PH3-DR138HTVHM FM MOBILE TRANSCEIVER

1 VHF FM MOBILE TRANSCEIVER User Manual Model name：DR-138HT Brand name：plum FCC ID:PH3- DR138HT A1.0-13/06 ALINCO, INC. Y odoyabashi Dai-bldg 13F 4-4-9 Koraibashi, Chuo-ku, Osaka 541-0043 Japan Phone: +81-6-7636-2362 Fax: +81-6-6208-3802 http://www.alinco.com E-mail:[email protected] Copyright Alinco, lnc. PS0795/FNEG-NI Printed in China VHF FM amateur transceiver 144.000-147.995MHz All EU and EFTA member states. Operator license is required. DR-138HT Instruction Manual VHF FM Mobile Transceiver Thank you for purchasing your new Alinco transceiver. Please read this manual carefully before using the product to ensure full performance, and keep this manual for future reference as it contains information on after-sales services. In case addendum or errata sheets are included with this product, please read those materials and keep them together with this instruction manual for future reference. A1.0-13/06 ■ Various scan modes, Key lock, Narrow operations ■ Output power selectable 60W Introduction Thank you very much for purchasing this excellent Alinco transceiver. Our products are ranked among the finest in the world. This radio has been manufactured with state of the art technology and it has been tested carefully at our factory. It is designed to operate to your satisfaction for many years under normal use. Please read this manual completely from the first page to the last, to learn all the functions the product offers. It is important to note that some of the operations may be explained in relation to information in previous chapters. By reading just one part of the manual, you may risk not understanding the complete explanation of the function. Before transmitting There are many radio stations operating in proximity to the frequency ranges this product covers. Be careful not to cause interference when transmitting around such radio stations. ■ Lightning Please note that no car provides adequate protection of its passengers or drivers against lightning. Therefore, Alinco will not take responsibility for any danger associated with using its radios or inside the car during lightning. ■ PC-programmable ■ Alphanumeric name tags ■ Voice Compander (Reduce Noise & enhance audio clarity) ■ Optional Inversion Scramble (DR-135S only) ■ Sub-tone (CTCSS/DCS) Encode/ Decode , DTMF/ANI , 2-tone and 5-tone and more at NO extra costs. Features Conformity Symbols Tested to comply MIL-STD-810G -Shock: Method 514.6/I,IV -Vibration: Method 516.6/I In case the unit you have purchased is marked with a CE symbol,a copy of relative conformity certificate or docu-ment can be reviewed at http:// www.alinco.com/usa.html.Please see the back-cover for more details. Copyright 2012 All rights reserved. NO part of this document may be reproduced, copied, translated or transcribed in any form or by any means without the prior writhout the prior written permission of Alinco. Inc,Osaka, Japan, English Edition Printed in China. Conformity Information SAFETY TRAINING INFORMATION WARNING: This radio generates RF electromagnetic energy during transmission. This radio is designed for and classified as “Occupational Use Only”, meaning it must be used only during the course of employment by individuals aware of the hazards, and the ways to minimize such hazards.This radio is NOT intended for use by the “GeneralPopulation” in an uncontrolled environment. • For compliance with FCC and Industry Canada RF Exposure Requirements, the transmitter antenna installation shall comply with the following two conditions: 1.The transmitter antenna gain shall not exceed 0 dBi. 2.The antenna is required to be located outside of a vehicle and kept at a distance of 63 centimeters or more between the transmitting antenna of this device and any persons during operation.For small vehicle as worst case, the antenna shall be located on the roof top at any place on the centre line along the vehicle in order to achieve 63 centimeters separation distance. In order to ensure this distance is met, the installation of the antenna must be mounted at least 63 centimeters away from the nearest edge of the vehicle in order to protect against exposure to bystanders. CAUTION: To ensure that your exposure to RF electromagnetic energy is within the FCC allowable limits for occupational use, always adhere to the following guidelines: • DO NOT operate the radio without a proper antenna attached, as this may damage the radio and may also cause you to exceed FCC RF exposure limits. A proper antenna is the antenna supplied with this radio by the manufacturer or an antenna specifically authorized by the manufacturer for use with this radio. • DO NOT transmit for more than 50% during the time of employment (50% duty cycle or less). Transmitting excessive amount of time can cause RF exposure compliance requirements to be exceeded. Please carefully read this instruction manual to learn how to transmit and stop transmitting before starting to use it. Electromagnetic Interference/Compatibility During transmissions, your radio generates RF energy that can possibly cause interference with other devices or systems. To avoid such interference, turn off the radio in areas where signs are posted to do so. DO NOT operate the transmitter in areas that are sensitive to electromagnetic radiation such as hospitals, aircraft, and blasting sites. Occupational/Controlled Use This product is used in situations that users are exposed to RF as consequence of their employment provided those users are fully aware of the potential RF hazards and can exercise control over their exposure. • This transceiver is NOT ATEX approved and NOT intended for the use in hazardous explosive atmospheres. Handling this product The manufacturer declines any responsibilities against loss of life and property due to a failure of this product when used with or as a part of a device made by third parties. Use of third party accessory may result in damage to this product. It will void our warranty for repair. Be sur…

Text truncated - open the document above for the full version.

1 PCB Section ItemCondition MeasurementAdjustment Specifications /Remarks TestequipmentTerminalPartsMethod 1. Setting1) Power supply voltage DC Power supply terminal : 13.8V 2. VCO lock voltage 1) CH: TX high Digital volt meterTC2 CV2014V±0.2V 2) CH: RX highCV2004V±0.2V 3) CH: TX low CheckMorethan 0.6V 4) CH: RX low Transmitter section ItemCondition MeasurementAdjustment Specifications /Remarks TestequipmentTerminalPartsMethod 1. Frequency1) CH: TX center 2) Transmit Frequencycounter ANT Encoder knob Adjust to the frequencyWithin±200Hz 2. Maximum power alignment 1) CH : TX high 2) Adjustment HEX value : FF 3) Transmit Power meter VR20060W 3. High power 1) CH : TX low CH : TX low’ CH : TX center CH : TX high’ CH : TX high 2) Transmit Encoder knob 59W±1.0W 4.Mid power 1) CH : TX low CH : TX low’ CH : TX center CH : TX high’ CH : TX high 2) Transmit 25W±2W 5. Low power 1) CH : TX low CH : TX low’ CH : TX center CH : TX high’ CH : TX high 2) Transmit 10W±1W 6. DCS balance 1)CH : TX low (Wide) CH : TX center (Wide/Narrow) CH : TX high (Wide) 2) Transmit Modulation analyzer or Linear detector (LPF : 3kHz) Oscilloscope Adjust the waveform as below 7.Max deviation 1)CH : TX low (Wide) CH : TX center (Wide/Narrow) CH : TX high (Wide) 2) AG : 1kHz/50mV 3) Transm it Modulation analyzer or linear detector (LPF15kHz) Oscilloscope AG AF. V. M ANT MIC ±4.75kHz (Wide) ±2.3kHz(Narrow) According to the large +, – ±200Hz ±100Hz 8. MIC sensitivity 1) CH : TX center (Wide/Narrow) 2) AG : 1kHz/4mV 3) Transmit Check ±2kHz±0.2kHz: Wide ±1kHz±0.1kHz: Narrow 2 Transmitter section ItemCondition MeasurementAdjustment Specifications /Remarks TestequipmentTerminalPartsMethod 9.2-Tone deviation 1)CH : TX center (Wide/Narrow) 2)LPF:15kHz 3)HPF:OFF 4) Transmit Modulation analyzer or linear detector (LPF15kHz) Oscilloscope AG AF. V. M ANT MIC Encoder Knob ±3kHz (Wide) ±1.5kHz(Narrow) ±150Hz ±100Hz 10.5-Tone deviation 1)CH : TX center (Wide/Narrow) 2)LPF:15kHz 3)HPF:OFF 4) Transmit ±3kHz (Wide) ±1.5kHz(Narrow) ±150Hz ±100Hz 11.CTCSS deviation 1)CH : TX low (Wide) CH : TX center (Wide/Narrow) CH : TX high (Wide) 2) Transmit Modulation analyzer or Linear detector (LPF : 3kHz) Oscilloscope ±0.7kHz (Wide) ±0.35kHz(Narrow) ±200Hz ±100Hz 10.DCS deviation 1)CH : TX low (Wide) CH : TX center (Wide/Narrow) CH : TX high (Wide) 2) Transmit ±0.7kHz (Wide) ±0.35kHz(Narrow) ±150Hz ±100Hz 11.DTMF deviation 1) CH: TX center (Wide/Narrow) 2) Transmit ±3.0kHz (Wide) ±1.5kHz(Narrow) ±100Hz Receiver Section ItemCondition MeasurementAdjustment Specifications /Remarks TestequipmentTerminalPartsMethod 1. Sensitivity1)CH : RX low (Wide/Narrow) CH : RX center (Wide/Narrow) CH : RX high (Wide/Narrow) 2) SSG output: : –121dBm (0.2μV) (Wide) :–119dBm (0.25μV) (Narrow) Mod : 1kHz Dev :±3.0kHz (Wide) Dev :±1.5kHz (Narrow) SSG Oscilloscope AF V.M Distortion meter ANT EXT. SP CheckSINAD: 12dB or higher 2. Squelch201)CH : TX low (Wide) CH : TX center (Wide/Narrow) CH : TX high (Wide) 2) SSG output: :–113dBm (0.501μV) (Wide) :–110dBm (0.707μV) (Narrow) Mod : 1kHz Dev:±3.0kHz (Wide) Dev :±1.5kHz (Narrow) Encoder knob Adjust to open the squelch 3. Squelch 11)CH : TX low (Wide) CH : TX center (Wide/Narrow) CH : TX high (Wide) 2) SSG output: : –123dBm (0.158μV) (Wide) :–122dBm (0.178μV) (Narrow) Mod : 1kHz Dev :±3.0kHz (Wide) Dev :±1.5kHz (Narrow)

Aug. 05, 2013 Federal Communication Commission Authorization and Evaluation Division FCC ID: PH3-DR138HT Re: Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below: 1: Block Diagram 2: Circuit Diagram 3: Operational Description 4: Parts List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rules 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Alinco, Incorporated; Electronics Division Contact person: Kazuhiro Kusuhara Title: General manager

DR‐138HT External Photos WHOLE VIEW OF EUT TOP VIEW OF EUT BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT

FCC ID Label Location VHF FM MOBILE TRANSCEIVER Model: DR-138HT Brand Name: ALINCO FCC ID: PH3-DR138HT

DR‐138HT Internal Photos OPEN VIEW-1 OF EUT OPEN VIEW-2 OF EUT INTERNAL VIEW-1 OF EUT INTERNAL VIEW-2 OF EUT INTERNAL VIEW-3 OF EUT INTERNAL VIEW-4 OF EUT INTERNAL VIEW-5 OF EUT INTERNAL VIEW-6 OF EUT INTERNAL VIEW-7 OF EUT

Report No.: AGC02X130602F1 Page 1 of 24 Report No.: AGC02X130602F1 FCC ID : PH3‐DR138HT TYPE OF AUTHORIZATION : Declaration of Conformity APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : VHF FM MOBILE TRANSCEIVER BRAND NAME : ALINCO TEST MODEL :DR‐138HT CLIENT : Alinco, Inc. Electronics Division DATE OF ISSUE : July 18, 2013 STANDARD(S) : FCC Part 15 Rules REPORT VERSION : V 1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd CAUTION: This report shall not be reproduced except in full without the written permission of the test laboratory and shall not be quoted out of context. FCC Test Report Report No.: AGC02X130602F1 Page 2 of 24 Report Revise Record Report Version Revise Time Issued Date Valid VersionNotes V1.0 / July 18, 2013Valid Original Report Report No.: AGC02X130602F1 Page 3 of 24 TABLE OF CONTENTS 1. VERIFICATION OF COMPLIANCE ............................................................................................................... 4 2. PRODUCT INFORMATION ........................................................................................................................... 5 3. TEST FACILITY ............................................................................................................................................. 6 4. SUPPORT EQUIPMENT LIST ....................................................................................................................... 7 5. SYSTEM DESCRIPTION ............................................................................................................................... 7 6 SUMMARY OF TEST RESULTS .................................................................................................................... 8 7. FCC LINE CONDUCTED EMISSION TEST .................................................................................................. 9 7.1. TEST EQUIPMENT OF LINE CONDUCTED EMISSION TEST .......................................................... 9 7.2 .LIMITS OF LINE CONDUCTED EMISSION TEST .............................................................................. 9 7.3. BLOCK DIAGRAM OF LINE CONDUCTED EMISSION TEST ............................................................ 9 7.4. PROCEDURE OF LINE CONDUCTED EMISSION TEST ................................................................. 10 7.5 TEST RESULT OF LINE CONDUCTED EMISSION TEST ................................................................ 11 8. FCC RADIATED EMISSION TEST .............................................................................................................. 12 8.1. TEST EQUIPMENT OF RADIATED EMISSION ................................................................................ 12 8.2. LIMITS OF RADIATED EMISSION TEST .......................................................................................... 12 8.3 BLOCK DIAGRAM OF RADIATED EMISSION TEST ......................................................................... 12 8.4 PROCEDURE OF RADIATED EMISSION TEST ................................................................................ 13 8.5 TEST RESULT OF RADIATED EMISSION TEST .............................................................................. 14 APPENDIX 1 .................................................................................................................................................... 16 PHOTOGRAPHS OF TEST SETUP ................................................................................................................ 16 APPENDIX 2 .................................................................................................................................................... 17 PHOTOGRAPHS OF EUT ............................................................................................................................... 17 Report No.: AGC02X130602F1 Page 4 of 24 1. VERIFICATION OF COMPLIANCE Applicant Alinco, Inc. Electronics Division Address Yodoyabashi Dai-Bldg 13F, 4-4-9 Koraibashi, Chuo-Ku, Osaka 541-0043, Japan Manufacturer Alinco, Inc. Electronics Division Address Yodoyabashi Dai-Bldg 13F, 4-4-9 Koraibashi, Chuo-Ku, Osaka 541-0043, Japan Product Designation VHF FM MOBILE TRANSCEIVER Brand name: ALINCO Test Model DR-138HT Hardware Version: V1.0 Software Version: V1.0 Measurement Procedure ANSI C63.4: 2003 Date of test: July 11, 2013 to July 16, 2013 Deviation: None Condition of Test Sample Normal The above equipment was tested by Attestation Of Global Compliance Co., Ltd. for compliance with the requirements set forth in the FCC Rules and Regulations Part 15, the measurement procedure according to ANSI C63.4:2003. This said equipment in the configuration described in this report shows the maximum emission levels emanating from equipment are within the compliance requirements. The test results of this report relate only to the tested sample identified in this report. Test By: Wall Huang July 18, 2013 Reviewed By: Forrest Lei July 18, 2013 Authorized By: Solger Zhang July 18, 2013 Report No.: AGC02X130602F1 Page 5 of 24 2. PRODUCT INFORMATION The EUT is a VHF FM MOBILE TRANSCEIVER designed for voice communication. It is designed by way of utilizing the FM modulation achieves the system operating. A major technical description of EUT is described as following: Communication Type Voice / Tone only Modulation FM Emission Type 11KфF3E Antenna Designation Detachable Power Supply DC 13.8V by DC source I/O Port Information ( Applicable Not Applicable) I/O Port of EUT I/O Port Type Q’TY Cable Tested with DC Input Port 1 1.5m, Unshielded Antenna Connect Port 1 0 1 Hand-Operated Microphone Connect Port 1 0.5m, Unshielded 1 Report No.: AGC02X130602F1 Page 6 of 24 3. TEST FACILITY Facility Attestation of Global Compliance (Shenzhen) Co., Ltd Location: 2/F., Building 2, No.1-No.4, Chaxi Sanwei Technical Industrial Park, Gushu, Xixiang, Bao'an District, Shenzhen, Guangdong, China Description: The test site is constructed and calibrated to meet th…

Text truncated - open the document above for the full version.

APPENDIX IV PHOTOGRAPHS OF TEST SETUP RADIATED TEST SETUP
