PHX-MMDS-BASE2Non-Line of Site Wireless Data Link

i Configuring, Installing, and Using Carrier Infrastructure Broadband Wireless Access System Part Number:104-0100-0011 ii BaseConnect, Expedience, NetProvision, and ProvisionLink are trademarks of NextNet Wireless, Inc. ©2000-2003 NextNet Wireless, Inc. All rights reserved. WARNING: This equipment has been tested with a 19 dBi gain antenna and found to comply with the FCC guidelines for Radio Frequency Radiation Exposure Limits as detailed below. A minimum of 2 meters or 6.5 feet of separation between the antenna and all persons must be maintained. Radio Frequency Radiation Exposure Limits. f = frequency in MHz * = Plane-wave equivalent power density NOTE 1 TO TABLE 1: Occupational/controlled limits apply in situations in which persons are exposed as a consequence of their employment provided those persons are fully aware of the potential for exposure and can exercise control over their exposure. Limits for occupational/controlled exposure also apply in situations when an individual is transient through a location where occupational/controlled limits apply provided he or she is made aware of the potential for exposure. NOTE 2 TO TABLE 1: General population/uncontrolled exposures apply in situations in which the general public may be exposed, or in which persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or can not exercise control over their exposure. Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio-frequency energy, and, if not installed and used in accordance with the installation manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case users will be required to correct the interference at their own expense. TABLE 1. Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field- strength (V/m) Magnetic field- strength (A/m) Power density (mW/cm 2) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3-3.06141.63*(100)6 3.0-301842/f4.89/f *(900/f 2 ) 6 30-30061.40.1631.06 300-1500——f/3006 1500-100,000——56 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.346141.63*(100)30 1.34-30824/f2.19/f *(180/f 2 ) 30 30-30027.50.073.230 300-1500——f/150030 1500-100,000——1.030 iii NextNet Wireless, Inc. recommends the following antennas for base station installations: This Class A digital apparatus complies with Canadian ICES-003. THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT WARRENTY OF ANY KIND. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCT. NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE ARE PROVIDED “AS IS” WITH ALL FAULTS. NEXTNET WIRELESS DISCLAIMS ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITATION, THOSE OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FOM A COUSRE OF DEALING, USAGE, OR TRADE PRACTICE. IN NO EVENT SHALL NEXTNET WIRELESS OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING, WITHOUT LIMITATION, LOST PROFITS OR LOSS OF DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF NEXTNET WIRELESS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. TABLE 2. Technical Information Transmitting power1m watts to 2 watts 1m watts to 5 watts (high power option) Operating voltage120 VAC nominal Frequency band2500 - 2686 MHz TX/RX Frequency stability±1.0 ppm Number of channels31 Channel bandwidth6 MHz ModulationOrthogonal frequency division multiplex TransmissionTime division duplex/time division multiplex TABLE 3. Recommended antennas for base station installations ManufacturerAntenna typeModel/part number Stella Doradus120 degree vertical polarization 18 dBi gain 26 12005V Stella Doradus90 degree vertical polarization 19 dBi gain 26 9005V Stella Doradus90 degree vertical polarization 17 dBi gain 26 9007.5NV Stella Doradus90 degree horizontal polarization 19 dBi gain 26 9005H Til-TekOmni vertical polar- ization 10 dBi gain TA-2550 iv v CONTENTS Preface About this guide Preface overview .............................................................................. xiii About this guide .............................................................................. xiii Chapters in this guide ........................................................................................ xiv Additional documentation ............................................................... xiv Typographical conventions this guide uses ......................................xv Where to go for more help ............................................................... xvi Technical support............................................................................................... xvi Documentation additions and corrections ..................................................... xvi Introduction to backhaul installations Chapter overview .............................................................................. 1-1 System overview ................................................................................ 1-1 System overview ................................................................................................ 1-1 Infrastructure overview .................................................................................... 1-2 Installation overview .........................................................................1-3 Planning…

Text truncated - open the document above for the full version.

FCC ID: PHX-MMDS-BASE2 Page 1 of 5 NextNet Wireless, Inc 11/20/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 2 Attestation Statement Cover Letters Exhibit 2 FCC ID: PHX-MMDS-BASE2 Attestation Statement Page 2 of 5 NextNet Wireless, Inc 11/20/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 The measurements performed on the test sample for this FCC product Certification were performed by me or by personnel under my direction. Tim Blom Principal Engineer Exhibit 2 FCC ID: PHX-MMDS-BASE2 Attestation Statement Page 3 of 5 NextNet Wireless, Inc 11/20/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 Cover Letters Gentlemen: This report is being submitted to the Federal Communications Commission for the Certification of equipment pursuant to 2000 Title 47 CFR parts 1, 2, 21, and 74 dated 6-10-2003 Edition. FCC Rule Part Description Response 0.457dii Records not routinely available for public inspection See exhibit 13 0.459 Requests that materials or information submitted to the Commission be withheld from public inspection. See exhibit 13 2.1033(c)1 The full name and mailing address of the manufacturer of the device and the applicant for certification. NextNet Wireless, Inc. 9555 James Avenue South, Suite 270 Bloomington, MN 55431 2.1033(c)2 FCC identifier. PHX-MMDS-BASE2 2.1033(c)3 A copy of the installation and operating instructions. See information located within exhibit 8 2.1033(c)4 Type or types of emission. 21.905(b): OFDM / 5M53W7D 74.936(a): OFDM / 5M53W7D 2.1033(c)5 Frequency range. 2500 – 2686 MHz 2.1033(c)6 21.909(g)2 74.939(g)2 Range of operating power values or specific operating power levels, and description of any means provided for variation of operating power. 0.001 Watts – 2 or 5 Watts Power is adjustable by system operator. 2.1033(c)7 Maximum power rating as defined in the applicable part(s) of the rules. 21.904(b): 33 dBW EIRP 74.935(b): 33 dBW EIRP 2.1033(c)8 The dc voltages applied to and dc currents into the several elements of the final radio frequency amplifying device for normal operation over the power range. See block diagram in exhibit 4 2.1033(c)9 Tune-up procedure over the power range, or at specific operating power levels. See tune-up information in exhibit 12 2.1033(c)10 A schematic diagram and a description of all circuitry and devices provided for determining and stabilizing frequency, for suppression of spurious radiation, for limiting modulation, and for limiting power. See schematics in exhibit 5. See circuit descriptions in exhibit 12. 2.1033(c)11 A photograph or drawing of the equipment identification plate or label showing the information to be placed thereon. See exhibit 1 Exhibit 2 FCC ID: PHX-MMDS-BASE2 Attestation Statement Page 4 of 5 NextNet Wireless, Inc 11/20/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 2.1033(c)12 Photographs (8”x10”) of the equipment of sufficient clarity to reveal equipment construction and layout, including meters, if any, and labels for controls and meters and sufficient views of the internal construction to define component placement and chassis assembly. Insofar as these requirements are met by photographs or drawings contained in instruction manuals supplied with the certification request, additional photographs are necessary only to complete the required showing. See photographs in Exhibit 9 2.1033(c)13 For equipment employing digital modulation techniques, a detailed description of the modulation system to be used, including the response characteristics (frequency, phase and amplitude) of any filters provided, and a description of the modulating wavetrain, shall be submitted for the maximum rated conditions under which the equipment will be operated. See Exhibit 12 2.1033(c)14 The data required by §§ 2.1046 through 2.1057, inclusive, measured in accordance with the procedures set out in § 2.1041 See Test Report measurements in Exhibit 6 2.1033(c)15 The application for certification of an external radio frequency power amplifier under part 97 of this chapter need not be accompanied by the data required by paragraph (b)(14) of this section. In lieu thereof, measurements shall be submitted to show compliance with the technical specifications in subpart C of part 97 of this chapter and such information as required by § 2.1060 of this part. Not applicable 2.1033(c)16 An application for certification of an AM broadcast stereophonic exciter-generator intended for interfacing with existing certified, or formerly type accepted or notified transmitters must include measurements made on a complete stereophonic transmitter. The instruction book must include complete specifications and circuit requirements for interconnecting with existing transmitters. The instruction book must also provide a full description of the equipment and measurement procedures to monitor modulation and to verify that the combination of stereo exciter-generator and transmitter meet the emission limitations of § 73.44. Not applicable 2.1033(c)17 A single application may be filed for a composite system that incorporates devices subject to certification under multiple rule parts, however, the appropriate fee must be included for each device. Not applicable Exhibit 2 FCC ID: PHX-MMDS-BASE2 Attestation Statement Page 5 of 5 NextNet Wireless, Inc 11/20/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 Test Report Summary CFR Rule Part Requirement Test Result 1.1310 Radio Frequency Radiation Exposure Limits Pass 2.1046 21.904(a) 74.935(a) RF Output Power Pass 2.1047 21.905(b) 74.936(a) Modulation Characteristics Pass 2.1049 21.908(a) 74.936(c) Occupied Bandwidth Pass 2.1051 Spurious Emissions at Antenna Terminals Pass 2.1053 Field Strength of Spurious Radiation Pass 2.1055 Frequency Stability Pass 2.1091 Radio Frequency radiation exposure evaluation: mobile devices. Pass Exhibit Summary Exhibit Section Contents 1 FCC ID Label / Location Information 2 Attestation Statement and Cover Letters 3 External…

Text truncated - open the document above for the full version.

NextNet Wireless, Inc Exhibit 13 9555 James Ave. South Suite 270 FCC ID: PHX-MMDS-BASE2 Bloomington, MN 55431 Page 2 of 5 11/20/2003 Request for Confidentiality 11/20/2003 NextNet Wireless, Inc. 9555 James Avenue South Suite 270 Bloomington, MN 55431 RE: Certification Application FCC ID: PHX-MMDS-BASE2 Please be advised that the following information is to be held confidential on behalf of NextNet Wireless, Inc.: • Exhibit 4 - Block Diagrams • Exhibit 5 – Schematics • Exhibit 10 – Parts list • Exhibit 12 - Technical Description This application contains technical information that NextNet Wireless, Inc. deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of NextNet Wireless, Inc. in the market place. Thank you for your attention to this matter. Tim Blom NextNet Wireless, Inc.

NextNet Wireless, Inc Exhibit 13 9555 James Ave. South Suite 270 FCC ID: PHX-MMDS-BASE2 Bloomington, MN 55431 Page 3 of 5 11/20/2003 Modification Letter 11/20/2003 NextNet Wireless, Inc. 9555 James Avenue South Suite 270 Bloomington, MN 55431 RE: Certification Application FCC ID: PHX-MMDS-BASE2 Please be advised that the following information is a list of modifications that will be included in the production process for the above-referenced equipment. The printed circuit board will be updated to include all design changes in effect at the time of FCC compliance testing. The schematics and bill of materials associated with this filing reflect the updated design changes. Thank you for your attention to this matter. Tim Blom NextNet Wireless, Inc.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 December 12, 2003 RE: FCC ID: PHX-MMDS-BASE2_ATCB000975 Attention: I have a few comments on this Application. 1. Please complete the technical contact information on the 731 form. 2. This device is an MMDS transmitter used typically for internet service connections etc. It does not appear to provide any of the modulation or services required for ITFS stations. While part 21 and part 74 use many frequencies on a shared basis, in order to fit into part 74 the device must provide the particular service of part 74. Please note that Instructional television fixed station. Is a “fixed station licensed to an educational organization and intended primarily for video, data, or voice transmissions of instructional, cultural, and other types of educational material to one or more fixed receiving locations. “ The intent of part 74I is to “...be used to transmit formal educational programming offered for credit to enrolled students of accredited schools, with limited exceptions as set forth in paragraph (e)(9) of this section and Secs. 74.990 through 74.992.” While part 74I allows OFDM modulation, the service must still apply. Please explain how, other than similar modulation characteristics, this device fits the definition and requirements of a part 74I “Instructional Television Fixed Service”. 3. Please note that you have a calculation error on page 5 of the report under “Test Conclusions” Vertically polarized. In the report your state “ Transmitted Power = 33 + 19 = 53 dBim. Please note the 33_19 is 52. Please correct. 4. Please note that on page 3and 52 of the report you state calibration is not required for the inline attenuator used in power and antenna spurious emissions measurements. The calibration chart also does not show the directional coupler as being calibrated. Please note that any test equipment used that has a direct affect of the measurement accuracy needs to be calibrated or the correction factors at least need to be known. When using non-calibrated equipment it is not possible to clearly and unambiguously state the measurement results. Please provide evidence that the attenuator used was calibrated. Alternately, please provide evidence that the attenuator was the value as stated and that it was appropriately included in calculating power and conducted spurious emissions. Please show the sample calculations using all appropriate inline losses or gains in the measurement system. How are they accounted for? For example, what affect does the MMDS channel filter have on the measurement of the 5 watt setup? What is the loss, if any, of the directional coupler? 5. Please note that while the method RECOMMENDATION ITU-R SM.329-10 may be accepted by and incorporated in many ETSI standards, it is not a recognized FCC spurious emissions certification test procedure for licensed devices. Radiated spurious emissions are required by the FCC to be a measurement done by antenna substitution methods. Please provide radiated spurious emissions in accordance with FCC accepted procedures for making EIRP measurements using antenna substitution test methods. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. z Page 2 December 12, 2003 Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Reply to ATCB comments for PHX-MMDS-BASE2 Page 1 of 3 12/15/03 RE: FCC ID: PHX-MMDS-BASE2_ATCB000975 1. Please complete the technical contact information on the 731 form. ** Completed. New 731 form uploaded. 2. This device is an MMDS transmitter used typically for internet service connections etc. It does not appear to provide any of the modulation or services required for ITFS stations. While part 21 and part 74 use many frequencies on a shared basis, in order to fit into part 74 the device must provide the particular service of part 74. Please note that Instructional television fixed station. Is a “fixed station licensed to an educational organization and intended primarily for video, data, or voice transmissions of instructional, cultural, and other types of educational material to one or more fixed receiving locations. “ The intent of part 74I is to “...be used to transmit formal educational programming offered for credit to enrolled students of accredited schools, with limited exceptions as set forth in paragraph (e)(9) of this section and Secs. 74.990 through 74.992.” While part 74I allows OFDM modulation, the service must still apply. Please explain how, other than similar modulation characteristics, this device fits the definition and requirements of a part 74I “Instructional Television Fixed Service”. ** While NextNet Wireless, Inc. does believe that most system installations of the Expedience product will be used for an internet connection at the end user computer, that is not the only capability of the system. A license holder in the ITFS spectrum could construct a system that utilizes the NextNet Wireless, Inc. Expedience products within a proprietary closed wireless Ethernet network that may or may not make a connection to the internet. A NextNet Wireless, Inc. system will transport information from one point to another via a wireless medium. The specific content of the user data being transmitted is beyond the control of NextNet Wireless, Inc. The requirement of ensuring that an ITFS channel is utilized for “educational purposes” rests solely on the channel license holder and system operator. NextNet Wireless, Inc. is responsible for insuring that it’s products supplied to the system operator meet the applicable technical equipment requirements that are detailed within the FCC rules. 3. Please note that you have a calculation error on page 5 of the report under “Test Conclusions” Vertically polarized. In the report your state “Transmitted Power = 33 + 19 = 53 dBim. Please note the 33_19 is 52. Please correct. ** Completed. New test report uploaded. 4. Please note that on page 3and 52 of the report you state calibration is not required for the inline attenuator used in power and antenna spurious emissions measurements. The calibration chart also does not show the directional coupler as being calibrated. Please note that any test equipment used that has a direct affect of the measurement accuracy needs to be calibrated or the correction factors at least need to be known. When using non-calibrated equipment it is not possible to clearly and unambiguously state the measurement results. Please provide evidence that the attenuator used was calibrated. Alternately, please provide evidence that the attenuator was the value as stated and that it was appropriately included in calculating power and conducted spurious emissions. Please show the sample calculations using all appropriate inline losses or gains in the measurement system. How are they accounted for? For example, what affect does the MMDS channel filter have on the measurement of the 5 watt setup? What is the loss, if any, of the directional coupler? Reply to ATCB comments for PHX-MMDS-BASE2 Page 2 of 3 12/15/03 ** Attenuators are not routinely sent to a calibration laboratory for certification like a power meter or spectrum analyzer would be. For all measurements, the loss of the coax, attenuator, and directional coupler is verified by means of a network analyzer measurement. Once the loss of the coax, attenuator, and thru path of the directional coupler is known, this value is entered into the reference level offset of the power meter such that power measurements can be displayed without additional mathematical manipulation. 20 dB attenuator / directional coupler thru path / coax cable RF characteristics 30 dB attenuator / directional coupler thru path / coax cable RF characteristics Reply to ATCB comments for PHX-MMDS-BASE2 Page 3 of 3 12/15/03 directional coupler thru path RF characteristics The MMDS channel filter provides additional loss to the transmitted signal. As discussed in Exhibit 12, the base station is calibrated for RF power at the antenna connector prior to the addition of the channel filter. The test data supplied in the test report was measured without the MMDS channel filter installed. The test report has been updated to include the transmit power at the output of the channel filter. For modulation mask and occupied bandwidth measurements, the attenuators are selected to ensure that the spectrum analyzer is not being over driven and generating distortion within the analyzer. The coupled path of the directional coupler is approximately 20 dB, add 26 dB for the attenuators and 1 dB for coax loss and the overall loss is about 47 dB. The specific loss of this signal path is not utilized for any calculations and is therefore not known to the degree of accuracy as is required for power measurements. Measurements performed via the coupled path of the directional coupler rely on the calibration of the spectrum analyzer to report a valid representation of the applied signal. 5. Please note that while the method RECOMMENDATION ITU-R SM.329-10 may be accepted by and incorporated in many ETSI standards, it is not a recognized FCC spurious emissions certification test procedure for licensed devices. Radiated spurious emissions are required by the FCC to be a measurement done by antenna substitution methods. Please pr…

Text truncated - open the document above for the full version.

FCC ID: PHX-MMDS-BASE2 Page 1 of 5 NextNet Wireless, Inc 11/20/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 3 External Photographs Exhibit 3 FCC ID: PHX-MMDS-BASE2 External Photographs Page 2 of 5 NextNet Wireless, Inc 11/20/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 Front view (2 watt) Exhibit 3 FCC ID: PHX-MMDS-BASE2 External Photographs Page 3 of 5 NextNet Wireless, Inc 11/20/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 Back view (2 watt) Exhibit 3 FCC ID: PHX-MMDS-BASE2 External Photographs Page 4 of 5 NextNet Wireless, Inc 11/20/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 Front view (5 watt) Exhibit 3 FCC ID: PHX-MMDS-BASE2 External Photographs Page 5 of 5 NextNet Wireless, Inc 11/20/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 Back view (5 watt)

FCC ID: PHX-MMDS-BASE2 Page 1 of 3 NextNet Wireless, Inc 11/20/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 1 FCC Labeling Requirements and Information Exhibit 1 FCC ID: PHX-MMDS-BASE2 FCC Labeling Requirements and Information Page 2 of 3 NextNet Wireless, Inc 11/20/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 11/20/2003 NextNet Wireless, Inc. 9555 James Avenue South Suite 270 Bloomington, MN 55431 RE: FCC Labeling Requirements FCC ID: PHX-MMDS-BASE2 The following label information is required by the FCC Rules and Regulations for certified devices. Thank you for your attention to these matters. Sincerely, Tim Blom NextNet Wireless, Inc. Exhibit 1 FCC ID: PHX-MMDS-BASE2 FCC Labeling Requirements and Information Page 3 of 3 NextNet Wireless, Inc 11/20/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 ID Label / Location Information The FCC ID label is attached to the fixed station unit with a permanent adhesive. Label sample Photo showing label location on base unit FCC ID: PHX-MMDS-BASE2 Part Number: 900-0150-1XXX ||||| ||||||| ||||| ||||| |||||||||| |||||| ||||| ||| ||||||| ||||| ||||||||||| ||||||| ||||| ||||||| ||||| ||||| |||||||||| |||||| ||||| ||| ||||||| ||||| ||||||||||| ||||||| SN: 1234X123XAAX87654321 ||||||||||||| |||||||||||| |||||||||||||||||| ||||| ||||||| |||| |||||||| |||| ||||||||||||| |||||||||||| |||||||||||||||||| ||||| ||||||| |||| |||||||| |||| This device complies with Part 15 of the FCC Rules. NextNet Wireless Inc. Minneapolis, MN 55431

FCC ID: PHX-MMDS-BASE2 Page 1 of 7 NextNet Wireless, Inc 11/20/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 9 Internal Photographs Exhibit 9 FCC ID: PHX-MMDS-BASE2 Internal Photographs Page 2 of 7 NextNet Wireless, Inc 11/20/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 RF Board Component Side (no shields) RF Board Solder Side Exhibit 9 FCC ID: PHX-MMDS-BASE2 Internal Photographs Page 3 of 7 NextNet Wireless, Inc 11/20/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 Logic Board Component Side Logic Board Solder Side Exhibit 9 FCC ID: PHX-MMDS-BASE2 Internal Photographs Page 4 of 7 NextNet Wireless, Inc 11/20/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 Power Supply Board Component Side Power Supply Board Solder Side Exhibit 9 FCC ID: PHX-MMDS-BASE2 Internal Photographs Page 5 of 7 NextNet Wireless, Inc 11/20/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 Input Connector Board Component Side Input Connector Board Solder Side Exhibit 9 FCC ID: PHX-MMDS-BASE2 Internal Photographs Page 6 of 7 NextNet Wireless, Inc 11/20/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 Overall Product Pictures RF Board and Input Connector Board RF Board, Power Supply Board and Input Connector Board Exhibit 9 FCC ID: PHX-MMDS-BASE2 Internal Photographs Page 7 of 7 NextNet Wireless, Inc 11/20/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 Logic Board, RF Board, Power Supply Board and Input Connector Board

Exhibit 11 FCC ID: PHX-MMDS-BASE2 Radio Frequency Exposure Page 1 of 6 NextNet Wireless, Inc 11/20/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 11 RF Exposure Information Exhibit 11 FCC ID: PHX-MMDS-BASE2 Radio Frequency Exposure Page 2 of 6 NextNet Wireless, Inc 11/20/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 Radio Frequency Radiation Exposure Evaluation Rule Part Number: 1.1307, 1.1310, 2.1091 1.1307 Actions that may have a significant environmental effect, for which Environmental Assessments (EAs) must be prepared. TABLE 1—TRANSMITTERS, FACILITIES AND OPERATIONS SUBJECT TO ROUTINE ENVIRONMENTAL EVALUATION Multipoint Distribution Service (subpart K of part 21). Non-building-mounted antennas: height above ground level to lowest point of antenna < 10 m and power > 1640 W EIRP Building-mounted antennas: power > 1640 W EIRP MDS licensees are required to attach a label to subscriber transceiver or transverter antennas that: (1) provides adequate notice regarding potential radio frequency safety hazards, e.g., information regarding the safe minimum separation distance required between users and transceiver antennas; and (2) references the applicable FCC-adopted limits for radio frequency exposure specified in § 1.1310. Experimental, auxiliary, and special broadcast and other program distributional services (part 74). Subpart I: non-building-mounted antennas: height above ground level to lowest point of antenna < 10 m and power > 1640 W EIRP Building-mounted antennas: power > 1640 W EIRP ITFS licensees are required to attach a label to subscriber transceiver or transverter antennas that: (1) provides adequate notice regarding potential radio frequency safety hazards, e.g., information regarding the safe minimum separation distance required between users and transceiver antennas; and (2) references the applicable FCC-adopted limits for radio frequency exposure specified in § 1.1310. 1.1310 Radio frequency radiation exposure limits. TABLE 1—LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) (A) Limits for Occupational/Controlled Exposures 1500–100,000 ..................... ...................... ......................... 5 6 (B) Limits for General Population/Uncontrolled Exposure 1500–100,000 ..................... ..................... ...................... 1.0 30 f = frequency in MHz Exhibit 11 FCC ID: PHX-MMDS-BASE2 Radio Frequency Exposure…
