DRAFT User Guide Nokia Lumia xxxx Issue 1.0 EN DRAFT Psst... This guide isn't all there is... There's a user guide in your phone – it's always with you, available when needed. On the start screen, swipe left, and tap Nokia Care. Check out the videos at www.youtube.com/NokiaSupportVideos. For info on Nokia Service terms and Privacy policy, go to www.nokia.com/privacy. © 2013 Nokia. All rights reserved. 2 DRAFT Contents Safety 5 Get started 6 Keys and parts 6 Back, start, and search key 6 Insert the SIM card 7 Remove the SIM card 8 Antenna locations 9 Charge your phone 9 First start-up 12 Lock the keys and screen 15 Connect the headset 16 Change the volume 17 Icons shown on your phone 17 Basics 19 Get to know your phone 19 Personalise your phone 24 Take a screenshot 29 Extend battery life 30 Save on data roaming costs 32 Write text 32 Scan codes or text 37 Clock 37 SkyDrive 39 Nokia account 40 Store 40 People & messaging 43 Calls 43 Contacts 45 Social networks 48 Messages 50 Mail 54 Camera 60 Camera basics 60 Advanced photography 63 Photos and videos 66 Maps & navigation 71 Switch location services on 71 HERE Maps 71 HERE Drive+ 76 Positioning methods 80 Internet 82 Define internet connections 82 Web browser 83 Search the web 85 Close all internet connections 85 Entertainment 86 Watch and listen 86 FM radio 87 Nokia Music 88 Sync music and videos between your phone and computer 90 Games 91 Office 93 Microsoft Office Mobile 93 Write a note 96 Continue with a document on another device 96 Calendar 97 Make a calculation 98 Use your work phone 98 Tips for business users 98 User Guide Nokia Lumia xxxx © 2013 Nokia. All rights reserved. 3 DRAFT Phone management & connectivity 101 Keep your phone up to date 101 Use a high speed connection 102 Wi-Fi 102 NFC 103 Bluetooth 106 Memory and storage 107 Copy content between your phone and computer 108 Security 109 Wallet 111 Access codes 112 Troubleshooting and support 114 Find your model number and serial number (IMEI) 116 Product and safety information 117 © 2013 Nokia. All rights reserved. 4 DRAFT Safety Read these simple guidelines. Not following them may be dangerous or illegal. SWITCH OFF IN RESTRICTED AREAS Switch the device off when mobile phone use is not allowed or when it may cause interference or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or blasting areas. Obey all instructions in restricted areas. ROAD SAFETY COMES FIRST Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety. INTERFERENCE All wireless devices may be susceptible to interference, which could affect performance. QUALIFIED SERVICE Only qualified personnel may install or repair this product. BATTERIES, CHARGERS, AND OTHER ACCESSORIES Use only batteries, chargers, and other accessories approved by Nokia for use with this device. Third-party chargers that comply with the IEC/EN 62684 standard, and that can connect to your device micro USB connector, may be compatible. Do not connect incompatible products. KEEP YOUR DEVICE DRY Your device is not water-resistant. Keep it dry. GLASS PARTS The device screen is made of glass. This glass can break if the device is dropped on a hard surface or receives a substantial impact. If the glass breaks, do not touch the glass parts of the device or attempt to remove the broken glass from the device. Stop using the device until the glass is replaced by qualified service personnel. PROTECT YOUR HEARING To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use. © 2013 Nokia. All rights reserved. 5 DRAFT Get started Get to grips with the basics, and have your phone up and running in no time. Keys and parts Explore the keys and parts of your new phone. 1SIM door key 2Micro-SIM holder 3Connector for headphones and loudspeakers (3.5 mm) 4Light sensor 5Front camera 6Volume keys 7Power/Lock key 8Camera key 9Search key 10Start key 11Back key 12Camera flash 13Camera lens 14Wireless charging connectors 15Wrist strap hole 16Micro-USB connector 17Loudspeaker Back, start, and search key The back, start, and search keys help you navigate your phone. •To switch between open apps, press and hold , swipe left or right, and tap the app you want. •To go back to the previous screen you were in, press . Your phone remembers all the apps and websites you've visited since the last time your screen was locked. •To go to the start screen, press . The app you were in remains open in the background. •To control your phone with your voice, press and hold , and say a voice command. © 2013 Nokia. All rights reserved. 6 DRAFT This feature is not available in all languages. For more info on feature and service availability, see the How-to section at www.windowsphone.com. •To search the web, press . Insert the SIM card Read on to learn how to insert a SIM card into your phone. Important: This device is designed to be used with a mini-UICC SIM card, also known as a micro- SIM card only. A micro-SIM card is smaller than the standard SIM card. Use of incompatible SIM cards, or use of SIM card adapters, may damage the card or the device, and may corrupt data stored on the card. Tip: Use the SIM door key to unlock the SIM holder. If you lose the key, you can use a paperclip. Make sure the phone is switched off. 1. Push the key into the hole until the holder is released. 2. Pull the holder out. © 2013 Nokia. All rights reserved. 7 DRAFT 3. Make sure the contact area is facing up, and put the card in the holder. 4. Push the holder back into your phone until it locks into place. Remove the SIM card Got a new SIM card? Learn how to remove the previous card from your phone. 1. Switch the phone off. 2. Unlock and pull out the holder. 3. Pull the card out of the holder. © 2013 Nokia. All rights reserved. 8 DRAFT Antenna locations Learn…
