PDNRM-807GSM/WCDMA cellular telephone w/BT, WLAN, FMTx and NFC

Nokia 808 PureView User Guide Issue 1 Contents Safety5 Get started7 Keys and parts7 Insert the SIM card7 Insert a memory card9 Charge the battery11 Switch the phone on or off12 Lock or unlock the keys and screen 13 Change the volume of a call, song, or video13 Nokia account14 Copy contacts or photos from your old phone14 Antennas15 Headset15 About NFC16 Activate NFC17 Connect to a Bluetooth accessory using NFC17 Switch the flashlight on or off 17 Attach a wrist strap or lanyard17 Use the user guide in your phone18 Basic use18 Use the toolbar18 Touch screen actions18 Use shortcuts21 Switch between open applications21 Write text22 Display indicators25 Set your phone to blink for missed calls or messages27 Flashlight27 Search your phone and the internet 28 Use your phone offline28 Prolong battery life28 Restore original settings30 Camera and photos30 About the camera30 Change the shooting mode31 Take photos32 Record videos33 Save location info to your photos and videos35 Send a photo or video35 Send a photo or other content to another phone that supports NFC36 Share a photo or video directly from the camera37 Set where to save photos and videos 38 Photos38 Personalisation and Nokia Store 43 Profiles43 Change your theme45 Home screen45 Organise your apps48 Nokia Store48 Telephone51 Use your T-coil hearing aid with your phone51 Call a phone number51 Switch the loudspeaker on during a call51 Search for a contact from the dialler 52 Turn to silence your phone52 Call a contact53 Answer a waiting call53 Make a video call54 Answer a video call54 Decline a video call55 Make a conference call55 Call the numbers you use the most56 Use your voice to call a contact56 Call the last dialled number57 Record a phone conversation57 View your missed calls57 Call your voice mailbox 58 2Contents Forward calls to your voice mailbox or another phone number58 Prevent making or receiving calls59 Allow calls only to certain numbers59 Contacts60 About Contacts60 Save phone numbers and mail addresses60 Save a number from a received call or message60 Contact your most important people quickly61 Add your important contacts to the home screen61 Add a photo for a contact62 Set a ringtone for a contact62 Create a contact group62 Send a message to a group of people62 Send your contact information using My Card63 Copy contacts from the SIM card to your phone63 Back up your contacts to Nokia services63 Social networks64 About Social64 See your friends' status updates in one view64 Post your status to social networking services65 Link your online friends to your contacts list65 See your friends' status updates on the home screen65 Upload a photo or video to a service 65 Share your location in your status update66 Contact a friend from a social networking service66 Add an event to your phone calendar 67 Messages67 About Messaging67 Send a message67 Read a received message68 Send an audio message69 Change the writing language69 Mail69 About Mail69 Add a mailbox70 Read a received mail70 Send a mail71 Respond to a meeting request72 Open mail from the home screen72 Internet73 About the web browser73 Browse the web73 Add a bookmark74 Subscribe to a web feed74 Allow a website to use your location info74 Access an online service using NFC75 Entertainment75 Music player75 About Nokia Music77 Record sounds78 Play music through a radio78 FM radio79 Play a game with a friend using NFC 81 Pay with your phone81 Videos82 Watch Web TV83 Connect to a high definition system 84 Stream content wirelessly85 Maps87 About Maps apps87 Navigate to your destination88 Contents3 Find and view locations92 Save and share places96 Report incorrect map information98 Clock and calendar99 Clock99 Calendar101 Office103 Quickoffice103 Read PDF documents105 Use the calculator105 Write a note106 Translate words106 Open or create zip files107 Connectivity107 Internet connections107 Keep track of your data traffic108 Wi-Fi 108 VPN connections110 Close a network connection110 Bluetooth111 USB data cable114 Phone management116 Keep your phone software and applications up to date116 Manage files117 Free up phone memory119 Manage applications120 Synchronise content120 Copy contacts or pictures between phones122 Protect your phone122 Prepare your phone for recycling124 Find more help124 Support124 Access codes125 Protect the environment126 Save energy126 Recycle126 Product and safety information126 Index133 4Contents Safety Read these simple guidelines. Not following them may be dangerous or illegal. For further information, read the complete user guide. SWITCH OFF IN RESTRICTED AREAS Switch the device off when mobile phone use is not allowed or when it may cause interference or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or blasting areas. Obey all instructions in restricted areas. ROAD SAFETY COMES FIRST Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety. INTERFERENCE All wireless devices may be susceptible to interference, which could affect performance. QUALIFIED SERVICE Only qualified personnel may install or repair this product. BATTERIES, CHARGERS, AND OTHER ACCESSORIES Use only batteries, chargers, and other accessories approved by Nokia for use with this device. Third-party chargers that comply with the IEC/EN 62684 standard, and that can connect to your device micro USB connector, may be compatible.Do not connect incompatible products. KEEP YOUR DEVICE DRY Your device is not water-resistant. Keep it dry. GLASS PARTS The device screen is made of glass. This glass can break if the device is dropped on a hard surface or receives a substantial impact. If the glass breaks, do not touch the glass parts of the device or attempt to remove the broken glass from the device. Stop using the device until the glass is replaced by qualified service personnel. Safety5 PROTECT YOUR HEARING Listen to a headset at a moderate level, and d…

Text truncated - open the document above for the full version.

NOKIA CORPORATION Yrttipellontie 6 90230 OULU FINLAND Tel. +358 7180 08000 Fax. +358 7180 48460 April 19, 2012 Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD. 21046 Attention: Equipment Authorization Branch REQUEST FOR CONFIDENTIALITY Pursuant to Sections 0.457 (d) (l) (ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of some of the information accompanying this Application of FCC ID: PDNRM-807 and as outlined below: - Exhibit 4: Block Diagram - Exhibit 5: Schematic Diagrams - Exhibit 12: Theory of Operation / Description of Circuitry These materials contain trade secrets and proprietary information not customarily released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457 (d) (l) (ii) disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. NOKIA CORPORATION Kare Oksanen Product Certification Officer CTO/PCC, Oulu

CONFIDENTIAL 16 April 2012 External Photographs FCC ID:PDNRM-807 IC: 661R-RM807 Exhibit 3 Applicant: Nokia Corporation Copyright © 2011 Nokia. All rights reserved. CONFIDENTIAL 16 April 2012 External Photographs FCC ID:PDNRM-807 IC: 661R-RM807 Exhibit 3 Applicant: Nokia Corporation Copyright © 2011 Nokia. All rights reserved. CONFIDENTIAL 16 April 2012 External Photographs FCC ID:PDNRM-807 IC: 661R-RM807 Exhibit 3 Applicant: Nokia Corporation Copyright © 2011 Nokia. All rights reserved.

Exhibit 01: Type Label FCC ID: PDNRM-807 IC: 661R-RM807 Applicant: Nokia Corporation Copyright c 2012 Nokia. All rights reserved 03 February 2012 EXTRA STICKER SPACE 30x12mm MADE IN XXXXXX Type: RM-807 1234567 Code: 123456789012345 IMEI: Nokia Corporation FCC ID:PDNRM-807 IC:661R-RM807 Model: FCC ID:PDNRM-807 IC:661R-RM807 MADE IN XXXXXX Type: RM-807 1234567 Code: 123456789012345 IMEI: Nokia Corporation FCC ID:PDNRM-807 IC:661R-RM807 Model: SCALE 1:1 EXTRA STICKER SPACE 30x12mm Exhibit 01: Type Label FCC ID: PDNRM-807 IC: 661R-RM807 Applicant: Nokia Corporation 03 February 2012 SCALE 2:1 SCALE 1:1 MADE IN XXXXXX Type: RM-807 1234567 Code: 123456789012345 IMEI: Nokia Corporation FCC ID:PDNRM-807 IC:661R-RM807 Model: MADE IN XXXXXX Type: RM-807 1234567 Code: 123456789012345 IMEI: Nokia Corporation FCC ID:PDNRM-807 IC:661R-RM807 Model: Copyright c 2012 Nokia. All rights reserved

Nokia ____________________________________________________________________________ SAR Report FCC_RM-807_03 Applicant: Nokia Corporation Type: RM-807 Copyright  2012 TCC Nokia 1/32 SAR Compliance Test Report Test report no.: FCC_RM-807_03 Date of report: 2012-03-15 Template version: 19.0 Number of pages: 32 Testing laboratory: TCC Nokia Salo Laboratory P.O.Box 86 Joensuunkatu 7H / Kiila 1B FIN-24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 Client: Nokia Corporation P.O. Box 68 Sinitaival 5 FIN-33721 TAMPERE, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 46880 Responsible test engineer: Alina Tähkäpää Product contact person: Tero Huhtala Measurements made by: Janne Hirsimäki, Teuvo Miettinen, Jani Tuomela, Virpi Tuominen, Alina Tähkäpää, Juha-Matti Varjonen Tested device: RM-807 FCC ID: PDNRM-807 IC: 661R-RM807 Supplement reports: SAR_Photo_RM-807_04 Testing has been carried out in accordance with: 47CFR §2.1093 Radiofrequency Radiation Exposure Evaluation: Portable Devices FCC OET Bulletin 65 (Edition 97-01), Supplement C (Edition 01-01) Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields RSS-102 Evaluation Procedure for Mobile and Portable Radio Transmitters with Respect to Health Canada’s Safety Code 6 for Exposure of Humans to Radio Frequency Fields IEEE 1528 - 2003 IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Technique Documentation: The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test results: The tested device complies with the requirements in respect of all parameters subject to the test. The test results and statements relate only to the items tested. The test report shall not be reproduced except in full, without written approval of the laboratory. Date and signatures: For the contents: Nokia ____________________________________________________________________________ SAR Report FCC_RM-807_03 Applicant: Nokia Corporation Type: RM-807 Copyright  2012 TCC Nokia 2/32 CONTENTS 1. SUMMARY OF SAR TEST REPORT ............................................................................................................................................. 4 1.1 TEST DETAILS ............................................................................................................................................................................. 4 1.2 MAXIMUM RESULTS .................................................................................................................................................................... 4 1.2.1 Head Configuration ........................................................................................................................................................ 4 1.2.2 Body Worn Configuration ............................................................................................................................................ 5 1.2.3 Summary SAR data ........................................................................................................................................................ 5 1.2.4 Maximum Drift ................................................................................................................................................................ 6 1.2.5 Measurement Uncertainty ........................................................................................................................................... 6 2. DESCRIPTION OF THE DEVICE UNDER TEST ........................................................................................................................... 7 2.1 DESCRIPTION OF THE ANTENNA .................................................................................................................................................. 8 3. TEST CONDITIONS ................................................................................................................................................................... 11 3.1 TEMPERATURE AND HUMIDITY ................................................................................................................................................. 11 3.2 TEST SIGNAL, FREQUENCIES AND OUTPUT POWER ................................................................................................................... 11 3.3 TEST CASES AND TEST MINIMISATION ..................................................................................................................................... 12 4. DESCRIPTION OF THE TEST EQUIPMENT ............................................................................................................................. 15 4.1 MEASUREMENT SYSTEM AND COMPONENTS ............................................................................................................................. 15 4.1.1 Isotropic E-field Probe Type ES3DV3 ...................................................................................................................... 16 4.1.2 Isotropic E-field Probe Type EX3DV4 ...................................................................................................................... 17 4.2 PHANTOMS ............................................................................................................................................................................. 17 4.3 TISSUE SIMULANTS ................................................................................................................................................................. 17 4.3.1 Tissue Simulant Recipes ............................................................................................................................................ 18 4.3.2 System Checking .........................................................................................................…

Text truncated - open the document above for the full version.

FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CWLAN_RM-807_16.docx Copyright © TCC Nokia 1 (29) TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 FCC Part 15C Compliance Test Report Test Report no.: FCC15CWLAN_RM-807_16.docx Date of Report: 15-Feb-2012 Number of pages: 29 Customer’s Contact person: Huhtala Tero Testing laboratory: TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 Customer: Nokia Corporation P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 FCC listing no.: IC recognition no.: 94436 661AK-1 Tested devices/ accessories: Phone RM-807 / Battery BV-4D FCC ID: PDNRM-807 IC: 661R-RM807 Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Part 15 Subpart C, ANSI C63.4 (2003), Public Notice DA 00-705, DTS procedures KDB 558074, IC standards, RSS-210 (Issue 8, December 2010). Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document Date and signature for the contents: Jari Jantunen, System Manager, EMC FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CWLAN_RM-807_16.docx Copyright © TCC Nokia 2 (29) TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 1. Summary for FCC Part 15C Compliance Test Report Date of receipt 07-Feb-2012 Testing completed 14-Feb-2012 The customer's contact person Huhtala Tero Test Plan referred to T:\Projects\RM-807\TestPlan\RS_testplan_RM-807.xls Notes - Document name T:\Projects\RM-807\EMC\FCC15CWLAN_RM-807_16.docx 1.1. EUT and Accessory Information The EUT is a mobile phone with following features: GSM/WCDMA/WLAN/Bluetooth/FM Transmitter The EUT is tested with maximum rated TX power, modulated with pseudo random bit sequence (PRBS9). Devices under tests Product Type SN HW MV SW DUT Phone RM-807 004402137763003 2010 - 112.010.0805 42782 Battery BV-4D 4175352012A10400619;0670613 Proto V4 PWB V1.1 - - 42784 1.2. Summary of Test Results WLAN: Section in CFR 47 Section in RSS-GEN or RSS-210 Name of the test Result 15.247(b)(1) A8(0.4(4)) Conducted peak output power PASSED 15.247(d), 15.205(b) A8(0.5) Band edge compliance of RF emissions NP 15.247(d) A8(0.5) Spurious RF conducted emissions PASSED 15.247(d), 15.209 A8(0.5) Spurious radiated emissions NP 15.207 7.2.2 AC powerline conducted emissions NP 15.247(a)(2) A8(0.1(1)) 6dB(bandwidth) PASSED 15.247(e) A8(0.1(2)) Power spectral density PASSED PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Nokia Laboratory. FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CWLAN_RM-807_16.docx Copyright © TCC Nokia 3 (29) TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 CONTENTS 1. Summary for FCC Part 15C Compliance Test Report .............................................. 2 1.1. EUT and Accessory Information ...........................................................................................................2 1.2. Summary of Test Results .....................................................................................................................2 2. Conducted peak output power (15.247(b)(1), RSS-210 A8.4 (4))........................................................................................ 4 2.1. Test Setup ............................................................................................................................................4 2.2. Test method and limit ...........................................................................................................................4 2.3. WLAN Test results ................................................................................................................................5 3. Spurious RF conducted emissions (FCC §15.247(d), RSS-210 A8.5) ..................................................................................... 10 3.1. Test Setup ......................................................................................................................................... 10 3.2. Test method and limit ........................................................................................................................ 10 3.3. WLAN Test results ............................................................................................................................. 11 4. 6 dB bandwidth (FCC §15.247(a)(2), RSS-210 A8.2 (1)) ........................................................................... 16 4.1. Test Setup ......................................................................................................................................... 16 4.2. Test method and limit ........................................................................................................................ 16 4.3. WLAN Test results ............................................................................................................................. 17 5. Power spectral density (FCC §15.247(e), RSS-210 A8.2 (2)) ................................................................................ 22 5.1. Test Setup ............…

Text truncated - open the document above for the full version.

FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CWLAN_RM‐807_27.docx Copyright © TCC Nokia 1 (7) TCC Nokia Salo Laboratory P.O.Box(86) Joensuunkatu 7H / Kiila 1B FIN‐24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 FCC Part 15C Compliance Test Report Test Report no.: FCC15CWLAN_RM-807_27.docx Date of Report: 02-Mar-2012 Number of pages: 7 Customer’s Contact person: Huhtala Tero Testing laboratory: TCC Nokia Salo Laboratory P.O.Box(86) Joensuunkatu 7H / Kiila 1B FIN-24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 Customer: Nokia Corporation P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 FCC listing no.: IC recognition no.: 533467 661V-1 Tested devices/ accessories: Phone RM-807 / Battery BV-4D (Samsung) / AC Charger AC-50E / USB Cable CA-190CD / Headset WH-208 FCC ID: PDNRM-807 IC: 661R-RM807 Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Part 15 Subpart C, ANSI C63.4 (2003), Public Notice DA 00-705, DTS procedures KDB 558074, IC standards, RSS-210 (Issue 8, December 2010). Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document Date and signature for the contents: Tomi Lipponen, Engineer, EMC & SAR FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CWLAN_RM‐807_27.docx Copyright © TCC Nokia 2 (7) TCC Nokia Salo Laboratory P.O.Box(86) Joensuunkatu 7H / Kiila 1B FIN‐24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 1. Summary for FCC Part 15C Compliance Test Report Date of receipt 15-Feb-2012 Testing completed 27-Feb-2012 The customer's contact person Huhtala Tero Test Plan referred to T:\Projects\RM-807\TestPlan\RS_testplan_RM-807.xls Notes - Document name \\vatcc001\certification\Projects\RM-807\EMC\FCC15CWLAN_RM- 807_27.docx 1.1. EUT and Accessory Information The EUT is a mobile phone with following features: GSM/WCDMA/WLAN/Bluetooth/FM Transmitter The EUT is tested with maximum rated TX power, modulated with pseudo random bit sequence (PRBS9). Devices under tests Product Type SNHWMVSW DUT Phone RM-807 004402137764472 2010 - 112.010.0805 16233 Battery BV-4D (Samsung) 4175352012A10401717ö0670613 Proto V4 PWB V1.1 - - 16234 AC Charger AC-50E 4090492023260400101ö0675619 0.5 0.4PV04 - 16194 USB Cable CA-190CD - - - - 16184 Headset WH-208 - - - - 16191 1.2. Summary of Test Results WLAN: Section in CFR 47 Section in RSS-GEN or RSS-210 Name of the test Result 15.247(b)(1) A8(0.4(4)) Conducted peak output power NP 15.247(d), 15.205(b) A8(0.5) Band edge compliance of RF emissions NP 15.247(d) A8(0.5) Spurious RF conducted emissions NP 15.247(d), 15.209 A8(0.5) Spurious radiated emissions NP 15.207 7.2.2 AC powerline conducted emissions PASSED 15.247(a)(2) A8(0.1(1)) 6dB(bandwidth) NP 15.247(e) A8(0.1(2)) Power spectral density NP PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Nokia Laboratory. FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CWLAN_RM‐807_27.docx Copyright © TCC Nokia 3 (7) TCC Nokia Salo Laboratory P.O.Box(86) Joensuunkatu 7H / Kiila 1B FIN‐24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 CONTENTS 1. Summary for FCC Part 15C Compliance Test Report ............................................... 2 1.1. EUT and Accessory Information ........................................................................................................ 2 1.2. Summary of Test Results .................................................................................................................. 2 2. AC powerline conducted emissions (FCC §15.207, RSS-GEN 7.2.2) ........................................................................................... 4 2.1. Test Setup ......................................................................................................................................... 4 2.2. Test method and limit ........................................................................................................................ 4 2.3. WLAN Test results ............................................................................................................................ 5 3. Test Equipment ............................................................................................................. 6 3.1. Conducted measurements ................................................................................................................ 6 3.2. Radiated measurements ................................................................................................................... 7 FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CWLAN_RM‐807_27.docx Copyright © TCC Nokia 4 (7) TCC Nokia Salo Laboratory P.O.Box(86) Joensuunkatu 7H / Kiila 1B FIN‐24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 2. AC powerline conducted emissions (FCC §15.207, RSS-GEN 7.2.2) EUT with DUT number RM-807, DUT 16233 Accessories with DUT numbers BV-4D (Samsung), DUT 16234 ; AC-50E, DUT 16194 ; CA-190CD, DUT 16184 ; WH-208, DUT 16191 Operation Voltage [V] / [Hz] 115 / 60 Results PASSED Remarks - Temp [ o C] / Humidity [%RH] / Air Pressure [kPa] 22 / 32 /101 Date of measurements 27-Feb-2012 Measured by Tomi Lipponen 2.1. Test Setup Receiver Pulse limiter LISN EUT 2.2. Test method and …

Text truncated - open the document above for the full version.

FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CWLANg_RM-807_24.docx Copyright © TCC Nokia 1 (16) TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 FCC Part 15C Compliance Test Report Test Report no.: FCC15CWLANg_RM-807_24.docx Date of Report: 05-Mar-2012 Number of pages: 16 Customer’s Contact person: Huhtala Tero Testing laboratory: TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 Customer: Nokia Corporation P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 FCC listing no.: IC recognition no.: 94436 661AK-1 Tested devices/ accessories: Phone RM-807 / Battery BV-4D / Charger AC-50E / Data Cable CA-190CD / Headset WH-209 FCC ID: PDNRM-807 IC: 661R-RM807 Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Part 15 Subpart C, ANSI C63.4 (2003), Public Notice DA 00-705, DTS procedures KDB 558074, IC standards, RSS-210 (Issue 8, December 2010). Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document Date and signature for the contents: Jari Jantunen, System Manager, EMC FCC Part 15C Compliance Test Report / Template Version 15.0 FCC15CWLANg_RM-807_24.docx Copyright © TCC Nokia 2 (16) TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 1. Summary for FCC Part 15C Compliance Test Report Date of receipt 02-Feb-2012 Testing completed 22-Feb-2012 The customer's contact person Huhtala Tero Test Plan referred to T:\Projects\RM-807\TestPlan\RS_testplan_RM-807.xls Notes - Document name T:\Projects\RM-807\EMC\FCC15CWLANg_RM-807_24.docx 1.1. EUT and Accessory Information The EUT is a mobile phone with following features: GSM/WCDMA/WLAN/Bluetooth/FM Transmitter The EUT is tested with maximum rated TX power, modulated with pseudo random bit sequence (PRBS9). Devices under tests Product Type SN HW MV SW DUT Phone RM-807 004402137764498 2010 - 112.010.0805 42774 Battery BV-4D 4175352012A10401710;0670613 Proto V4 PWB V1.1 - - 42775 Charger AC-50E 4090492023260400312;0675619 0.5 0.4 - 42776 Data Cable CA-190CD - - - - 42778 Headset WH-209 - 0.5 0.1 - 42777 1.2. Summary of Test Results WLAN: Section in CFR 47 Section in RSS-GEN or RSS-210 Name of the test Result 15.247(b)(1) A8.4 (4) Conducted peak output power NP 15.247(d), 15.205(b) A8.5 Band edge compliance of RF emissions PASSED 15.247(d) A8.5 Spurious RF conducted emissions NP 15.247(d), 15.209 A8.5 Spurious radiated emissions PASSED 15.207 7.2.2 AC powerline conducted emissions NP 15.247(a)(2) A8.2 (a) 6dB(bandwidth) NP 15.247(e) A8.2 (b) Power spectral density NP PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP Th…
