PC6CF2031PCS CDMA Modem Card CF Type II

For more information about RF exposure, please visit the FCC website at www.fcc.gov FCC RF EXPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and inte rnational standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Use only the supplied or an approved antenna. Unauthor ized antennas, modifications, or attachments could impair call quality, damage the phone, or resu lt in violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged ant enna comes into contact with the skin, a minor burn may result. Please contact your local dealer for replacement antenna. Body-worn Operation This device was tested for typical body-worn operations with the back of the device kept 2. 0 cm. from the body. To maintain compliance with FCC RF exposure requirement s, use only belt-clips, holsters or similar accessories that maintain a 2. 0 cm. separation distance between the user’s body and the back of the device, including the antenna, whether extended or retracted. The use of other belt-clip/holster s and other non-tested accessories may not comply with FCC RF Exposur e requirements and should be avoided. WARNING! Read this information before using your phone Product Specifications I Technical Specifications. Technical Specifications CC-Phone Modem Approvals: 1 x RTT FCC Parts 15 and 24. Voltage: +5 Vdc from PCMCIA Slot Current: 740 mA max. Transmitter Power: 25.4dBm 0.473 EIRP Transmit: 1850 to 1910 MHz Receive: 1930 to 1990 MHz Channel Spacing: 50 kHz Freq. Stability: +I .O ppm. Environmental Specifications These specifications apply to the CC-Phone Modem PCS radio modem only, not to the accessory components. Operating Temp: -30 to +60 "C (ambient, outside PCMCIA enclosure) Storage Temp: -30 to +85 "C Hum id i ty : 95%, n on -co nd en s i n g Vibration: 15G peak 10-2000 Hz (not operating) Drop: 30" (76.2 cm) on to vinyl covered concrete Regulatory Information This device complies with Part 15 of the FCC Rules. Operation of this device is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesirable operations. FCC guidelines stipulate that the antenna should be more than 2 .0 cm (0.8”)from all persons. FCC ID: PC6CF2031 Where appropriate, the use of the equipment is subject to the following conditions: CAUTION Unauthorized modifications or changes not expressly approved by Sierra Wireless, Inc. could void compliance with regulatory rules, and thereby your authority to use this equipment. WARNING (EMI) - United States FCC Information -This equipment has been tested and found to comply with the limits pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in an appropriate installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communication. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna Increase the separation between the equipment and receiver Connect the equipment into an outlet on a circuit different from that to which the receiver is connected Consult the dealer or an experienced radioiTV technician for help WARNING (EMI) - Canada - This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the interference causing equipment standard entitled “Digital Apparatus”, ICES -003 of the Department of Communications. Cet appareil numerique respecte les limites de bruits radioelectriques applicables aux appareils numeriques de Classe B prescrites dans la norme sur le materiel brouilleur: “Appareils Numeriques”, NMB -003 edictee par le ministre des Communications. If you have purchased this product under a United States Government contract, it shall be subject to restrictions as set forth in subparagraph (c)( 1 )(ii) of Defense Federal Acquisitions Regulations (DFARs) Section 252.227 -7013 for Department of Defense contracts, and as set forth in Federal Acquisitions Regulations (FARs) Section 52.227-19 for civilian agency contracts or any successor regulations. If further government

Using the battery Your CC-Phone comes packaged with a partially charged, rechargeable Lithium battery so that you can use your CC-Phone immediately after it is activated. Installing the battery To attach the battery to your CC-Phone: 1. Hold the battery so that the metal contacts on the base of the battery line up with the metal contacts on the base of the battery pack 2. Place the battery on the back of the battery pack with the top of the battery 3. 밧데리 덮개를 밧데리 Pack 에 씌운다 . Removing the battery To remove the battery from your CC-Phone: 1. Turn the phone off. 2. Remove battery pack from CC-Phone. 3. Pull the battery release point(see illustration). Charging the battery You can tell whether or not your battery needs to be recharged by checking the indicator in the upper-right corner of your CC-Wiz. Charging with the Adapter As adapter jack is connected into battery pack, it is charged. (See picture above) The LED on the front of the Battery Pack indicate the following: 1) Red indicates that the battery is fully charged. 2) Green indicates that battery is fully charged. Using with battery pack charger, a completely discharged battery recharges fully in a approximately 2.5 hours. The empty battery icon Two or three minutes before the battery charge level gets too low to operate the phone, the battery sensor will let you know by blinking an empty battery icon( ). If you continue to operate the CC-Phone without charging, the CC-Phone will turn off automatically. © 2002 PCTEST Lab NVLAP Lab Code: 100431-0 © 2002 PCTEST Lab NVLAP Lab Code: 100431-0 © 2002 PCTEST Lab NVLAP Lab Code: 100431-0

Product Specifications I Technical Specifications. Technical Specifications CC-Phone Modem Approvals: 1 x RTT FCC Parts 15 and 24. Voltage: +5 Vdc from PCMCIA Slot Current: 740 mA max. Transmitter Power: 23.4dBm 0.473 EIRP Transmit: 1850 to 1910 MHz Receive: 1930 to 1990 MHz Channel Spacing: 50 kHz Freq. Stability: +I .O ppm. Environmental Specifications These specifications apply to the CC-Phone Modem PCS radio modem only, not to the accessory components. Operating Temp: -30 to +60 "C (ambient, outside PCMCIA enclosure) Storage Temp: -30 to +85 "C Hum id i ty : 95%, n on -co nd en s i n g Vibration: 15G peak 10-2000 Hz (not operating) Drop: 30" (76.2 cm) on to vinyl covered concrete Regulatory Information This device complies with Part 15 of the FCC Rules. Operation of this device is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesirable operations. FCC guidelines stipulate that the antenna should be more than 2 .0 cm (0.8”)from all persons. FCC ID: PC6CF2031 Where appropriate, the use of the equipment is subject to the following conditions: CAUTION Unauthorized modifications or changes not expressly approved by Sierra Wireless, Inc. could void compliance with regulatory rules, and thereby your authority to use this equipment. WARNING (EMI) - United States FCC Information -This equipment has been tested and found to comply with the limits pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in an appropriate installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communication. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna Increase the separation between the equipment and receiver Connect the equipment into an outlet on a circuit different from that to which the receiver is connected Consult the dealer or an experienced radioiTV technician for help WARNING (EMI) - Canada - This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the interference causing equipment standard entitled “Digital Apparatus”, ICES -003 of the Department of Communications. Cet appareil numerique respecte les limites de bruits radioelectriques applicables aux appareils numeriques de Classe B prescrites dans la norme sur le materiel brouilleur: “Appareils Numeriques”, NMB -003 edictee par le ministre des Communications. If you have purchased this product under a United States Government contract, it shall be subject to restrictions as set forth in subparagraph (c)( 1 )(ii) of Defense Federal Acquisitions Regulations (DFARs) Section 252.227 -7013 for Department of Defense contracts, and as set forth in Federal Acquisitions Regulations (FARs) Section 52.227-19 for civilian agency contracts or any successor regulations. If further government

261 Yangjae-dong, Seocho-ku, Seoul Korea Tel : 82-2-576-1209 Fax : 82-2-576-1065 GROWELLTELECOM July 12,2002 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 U.S.A To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory Inc., to act on our behalf in a1 matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti -Drug Abuse Act of 1988, 21 U.S.C. 853(a). Sincerely, Name : Sung Hyun Lee Title : Manager Company name : GROWELL Telecom 261 Yangjae-dong, Seocho-ku, Seoul Korea Tel : 82-2-576-1209 Fax : 82-2-576-1065 GROWELL TELECOM July 12,2002 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 U.S.A To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory Inc., to act on our behalf in a1 matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti -Drug Abuse Act of 1988, 21 U.S.C. 853(a). I Sincerely, I, Name : Sung Hyun Lee Title : Manager Company name : GROWELL Telecom 26 1 Yangjae-dong, Seocho-ku, Seoul Korea Tel : 82-2-576-1209 Fax : 82-2-576-1065 GROWELL TELECOM July 12,2002 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 2 1046 U.S.A SUBJECT : Gentlement : GROWELL TELECOM CO. LTD. FCC ID : PC6CF2031 Users Manual RF Exposure Warning Statement GROWELL TELECOM CO. LTD. Hereby confirms that attached RF exposure warning page will be Reality visible to the user, and will be placed at a prominent location in the front section of the Users manual. If you have any further questions regarding this metter, please do not hesitate to contact PCTEST Engineering Laboratory, Inc. at 4 10-290-6652 Sincerely, i Name : Sung Hyun Lee Title : Manager Company name : GROWELL Telecom 26 1 Yangjae-dong, Seocho-ku, Seoul Korea Tel : 82-2-576-1209 Fax : 82-2-576-1065 GROWELL TELECOM July 12,2002 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 U.S.A FCC ID.: PC6CF2031 Section 2.97 (a) (b)-Statement of Compliance Dear Sirs: This equipment has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that equipment complies with the appropriate standard. Each unit manufactured, imported, or marked, as defined in the commission's regulation, will conform to the samples tested within the variations that can be expected due to production and tested on a statistical basis. I further certify that the necessary measurements were made by: PCTEST Engineering Laboratory, Inc. 6660 -Bdobbin Road Columbia, MD 2 1045 Sincerely, Name : Sung Hyun Lee 'Title : Manager Company name : GROWELL Telecom 261 Yangjae-dong, Seocho-ku, Seoul, Korea Tel : 82 - 2 - 576 - 1209 Fax : 82 - 2 - 576 - 1065 Affidavit for ESN Protection The ESN(E1ectronic Serial Number) is a 32-bit binary number that uniquely indentifies the mobile station to any wireless system. The ESN must be determined in the factory and after that, this number must not be modified or duplicated to any mobile station. So we have the following methods to protect from any attempt to change the ESN. 1. In our device, the ESN is stored in non-volatile memory, the type of which is a BGA (Ball Grid Array, a surface mount chip package that uses a grid of solder balls beneath its package as connectors to PCB). So any attempt to modify the ESN through the outer -lead connections is impossible. Of course, removal of this memory will disable our device. In addition to the ESN, we have two more 32-bit validity numbers in the scattered region of the same memory. And the validity number is calculated by CRC (Cyclic Redundancy Code) Method. If any of these numbers is modified and does not match, our device will be inoperative. To read the ESN, a predetermined packet must be transferred to our device. This packet includes another CRC code. Thus anybody that does not know the packet formats cannot read at all. We do not provide any software for ESN reading, either. To write or change the ESN, three passwords must be transferred to our device via the above packets. These passwords are two 24 -bit numbers and one 32-bit number. If incorrect password is transferred, the ESN cannot be modified and our device will not take any packet for about 10 seconds. ESN writing software used in our factory can write ESN only if the ESN is the default factory value. This software is strictly administered not to be distributed to any unauthorized user. 2. 3. 4. 5. With above methods, we are able to protect illegal modification or duplication of the ESN. And we swear to make all efforts to protect illegal change of the ESN. /+ GROWELL Telecom Co. Ltd.

261 Yangjae-dong, Seocho-ku, SeoulKorea Tel : 82-2-576-1209 Fax : 82-2-576-1065 4 GROWELL TELECOM July 12,2002 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 2 1046 U.SA In re : GROWELL Telecom Co., Ltd. CDMA CF TYPE II MODEM CARD FCC ID : PC6CF2031 Part 24 Certification REQUEST FOR CONFIDENTIALITY Gentlemen : In accordancewith 0.459 of CFR 47, GROWELL Telecom Co., Ltd. Hereby requests confidentialityof The Block Diagram attachment, OperatiodCircuit Description attachment, Antenna Specification Attachment, Part List attachment, Ture -up Procedure attachment, and Schematics attachment for The above -reference Certification application. There documents contain detailed system and equipment description and related information About the product which GROWELL Telecom Co., Ltd Considers to be proprietary, confidential, and a Custom design and, otherwise, would not release to the general public. Basis fkom which hture technological products will evolve, GROWELL Telecom Co. Ltd. Feels this Information would be of benefit to its competitors, and that the disclosureof the information in These documents would give our competitors an unfair advantage in the market. Since this design is a Sincerely, Name : Sung Hyun Lee Title :Manager Companyname : GROWELL Telecom

July 11, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: GROWELL TELECOM CO., LTD. FCC ID: PC6CF2031 Part 24 Certification Gentlemen: Attached herewith, on behalf of GROWELL TELCOM CO., LTD. is an application for Part 24 Certification of the following PCS CDMA Modem Card CF Type II: FCC ID: PC6CF2031 TRADE / MODEL(s): CF2031 EUT TYPE: PCS CDMA Modem Card CF Type II Attached is the applicant’s Letter of Authorization, Confidentiality Request, measurement report data and plots, RF Exposure measurement report, FCC ID label and location, test setup photographs, internal and external photographs, block diagrams (confidential), schematic diagrams & circuit description (confidential), operational description (confidential), parts list & tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: GROWELL TELECOM CO., LTD.

August 2, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Martin Perrine SUBJECT: Growell Telecom Co., Ltd. FCC ID: PC6CF2031 731 Confirmation No.: TC217967 Request for Tech. Info.: 8/21/2002 Dear Martin: Per our conversation, transmitted herewith, on behalf of Growell Telecom Co., Ltd., is an amendment provided in response to the request for technical information dated August 21, 2002. 1. Attached is the test data and photo for the PCS CDMA Type II CF Modem Card. The EUT was tested with the Panasonic CF-72 Notebook PC in the lap position. If you have any further questions, please do not hesitate to contact us. cc: Growell Telecom Co., Ltd.

September 19, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Stan Lyles SUBJECT: Growell Telecom Co., Ltd. FCC ID: PC6CF2031 731 Confirmation No.: TC217967 Request for Tech. Info.: 8/23/2002 Correspondence Ref. Num.: 4955 Dear Stan: Per our conversation, transmitted herewith, on behalf of Growell Telecom Co., Ltd., is an amendment provided in response to the request for technical information dated August 23, 2002. 1. This model is electrically identical to the previous model: ( FCC ID: PC6CF-2031) except a slight change in the PC board and has been upgraded to accommodate other host PC’s. Please find attached the amended EMC portion of the report. 2. The reference to the Sierra Aircard was for the software driver for the device. This is because the manufacturer of the RF part is Sierra Wireless. 3. Photos of the battery pack are attached. Since the EUT contains a transmitter the battery pack is used to extend the talk/text time. 4. Growell has confirmed that the users manual has 2 pages per page shown. Please note that this manual is preliminary and contains all the pages that Growell has provided to PCTEST. 5. Yes, the SAR setup photo is applicable for device in a laptop. Please find attached a revised SAR set photo with the laptop. 6. Attached is the test data and photo for the PCS CDMA Type II CF Modem Card. The EUT was tested with the Panasonic CF-72 Notebook PC in the lap position. 7. Please note that a Class II Permissive change will be filed to the FCC within 30 days to remove the single host condition on the grant. If you have any further questions, please do not hesitate to contact us. cc: Growell Telecom Co., Ltd.

October 30, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Stan Lyles SUBJECT: Growell Telecom Co., Ltd. FCC ID: PC6CF2031 731 Confirmation No.: TC217967 Request for Tech. Info.: 10/01/2002 Correspondence Ref. Num.: 5322 Dear Stan: Transmitted herewith, on behalf of Growell Telecom Co., Ltd., is an amendment provided in response to the request for technical information dated October 1, 2002. These questions were addressed in the Class II Permissive Change (EA127671). If you have any further questions, please do not hesitate to contact us. cc: Growell Telecom Co., Ltd.

November 14, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Stan Lyles SUBJECT: Growell Telecom Co., Ltd. FCC ID: PC6CF2031 731 Confirmation No.: TC217967 Request for Tech. Info.: 11/01/2002 Correspondence Ref. Num.: 5675 Dear Stan: Transmitted herewith, on behalf of Growell Telecom Co., Ltd., is an amendment provided in response to the request for technical information dated October 1, 2002. 1. Please find updated User’s Manual with revised RF warning statement. 2. Please also note that the grant condition has been revised according to your email dated October 1, 2002 Correspondence Ref. Number: 5322. If you have any further questions, please do not hesitate to contact us. cc: Growell Telecom Co., Ltd.

© 2002 PCTEST Lab GROWELL TELECOM FCC ID: PC6CF2031 PCS CDMA Modem Card CF Type II Model: CF2031 © 2002 PCTEST Lab GROWELL TELECOM FCC ID: PC6CF2031 PCS CDMA Modem Card CF Type II Model: CF2031 © 2002 PCTEST Lab GROWELL TELECOM FCC ID: PC6CF2031 PCS CDMA Modem Card CF Type II Model: CF2031 © 2002 PCTEST Lab GROWELL TELECOM FCC ID: PC6CF2031 PCS CDMA Modem Card CF Type II Model: CF2031 © 2002 PCTEST Lab GROWELL TELECOM FCC ID: PC6CF2031 PCS CDMA Modem Card CF Type II Model: CF2031

© 2002 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) FCC LABEL GROWELL Telecom Model : CF-2031, YM-2031 U FCC ID: PC6CF2031 Serial No : (Pre-Production) Develop men t : GROWELL Telecom Tested to comply With FCC Standards MADE IN KOREA GROWELL TELECOM Co., Ltd. FOR HOME OR OFFICE USE

© 2002 PCTEST Lab GROWELL TELECOM FCC ID: PC6CF2031 PCS CDMA Modem Card CF Type II Model: CF2031 © 2002 PCTEST Lab GROWELL TELECOM FCC ID: PC6CF2031 PCS CDMA Modem Card CF Type II Model: CF2031 © 2002 PCTEST Lab GROWELL TELECOM FCC ID: PC6CF2031 PCS CDMA Modem Card CF Type II Model: CF2031 © 2002 PCTEST Lab GROWELL TELECOM FCC ID: PC6CF2031 PCS CDMA Modem Card CF Type II Model: CF2031

1900MHz Brain Dipole Validation SAM Phantom; Flat Section; Probe:ET3DV6 - SN1677; ConvF(5.30,5.30,5.30) Med. Parameters 1900 MHz Brain: σ = 1.43 mho/m ε r = 41.0 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 10.1 mW/g, SAR (10g): 5.22 mW/g 1900MHz Brain Dipole Validation (D1900V2 S/N: 502) Frequency: 1900 MHz; Antenna Input Power: 250 [mW]; Ambient Temp. = 22.4°C / Meas. Tissue Temp. = 22.2°C PCTEST Brain Tissue Simulating Liquid [07/05/2002] SAR Tot [mW/g] 9.87E-1 2.96E+0 4.93E+0 6.91E+0 8.88E+0 PCTEST Engineering Laboratory, Inc.

© 2002 PCTEST Lab GROWELL TELECOM FCC ID: PC6CF2031 PCS CDMA Modem Card CF Type II Model: CF2031 © 2002 PCTEST Lab GROWELL TELECOM FCC ID: PC6CF2031 PCS CDMA Modem Card CF Type II Model: CF2031 © 2002 PCTEST Lab GROWELL TELECOM FCC ID: PC6CF2031 PCS CDMA Modem Card CF Type II Model: CF2031 © 2002 PCTEST Lab GROWELL TELECOM FCC ID: PC6CF2031 PCS CDMA Modem Card CF Type II Model: CF2031 © 2002 PCTEST Lab GROWELL TELECOM FCC ID: PC6CF2031 PCS CDMA Modem Card CF Type II Model: CF2031 © 2002 PCTEST Lab GROWELL TELECOM FCC ID: PC6CF2031 PCS CDMA Modem Card CF Type II Model: CF2031

PCTEST ENGINEERING LABORATORY, INC. 6660 — B Dobbin Road • Columbia, MD 21045 • USA Telephone 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com (email: [email protected]) CERTIFICATE OF COMPLIANCE (SAR EVALUATION) PCTEST SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR-220620351.PC6 Test Dates: July 5-8, 2002 EUT Type: PCS CDMA CF Card Type II FCC ID: PC6CF2031 Page 1 of 22 © 2002 PCTEST Engineering Laboratory, Inc APPLICANT NAME & ADDRESS: DATE & LOCATION OF TESTING: GROWELL TELECOM CO., LTD. Dates of Tests: July 5-8, 2002 319-8, Gasan-dong, Geumcheon-ku Test Report S/N: 15.220620351.PC6 Seoul, KOREA 153-802 Test Site: PCTEST Lab, Columbia MD Attn: Mr. Sung Hyun Lee, Wireless Comm. Lab Senior Engineer FCC ID: PC6CF2031 APPLICANT: GROWELL TELECOM EUT Type: PCS CDMA Modem Card CF Type II Tx Frequency: 1851.25 — 1908.75 MHz (PCS CDMA) Rx Frequency: 1931.25 — 1988.75 MHz (PCS CDMA) Max. RF Output Power: 0.473 W EIRP PCS CDMA (26.751 dBm) (23.4 dBm conducted) Max. SAR Measurement: 0.615mW/g PCS Body SAR Trade Name/Model(s): CF2031 FCC Classification: Part 24 Licensed Portable Transmitter worn on body (PCT) FCC Rule Part(s): §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] Application Type: Certification Test Device Serial No.: identical prototype This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528-200X (Draft 6.4, July 2001). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 220401146.A3L PCTEST SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR-220620351.PC6 Test Dates: July 5-8, 2002 EUT Type: PCS CDMA CF Card Type II FCC ID: PC6CF2031 Page 2 of 22 © 2002 PCTEST Engineering Laboratory, Inc TABLE OF CONTENTS 1. INTRODUCTION .................................................................................................. 3 SAR DEFINITION ................................................................................................. 3 2. SAR MEASUREMENT SETUP .................................................................................. 4 Robotic System ....................................................................................................... 4 System Hardware ................................................................................................... 4 System Electronics .................................................................................................. 4 3. DASY3 E-FIELD PROBE SYSTEM ............................................................................ 5 Probe Measurement System.................................................................................... 5 Probe Specifications ............................................................................................... 5 4. Probe Calibration Process....................................................................................... 6 Dosimetric Assessment Procedure .......................................................................... 6 Free Space Assessment ........................................................................................... 6 Temperature Assessment ........................................................................................ 6 5. PHANTOM & EQUIVALENT TISSUES .................................................................... 6 SAM Phantom ........................................................................................................ 7 Brain & Muscle Simulating Mixture Characterization ............................................. 7 Device Holder for Transmitters............................................................................... 7 6. TEST SYSTEM SPECIFICATIONS ............................................................................. 8 Automated Test System Specifications .................................................................... 8 7. DOSIMETRIC ASSESSMENT & PHANTOM SPECS ................................................. 9 Measurement Procedure......................................................................................... 9 Specific Anthropomorphic Mannequin (SAM) Specifications.................................. 9 8. DEFINITION OF REFERENCE POINTS ................................................................. 10 EAR Reference Point............................................................................................. 10 Handset Reference Points ..................................................................................... 10 9. TEST CONFIGURATION POSITIONS .................................................................. 11 Positioning for Cheek/Touch ................................................................................ 11 Positioning for Ear / 15° Tilt .......................................................................…
