PH3DJ-S40TAmature Transceiver with Scanning Receiver

Alinco Incorporated, Electronics Division
Amature Transceiver with Scanning Receiver - FCC ID PH3DJ-S40T - Alinco Incorporated, Electronics Division
Click to zoom

Application Details

Equipment Class
CSR - Scanning Receiver
Date of Grant
Nov 20, 2001
Application Purpose
Original Equipment
Date of Application
Nov 20, 2001
Equipment Note
Amature Transceiver with Scanning Receiver
Frequency Range
440.00000000 - 479.99500000
Company
Alinco Incorporated, Electronics Division
Country
Japan

Documents & Files

Select a file to view

Users Manual

โ†—

Attestation Statements

โ†—

Cover Letter(s)

โ†—
โ†—
โ†—

External Photos

โ†—

ID Label/Location Info

โ†—

Test Report

โ†—

Test Setup Photos

โ†—

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Cover Letter(s)

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 November 18, 2001 RE: Alinco, Inc. FCC ID: PH3DJ-S40T After a review of the submitted information, I have a few comments on the above referenced Application. 1) Please provide a clearer or higher resolution copy of the schematics. Portions of the schematic are not readable. 2) The attachments provided for external photographs and the labeling information show conflicting warning labeling information (i.e., one shows labeling information for 15.19(a)(1), while the other states the labeling specified by 15.19(a)(3)). Please clarify this issue and also explain why the unit has been labeled for DoC. 3) Section 3.1 of the test report states that the EUT was locked to a set frequency, yet the next sentence states that the scanning mode was deemed the worst case mode. Please clarify this issue. 4) The test equipment listed in section 5.1 of the report does not match the test equipment specified in Table 12 of the test report. The correction factors appear to include preamplifier gain, yet Table 12 does not specify a preamplifier. Please clarify these discrepancies. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Cover Letter(s)

COMPANY NAME: ALINCO, INC. EUT: DJ-X2000T WORK ORDER NUMBER: 2000448 FCC ID: EUG DJ-X2000T Scanning Receiver Certification Report Page 65 of 65

Cover Letter(s)

Engineering and Testing for EMC and Safety Compliance 360 Herndon Parkway, Suite 1400 Herndon, VA 20170 Phone: 703-689-0368; Fax: 703-689-2056; Metro: 703-471-6441 November 13, 2001 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: The following information is to be held confidential pursuant of 47 CFR Part 0 ยง0.457 and Section 552(b)(4) of the Freedom of Information Act, because the information provided contains trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. โ€ข Schematics โ€ข Product Description โ€ข Block Diagram โ€ข Bill of Materials (Parts List) Best Regards, Melissa Carter [email protected] Rhein Tech Laboratories, Inc.

External Photos

360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Scanning Receiver Certification Report Page 28 Alinco, Inc. FCC ID: PH3 DJ-S40T Work Order: 2001281 / QRTL01-153F APPENDIX H: EXTERNAL PHOTOGRAPHS PHOTOGRAPH 8: FRONT VIEW OF DEVICE 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Scanning Receiver Certification Report Page 29 Alinco, Inc. FCC ID: PH3 DJ-S40T Work Order: 2001281 / QRTL01-153F PHOTOGRAPH 9: LEFT SIDE OF EUT 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Scanning Receiver Certification Report Page 30 Alinco, Inc. FCC ID: PH3 DJ-S40T Work Order: 2001281 / QRTL01-153F PHOTOGRAPH 10: RIGHT SIDE OF EUT 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Scanning Receiver Certification Report Page 31 Alinco, Inc. FCC ID: PH3 DJ-S40T Work Order: 2001281 / QRTL01-153F PHOTOGRAPH 11: REAR VIEW OF EUT WITH BATTERY 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Scanning Receiver Certification Report Page 32 Alinco, Inc. FCC ID: PH3 DJ-S40T Work Order: 2001281 / QRTL01-153F PHOTOGRAPH 12: BATTERY 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Scanning Receiver Certification Report Page 33 Alinco, Inc. FCC ID: PH3 DJ-S40T Work Order: 2001281 / QRTL01-153F PHOTOGRAPH 13: INTERNAL VIEW OF FRONT COVER 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Scanning Receiver Certification Report Page 34 Alinco, Inc. FCC ID: PH3 DJ-S40T Work Order: 2001281 / QRTL01-153F PHOTOGRAPH 14: WHIP ANTENNA

ID Label/Location Info

360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Scanning Receiver Certification Report Page 18 Alinco, Inc. FCC ID: PH3 DJ-S40T Work Order: 2001281 / QRTL01-153F APPENDIX A: LABEL INFORMATION I DENTIFICATION L ABEL : Warning Label L OCATION OF L ABEL PHOTOGRAPH 3: LABEL LOCATION Alinco, Inc. DJ-S40T Industry Canada: XXXXX FCC ID: PH3 DJ-S40T This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. WARNING: Modification of this device to receive cellular radio-telephone service signals is prohibited under FCC rules and federal law. LABEL LOCATION Warning Label

Test Report

Engineering and Testing for EMC and Safety Compliance 360 Herndon Parkway, Suite 1400 Herndon, VA 20170 Phone: 703-689-0368; Fax: 703-689-2056; Metro: 703-471-6441  APPLICATION FOR FCC CLASS B CERTIFICATION WIDE BAND COMMUNICATION RECEIVER Alinco Incorporated; Electronics Division Shin Dai Building 9F 1-2-6 Dojimahama Kita-ku, Osaka 530-0004 Japan MODEL: DJ-S40T FCC ID: PH3 DJ-S40T October 24, 2001 STANDARDS REFERENCED FOR THIS REPORT PART 2: 1999 FREQUENCY ALLOCATIONS AND RADIO TREATY MATTERS; GENERAL RULES AND REGULATIONS PART 15: 1999 RADIO FREQUENCY DEVICES ANSI C63.4-1992 STANDARD FORMAT MEASUREMENT/TECHNICAL REPORT PERSONAL COMPUTER AND PERIPHERALS RSS-215; ISSUE 1 (PROVISIONAL) ANALOGUE SCANNER RECEIVERS FCC Rules Parts Frequency Range MHz Output Power (W) Freq. Tolerance Emission Designator 15.121 400-479..995 MHz N/A N/A N/A REPORT PREPARED BY: Test Engineer: Franck Schuppius Administrative Writer: Franck Schuppius Rhein Tech Laboratories, Inc. Document Number: 2001281 / QRTL01-153F No part of this report may be reproduced without the full written approval of Rhein Tech Laboratories, Inc. 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Scanning Receiver Certification Report Page 2 Alinco, Inc. FCC ID: PH3 DJ-S40T Work Order: 2001281 / QRTL01-153F TABLE OF CONTENTS 1 GENERAL INFORMATION.............................................................................................................................................4 1.1 MODIFICATIONS..........................................................................................................................................................................................................4 1.2 RELATED SUBMITTAL(S)/GRANT(S).....................................................................................................................................................................4 1.3 TEST METHODOLOGY...............................................................................................................................................................................................4 1.4 TEST FACILITY.............................................................................................................................................................................................................4 2 CONFORMANCE STATEMENT.....................................................................................................................................5 3 SYSTEM TEST CONFIGURATION.................................................................................................................................6 3.1 JUSTIFICATION............................................................................................................................................................................................................6 3.2 EXERCISING THE EUT...............................................................................................................................................................................................6 3.3 TEST SYSTEM DETAILS............................................................................................................................................................................................6 3.4 CONFIGURATION OF TESTED SYSTEM..............................................................................................................................................................7 4 CONDUCTED EMISSIONS.............................................................................................................................................8 4.1 TEST METHODOLOGY FOR CONDUCTED EMISSIONS MEASUREMENTS..............................................................................................8 4.2 CONDUCTED EMISSION TEST................................................................................................................................................................................8 4.3 CONDUCTED EMISSION TEST DATA....................................................................................................................................................................9 5 RADIATED EMISSIONS...............................................................................................................................................12 5.1 TEST METHODOLOGY FOR RADIATED EMISSIONS MEASUREMENTS.................................................................................................12 5.2 RADIATED EMISSION DATA...................................................................................................................................................................................13 6 38DB REJECTION TEST.............................................................................................................................................15 6.1 38DB REJECTION TEST DATA FOR BASE BAND (869.040-893.970 MHZ)...............................................................................................16 6.2 38DB REJECTION TEST DATA FOR MOBILE BAND (824.040-848.970 MHZ)...........................................................................................17 TABLE OF TABLE TABLE 1: EQUIPMENT UNDER TEST (EUT)....................................................................................................................................................................6 TABLE 2: EXTERNAL COMPONENTS IN TEST CONFIGURATION...........................................................................................................................6 TABLE 3: CONDUCTED EMISSIONS TEST (PHASE SIDE) (400.000 MHZ).............................................................................................................9 TABLE 4: CONDUCTED EMISSIONS TEST (NEUTRAL SIDE) (439.995 MHZ).........................................................................................โ€ฆ

Text truncated - open the document above for the full version.

Test Setup Photos

360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Scanning Receiver Certification Report Page 26 Alinco, Inc. FCC ID: PH3 DJ-S40T Work Order: 2001281 / QRTL01-153F APPENDIX G: TEST CONFIGURATION PICTURES PHOTOGRAPH 4: CONDUCTED TEST CONFIGURATION (FRONT VIEW) PHOTOGRAPH 5: CONDUCTED TEST CONFIGURATION (REAR VIEW) 360 Herndon Parkway Suite 1400 Herndon, VA 20170 http://www.rheintech.com Scanning Receiver Certification Report Page 27 Alinco, Inc. FCC ID: PH3 DJ-S40T Work Order: 2001281 / QRTL01-153F PHOTOGRAPH 6: RADIATED TEST CONFIGURATION (FRONT VIEW) PHOTOGRAPH 7: RADIATED TEST CONFIGURATION (REAR VIEW)

Contact Information

Applicant

Kazuhiro Kusuhara(General Manager, Production, Electronics Div.)
[email protected]06-7636-2360Fax: 06-6208-3801

Technical Contact

Rhein Tech Laboratories, Inc.Desmond A Fraser
[email protected]703-689-0368

360 Herndon Parkway, Suite 1400 ยท Herndon, Virginia ยท United States

Non-Technical Contact

Rhein Tech Laboratories, Inc.Melissa Fleming
[email protected]703-689-0368

Test Firm

Rhein Tech Laboratories, Inc.Rick McMurray
[email protected]703-689-0368Fax: 703-689-2056

Technical Specifications

#Rule PartsFrequency RangePower Output
215B440 MHz - 479.995 MHz-
Confidentiality
Long Term
