PB6-04021802.11b CF Card Module

Wireless LAN CF Card User’s Manual For OEM Instruction Ver. 1.4 1 Copyright © 2001 by manufacturer. All rights reserved. No part of this documentation may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation, or adaptation) without written permission from the copyright owner. All the other trademarks and registered trademarks are the property of their respective owners. Statement of Conditions The content described in this manual may be improved or changed at any time and it is subject to be changed without notice. Manufacturer assumes no responsibility for errors contained herein or for direct, indirect, special, incidental or consequential damages with the furnishing, performance, or use of this manual or equipment supplied with it, even if manufacturer of its suppliers have been advised of the possibility of such damages. Electronic Emission Notices This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device will accept any interference received, including interference that may cause undesired operation. FCC Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user need to correct the interference at his area. If the equipment causes interference to radio or television reception, try to correct the interference by using one or more of the following measures: ü Plug the equipment into an outlet that is on a different circuit from the television or radio. ü Change the direction of the television or radio antenna until the interference disappears. ü Move the equipment to one side or the other of the television or radio. ü Move the equipment farther away from the television or radio. ü Manufacturer could void the user’s authority to operate the equipment. 2 FCC Radiation Exposure Statement This device and its antennas must operate with a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End users must be provided with specific operating instructions for satisfying RF exposure compliance. This product has been certified in France, Germany, Italy, Spain, Sweden, UK, and US. Regulatory information / Disclaimers Installation and use of this Wireless LAN device must be in strict accordance with the instructions included in the user documentation provided with the product. Any changes or modifications (including the antenna) made to this device that are not expressly approved by manufacturer may void the user’s authority to operate the equipment. The manufacturer is not responsible for any radio or television interference caused by unauthorized modification of this device, or the substitution or attachment of connecting cables and equipment other than manufacturer specified. It is the responsibility of the user to correct any interference caused by such unauthorized modification, substitution or attachment. Manufacturer and its authorized resellers or distributors will assume no liability for any damage or violation of government regulations arising from failing to comply with these guidelines. Modular Approval This device is intended only form OEM integrators under the following conditions: The antenna must be installed such that 20cm is maintained between the antenna and users, and The transmitter module may not be co-located with any other transmitter or antenna. 3 IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID:PB6 - 04021 can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. End Product Labeling This transmitter module is authorized only for use in devices where the antenna may be installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled in visible area with the following: “Contains TX FCC ID: PB6 - 04021” End Product Manual Information The user manual for end users must include the following information in a prominent location “IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.” 4 LIMITED WARRANTY This product is warranted by manufacturer to be free from defects in material and workmanship for one (1) year from the date of purchase, unless otherwise stated. During this period if this product is found to be defective in material or workmanship, manufacturer or one of its authorized service facilities will at its option either repair or replace this product without charge, subject to the following conditions, limitations and exclusions: 1. This warranty extends to the original consumer purchaser only and is not assignable or transferable. 2. This warranty shall not apply to any product which has been subjected to misuse, abuse, abnormal use, negligence, alteration or accident, or has had its serial number altered or removed. 3. This warranty doe…

Text truncated - open the document above for the full version.

Wireless LAN CF Modular OEM Installation Guide Ver. 1.4 1 Copyright © 2001 by manufacturer. All rights reserved. No part of this documentation may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation, or adaptation) without written permission from the copyright owner. All the other trademarks and registered trademarks are the property of their respective owners. Statement of Conditions The content described in this manual may be improved or changed at any time and it is subject to be changed without notice. Manufacturer assumes no responsibility for errors contained herein or for direct, indirect, special, incidental or consequential damages with the furnishing, performance, or use of this manual or equipment supplied with it, even if manufacturer of its suppliers have been advised of the possibility of such damages. Electronic Emission Notices This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device will accept any interference received, including interference that may cause undesired operation. FCC Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user need to correct the interference at his area. If the equipment causes interference to radio or television reception, try to correct the interference by using one or more of the following measures: ü Plug the equipment into an outlet that is on a different circuit from the television or radio. ü Change the direction of the television or radio antenna until the interference disappears. ü Move the equipment to one side or the other of the television or radio. ü Move the equipment farther away from the television or radio. To assure continued compliance, any changes or modifications not expressly approved by manufacturer could void the user’s authority to operate the equipment. 2 FCC Radiation Exposure Statement This device and its antennas must operate with a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End users must be provided with specific operating instructions for satisfying RF exposure compliance. This product has been certified in France, Germany, Italy, Spain, Sweden, UK, and US. Regulatory information / Disclaimers Installation and use of this device must be in strict accordance with the instructions included in the user documentation provided with the product. Any changes or modifications (including the antenna) made to this device that are not expressly approved by manufacturer may void the user’s authority to operate the equipment. The manufacturer is not responsible for any radio or television interference caused by unauthorized modification of this device, or the substitution or attachment of connecting cables and equipment other than manufacturer specified. It is the responsibility of the user to correct any interference caused by such unauthorized modification, substitution or attachment. Manufacturer and its authorized resellers or distributors will assume no liability for any damage or violation of government regulations arising from failing to comply with these guidelines. Modular Approval This device is intended only form OEM integrators under the following conditions: The antenna must be installed such that 20cm is maintained between the antenna and users, and The transmitter module may not be co-located with any other transmitter or antenna. 3 IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. End Product Labeling This transmitter module is authorized only for use in devices where the antenna may be installed such that 20 cm may be maintained between the antenna and users. The final end product must be labeled in visible area with the following: “Contains TX FCC ID: PB6-04021” End Product Manual Information The user manual for end users must include the following information in a prominent location “IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.” 4 LIMITED WARRANTY This product is warranted by manufacturer to be free from defects in material and workmanship for one (1) year from the date of purchase, unless otherwise stated. During this period if this product is found to be defective in material or workmanship, manufacturer or one of its authorized service facilities will at its option either repair or replace this product without charge, subject to the following conditions, limitations and exclusions: 1. This warranty extends to the original consumer purchaser only and is not assignable or transferable. 2. This warranty shall not apply to any product which has been subjected to misuse, abuse, abnormal use, negligence, alteration or accident, or has had its seri…

Text truncated - open the document above for the full version.

TeLLUS Group Corporation Modular Approval Request Letter August 19, 2004 Compliance Certification Services 561F Monterey Rd., Morgan Hill, CA 95037, USA To Whom It May Concern: ‘ CF Card, with the FCC ID: PB6-04021 has your authorization as a limited modular approval specific to products below: This transmitter module is authorized only for use in OEM device where the antenna may be installed such that 20cm may be maintained between the antenna and users. The requirements of the Public Notice DA-00-1407 have been met and shown on the following statements: 1. The modular transmitter must have its own RF shielding: The radio portion of this module has been shielded. Please refer to EUT Photo. 2. The modular transmitter must have buffered modulation / data inputs: The EUT has buffered data inputs, it is integrated in chip ZyDas ZD1200. 3. The modular transmitter must have its own power supply regulation: The chips IF converter and RF/IF converter which will influence the frequency radiation, have to be 3.3VDC/1.8VDC powered. The CF interface provides 3.3VDC so there are regulators in front of these chips, the part number of this regulator is AME8800A 4. The modular transmitter must comply with the antenna requirements of the Section 15.203 and 15.204(c): The EUT meets the FCC antenna requirements. The spurious emission unique antenna connector and photo of antennas are shown in the test report. 5. The modular transmitter must be tested in a stand-alone configuration: The EUT was tested in a stand-alone configuration via a Compact Flash interface to test kit. Please see section Photographs of Test Configuration in the test report, the EUT was plugged in this test kit. 6. The modular transmitter must be labeled with its own FCC ID number and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements: The EUT is complied with all FCC rules. Please refer to user’s manual for detail. 8. The modular transmitter must comply with any applicable RF exposure requirements: The EUT is complied with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Should you have any question, please don’t hesitate to ask us. Best regards, ________________________ Fred Huang TeLLUS Group Corporation Tel:886-3-578-0275 #368 Fax:886-3-578-0279 [email protected]

Compliance Certification Services Inc. Report No: 40625001 Date of Issue: August 10, 2004 Page 1 EXTERNAL PHOTOGRPHS OF EUT

TeLLUS Group Corporation Product Name: 11Mbps wireless LAN CF Card Model: F111 Label format for FCC ID: PB6-04021 Label size: 3.5cm* 3.5cm 11Mbps Wireless LAN CF Card Model: F111 FCC ID: PB6-04021 MAC:0004DB00EE2A S/N: 040700000018

Compliance Certification Services Inc. Report No: 40625001 Date of Issue: August 10, 2004 Page 2 INTERNAL PHOTOGRPHS OF EUT Compliance Certification Services Inc. Report No: 40625001 Date of Issue: August 10, 2004 Page 3 Compliance Certification Services Inc. Report No: 40625001 Date of Issue: August 10, 2004 Page 4

客 客 戶 戶 名 名 稱 稱 C C U U S S T T O O M M E E R R 承 承 認 認 書 書 A A P P P P R R O O V V A A L L S S H H E E E E T T 產 產 品 品 品 品 名 名 / / P P r r o o d d u u c c t t M M o o d d e e l l N N o o . . : : ACA7636A1XX 發 發 行 行 日 日 期 期 / / I I s s s s u u e e D D a a t t e e : : 2 2 0 0 0 0 4 4 / / 0 0 7 7 / / 0 0 6 6 承 承 認 認 日 日 期 期 / / A A p p p p r r o o v v e e d d D D a a t t e e : : A A p p p p r r o o v v e e d d b b y y c c u u s s t t o o m m e e r r : : ( ( s s i i g g n n i i n n g g o o r r s s t t a a m m p p i i n n g g h h e e r r e e ) ) □300 新竹科學園區工業東㆕路38號1F□苗栗縣竹南鎮大厝里9鄰59-12號 1F. N038. Industry E. Rd., Science- Based Industrial Pack, Hsinchu, Taiwan 300 No. 59-12, 9 Lin, Ta Tsuo Li, Chu Nan Chen, Miao Li Hsien, Taiwan, R.O.C. ： 興瑞通信 D D o o c c N N o o . . : : R R e e v v . . : : 000401001005 A3 佳邦科技股份(有)限公司 INPAQ TECHNOLOGY Co., Ltd. A-FM-19-03E

Compliance Certification Services Inc. Report No: 40625001-RP FCC ID: PB6-04021 Date of Issue: August 10, 2004 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 of 48 FCC 47 CFR PART 15 SUBPART C TEST REPORT For Tellus Group Corp CF card Model: F111 Trade Name: Tellus Prepared for Tellus Group Corp 5F, No.24-2 Industrial E.Rd.IV, Science - Based Industrial Park, Hsinchu, Taiwan, R.O.C. Prepared by Compliance Certification Services Inc. No. 81-1, Lane 210, Bade Rd. 2, Luchu Hsiang, Taoyuan Hsien, (338) Taiwan, R.O.C. TEL: 886-3-324-0332 FAX: 886-3-324-5235 Compliance Certification Services Inc. Report No: 40625001-RP FCC ID: PB6-04021 Date of Issue: August 10, 2004 Page 2 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION........................................................................................................3 2. EUT DESCRIPTION..............................................................................................................................4 3. TEST METHODOLOGY.......................................................................................................................5 3.1 EUT CONFIGURATION........................................................................................................................5 3.2 EUT EXERCISE....................................................................................................................................5 3.3 GENERAL TEST PROCEDURES.............................................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS........................................................6 3.5 DESCRIPTION OF TEST MODES...........................................................................................................6 4. INSTRUMENT CALIBRATION...........................................................................................................7 5. FACILITIES AND ACCREDITATIONS ..............................................................................................8 5.1 FACILITIES....................................................................................................................................... 8 5.2 EQUIPMENT........................................................................................................................................8 5.3 LABORATORY ACCREDITATIONS AND LISTING..................................................................................8 5.4 TABLE OF ACCREDITATIONS AND LISTINGS.......................................................................................9 6. SETUP OF EQUIPMENT UNDER TEST...........................................................................................10 6.1 SETUP CONFIGURATION OF EUT.......................................................................................................10 6.2 SUPPORT EQUIPMENT ...............................................................................................................10 7. FCC PART 15.247 REQUIREMENTS ................................................................................................11 7.1 6DB BANDWIDTH.............................................................................................................................11 7.2 PEAK POWER....................................................................................................................................15 7.3 BAND EDGES MEASUREMENT ................................................................................................19 7.4 PEAK POWER SPECTRAL DENSITY....................................................................................................20 7.5 RADIO FREQUENCY EXPOSURE........................................................................................................26 7.6 SPURIOUS EMISSIONS ................................................................................................................31 7.7 POWERLINE CONDUCTED EMISSIONS...............................................................................................44 APPENDIX 1 PHOTOGRPHS OF TEST SETUP......................................................................................47 Compliance Certification Services Inc. Report No: 40625001-RP FCC ID: PB6-04021 Date of Issue: August 10, 2004 Page 4 2. EUT DESCRIPTION Product CF card Trade Name Tell us Model Number F111 Model Discrepancy N/A Power Supply Powered from host device Frequency Range 2412 ~ 2462 MHz Transmit Power 16.77 dBm Modulation Technique DSSS (CCK; DQPSK; DBPSK) Transmit Data Rate 11Mbps(CCK) with fall back rates of 5.5, 2, and 1Mbps Number of Channels 11 Channels Antenna Specification Chip Antenna Gain: 2.5 dBi (Max) Note: This submittal(s) (test report) is intended for FCC ID: PB6-04021 filing to comply with Section 15.207, 15.209 and 15.247 of the FCC Part 15, Subpart C Rules. Compliance Certification Services Inc. Report No: 40625001-RP FCC ID: PB6-04021 Date of Issue: August 10, 2004 Page 5 3. TEST METHODOLOGY The tests documented in this report were performed in accordance with ANSI C63.4 and FCC CFR 47 2.1046, 2.1047, 2.1049, 2.1051, 2.1053, 2.1055, 2.1057, 15.207, 15.209 and 15.247. 3.1 EUT CONFIGURATION The EUT configuration for testing is installed on RF field strength measurement to meet the Commissions requirement and operating in a manner that intends to maximize its emission characteristics in a continuous normal application. 3.2 EUT EXERCISE The EUT was operated in the engineering mode to fix the TX frequency that was for the purpose of the measurements. According to its specifications, the EUT must comply with the requirements of the Section 15.207, 15.209 and 15.247 under the FCC Rules Part 15 Subpar…

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. Report No: 40625001-RP FCC ID: PB6-04021 Date of Issue: August 10, 2004 Page 47 APPENDIX 1 PHOTOGRPHS OF TEST SETUP Radiated Emission Set up Photos Compliance Certification Services Inc. Report No: 40625001-RP FCC ID: PB6-04021 Date of Issue: August 10, 2004 Page 48 Conducted Emission Set Up Photos
