PCMCUBE2MP3 Player

Test Report No.: GETEC-E3-06-027 FCC Class B Certification EUT Type: MP3 Player FCC ID : PCMCUBE2 APPENDIX H : USER’S MANUAL CUBE-2 Manual SRS is a registered trademark of SRS Labs. WOW Technology is an intellectual property of SRSLabs. 1 View Index 1 - Special Features 3 - Technical Specifications 4 - Accessories 5 - Part Specifications 7 - Buttons 8 - Recharging 9 - Connecting to a PC 10 - Disconnecting 12 - Power ON/OFF 13 - Play Menu 14 - Play/ Pause 15 - Music Selection 16 - Voice Recording 18 - FM Radio Function FCC RF INTERFERENCE STATEMENT Warranty Card 1 Worlds smallest Mp3 Player Super compact size (24*24*24mm) and weighs only 18 grams.A fully featured MP3/audio player that fits in the palm of you hand! COLOR OLED Display COLOR OLED Display combined with blue letters brings new beauty to the unit. COLOR OLED provides superior sharpness, brilliance and easy to read display. Five Preset EQ modes plus one User-set EQ mode Features 5 preset equalization modes; Normal/ Rock/ Jazz/ Classic/ Pop and you can also customize equalization to suit your sound. File Navigation System and Unlimited Folder Capacity The player can play MP3 files saved in multiple folders. Those files and folders can be selected and played as if in a Windows environment. Easy & Convenient Clock Built in clock keeps you on time. Special Features SRS Function 3D surrounding and superior Base enhances your music listening experience. 2 PC Peripheral Device By connecting the product to PC, the Windows system automatically recognizes it as a removable disk. No additional software needed. It can also be used as storage for other types of files. FM Radio receptor and recorder Enjoy FM radio listening as well as digital music files (MP3/WMA). It can also record your FM programming which allows you to listen to it over and over or to save it on your PC. Built-in Lithium-Polymer Battery No extra battery or recharger is required. This advanced battery system is easily recharged by connecting into the USB port on your PC. Resume Function in Second Unit Settings are automatically restored when the unit is powered ON in case of sudden power down. Firmware Upgradeable Firmware is easily upgradeable to new features and functions. Special Features Voice Recorder & Music Recorder Built in high quality microphone allows you to record your voice. 3 Technical Specifications Functions FM Tuner Audio Supporting Files Max. Running Time Operating Temperature Size (W HD) Weight Battery (Built-in) USB FM Frequency Range Headset Output S/N Ratio Antenna Frequency Characteristics Headset Output S/N ratio File format Bit Rate Download speed 25Mbps (USB Ver 2.0) 10 Hr -5~70 25.2 X 25.2 X 25.2 (mm) 18 (g) Li-Polymer 87.5 MHz~108.0MHz/ 76.0MHz~108.0MHz Max. 7mW (16 ) Max Volume 50dB Headset/earphone antenna 20Hz ~ 20KHz Max. 15mW (16 ) Max Volume 90dB MP3, WMA, WMA DRM MP3 : 8~320Kbps, WMA : 32~192Kbps ItemsSpecifications Recording Time 520min voice recording(256MB, 64Kbps Recording Mode) 4 Accessories USB / Charging Cable Necklace Earphone Cube Crate Protective Case Users Manual Program CD Illustrations may be different from the actual product. Accessories shown below may be different from purchased products to improve quality of the unit. 5 Part Specifications LCD screen Necklace Link pin Reset button/MIC Earphone jack/ USB jack Front TopBottom 6 Part Specifications Power/ Play/ Pause FF/ REW/ VOL+/ VOL- MENU/ Navigation Hold/ Clock button A-B Repeat button Sides 7 Buttons Power ON/OFF File Play/ Pause Move to Submenu/ Menu Set-value Save Volume Up/Down Move to Navigation sub/preceding folder or file Move into Menu/ Navigation Mode Move to preceding Menu Hold Clock View A-B Repeat Searching Previous/Next File Move to Left/Right Menu Move to Navigation sub/preceding Folder 8 Recharging To recharge the battery use the USB cable to connect the unit to the PC. It takes approx 3 hours to completely recharge a fully discharged battery. Recharging is not interrupted while downloading/uploading files from/to PC. Recharge the product using USB cable when LCD screen is not activated. Note! 9 Connecting to a PC USB Cable Connection Connect one end of the cable into a USB port on the back of your PC and the other end to the earphone jack of the DAH-1500i. What is USB (Universal Serial Bus)? This is a new connection system between PC and peripheral devices. Connect the USB cable supplied with the product into a USB port in PC. Any unexpected error can happen when connecting to the USB port in front of PC or USB hub. Windows version 98SE or lower will not detect the DAH-1500i as a peripheral device. To have your PC detect the player Install the Program CD supplied. Note! 10 Disconnecting Windows ME, 2000 and XP Operating Systems Double click on the green arrow on the right-bottom part of the initial Window screen. Click on Stopand OKafter selecting USB High Capacity Storage Device 1 2 Double Click Click Click 11 Disconnecting Click OKon Safe To Remove Hardwarewindow and remove the cable. 3 Open “My Computer” or Windows “Search”. Select “Removable Disk”. Using the right mouse button select “Remove”. Remove the USB cable. Disconnecting with Windows 98SE Removing the cable without following the instructions above will display a warning message and may cause a fatal error in PC or the product. Removing the cable while downloading or uploading files, or while formatting files may cause a fatal error in PC or the product. Click Click Note! 12 Power ON/OFF Turn Power ON Press and hold the play/pause button to turn the power on. When the battery needs recharging the LCD will display the Battery Lowicon. Recharge the battery when LCD is not activated. Turning Power OFF When no button manipulation in pause condition is done after the set period of time for “Auto Power Off,” it automatically turns off the power. When you try to play a file after the restarting of the product, it completely recovers all previous setting. All track numbers, equalizer and other settings…
