PH3DJ-A10Handheld two way radio

A1.0-12/07 Alinco Incorporated, Electronics Division Yodoyabashi Dai-bldg 13F 4-4-9 Koraibashi, Chuo-ku, Osaka 541-0043 Japan Phone: +81-6-7636-2362 Fax: +81-6-6208-3802 http://www.alinco.com E-mail:[email protected] Copyright Alinco, lnc. PS0662/FNEF-NJ Introduction Thank you very much for purchasing this excellent Alinco transceiver. Our products are ranked among the finest in the world. This radio has been manufactured with state of the art technology and it has been tested carefully at our factory. It is designed to operate to your satisfaction for many years under normal use. Please read this manual completely from the first page to the last, to learn all the functions the product offers. It is important to note that some of the operations may be explained in relation to information in previous chapters. By reading just one part of the manual, you may risk not understanding the complete explanation of the function. Before transmitting There are many radio stations operating in proximity to the frequency ranges this product covers. Be careful not to cause interference when transmitting around such radio stations. ■ Lightning Any person is not safe outdoor during thunderstorm and lightning. This condition is getting worse if somebody keeps a hand-held radio; chances of being hit by lightning are doubled since lightning may hit a radio antenna as well. At this time, there is no hand-held radio having any kind of protection against lightning current (which is higher than10 kA.). Note also that no car provides adequate protection of its passengers or drivers against lightning as well. Therefore, Alinco will not take responsibility for any danger associated with using its hand-held radios outdoor or inside the car during lightning. ■ About IP54 rating / Dust and splash resistant About IP54 rating 5: Dust protected /Ingress of dust is not entirely prevented, but it must not enter in sufficient quantity to interfere with the satisfactory operation of the equipment; complete protection against contact. 4: Splashing water / Water splashing against the enclosure from any direction shall have no harmful effect. Test duration: 5 minutes / Water volume: 10 litters per minute /Pressure: 80~100 kN/m² The IP54 designation provides for limited dust and splash proofing of the radio per specified above. This compatibility is factory guaranteed for a period of one year provided all the jack covers are securely in place, any accessories connected must be specified genuine Alinco accessories and the radio has not been disassembled by the customer. The factory has tested and made the equipment compatible to IP54 certi fication during engineering. However, please understand that this equipment is NOT certified IP54 compliant but is designed to remain operational when used in hard conditions and is in no way stating that you should attempt to wash the radio for cleaning. Warranty will not cover radios that are water/dust damage due to negligence or misuse of the product. SAFETY TRAINING INFORMATION WARNING Your radio generates RF electromagnetic energy during transmit mode. This radio is designed for and classified as “Occupational Use Only”, meaning it must be used only during the course of employment by individuals aware of the hazards, and the ways to minimize such hazards. This radio is NOT intended for use by the“General Population” in an uncontrolled environment. This radio has been tested and complies with the FCC RF exposure limits for “Occupational Use Only”. In addition, your radio complies with the following Standards and Guidelines with regard to RF energy and electromagnetic energy levels and evaluation of such levels for exposure to humans: FCC OET Bulletin 65 Edition 97-01 Supplement C, Evaluating Compliance with FCC Guidelines for ● Human Exposure to Radio Frequency Electromagnetic Fields. American National Standards Institute (C95.1-1992), IEEE Standard for Safety Levels with Respect to ● Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. American National Standards Institute (C95.3-1992), IEEE Recommended Practice for the Measurement ● of Potentially Hazardous Electromagnetic Fields– RF and Microwave. The following accessories are authorized for use with this product. Use of accessories other than those ● specified may result in RF exposure levels exceeding the FCC requirements for wireless RF exposure.; Belt Clip (MB-94), Rechargeable Li-Ion Battery Pack (BP-230N/BP-232N) and Speaker-microphone (HM-131L). CAUTION To ensure that your expose to RF electromagnetic energy is within the FCC allowable limits for occupational use, always adhere to the following guidelines: DO NOT operate the radio without a proper antenna attached, as this may damaged the radio and may ● also cause you to exceed FCC RF exposure limits. A proper antenna is the antenna supplied with this radio by the manufacturer or antenna specifically authorized by the manufacturer for use with this radio. DO NOT transmit for more than 50% of total radio use time (“50% duty cycle”). “50% duty cycle” is also ● applicable to VOX/PTT mode. Transmitting more than 50% of the time can cause FCC RF exposure compliance requirements to be exceeded. The radio is transmitting when the “LED indicator” lights red. You can cause the radio to transmit by pressing the “PTT” switch or VOX function. ALWAYS keep the antenna at least 2.5 cm (1 inch) away from the body when transmitting and only use ● the belt-clip which is listed on page 33 when attaching the radio to your belt, etc., to ensure FCC RF exposure compliance requirements are not exceeded. To provide the recipients of your transmission the best sound quality, hold the antenna at least 5 cm (2 inches) from your mouth, and slightly off to one side. The information listed above provides the user with the information needed to make him or her aware of RF exposure, and what to do to assure that this radio operates with the FCC RF exposure limits of this radio. Elect…

Text truncated - open the document above for the full version.

Aug. 28, 2012 PHOENIX TESTLAB GmbH Koenigswinkel 10 D‐32825 Blomberg， Germany Subject: FCC ID: PH3DJ-A10 Attestation statement of the authorized use and the exact frequencies Gentlemen; The equipment meets the requirements of the FCC Rules, Part 90.203(e) and (g), as applicable. 1. A waiver of the rules. following is based on 2.106 listings, FCC ONLINE TABLE OF FREQUENCY ALLOCATIONS, 136‐137 87 137‐138 25 138‐144 no FCC alloc. nor service rules 144‐148 97 148‐150.05 25 150.05‐150.8 no FCC alloc. nor service rules 150.8‐152.855 22,90,95 152.855‐154 74D,90 154‐156.2475 80,90,95 156.2475‐157.0375 80,87 157.0375‐157.1875 80 157.1875‐157.45 80,87,90 157.45‐161.575 22,74D,80,90 161.575‐161.625 22,80 161.625 ‐161.775 22,74D,74H 161.775‐161.9625 80,90 161.9625‐162.0375 80 162.0375‐173.2 74D,90 173.2‐173.4 90 173.4‐174 no FCC alloc. nor service rules 2. Programming of this product’s transmit frequencies can be performed ONLY by the manufacturer or by service or maintenance personal. The operator cannot be program transmit frequencies using the equipment’s external operation controls. Sincerely, Alinco Incorporated, Electronics Division Kazuhiro Kusuhara/G.M.

Aug. 7, 2012 Federal Communication Commission Authorization and Evaluation Division FCC ID: PH3DJ-A10 Re: Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below: 1: Block Diagram 2: Circuit Diagram 3: Operational Description 4: Parts List 5:Tune Up Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rules 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Alinco Incorporated, Electronics Division Kazuhiro Kusuhara/G.M.

Alinco Incorporated, Electronics Division Yodoyabashi Dai‐Bldg 13F, 4‐4‐9 Koraibashi, Chuo‐Ku, Osaka 541‐0043, Japan Tel: 06‐7636‐2362; FAX: 06‐6208‐3802 Date: Aug. 7, 2012 Statement We, Alinco Incorporated, Electronics Division states that our device, FCC ID: PH3DJ‐A10, has no space to put the label except the battery compartment of this device. It is visible to the users as they purchase the products and install the battery. Sincerely yours, Alinco Incorporated, Electronics Division Kazuhiro Kusuhara/G.M.

TOTAL VIEW OF EUT TOP VIEW OF EUT BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT

FCC ID Label Location FCC RF Warning Label VHF FM HANDHELD TRANSCEIVER FCC ID: PH3DJ‐A10 Brand : ALINCO Model : DJ‐A10 Frequency Range : 136MHz to 174MHz

OPEN VIEW OF EUT INTERNAL VIEW OF EUT - 1 INTERNAL VIEW OF EUT - 2 INTERNAL VIEW OF EUT – 3 INTERNAL VIEW OF EUT – 4 INTERNAL VIEW OF EUT – 5 INTERNAL VIEW OF EUT – 6 INTERNAL VIEW OF EUT – 7

FCC Part 90 Test Report Report No.: AGC02X120602F1 FCC ID : PH3DJ‐A10 PRODUCT DESIGNATION : VHF FM HANDHELD TRANSCEIVER BRAND NAME : ALINCO MODEL NAME : DJ‐A10 CLIENT : Alinco Incorporated, Electronics Division DATE OF ISSUE : Aug.06, 2012 STANDARD(S) : FCC Part 90 Rules REPORT VERSION : V 1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd. CAUTION: This report shall not be reproduced except in full without the written permission of the test laboratory and shall not be quoted out of context. Report No.: AGC02X120602F1 Page 1 of 52 VERIFICATION OF COMPLIANCE Applicant: Alinco Incorporated, Electronics Division Yodoyabashi Dai-Bldg 13F, 4-4-9 Koraibashi, Chuo-Ku, Osaka 541-0043, Japan Manufacturer: Alinco Incorporated, Electronics Division Yodoyabashi Dai-Bldg 13F, 4-4-9 Koraibashi, Chuo-Ku, Osaka 541-0043, Japan Product Designation: VHF FM HANDHELD TRANSCEIVER Brand Name: ALINCO Model Name: DJ-A10 Hardware Version: V2.02 Software Version: V2.02 Report No.: AGC02X120602F1 Date of Test: Jul.27,2012 to Aug.03, 2012 We hereby certify that: The above equipment was tested by Attestation of Global Compliance (Shenzhen) Co., Ltd. The data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C 63.4:2003. The sample tested as described in this report is in compliance with the FCC Rules Part 90 requirements The test results of this report relate only to the tested sample identified in this report. Tested By Bart Xie Aug. 06, 2012 Reviewed By Forrest Lei Aug. 06, 2012 Approved By Solger Zhang Aug. 06, 2012 Report No.: AGC02X120602F1 Page 2 of 52 TABLE OF CONTENTS 1. GENERAL INFORMATION ............................................................................................. 4 1.1 PRODUCT DESCRIPTION ....................................................................................................................... 4 1.3 TEST METHODOLOGY ........................................................................................................................... 5 1.4 TEST FACILITY ........................................................................................................................................ 5 1.5 SPECIAL ACCESSORIES ....................................................................................................................... 5 1.6 EQUIPMENT MODIFICATIONS ............................................................................................................... 5 2. SYSTEM TEST CONFIGURATION ................................................................................. 6 2.1 EUT CONFIGURATION ............................................................................................................................ 6 2.2 EUT EXERCISE ........................................................................................................................................ 6 2.3 GENERAL TECHNICAL REQUIREMENTS............................................................................................. 6 2.4 CONFIGURATION OF TESTED SYSTEM ............................................................................................. 6 3. SUMMARY OF TEST RESULTS .................................................................................... 7 4. DESCRIPTION OF TEST MODES .................................................................................. 8 5. CONDUCTED LIMITS ..................................................................................................... 9 5.1 PROVISIONS APPLICABLE .................................................................................................................... 9 5.2 MEASUREMENT PROCEDURE .............................................................................................................. 9 5.3 TEST SETUP BLOCK DIAGRAM .......................................................................................................... 10 5.4 TEST EQUIPMENT USED ..................................................................................................................... 10 5.5 TEST RESULT ........................................................................................................................................ 11 6. FREQUENCY TOLERANCE ......................................................................................... 13 6.1 PROVISIONS APPLICABLE .................................................................................................................. 13 6.2 MEASUREMENT PROCEDURE ............................................................................................................ 13 6.3 TEST SETUP BLOCK DIAGRAM .......................................................................................................... 14 6.4 TEST EQUIPMENT USED: .................................................................................................................... 14 6.5 TEST RESULT ........................................................................................................................................ 14 7. EMISSION BANDWIDTH .............................................................................................. 18 7.1 PROVISIONS APPLICABLE .................................................................................................................. 18 7.2 MEASUREMENT PROCEDURE ............................................................................................................ 18 7.3 TEST SETUP BLOCK DIAGRAM .......................................................................................................... 18 7.4 MEASUREMENT EQUIPMENT USED: ................................................................................................. 18 7.5 MEASUREMENT RESULT: .................................................................................................................... 19 8. UNWANTED RADIATION ...........................................…

Text truncated - open the document above for the full version.

CONDUCTED EMISSION TEST SETUP RADIATED TEST SETUP
