PB6-2206Wireless LAN PCI Card

User Guide P120 11Mbps Wireless LAN PCI Adapter 2 INFORMATION TO USER Federal Communications Commission Statement This product has been tested and complies with the specifications for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. The antenna used for this transmitter must be installed to provide a separation distance of least 20 centimeters from all persons and must not be operating in conjunction with other antenna or transmitters. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used according to the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which is found by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment or device. Connect the equipment to an outlet other than receiver. Consult a dealer or an experienced radio/TV technician for assistance Notice: The Part 15 radio device operates on a non-interference basis with other devices operating at this frequency. Any change or modification not expressly approved by the party responsible could void the user authority to operate the device. Regulatory The wireless LAN PCI Adapter must be installed and used in strict accordance with the manufacturer instructions. This device complies with the following radio frequency and safety standards. USA - Federal Communications Commission (FCC) This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference that may cause undesired operation. Europe - R&TTE Directive This device complies with the specifications listed below: ETS 301-489 General EMC requirements for Radio equipment. ETS 300-328 Technical requirements for Radio equipment. EN60950 Safety requirements for Radio equipment. EU Countries not intend for use The ETSI version of this device is intended for home and office use in Austria, Belgium, Denmark, Finland, France (with Frequency channel restrictions). Germany, Greece, Ireland, Italy, Luxembourg, Netherlands, Portugal, Spain, Sweden and United Kingdom. The ETSI version of this device is also authorized for use in EFTA member states Iceland, Liechtenstein, Norway and Switzerland. 3 TABLE OF CONTENTS 1 INTRODUCTION ...............................................................................................................4 1.1 The 11Mbps Wireless LAN PCI Adapter ........................................................................................4 1.2 Feature ...........................................................................................................................................4 1.3 Package Contents ..........................................................................................................................4 1.4 System Requirements ....................................................................................................................5 2 NETWORK CONFIGURATION AND PLANNING.............................................................6 2.1 Wireless LAN Basic ........................................................................................................................6 2.2 Network Topology ...........................................................................................................................6 2.3 Roaming .........................................................................................................................................8 3 INSTALLING AND UN-INSTALLING THE DRIVERS AND CONFIGURATION UTILITY .9 3.1 Inserting the adapter.....................................................................................................................13 3.2 Running the Auto Driver/Utility Installation .....................................................................................9 3.3 Uninstalling the Driver and Utilty ..................................................................................................11 4 CONFIGURATION UTILITY ............................................................................................14 4.1 Using the configuration Utility .......................................................................................................14 4.1.1 Profile ...................................................................................................................................14 4.1.2 Link State .............................................................................................................................18 4.1.3 Site Survey:..........................................................................................................................19 4.1.4 Statistics...............................................................................................................................20 4.1.5 About....................................................................................................................................21 5 GLOSSARY.....................................................................................................................23 6 SPECIFICATIONS...........................................................................................................24 4 1 Introduction 1.1 The 11Mbps Wireless LAN PCI Adapter The 11Mbps Wireless LAN PCI Adapter now has a new, higher-powered antenna that provides a greater range than ever. The increased sensitivity helps filter out interference and notice to keep your signal clear. Improved error correction i…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT

(Fig. 1) FCC ID: FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4

FCC ID: PB6-2206 ADT No. 920602H02 Operational Description The transmitter of the EUT is powered by host equipment. The antenna is Dipole Antenna with SMA connector. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

FCC ID: PB6-2206 Report No.: 920602H02 ADT No. 920602H02 1 RF EXPOSURE REPORT REPORT NO.: RF920602H02 MODEL NO.: P120 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Tellus Group Corporation ADDRESS: 5F, No. 24-25, Industrial E.Rd. Iv, Science- Based Industrial Park, Hsinchu, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 81-1, Lu Liao Keng, 9 Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien, Taiwan, R.O.C. Lab Code: 200376-0 FCC ID: PB6-2206 Report No.: 920602H02 ADT No. 920602H02 2 RF Exposure Measurement 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz FCC ID: PB6-2206 Report No.: 920602H02 ADT No. 920602H02 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance 20cm. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. FCC ID: PB6-2206 Report No.: 920602H02 ADT No. 920602H02 4 6. Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber are 1.5Bi or 1.41 (numeric). 6.2 Output Power Into Antenna & RF Exposure value at distance 20cm: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241237.84430.01061.0 6243734.04080.00961.0 11246230.83190.00871.0

FCC ID: PB6-2206 Report No.: RF920602H02 1 Issued: Jun. 11, 2003 ADT No. 920602H02 FCC TEST REPORT REPORT NO.: RF920602H02 MODEL NO.: P120 RECEIVED: Jun. 02, 2003 TESTED: May 31 to Jun. 03, 2003 APPLICANT: Tellus Group Corporation ADDRESS: 5F, No. 24-25, Industrial E.Rd. Iv, Science-Based Industrial Park, Hsinchu, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: No. 81-1, Lu Liao Keng, 9 Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien, Taiwan, R.O.C. This test report consists of 52 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. Lab Code: 200376-0 FCC ID: PB6-2206 Report No.: RF920602H02 2 Issued: Jun. 11, 2003 ADT No. 920602H02 Table of Contents 1 CERTIFICATION......................................................................................................4 2 SUMMARY OF TEST RESULTS..........................................................................5 3 GENERAL INFORMATION....................................................................................6 3.1 GENERAL DESCRIPTION OF EUT.....................................................................6 3.2 DESCRIPTION OF TEST MODES.......................................................................7 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS..................................7 3.4 DESCRIPTION OF SUPPORT UNITS................................................................8 4 TEST TYPES AND RESULTS...............................................................................9 4.1 CONDUCTED EMISSION MEASUREMENT.....................................................9 4.1.1 TEST INSTRUMENTS...............................................................................................9 4.1.2 TEST PROCEDURES..............................................................................................10 4.1.3 DEVIATION FROM TEST STANDARD...................................................................10 4.1.4 TEST SETUP............................................................................................................11 4.1.5 EUT OPERATING CONDITIONS............................................................................12 4.1.6 TEST RESULTS.......................................................................................................13 4.2 RADIATED EMISSION MEASUREMENT.........................................................19 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT............................................19 4.2.2 TEST INSTRUMENTS.............................................................................................20 4.2.3 TEST PROCEDURES..............................................................................................21 4.2.4 DEVIATION FROM TEST STANDARD...................................................................21 4.2.5 TEST SETUP...........................................................................................................22 4.2.6 EUT OPERATING CONDITIONS............................................................................22 4.2.7 TEST RESULTS.......................................................................................................23 4.3 6dB BANDWIDTH MEASUREMENT.................................................................30 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT....................................................30 4.3.2 TEST INSTRUMENTS.............................................................................................30 4.3.3 TEST PROCEDURE................................................................................................31 4.3.4 DEVIATION FROM TEST STANDARD...................................................................31 4.3.5 TEST SETUP...........................................................................................................31 4.3.6 EUT OPERATING CONDITIONS............................................................................31 4.3.7 TEST RESULTS.......................................................................................................32 4.4 MAXIMUM PEAK OUTPUT POWER.................................................................36 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT......................36 4.4.2 INSTRUMENTS.......................................................................................................36 4.4.3 TEST PROCEDURES..............................................................................................37 4.4.4 DEVIATION FROM TEST STANDARD...................................................................37 4.4.5 TEST SETUP...........................................................................................................37 FCC ID: PB6-2206 Report No.: RF920602H02 3 Issued: Jun. 11, 2003 ADT No. 920602H02 4.4.6 EUT OPERATING CONDITIONS............................................................................37 4.4.7 TEST RESULTS.......................................................................................................38 4.4.8 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT..............................39 4.4.9 TEST INSTRUMENTS.............................................................................................39 4.4.10 TEST PROCEDURE................................................................................................40 4.4.11 DEVIATION FROM TEST STANDARD...................................................................40 4.4.12 TEST SETUP...........................................................................................................40 4.4.13 EUT OPERATING CONDITION...............................................................................…

Text truncated - open the document above for the full version.

Report No. 920602H02 ADT No. 920602H02 1 The Measurement of Conducted Spurious Emissions CONDUCTED SPURIOUS EMISSIONS MEASUREMENT 1. LIMITS OF CONDUCTED SPURIOUS EMISSIONS EASUREMENT Below 20dB of the highest emission level of operating band (in 100KHz Resolution Bandwidth, see Section 15.247(c)). Emissions which fall in the restricted bands, as defined in Section 15.205(a), must also comply with the limits specified in Section 15.209(a) (see Section 15.205(c)). 2. TEST INSTRUMENTS Description & Manufacturer Model No. Serial No. Calibrated Until R&S SPECTRUM ANALYZER FSP 1093.4495.30 Dec. 19, 2003 NOTE: 1.The measurement uncertainty is less than +/- 2.6dB, which is calculated as per the NAMAS document NIS81. 2.The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. 3. TEST PROCEDURE The transmitter output was connected to the spectrum analyzer via a low lose cable. Set both RBW and VBW of spectrum analyzer to 100 kHz with suitable frequency span including 100 kHz bandwidth from band edge. The band edges was measured and recorded. Report No. 920602H02 ADT No. 920602H02 2 4. TEST SETUP 5. EUT OPERATING CONDITIONS The software provided by client to enable the EUT under transmission condition continuously at lowest, middle and highest channel frequencies individually. EUT SPECTRUM ANALYZER Report No. 920602H02 ADT No. 920602H02 3 TEST RESULTS The spectrum plots are attached on the following 4 pages. It shows compliance with the requirement in part 15.247(C),.15.205 and 15.209. Report No. 920602H02 ADT No. 920602H02 4 Ch1 Report No. 920602H02 ADT No. 920602H02 5 Ch1 Report No. 920602H02 ADT No. 920602H02 6 Ch11 Report No. 920602H02 ADT No. 920602H02 7 Ch11

FCC ID: PB6-2206 Report No.: RF920602H0250Issued: Jun. 11, 2003 ADT No. 920602H02 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: PB6-2206 Report No.: RF920602H0251Issued: Jun. 11, 2003 ADT No. 920602H02 RADIATED EMISSION TEST
