PANWL1102WLAN Cardbus PCMCIA Card

1 IEEE802.11b Wireless LAN Adapter User Manual Version 1.0 2003/2/20 2 FCC INFORMATION Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 3 REGULATORY INFORMATION The Wireless LAN PC Card must be installed and used in strict accordance with the manufacturer’s instructions. This device complies with the following radio frequency and safety standards. USA - Federal Communications Commission (FCC) This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference that may cause undesired operation. Europe - R&TTE Directive This device complies with the specifications listed below • ETS 300-826 General EMC requirements for Radio equipment. • ETS 300-328 Technical requirements for Radio equipment. • EN60950 Safety Requirements for Radio equipment The channel identifiers, channel center frequencies, and regulatory domains of each 22- MHz-wide channel are shown in following Table. Regulatory Domains Channel Identifier Center Frequency (MHZ) JapanETSI North America IsraelFranceMexico 12412 ˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇ 22417 ˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇ 32422 ˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇ 42427 ˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇ 52432 ˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇ 62437 ˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇ 72442 ˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇ 82447 ˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇ 92452 ˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇ 102457 ˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇ 112462 ˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇ 122467 ˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇ 132472 ˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇˇ ˇ 142484 ˇ ˇˇ ˇ 4 CONTENTS 1. INTRODUCTION ................................................................... 5 2. Wireless LAN basics ................................................................. 6 3. Configuration Utility.................................................................. 7 3.1 Configured at “ Windows XP configuration mode ”. 3.2 Configured at “Realtek advanced configuration ”. 4. Technical Specifications of WLAN PC Card .................................... 11 5. Glossary ................................................................................. 12 5 1 Introduction First of all, we deeply appreciated your purchasing our wireless LAN PC card. This powerful LAN card not only providing stable linking quality but also safe to transmitting data. We supply several security authentication login to enhance your safekeeping, as 802.1x and 802.11i standard. This user manual will guide you to install WLAN PC Card driver and utility quickly! Features • Completely accordance with IEEE 802.11 and IEEE 802.11b standards • Ultra low power consumption in sleep mode • High throughput and long transmission range • 128-pin LQFP, world's most compact size • Requires 50% fewer discrete components • Patented integrated Wireless LAN MAC and Direct Sequence Spread Spectrum Baseband Processor in one chip • On-chip A/D and D/A converters for I/Q Data, AGC, and Adaptive Power Control • Multi-path Delay Spreads 250ns at 11Mbps • Supports Antenna Diversity • 1 Mbps, 2 Mbps, 5.5 Mbps, and 11 Mbps operation • PCI local bus network interface controller • Compliant to PCI Revision 2.2 • Supports ACPI, PCI power management • Supports CardBus. The CIS can be stored in a 93C56 • Compliant to PC97, PC98, PC99 and PC2001 standards • Supports auxiliary power-on internal reset, to be ready for remote wake-up when main power remains off. • Supports auxiliary power auto-detect, and sets the related capability of power management registers in PCI configuration space • Supports Short Preamble option 6 • Internal encryption/decryption engine executes IEEE 802.11 64-bit and 128-bit WEP • 3.3V and 1.8V power supplies needed and 5V tolerant I/Os 2 Wireless LAN basics Wireless LAN network defined by IEEE 802.11b standard committee could be Configure as: Ad Hoc wireless LAN or Infrastructure wireless LAN. Ad Hoc network is a group of notebooks with wireless LAN PC cards, called a BSS (Basic Service Set). These notebooks use their wireless LAN PC cards to communicate with each other directly. The most obvious differentiation between Infrastructure wireless network and Ad Hoc wireless network is that the notebooks in Infrastructure wireless network can make use of the resource in the Internet …

Text truncated - open the document above for the full version.

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2

Page 3 Page 4 Page 5

FCC ID: PANWL1102 ADT No.920218R06 Operational Description The transmitter of the EUT (WLAN Cardbus PCMCIA Card) is powered by host equipment via a PCMCIA interface. The antenna is Printed antenna without antenna connector. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

FCC ID: PANWL1102 Report No.: RF920218R06 1 Issued: Mar. 11, 2003 FCC TEST REPORT REPORT NO.: RF920218R06 MODEL NO.: WL-1102 RECEIVED: Feb. 18, 2003 TESTED: Feb. 24~ Mar. 5, 2003 APPLICANT:CC&C TECHNONGIES INC. ADDRESS:8F, 150, JIAN YI ROAD, CHUNG HO CITY, TAIPEI COUNTRY, TAIWAN 235, R.O.C ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 48 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: PANWL1102 Report No.: RF920218R06 2 Issued: Mar. 11, 2003 Table of Contents 1CERTIFICATION ........................................................................................... 4 2SUMMARY OF TEST RESULTS................................................................... 5 3GENERAL INFORMATION ........................................................................... 6 3.1GENERAL DESCRIPTION OF EUT ............................................................. 6 3.2DESCRIPTION OF TEST MODES ............................................................... 7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS............................... 7 3.4DESCRIPTION OF SUPPORT UNITS.......................................................... 8 4TEST TYPES AND RESULTS ...................................................................... 9 4.1CONDUCTED EMISSION MEASUREMENT ................................................ 9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT ............................. 9 4.1.2TEST INSTRUMENTS .................................................................................. 9 4.1.3TEST PROCEDURES................................................................................. 10 4.1.4DEVIATION FROM TEST STANDARD ....................................................... 10 4.1.5TEST SETUP ...............................................................................................11 4.1.6EUT OPERATING CONDITIONS.................................................................11 4.1.7TEST RESULTS.......................................................................................... 12 4.2RADIATED EMISSION MEASUREMENT ................................................... 18 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ................................ 18 4.2.2TEST INSTRUMENTS ................................................................................ 19 4.2.3TEST PROCEDURES................................................................................. 20 4.2.4DEVIATION FROM TEST STANDARD ....................................................... 20 4.2.5TEST SETUP .............................................................................................. 21 4.2.6EUT OPERATING CONDITIONS................................................................ 21 4.2.7TEST RESULTS.......................................................................................... 22 4.36dB BANDWIDTH MEASUREMENT .......................................................... 26 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT........................................ 26 4.3.2TEST INSTRUMENTS ................................................................................ 26 4.3.3TEST PROCEDURE ................................................................................... 27 4.3.4DEVIATION FROM TEST STANDARD ....................................................... 27 4.3.5TEST SETUP .............................................................................................. 27 4.3.6EUT OPERATING CONDITIONS................................................................ 27 4.3.7TEST RESULTS.......................................................................................... 28 4.4MAXIMUM PEAK OUTPUT POWER .......................................................... 32 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ........... 32 4.4.2TEST INSTRUMENTS ................................................................................ 32 FCC ID: PANWL1102 Report No.: RF920218R06 3 Issued: Mar. 11, 2003 4.4.3TEST PROCEDURES................................................................................. 33 4.4.4DEVIATION FROM TEST STANDARD ....................................................... 33 4.4.5TEST SETUP .............................................................................................. 33 4.4.6EUT OPERATING CONDITIONS................................................................ 33 4.4.7TEST RESULTS.......................................................................................... 34 4.5POWER SPECTRAL DENSITY MEASUREMENT ..................................... 35 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ................... 35 4.5.2TEST INSTRUMENTS ................................................................................ 35 4.5.3TEST PROCEDURE ................................................................................... 36 4.5.4DEVIATION FROM TEST STANDARD ....................................................... 36 4.5.5TEST SETUP .............................................................................................. 36 4.5.6EUT OPERATING CONDITIONS................................................................ 36 4.5.7TEST RESULTS.......................................................................................... 37 4.6BAND EDGES MEASUREMENT ................................................................ 41 4.6.1LIMITS OF BAND EDGES MEASUREMENT ............................................. 41 4.6.2TEST INSTRUMENTS ................................................................................ 41 4.6.3TEST PROCEDURE ......…

Text truncated - open the document above for the full version.

FCC ID: PANWL1102 Report No.: RF920218R06 46 Issued: Mar. 11, 2003 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: PANWL1102 Report No.: RF920218R06 47 Issued: Mar. 11, 2003 RADIATED EMISSION TEST
