph displays the quality and strength of the link between the node and its Access Point. Link Quality is a measurement of receiving and transmitting performances over the radio. Network Address displays current MAC Address, IP Address, Subnet. and Gateway. Click Renew IP button to refresh IP address leased from wireless AP. 5.2.2 PROFILE SETTING In profile tab, you can Add, Remove, Edit, Duplicate and Set Default to manipulate profile content manually. Strongly recommend to use profile after you do Available Network. 8 5.2.3 AVAILABLE NETWOEK SETTING Click Available Network tab and it will show all available networks that radio can reaches. …

Text truncated - open the document above for the full version.

G G a a i i n n F F o o r r c c e e T T e e c c h h n n o o l l o o g g y y C C o o . . , , L L t t d d 嘉光科技股份有限公司 R&D / PE / QC /PURCHASE / VENDOR 承認書 A A P P P P R R O O V V A A L L S S H H E E E E T T 品 名： Multilayer Chip Antenna MODEL NAME 料 號： AT3216-B2R7HAAT/LF PAT NUMBER 3.2*1.6mm Multilayer Chip Antenna 客戶名稱： 晶訊科技股份有限公司 CUSTOMER 供 應 商： 嘉光科技股份有限公司 VENDOR 承認料號： Approve P/N 使用機種： MODEL 聯 絡 人： 許志遠 DENNIS 聯絡電話： +886-915-296-557 附 件： ACCESSORIES ■規格書 □樣品 SPECIFICATION SAMPLE □圖樣 ■檢驗報告 DRAWING TEST REPORT 認可狀況： （APPROVED STATUS） ACX Advanced Ceramic X AT3216 Series Multilayer Chip Antenna Features ™ Monolithic SMD with small, low-profile and light-weight type. ™ Wide bandwidth Applications ™Bluetooth/Wireless LAN/Home RF ™ISM band 2.4GHz applications Specifications Part Number Frequency Range (MHz) Peak Gain XZ-V Average Gain XZ-V VSWR Impedance AT3216 -B2R7HAA_ 2400 ~ 2500 0.5 dBi typ. -0.5 dBi typ. 2 max. 50 Ω Q’ty/Reel (pcs) : 3,000pcs Operating Temperature Range : -40 ~ +85 o C Storage Temperature Range : -40 ~ +85 o C Power Capacity : 3W max. Part Number AT 3216 - B 2R7 HAA ‡ /LF c d e f g h i c Type AT : Antenna d Dimensions ( L × W ) 3.2× 1.6 mm e Material Code B f Frequency Range 2R7=2700MHz g Specification Code HAA h Packaging T: Tape & Reel B: Bulk i Soldering =lead-containing /LF=lead-free Terminal Configuration No. Terminal Name No. Terminal Name c Feeding Point d NC d c ACX Advanced Ceramic X Dimensions and Recommended PC Board Pattern Unit : mm a W T L Mark L W T a Dimensions 3.20.2 1.60.2 1.3+ 0.1/-0.2 0.50.3 (a) Without Matching Circuits (b) With Matching Circuits 1.2pF 3.3nH 2.6 4.2 1.6 1.9 2.7nH 0.4 * *Line width should be designed to match 50Ω characteristic impedance, depending on PCB material and thickness. ACX Advanced Ceramic X Typical Electrical Characteristics (T=25 o C) ™Test Board Ground 13.5mm 6.5mm 39.5mm 4mm No Ground Matching Circuit 50Ω Feed Line 19mm Antenna 6.5mm ™Return Loss (a) Without Matching Circuits (b) With Matching Circuits SGS Taiwan Ltd. Chemical-Taipei 33 WuChyuan Road, Wuku Industrial Zone, Taipei County, Taiwan /33 t + 886 (02)2299 3279 f + 886 (02)2299 3237 www.sgs.com Member of the SGS Group (SGS SA) Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This test report cannot be reproduced, except in full, without prior written permission of the Company. This Test Report is issued by the Company under its General Conditions of Service printed overleaf or available on request and accessible at http://www.sgs.com/terms_and_conditions.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this Test Report is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Sample Description : Style/Item No. : Buyer/Order No. : Sample Receiving Date : Testing Period : ============================================================================================ Test Requested : Test Method: (1) (2) (3) (4) (5) Test Result(s) : The following sample(s) was/were submitted and identified by/on behalf of the client as : Test Report 2010/02/25 MULTILAYER LTCC-A COMPONENTS (CERAMIC BODY) *CE/2010/25138* No. : CE/2010/25138Date : 2010/03/04Page : 1 of 5 ADVANCED CERAMIC X (ACX) CORPORATION 16 TZU CHIANG ROAD, HSINCHU INDUSTRIAL DISTRICT, HSINCHU HSIEN, TAIWAN 303 2010/02/25 TO 2010/03/04 AD SERIES, AM SERIES, AT SERIES, AW SERIES, BD SERIES, BF SERIES, BL SERIES, BM SERIES, CD SERIES, CF SERIES, CP SERIES, DM SERIES, DP SERIES, DS SERIES, FA SERIES, FB SERIES, FD SERIES, HI SERIES, HF SERIES, HM SERIES, HS SERIES, LF SERIES, PD SERIES, NF SERIES, QS SERIES, SF SERIES, TS SERIES, LTCC SUBSTRATES, BCM2037 LOCAL COMPANY OR USA COMPANY In accordance with the RoHS Directive 2002/95/EC, and its amendment directives. With reference to IEC 62321: 2008 Procedures for the Determination of Levels of Regulated Substances in Electrotechnical Products. Determination of Cadmium by ICP-AES. Please refer to next page(s). Determination of Lead by ICP-AES. Determination of Mercury by ICP-AES. Determination of Hexavalent Chromium by UV/Vis Spectrometry. Determination of PBB and PBDE by GC/MS. SGS Taiwan Ltd. Chemical-Taipei 33 WuChyuan Road, Wuku Industrial Zone, Taipei County, Taiwan /33 t + 886 (02)2299 3279 f + 886 (02)2299 3237 www.sgs.com Member of the SGS Group (SGS SA) Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This test report cannot be reproduced, except in full, without prior written permission of the Company. This Test Report is issued by the Company under its General Conditions of Service printed overleaf or available on request and accessible at http://www.sgs.com/terms_and_conditions.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this Test Report is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Result No.1 n.d.2 382 n.d.2 n.d.2 n.d.- n.d.5 n.d.5 n.d.5 n.d.5 n.d…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Date of Issue :December 14, 2015 Report No: C151023R01-RPW FCC ID: PANCL8723BU Page 1 / 3 EXTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Date of Issue :December 14, 2015 Report No: C151023R01-RPW FCC ID: PANCL8723BU Page 2 / 3 Compliance Certification Services Inc. Date of Issue :December 14, 2015 Report No: C151023R01-RPW FCC ID: PANCL8723BU Page 3 / 3

Compliance Certification Services Inc. Date of Issue :December 14, 2015 Report No: C151023R01-RPW FCC ID: PANCL8723BU Page 1 of 2 INTERNAL PHOTOGRAPHS OF EUT Wifi & BT Antenna Compliance Certification Services Inc. Date of Issue :December 14, 2015 Report No: C151023R01-RPW FCC ID: PANCL8723BU Page 2 of 2

Compliance Certification Services Inc. Date of Issue :December 14, 2015 Report No: C151023R01-RPB FCC ID: PANCL8723BU Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by A2LA or any government agencies. The test results in the report only apply to the tested sample. Rev.01 Page 1 of 62 FCC 47 CFR PART 15 SUBPART C TEST REPORT For Product Name: WLAN and BT Combo Dongle Brand Name: CC&C Model No.: CL-8723BU Series Model:N/A FCC ID: PANCL8723BU Test Report Number: C151023R01-RPB Issued for CC&C Technologies,Inc. 8F,No.150,Jian Yi Rd,Zhonghe District,New Taipei City,235,Taiwan Issued by Compliance Certification Services Inc. Kun shan Laboratory No.10 Weiye Rd., Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China TEL: 86-512-57355888 FAX: 86-512-57370818 Compliance Certification Services Inc. Date of Issue :December 14, 2015 Report No: C151023R01-RPB FCC ID: PANCL8723BU Page 2 of 62 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION ............................................................................. 4 2. EUT DESCRIPTION ................................................................................................. 5 3. TEST METHODOLOGY ........................................................................................... 6 3.1 EUT CONFIGURATION ...................................................................................................... 6 3.2 EXERCISEEUT ................................................................................................................... 6 3.3 GENERAL TEST PROCEDURES ....................................................................................... 6 3.4 TEST MODE ......................................................................................................................... 7 3.5 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS ............................................ 8 4. INSTRUMENT CALIBRATION ................................................................................. 9 5. FACILITIES AND ACCREDITATIONS ..................................................................... 9 5.1 FACILTIES .......................................................................................................................... 9 5.2 EQUIPMENT ....................................................................................................................... 9 5.3 LABORATORY ACCREDITATIONS AND LISTING ............................................................ 9 5.4 TABLE OF ACCREDITATIONS ........................................................................................ 10 5.5 LIST OF MEASURING EQUIPMENT ................................................................................ 11 5.6 SETUP CONFIGURATION ............................................................................................... 12 5.7 SUPPORT EQUIPMENT .................................................................................................. 12 6. FCC PART 15.247 REQUIREMENTS .................................................................... 13 6.1 PEAK POWER .................................................................................................................. 13 6.2 20DB BANDWIDTH MEASUREMENT .............................................................................. 15 6.3 HOPPING CHANNEL SEPARATION ................................................................................ 20 6.4 NUMBER OF HOPPING FREQUENCY ............................................................................ 23 6.5 TIME OF OCCUPANCY (DWELL TIME) ........................................................................... 26 6.6 C ONDUCTED BAND EDGES MEASUREMENT .......................................................................... 31 6.7 C ONDUCTED SPURIOUS EMISSION MEASUREMENT ............................................................... 37 6.8 R ADIATED BAND EDGE AND SPURIOUS EMISSION MEASUREMENT ......................................... 44 6.9 POWERLINE CONDUCTED EMISSIONS ........................................................................ 60 Compliance Certification Services Inc. Date of Issue :December 14, 2015 Report No: C151023R01-RPB FCC ID: PANCL8723BU Page 3 of 62 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. SUMMARY OF TEST RESULT Report Section FCC Rule Description Limit Result 3.1 15.247(a)(1) Number of Channels ≥ 15Channels Pass 3.2 15.247(a)(1) Hopping Channel Separation ≥2/3 of 20dB BW Pass 3.3 15.247(a)(1) Dwell Time of Each Channel ≤0.4sec in 31.6sec period Pass 3.4 15.247(a)(1) 20dB Bandwidth NA Pass 3.5 15.247(b) (1) Peak Output Power ≤125mW Pass 3.6 15.247(d) Conducted Band Edges and Spurious Emission ≤ 20dBc Pass 3.7 15.247(d) Radiated Band Edges and Spurious Emission 15.209(a) &15.247(d) Pass 3.8 15.207 AC Conducted Emission15.207(a) Pass 3.9 15.203 &15.247(b) Antenna RequirementN/A Pass Compliance Certification Services Inc. Date of Issue :December 14, 2015 Report No: C151023R01-RPB FCC ID: PANCL8723BU Page 4 of 62 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. 1. TEST RESULT CERTIFICATION Product Name: WLAN and BT Combo Dongle Trade Name: CC&C Model Name: CL-8723BU Series Model: N/A Applicant Discrepancy: Initial Device Category: Portable Device Date of Test: October 31, 2015~December 12, 2015 Applicant: CC&C Technologies,Inc. 8F,No.150,Jian Yi Rd,Zhonghe District,New Taipei City,235,Taiwan Manufacturer: Kunshan CC&C Technolog…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Date of Issue :December 14, 2015 Report No: C151023R01-RPW FCC ID: PANCL8723BU Page 1 / 2 TEST SETUP PHOTOGRAPHS OF EUT RADIATED Compliance Certification Services Inc. Date of Issue :December 14, 2015 Report No: C151023R01-RPW FCC ID: PANCL8723BU Page 2 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. CONDUCTIED
