PH3DR-MD520TDMR VHF/UHF MOBILE TRANSCEIVER

A1.210310 Manufacture: ALINCO, INC. Y odoyabashi Dai-bldg 13F 4-4-9 Koraibashi, Chuo-ku, Osaka 541-0043 Japan Phone: +81-6-7636-2362 Fax: +81-6-6208-3802 http://www.alinco.com E-mail:[email protected] Copyright Alinco, lnc. PS1001A / FNFN-EE Printed in China Electrical and electronic equipment and batteries should be recycled at a facility capable of handling these items. Contact your local authority for details of disposal rules. DR-MD520T/E Instruction Manual VHF/UHF FM Digital Transceiver Thank you for purchasing your new Alinco transceiver. Please read this manual carefully before using the product to ensure full performance, and keep this manual for future reference as it contains information on after-sales services. In case addendum or errata sheets are included with this product, please read those materials and keep them together with this instruction manual for future reference. NOTE: DR-MD520 may be delivered to you after dealer- programming. In such cases, please ask your dealer about the available features in your unit and how to operate this unit. Features and functions may be limited due to dealer- programming. ALINCO, INC. ■ Introduction Please read this manual completely from the first page to the last, to learn all the functions the product offers. It is important to note that some of the operations may be explained in relation to information in previous chapters. By reading just one part of the manual, you may risk not understanding the complete explanation of the function. ■ Safety It is important that the operator is aware of, and understands, hazards common to the operation of any transceiver. Before transmitting There are many radio stations operating in proximity to the frequency ranges this product covers. Be careful not to cause interference when transmitting around such radio stations. ■ Covering ranges It may vary drastically depending on the type and location of antenna system. Please consult your dealer for details as DR-MD520 requires an external antenna. ■ Lightning Any person is not safe outdoors during thunderstorms and lightning. Note also that no car provides adequate protection of its passengers or drivers against lightning as well. Therefore, Alinco will not take responsibility for any danger associated with using radios outdoors or inside the car during lightning. ■ Enclosure protection This transceiver is NOT water and dust protected. Avoid contacts with water and dust, and if wet or dirty, immediately wipe them out with clean dry cloth. This product is NOT anti-explosive. Never use in close vicinity to explosive gas, combustible dust,on an oil rig or in an open mine. ■ Integrated GPS receiver An internal GPS receiver is installed in T(FCC) and E(CE) models. ■ When using the GPS receiver • A GPS receiver is installed under the top panel. When the GPS receiver is activated, do not cover the top part with anything that will block satellite signals. • GPS signals can't pass through metal objects. When driving or navigating, you may risk not receiving GPS signals if covered by metal roof. External antenna can't be connected, so we recommend to operate near a window or on a deck. • GPS signals can't reach to the receiver in places like: - Tunnels or a shadow of tall buildings. - Underground floors and parking lots - Under a wide bridge - In remote forested areas Also in severe weather conditions, clouds, rain, snow etc may obstacles signals also. • The Global Positioning System is operated by the U.S. Department of Defense. The Department is responsible for accuracy and maintenance of the system. Any changes by the Department may affect the accuracy and function of the GPS system. Copyright © All rights reserved. No part of this document may be reproduced, translated or transcribed in any from or by any means without the prior permission of Alinco. Inc., Osaka, Japan. Alinco and ALINCO logo are registered trademarks of Alinco incorporated, Japan in United States, EU States, Russia, China and many other countries. Windows is a registered trademark of Microsoft Corporation in the United States and other countries. All other trademarks are the properties of their respective holders. ALINCO and authorized dealers are not responsible for any typographical errors there may be in this manual. The contents of Conformity Symbols Copyright 2012 All rights reserved. NO part of this document may be reproduced, copied, translated or transcribed in any form or by any means without the prior writhout the prior written permission of Alinco. Inc, Osaka, Japan, English Edition Printed in China. Comformity information Manufacturer: ALINCO, Inc. Electronics Division Yodoyabashi Dai-bldg. 13F 4-4-9 Koraibashi, Chuo-ku, Osaka 541-0043 Japan Check with your local waste officials for details on recycling or proper disposal in your area. Hereby, ALINCO, INC. declares that the radio equipment type DR-MD520 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://www.alinco.com/Ce/. this manual may be updated without any notice or obligation. Alinco cannot be liable for pictorial or typographical inaccuracies. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment ■ For North American users Due to strict rules, this product is blocked for operations before sales and only dealers can program the radio before delivery to consumers. Manufacturer is not aware of details of such dealer-programming therefore please kindly contact your dealer first in case technical-service may be necessary. ■ Important Notice The utility software may be available to distributors/dealers only. Programming cable is optional. The manufacturer will not release the software to unauthorized party so please contact your dealer for details. This product may be delivered to the consumer after being preprogrammed with the operating p…

Text truncated - open the document above for the full version.

Alinco Incorporated, Electronics Division ___________________________________________________________________________________________ Date: 2021-05-24 Declaration Letter FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Declaration of compliance to the requirements of §15.121 FCC ID: PH3DR-MD520T Dear Sir/Madam, We declare that, this scanning receiver is incapable of operating (tuning), or readily being altered by the users to operate, within the frequency bands allocated to the Cellular Radiotelephone Service in part 22 of this chapter (cellular telephone bands). This device will not be able to receive transmissions in the cellular telephone bands by means of clipping the leads of, or installing, a simple component such as a diode, resistor or jumper wire; replacing a plug-in semiconductor chip; or programming a semiconductor chip using special access codes or an external device, such as a personal computer. This device is also incapable of converting digital cellular communication transmissions to analog voice audio. This device is designed so that the tuning, control and filtering circuitry is inaccessible. Any attempts to modify the equipment to receive transmissions from the Cellular Radiotelephone Service will render the receiver inoperable. This scanning receiver rejects any signals from the Cellular Radiotelephone Service frequency bands that are 38 dB or lower based upon a 12 dB SINAD measurement. We are aware that the modification of this device to receive transmissions from Cellular Radiotelephone Service frequency bands will be considered to constitute manufacture of such equipment. This includes any individual, individuals, entity or organization that modifies one or more scanners. Any modification to receive transmissions from the Cellular Radiotelephone Service frequency bands voids the certification of the scanning receiver, regardless of the date of manufacture of the original unit. Sincerely Yours, Signature: ___________________________ Katsumi Nakata

Alinco Incorporated, Electronics Division Agent Authorization Company: Alinco Incorporated, Electronics Division Address: Yodoyabashi Dai-Bldg 13F, 4-4-9 Koraibashi, Chuo-Ku, Osaka 541-0043, Japan Product Name: DMR VHF/UHF MOBILE TRANSCEIVER Model Number(s): DR-MD520T Product Description: DMR VHF/UHF MOBILE TRANSCEIVER We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2021-05-21 Name: Katsumi Nakata Company: Alinco Incorporated, Electronics Division

Alinco Incorporated, Electronics Division Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2021-05-17 Subject; Request for Confidentiality FCC ID: PH3DR-MD520T To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely Alinco Incorporated, Electronics Division Contact person: Kazuhiro Kusuhara

External Photos ALL VIEW OF EUT TOP VIEW OF EUT Antenna Port GPS Antenna BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT Hand microphone TOP VIEW OF EUT BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT

FCC ID Label Location 30mm&30mm FCC ID: PH3DR-MD520T

Internal Photos OPEN VIEW-1 OF EUT INTERNAL VIEW-1 OF EUT Antenna INTERNAL VIEW-2 OF EUT INTERNAL VIEW-3 OF EUT INTERNAL VIEW-4 OF EUT INTERNAL VIEW-5 OF EUT INTERNAL VIEW-6 OF EUT INTERNAL VIEW-7 OF EUT INTERNAL VIEW-8 OF EUT INTERNAL VIEW-9 OF EUT INTERNAL VIEW-10 OF EUT INTERNAL VIEW-11 OF EUT INTERNAL VIEW-12 OF EUT INTERNAL VIEW-13 OF EUT INTERNAL VIEW-14 OF EUT INTERNAL VIEW-15 OF EUT INTERNAL VIEW-16 OF EUT INTERNAL VIEW-17 OF EUT INTERNAL VIEW-18 OF EUT INTERNAL VIEW-19 OF EUT INTERNAL VIEW-20 OF EUT INTERNAL VIEW-21 OF EUT INTERNAL VIEW-22 OF EUT INTERNAL VIEW-23 OF EUT GPS ANTENNA Hand microphone OPEN VIEW-1 OF EUT INTERNAL VIEW-1 OF EUT INTERNAL VIEW-2 OF EUT INTERNAL VIEW-3 OF EUT

Page 1 of 25 FCC Test Report Report No.: AGC01284210401FE08 FCC ID : PH3DR-MD520T PRODUCT DESIGNATION : DMR VHF/UHF MOBILE TRANSCEIVER BRAND NAME : ALINCO MODEL NAME : DR-MD520T APPLICANT : Alinco Incorporated, Electronics Division DATE OF ISSUE : May 17, 2021 STANDARD(S) : FCC Part 15 Rules REPORT VERSION : V 1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd Report No.: AGC01284210401FE08 Page 2 of 25 REPORT REVISE RECORD Report Version Revise Time Issued Date Valid Version Notes V1.0 / May 17, 2021 Valid Initial Release Report No.: AGC01284210401FE08 Page 3 of 25 TABLE OF CONTENTS 1. VERIFICATION OF COMPLIANCE ................................................................................................................. 4 2. PRODUCT INFORMATION .............................................................................................................................. 5 3. IDENTIFICATION OF THE RESPONSIBLE TESTING LOCATION ............................................................... 6 4. SUPPORT EQUIPMENT LIST ......................................................................................................................... 7 5. SYSTEM DESCRIPTION .................................................................................................................................. 7 6. MEASUREMENT UNCERTAINTY ................................................................................................................... 8 7. SUMMARY OF TEST RESULTS ..................................................................................................................... 8 8. FCC RADIATED EMISSION TEST .................................................................................................................. 9 8.1 PROVISIONS APPLICABLE ................................................................................................................... 9 8.2 TEST SETUP BLOCK DIAGRAM ........................................................................................................... 9 8.3 TEST PROCEDURE .............................................................................................................................. 11 8.4 TEST RESULT ....................................................................................................................................... 12 9. FCC CONDUCTED EMISSION TEST ............................................................................................................ 16 9.1 PROVISIONS APPLICABLE ................................................................................................................. 16 9.2 TEST SETUP BLOCK DIAGRAM ......................................................................................................... 16 9.3 TEST PROCEDURE .............................................................................................................................. 17 9.4 TEST RESULT ....................................................................................................................................... 18 10. ANTENNA CONDUCTED POWER FOR RECEIVERS ............................................................................... 19 10.1 PROVISIONS APPLICABLE ............................................................................................................... 19 10.2 TEST SETUP BLOCK DIAGRAM ....................................................................................................... 19 10.3 TEST PROCEDURE ............................................................................................................................ 19 10.4 TEST RESULT ..................................................................................................................................... 20 11. SCANNING RECEIVERS AND FREQUENCY CONVERTERS USED WITH SCANNING RECEIVERS .. 22 11.1 PROVISIONS APPLICABLE ............................................................................................................... 22 11.2 TEST SETUP BLOCK DIAGRAM ....................................................................................................... 22 11.3 TEST PROCEDURE ............................................................................................................................ 22 11.4 TEST RESULT ..................................................................................................................................... 23 APPENDIX I PHOTOGRAPHS OF TEST SETUP ............................................................................................. 24 APPENDIX II: PHOTOGRAPHS OF EUT .......................................................................................................... 25 Report No.: AGC01284210401FE08 Page 4 of 25 1. VERIFICATION OF COMPLIANCE Applicant: Alinco Incorporated, Electronics Division Address: Yodoyabashi Dai-Bldg 13F, 4-4-9 Koraibashi, Chuo-Ku, Osaka 541-0043, Japan Manufacturer: Alinco Incorporated, Electronics Division Address: Yodoyabashi Dai-Bldg 13F, 4-4-9 Koraibashi, Chuo-Ku, Osaka 541-0043, Japan Factory: Alinco Incorporated, Electronics Division Address: Yodoyabashi Dai-Bldg 13F, 4-4-9 Koraibashi, Chuo-Ku, Osaka 541-0043, Japan Product Designation DMR VHF/UHF MOBILE TRANSCEIVER Brand Name ALINCO Test Model DR-MD520T Measurement Procedure: ANSI C63.4: 2014 Deviation: No any deviation from the test method. Date of Test: Apr. 06, 2021~May 12, 2021 Condition of Test Sample: Normal Test Result: Pass Report Template； AGCRT-US-PTT/EMC The above equipment was tested by Attestation Of Global Compliance (Shenzhen) Co., Ltd. for compliance with the requirements set forth in the FCC Rules and Regulations Part 15, the measurement procedure according to ANSI C63.4:2014. This said equipment in the configuration described in this report shows the maximum emission levels emanating from equipment are within the compliance requirements. The test results of this report relate only to the tested sample identified in this report…

Text truncated - open the document above for the full version.

Test Setup Photos RADIATED EMISSION TEST SETUP-BELOW 1GHZ RADIATED EMISSION TEST SETUP-ABOVE 1GHZ
