PH3DJ-500TBVHF/UHF FM HANDHELD TRANSCEIVER

A1.131 121 ALINCO, INC. Yodoyabashi Dai-bldg 13F 4-4-9 Koraibashi, Chuo-ku, Osaka 541-0043 Japan Phone: +81-6-7636-2362 Fax: +81-6-6208-3802 http://www.alinco.com E-mail:[email protected] Copyright Alinco, lnc. PS0800/FNEG-EF Printed in China VHF/UHF FM amateur transceiver 144.000~145.995MHz / 430.000~439.995MHz All EU and EFTA member states. Operator license is required. Thank you for purchasing your new Alinco transceiver. Please read this manual carefully before using the product to ensure full performance, and keep this manual for future reference as it contains information on after-sales service. In case addendum or errata sheets are included with this product, please read those materials and keep them together with this instruction manual for future reference. VHF/UHF FM Handheld Transceiver Instruction Manual DJ-500 Introduction Thank you very much for purchasing this excellent Alinco transceiver. Our products are ranked among the finest in the world. This radio has been manufactured with state of the art technology and it has been tested carefully at our factory. It is designed to operate to your satisfaction for many years under normal use. Please read this manual completely from the first page to the last, to learn all the functions the product offers. It is important to note that some of the operations may be explained in relation to information in previous chapters. By reading just one part of the manual, you may risk not understanding the complete explanation of the function. Before transmitting There are many radio stations operating in proximity to the frequency ranges this product covers. Be careful not to cause interference when transmitting around such radio stations. ■ Lightning Any person is not safe outdoor during thunderstorm and lightning. This condition is getting worse if somebody keeps a hand-held radio; chances of being hit by lightning are doubled since lightning may hit a radio antenna as well. At this time, there is no hand-held radio having any kind of protection against lightning current (which is higher than10 kA.). Note also that no car provides adequate protection of its passengers or drivers against lightning as well. Therefore, Alinco will not take responsibility for any danger associated with using its hand-held radios outdoor or inside the car during lightning. ■ About IP54 rating / Dust and splash resistant About IP54 rating 5: Dust protected / Ingress of dust is not entirely prevented, but it must not enter in sufficient quantity to interfere with the satisfactory operation of the equipment; complete protection against contact. 4: Splashing water / Water splashing against the enclosure from any direction shall have no harmful effect. Test duration: 5 minutes / Water volume: 10 litters per minute / Pressure: 80~100 kN/m² The IP54 designation provides for limited dust and splash proofing of the radio per specified above. This compatibility is factory guaranteed for a period of one year provided all the jack covers are securely in place, any accessories connected must be specified genuine Alinco accessories and the radio has not been disassembled by the customer. The factory has tested and made the equipment compatible to IP54 certi fication during engineering. However, please understand that this equipment is NOT certified IP54 compliant but is designed to remain operational when used in hard conditions and is in no way stating that you should attempt to wash the radio for cleaning. Warranty will not cover radios that are water/dust damage due to negligence or misuse of the product. ■ Covering ranges You may expect a range of approx.3km/2 miles or more at high-power when located on a flat, noise-free place like on a beach. However, it may vary drastically depending on how to wear and carry the radios, surrounding locations/conditions and static noise levels (below or near power transmission lines), etc. In urban areas with many buildings or inside a building, such covering range will become drastically short even to several tens of meters. ■ Output power selectable 5W/2.5W/1W(0.2W) ■ Li-Ion battery pack and stand-charger as standard accessories ■ Alphanumeric name tags ■ FM broadcast 76-108MHz receiver built-in ■ Selectable Battery-save parameters ■ Busy Channel Lockout ■ CTCSS/DCS Encode/Decode, DTMF, 5-Tone ■ VOX built-in ■ Emergency, Alarm signal, Various scan modes, Key lock, Wide/Narrow operations and more at NO extra costs. Features Conformity Symbols Tested to comply MIL-STD-810G -Shock: Method 514.6/I,IV -Vibration: Method 516.6/I NOTICE / Compliance Information Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Information in this document is subject to change without notice or obligation. All brand names and trademarks are the property of their respective owners. Alinco cannot be liable for pictorial or typographical inaccuracies. Some parts, options and/or accessories are unavailable in certain areas. Changes or modifi…

Text truncated - open the document above for the full version.

Alinco Incorporated, Electronics Division Attestation Statement Hereby we declare that this radio (FCC ID: PH3DJ-500TB; IC: 3070C-DJ500TB) is compliant with Rule Part 90.203(e). The operator cannot program and transmit on frequencies, other than those programmed by the manufacturer, service or maintenance personnel, using the equipment's external operation controls. Signatory Kazuhiro Kusuhara General Manager, Production, Electronics Div. Alinco Incorporated, Electronics Division [email protected]

Date:July 31, 2014 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: Alinco Incorporated, Electronics Division the undersigned, hereby authorizes Ms. Ivy Zhu from Shenzhen Morlab Communications Technology Co., Ltd., to act on the behalf of Alinco Incorporated, Electronics Division solely in matters relating to the application for an FCC equipment authorization for FCC ID: PH3DJ-500TB including the signing of documents in connection with this Application. Necessary acts carried out by Shenzhen Morlab Communications Technology Co., Ltd on our behalf of Alinco Incorporated, Electronics Division in connection with the Application shall have the same effect as acts of Alinco Incorporated, Electronics Division. Alinco Incorporated, Electronics Division also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Thank you for your attention to this matter. Signatory Kazuhiro Kusuhara General Manager, Production, Electronics Div. Alinco Incorporated, Electronics Division [email protected]

Date: 2014-07-31 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: Alinco Incorporated, Electronics Division FCC ID:PH3DJ-500TB Confidentiality Request Gentlemen: This letter is to comply with 47 CFR 0.457 and 0.459 pertaining to confidentiality material. Alinco Incorporated, Electronics Division requests that the following documents regarding this submission for FCC ID: PH3DJ-500TB be kept confidential: Exhibit Type File Name Block Diagram Block Diagram.pdf Schematics Schematics.pdf Operational Description Operational Description.pdf Part list BOM.pdf Those documents contain detailed system and equipment description and related information about the product which Alinco Incorporated, Electronics Division considers to be confidential proprietary, a custom design and, otherwise, not releasable to the general public. Since this design is a basis form which future technological products will evolve, Alinco Incorporated, Electronics Division considers this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Signatory Kazuhiro Kusuhara General Manager, Production, Electronics Div. Alinco Incorporated, Electronics Division [email protected]

戒防鼻 Bay Area Compliance Labs Corp.(Shcnzhcn) 6/F , Ihe 3rd Phase ofWan Li Induslrial Bldg., Shihua Rd., FuTian Free Trade Zone, Shenzhen, Chìna Tel: +86 755 33320018 Fax: +86755 33320008 D ate of Test Applicant Name: FCC 10: T est Items Name of Engineer Performing Test: Statement of Compliance: The measurements were m ade . t Test lab Witness Signature of Test lab W忧ness Full Name, Typed: Test Lab Attestation Letter 2014-07-25 Alinco Incorporated, Electronics Division PH30J-5∞TB FCC SAR Bell (Test lab) declares that this Unit has been tested in accordance with th e test method identified in this test report and that we 。bse阿edit being tested. It also declares that the Unit complies with the relevant limits. AII instrumentation and accessories used 10 test this unit for compliance to the indicated test method are calibrated regularly in accordance with 1$0 17025:2005 requirements by laboratories accredited by A2LA, NVLAP, or AClAS fo r the measurement parameters Bay Area Com~川iancelabs Corp.(Shenzhen) 6/F , the 3rd Phase ofWan Li Induslrial Bldg., Shihua Rd., FuTian Free Trade Zone, Shenzhen, China Bell B已l (~llI- Bell Hu Title of Witness: SAR Engineer 苦苦J ~主&!f..2.ι斗 Email Address:[email protected] Phone No.: +8675533320018 PílgC 1 of 1

Shenzhen Morlab Communications Technology Co., Ltd. Phone: +86 (0) 755 36698555 Web site: http://www.morlab.cn/ Fax: +86 (0) 755 36698525 External Photos 1. EUT front view 2. EUT rear view 3. EUT left side view Shenzhen Morlab Communications Technology Co., Ltd Phone: +86 (0) 755 36698555 Web site: http://www.morlab.cn/ Fax: +86 (0) 755 36698525 Email: [email protected] Page 2 of 3 4. EUT right side view 5. EUT top view 6. EUT bottom view Shenzhen Morlab Communications Technology Co., Ltd Phone: +86 (0) 755 36698555 Web site: http://www.morlab.cn/ Fax: +86 (0) 755 36698525 Email: [email protected] Page 3 of 3 7. EUT and Accessory

FCC label and label location 1. Label Restricted to occupational use to satisfy RF Exposure limits. See User Manual for Operating instructions. 2. Label location

Shenzhen Morlab Communications Technology Co., Ltd. Phone: +86 (0) 755 36698555 Web site: http://www.morlab.cn/ Fax: +86 (0) 755 36698525 Internal Photos 1. EUT uncover view Shenzhen Morlab Communications Technology Co., Ltd Phone: +86 (0) 755 36698555 Web site: http://www.morlab.cn/ Fax: +86 (0) 755 36698525 Email: [email protected] Page 2 of 6 2. LCD and Buttons Shenzhen Morlab Communications Technology Co., Ltd Phone: +86 (0) 755 36698555 Web site: http://www.morlab.cn/ Fax: +86 (0) 755 36698525 Email: [email protected] Page 3 of 6 3. Mainboard Shenzhen Morlab Communications Technology Co., Ltd Phone: +86 (0) 755 36698555 Web site: http://www.morlab.cn/ Fax: +86 (0) 755 36698525 Email: [email protected] Page 4 of 6 Shenzhen Morlab Communications Technology Co., Ltd Phone: +86 (0) 755 36698555 Web site: http://www.morlab.cn/ Fax: +86 (0) 755 36698525 Email: [email protected] Page 5 of 6 Shenzhen Morlab Communications Technology Co., Ltd Phone: +86 (0) 755 36698555 Web site: http://www.morlab.cn/ Fax: +86 (0) 755 36698525 Email: [email protected] Page 6 of 6 4. Antenna view ** END OF REPORT **

Powerlevel: Mode Channel Spacing Rate Power Tune-up power tolerance (dBm) VHF 25KHz 5W Max output power =36.5+-0.5 2.5W Max output power =33.5+-0.5 0.2W Max output power =23.5+-0.5 12.5KHz 5W Max output power =36.5+-0.5 2.5W Max output power =33.5+-0.5 0.2W Max output power =24.7+-0.5 UHF 25KHz 5W Max output power = 36.5+-0.5 2.5 W Max output power =33.5+-0.5 0.2W Max output power =25+-0.5 12.5KHz 5W Max output power =36.5+-0.5 2.5W Max output power =33.5+-0.5 0.2W Max output power =25+-0.5

Ref : ACR.261.2.13.SATU.A SHENZHEN MORLAB COMMUNICATIONS TECHNOLOGY CO., LTD FL3, BUILDING A, FEIYANG SCIENCE PARK, NO.8 LONGCHANG ROAD, BLOCK 67, BAOAN DISTRICT, SHENZHEN, GUANGDONG PROVINCE, P.R. CHINA SATIMO COMOSAR REFERENCE DIPOLE FREQUENCY: 450 MHZ SERIAL NO.: SN 36/08 DIPB98 Calibrated at SATIMO US 2105 Barrett Park Dr. - Kennesaw, GA 30144 09/25/2013 Summary: This document presents the method and results from an accredited SAR reference dipole calibration performed in SATIMO USA using the COMOSAR test bench. All calibration results are traceable to national metrology institutions. SAR Reference Dipole Calibration Report SAR REFERENCE DIPOLE CALIBRATION REPORT Ref: ACR.261.2.13.SATU.A Page: 2/10 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. Name Function Date Signature Prepared by : Jérôme LUC Product Manager 9/18/2013 Checked by : Jérôme LUC Product Manager 9/18/2013 Approved by : Kim RUTKOWSKI Quality Manager 9/18/2013 Customer Name Distribution : Shenzhen Morlab Communications Technology Co., Ltd Issue Date Modifications A 9/18/2013 Initial release SAR REFERENCE DIPOLE CALIBRATION REPORT Ref: ACR.261.2.13.SATU.A Page: 3/10 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. TABLE OF CONTENTS 1 Introduction ................................................................................................................ 4 2 Device Under Test ..................................................................................................... 4 3 Product Description ................................................................................................... 4 3.1 General Information _______________________________________________________ 4 4 Measurement Method ................................................................................................ 5 4.1 Return Loss Requirements __________________________________________________ 5 4.2 Mechanical Requirements ___________________________________________________ 5 5 Measurement Uncertainty .......................................................................................... 5 5.1 Return Loss ______________________________________________________________ 5 5.2 Dimension Measurement ___________________________________________________ 5 5.3 Validation Measurement ____________________________________________________ 5 6 Calibration Measurement Results .............................................................................. 6 6.1 Return Loss ______________________________________________________________ 6 6.2 Mechanical Dimensions ____________________________________________________ 6 7 Validation measurement ............................................................................................ 7 7.1 Measurement Condition ____________________________________________________ 7 7.2 Head Liquid Measurement __________________________________________________ 7 7.3 Measurement Result _______________________________________________________ 8 7.4 Body Measurement Result __________________________________________________ 9 8 List of Equipment .................................................................................................... 10 SAR REFERENCE DIPOLE CALIBRATION REPORT Ref: ACR.261.2.13.SATU.A Page: 4/10 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. 1 INTRODUCTION This document contains a summary of the requirements set forth by the IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards for reference dipoles used for SAR measurement system validations and the measurements that were performed to verify that the product complies with the fore mentioned standards. 2 DEVICE UNDER TEST Device Under Test Device Type COMOSAR 450 MHz REFERENCE DIPOLE Manufacturer Satimo Model SID450 Serial Number SN 36/08 DIPB98 Product Condition (new / used) Used A yearly calibration interval is recommended. 3 PRODUCT DESCRIPTION 3.1 GENERAL INFORMATION Satimo’s COMOSAR Validation Dipoles are built in accordance to the IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards. The product is designed for use with the COMOSAR test bench only. Figure 1 – Satimo COMOSAR Validation Dipole SAR REFERENCE DIPOLE CALIBRATION REPORT Ref: ACR.261.2.13.SATU.A Page: 5/10 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. 4 MEASUREMENT METHOD The IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards provide requirements for reference dipoles used for system validation measurements. The following measurements were performed to verify that the product complies with the fore mentioned standards. 4.1 RETURN LOSS REQUIREMENTS The dipole used for SAR system validation measurements and checks must have a return loss of -20 dB or better. The return loss measurement shall be performed against a liquid filled flat phantom, with the phantom constucted as outlined in the fore mentioned standards. 4.2 MECHANICAL REQUIREMENTS The IEEE Std. 1528 and CEI/IEC 62209 standards specify the mechanical components and dimensions of the validation dipoles, with the dimensions frequency and phantom shell thickness dependent. The COMOSAR test bench employs a…
