PCMDAH-1800MP3 Player

D A N G E R DANGER

Block Diagram CPU 12Mhz OLED 96*96 Key Pannel Nand Flash Line-in Earphone Mic FM 32.768Mhz USB2.0 Power USB2.0CHIP 12Mhz Nor Flash Codec SDRAM128Mbit

ID Label Sample & Location Imformation Hyun Won Inc. DAH-1800 / 256MB FCC ID : PCMDAH-1800 BATT : Li-Polymer MADE IN KOREA

IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 05-IST-0339 1 of 24 Certification of Compliance CFR 47 Part 15 Subpart B Test Report File No. : 05-IST-0339 Date of Issue : October 26, 2005 Model(s) : DAH-1800 Kind of Product : MP3 PLAYER FCC ID : PCMDAH-1800 Applicant : Hyun Won Inc. Address : 333-1, Shindae-Ri, Kumho-Eup, Youngcheon-City, Kyoungbuk, South Korea Manufacturer : Hyun Won Inc. Address : 333-1, Shindae-Ri, Kumho-Eup, Youngcheon-City, Kyoungbuk, South Korea Test Result ■ Positive □ Negative Reviewed By Approved By S.J.CHO / EMC Group Manager J.H.LEE / Chief Comment(s) - Investigations requested : Measurement to the relevant clauses of FCC rules and regulations Part 15 Subpart B – Unintentional Radiators, Class B. - The test report with appendix consists of 24 pages. - The test result only responds to the tested sample. - It is not allowed to copy this report even partly without the allowance of IST EMC Laboratory. - This equipment as for has been shown to be capable of continued compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4 2003. IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 05-IST-0339 2 of 24 TABLE OF CONTENTS Table of contents 2 Information of test laboratory, Environmental conditions, Power used, Product information 3 Descriptions of test Conducted Emission 4 Radiated Emission 5 Measurement Uncertainty Calculations 6 Equipment Under Test 7 Test Set-Up (Figure) 8 Summary 9 ■ Test Conditions and Data - Emissions ◆ Conducted Emissions 0.15MHz - 30MHz Applicable Test Conditions / Data and Plots 10-12 ◆ Radiated Emissions 30MHz - 1GHz Applicable Test Conditions / Data and Plots 13-19 Appendix A. The Photos of Test Setup 20-22 B. The Photos of Equipment Under Test 23-24 Note: IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 05-IST-0339 3 of 24 INFORMATIONS OF TEST LABORATORY EMC LABORATORY of IST Co., Ltd. (FCC Filing Lab.) San 21-8, Goan-Ri, Baekam-Myun, Yongin-City Kyonggi-Do, 449-860, Korea TEL : +82 31 333 4093 FAX : +82 31 333 4094 ENVIRONMENTAL CONDITIONS Temperature 22 °C Humidity 54 % Atmospheric pressure 1014 mbar POWER SUPPLY SYSTEM USED Power supply system AC 120Vac, 60Hz(PC Power) (Refer to the product information) PRODUCT INFORMATION The Equipment Under Test(EUT) is MP3 PLAYER of Hyun Won Inc. (FCC ID : PCMDAH-1800) FM Frequency Range : 76MHz ~ 108.0MHz Headset Output(FM Tuner) : Left 7mW + Right 7mW(16Ω) Max.Volume S/N ratio(FM Tuner) : 50dB Antenna : Headset/Earphone code antenna Frequency Characteristic : 20Hz ~ 20KHz Headset Output(Audio) : Left 20mW + Right 20mW(16 Ω ) Max.Volume S/N ratio(Audio) : 90dB File Type : MP3, WMA, OGG, WAV, ASF, JPEG, MPEG4 Bit Rate : MP3(8Kbps ~ 320Kbps, VBR), WMA(32 ~ 192Kbps) OGG(Q-1 ~ Q10), WAV(MS-ADPCM) USB Download Speed : 40Mbps Recording hours : 1040 minutes for voice recording (with 256MB and based on 32Kbps) Max. Playback hours : Audio(approx. 12hours) Video(approx. 3hours) Operational Temperature : -5 °C ~ 70 °C Display : 65000 Color OLED Size(W x H x D mm) : 58 x 28 x 22 Weight(g) : 35(Battery inclusive) Battery : Lithium Polymer(built – in type) - EMC suppression device is not used during the test . - Please refer to user’s manual. IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 05-IST-0339 4 of 24 < Concept Drawing > 215 >150 >40 80 Receiver EUT LISN 80 ≥ 80 80 40 ≥ 80 Measuring apparatus Mains Filter Mains Rear side Equipment under test Coaxial cable Artificial mains networ k Screened room Non-metallic support 80 DESCRIPTIONS OF TEST Conducted Emissions: The measurement were performed over the frequency range of 0.15MHz to 30MHz using a 50 Ω /50uH LISN as the input transducer to a Spectrum Analyzer or a Field Intensity Meter. The measurements were made with the detector set for "Peak" amplitude within a bandwidth of 10KHz or for "quasi-peak" & “Average” within a bandwidth of 9KHz. - Procedure of Test The line-conducted facility is located inside a shielded room No.1. A 1m X 1.5m wooden table 80cm height is placed 40cm away from the vertical wall and 1.5m away from the other wall of the shielded room. The R/S ESH3 and Hyup-Rip KNW-407 LISN are bonded to bottom of the shielded room. The EUT is located on the wooden table with distance more than 80cm from the LISN and powered from the EMCO LISN .The peripheral equipment is powered from the other LISN. Power to the LISNs are filtered by a noise cut power line filters. All electrical cables are shielded by braided tinned steel tubing with inner φ 1.2cm. If the EUT is a DC-powered device, power will be derived from the source power supply it normally will be powered from and this supply lines will be connected to the EMCO LISN. All interconnecting cables more than 1m were shortened by non-inductive bundling to a 1m length. Sufficient time for the EUT, support equipment, and test equipment was allowed in order for them to warm up to their normal operating conditions. The RF output of the LISN was connected to the R/S receiver to determine the frequency producing the maximum emission from the EUT. The frequency producing the maximum level was reexamined using Quasi-Peak mode by manual measurement, after scanned by automatic Peak mode for frequency range from 0.15 to 30MHz. The bandwidth of the receiver was set to 10kHz. The EUT, peripheral equipment, and interconnecting cables were arranged and manipulated to maximize each EME emission. < Side View > IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 05-IST-0339 5 of 24 DESCRIPTION OF TEST Radiated Emissions: The measurement was performed over the frequency range of 30MHz to 1GHz using antenna as the input transducer to a Spectrum analyzer or a Field Intensity Meter. The measurement was made with the detector set for "quasi-peak" within a bandwidth of 120KHz. - Procedure of Test Preliminary measurements were made at 3 meter using bi-conical and log-periodic antennas, and spectrum analyzer to determine the frequ…
