PATRX1UTEKRF Remote Switch

Transmitter • • • FUNCTION (1) LED Power ON/.OFF. While press the button • OR • , The light ON (2) DATA CODING SWITCH( • and • ) • When press the button • or • ; programmed Data automatically connected to the RECEIVER • If supplied DATA Coincide with receiver, The RECEIVER start operation. • When press the button one more time, The RECEIVER stop operation. Receiver • • • ( Top view ) • Green_wire : No.1 Switching • Green_wire : No.1 Switching • Blue_wire : No.2 Switching • Blue_wire : No.2 Switching • Red_wire : 6 ~ 8[V] DC Voltage • Black_wire : Ground • N.C : No Connection • Tact_switch : While LED on, If press the switch No.1, then the LED light off also be added memory quantity. • (Be able to add maximum 20pcs, If repeat No.8 action.) THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS : (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. BESTEC.CO ADDRESS : 1594S. ANAHEIM BLVD.SUITE.C ANAHEIM. CA 92805 TEL : 714)520-3030 FAX : 714)520)5653 NAME : LEE. JAY.Y Caution : Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void user's authority to operate the equipment.

RECEIVER OUTPUT 1 OUTPUT 2 ANTENNA RF AMP (Q1) MIX , OSC & DET (Q2, L1) DET PRE AMP(R16, R3, IC1)DRIVER AMP RELAY1RELAY2 SW1 TRSW2 TR CPU IC DATA CONTROL

External Photos

ID LABEL RECEIVER (Bottom view ) FCC ID : XXXRX1UTEK TRADE NAME : WD-202 MODEL NO.:FMT-202 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS : (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

ID LABEL RECEIVER (Bottom view ) FCC ID : PATRX1UTEK TRADE NAME : WD-202 MODEL NO.:FMT-202 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS : (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

Internal Photos

RX SCHEMETIC DIAGRAM #1RX SCHEMETIC DIAGRAM #2 RL1RLY6P 3 54 12 R24 4.7K 12[V] VI GND VO R23 470 X14MHz C13220uF/16V RL2RLY6P 3 54 12 RXIN U2PI C16C 57 1 2 22232425 6789 1011 12131415161718192021 262728 T0C LK VD D RC4RC5RC6RC7 RA0RA1RA2RA3RB0RB1 RB2RB3RB4RB5RB6RB7 RC0RC1RC2RC3 OSC2/CLKOUTOSC1/CLKMCLR/ VPP 5[V] Q1C200Y U224C02B 132 4657 8 A0A2A1 Vs sSC LSD AWP Vcc 78L05 12[V] SI P-7PCON21234567 C12104 R2110K R25 4.7K CON1H EADER 2 12 C15220uF/16V LED1RED 12[V] Q2C200Y 5[V] 5[V] R22 10K R1910K 12[V] C14104 5[V] D11N4007 SW1 D11N4007 R66.8K R233K C54pF Q1 C1674YC R12470K C7 390pF L1 C16 3pF R1 R18 6.8M C4 2pF R31K C3 100pF R11 6.8M C9 104 R547K +- U1AKI A4558 32 1 84 R16 100 C2 0.001 R14 R1510K R1310K +- U1BKI A4558 56 7 8 RXIN 5[V] R9 27K R4 R8 3.3K R10 82K C11100/35 R18 6.8M L2 10uH C6 33pF Q2C5065 C10001

KTL Korea Testing Laboratory Page 1 of 9 TEST REPORT This test report only responds to the tested sample and shall not be reproduced except in full without written approval of the Korea Testing Laboratory. Tested and reported by Reviewed by Jeong-Min Kim , Senior Engineer Seok-Jin Kim , EMC Team Leader KOREA TESTING LABORATORY FG101-01-02-00 222-13, Guro-Dong Guro-Gu Seoul Korea 152-053 http://www.ktl.re.kr Ref. Report No. 00-341-047-02 Name and address of the applicant U-TEK Engineering 2-237, Ichon Ind. Goods Center 129, Songhyun-Dong, Dong-Gu, Inchon, 401-040, Korea Standard / Test regulation FCC Part 15, Subpart C Test result Pass Incoming date : October 05, 2000 Test item( s) ; Superregenerative Receiver (RF Remote Switch) Model/type ref. ; FMT-202 Manufacturer ; U-TEK Engineering Additional information ; -Re quire d Aut ho riz atio n : Ce rtificatio n -FCC ID. : PATRX1UTEK Test date : October 13, 2000Issue date : October 14, 2000 Ref. Report No. 00-341-047-02 2 Page of 9 TABLE O F CONTENTS I. GENERAL INFORMATION ............................................................................................................ 3 1. Grantee’s Name and Mailing Address 2. Manufacturer's Name and Mailing Address 3. Equipment Descriptions 4. Rules and Regulations 5. Measuring Procedure 6. Date of Measurement α. GENERAL REQUIREMENTS OF THE EUT .................................................................4 1. Labelling Requirement (Section 15.19) 2. Information to User (Sections 15.21) 3. Special Accessories (Section 15.27) β. RADIATED EMISSION MEASUREMENT (Section 15.109) .......................................................5-8 1. Test Procedure 2. Photograph for the test configuration 3. Sample Calculation 4. Measurement Data 5. Reference Data χ. TEST EQUIPMENTS USED FOR MEASUREMENT..................................................................9 Ref. Report No. 00-341-047-02 3 Page of 9 . GENERAL INFORMATION 1. Grantee’s Name and : U-TEK Engineering Mailing Address 2-237, Ichon Ind. Goods Center 129, Songhyun-Dong, Dong-Gu, Inchon, Korea 401-040 2. Manufacturer's Name and: U-TEK Engineering Mailing Address 2-237, Ichon Ind. Goods Center 129, Songhyun-Dong, Dong-Gu, Inchon, Korea 401-040 3. Equipment Descriptions 3.1 Tunning Frequency : 311 MHz 3.2 Detect Method : Superregenerative Detector 3.3 Oscillator Used: 311 MHz (Resonator) 3.4 Power Supply: DC 8V(Battery) 4. Rules and Regulations: FCC Part 15, Subpart B 5. Measuring Procedure: ANSI C63.4-1992 6. Date of Measurement 6.1 Line Conducted: Not Applicable 6.2 Radiated Emission : October 13, 2000 Ref. Report No. 00-341-047-02 4 Page of 9 . GENERAL REQUIREMENTS O F THE EUT 1. Labelling Requirement (Section 15.19) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interface, and (2) this device must accept any interference received, including interference that may cause undesired operation. 1.1 Location of Label : Bottom side of EUT 1.2 How Applied : By ink-printing on adhesive label 2. Information to User (Section 15.21) The following or similar statements were provided in the manual for user instruction. Please refer page 3 of the attached manual for details. CA UT ION : A ny c ha nges or modifications i n cons truc tion o f this device w hich are not e xpressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 3. Special Accessories (Section 15.27) 3.1 Were the special Accessories provided? [ ] yes, [ x ] no 3.2 If yes, details for the special accessories are as follows : 3.3 If yes, were the appropriate instructions provided on the first page of the text concerned with the device? [ ] yes, [ ] no 3.4 Are these accessories provided of the type which can be readily obtained from multiple retail outlets ? [ ] yes, [ ] no And therefore does the manual specify what additional components or accessories are required to used in order to comply with the Rules? [ ] yes, [ ] no Ref. Report No. 00-341-047-02 5 Page of 9 . RADIATED EMISSION MEASUREMENT (Section 15.109) 1. Test Procedure 1.1 Preliminary Testing for Reference Preliminary testing was performed in a KTL absorber-lined room to determine the emission characteristics of the EUT. The EUT was placed on the wooden table which has dimensions of 0.8 meters in height, 1 meter in length and 1.5 meters in width. Receiving antenna (Biconical antenna : 30 to 300MHz, Log-periodic antenna : 200 to 1000MHz or Horn Antenna : 1 to 18GHz) was placed at the distance of 1 meter from the EUT. In order to cohere the individual components of the characteristic broadband emission from the receiver(EUT), a RF generator(CW signal) and a log-periodic antenna were used. The frequency and output level of the generator were adjusted for highest observed coherent receiver emissions on the spectrum analyzer with RF amplifier. An attempt was made to maximize the emission level with the various configurations of the EUT. The effect of changing the position of the cable was observed to find the worst case configuration while rotating the table and varying antenna height and it’s polarization. Radiated and spurious emissions were checked from 30 MHz to 3000 MHz according to section 15.33. 1.2 Final Radiated Emission Test at an Absorber-Lined Room The final measurement of radiated field strength was carried out in a KTL Absorber-Lined Room that was listed up at FCC according to the "Radiated Emissions Testing" procedure specified by ANSI C63.4. Based on the test results in preliminary test, measurement was made in same test set up and configuration which produced maximum emission level. Receiving antenna was installed at 3-meter distance from the EUT, and was connected to an EMI receiver or spectrum analyzer(for above 1GHz) with a RF amplifier. Turntable was rotated through 360 degrees and receiving antenna height was varied from 1 to 4 meters above the ground plane to r…
