PHX-MMDS-CPE4Non-Line of Site Wireless Data Link

i Installing and using the Expedience RSU-2510 Directions for connecting your RSU to a computer or LAN and obtaining high-speed Internet access. ii Expedience and LinkMonitor are trademarks of NextNet Wireless, Inc. Other brand and product names may be registered trademarks or trademarks of their respective holders. Part number: 104-0015-0002 ©2002 NextNet Wireless, Inc. All rights reserved. THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS GUIDE ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS GUIDE ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCT. FOR WARRANTY INFORMATION ON THE EXPEDIENCE RSU-2510, CONTACT THE INTERNET SERVICE PROVIDER THAT SUPPLIED THE RSU. NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE THAT ARE PROVIDED ON THE EXPEDIENCE BROADBAND WIRELESS ACCESS MODEM CD-ROM ARE PROVIDED “AS IS” WITH ALL FAULTS. NEXTNET WIRELESS DISCLAIMS ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITATION, THOSE OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF DEALING, USAGE, OR TRADE PRACTICE. IN NO EVENT SHALL NEXTNET WIRELESS OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING, WITHOUT LIMITATION, LOST PROFITS OR LOSS OF DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS GUIDE, EVEN IF NEXTNET WIRELESS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Contents iii Welcome................................................................................ 1 Before you begin .................................................................. 1 Connecting your RSU to a computer ...................................... 3 Installation overview ............................................................ 3 Setting up the computer to dynamically receive an IP address .... 3 Windows 95, Windows NT, Windows 98, Windows ME: Setting up the network connection ......................................................... 3 Windows 2000: Setting up the network connection ................... 3 Windows XP: Setting up the network connection ....................... 4 Plugging in the RSU .............................................................. 4 Finding the strongest service provider signal ............................ 7 Using the indicator lights to find the strongest service provider signal ................................................................................. 8 Using the software-assisted method to find the strongest signal 10 Fine-tuning the connection to the service provider ...................12 Connecting to the Internet ...................................................12 Renewing the host computer’s IP address........................... 13 Windows users: Renewing the IP address ...............................13 Non-Windows users: Renewing the IP address ........................13 Connecting the RSU to a network ........................................ 13 Troubleshooting .................................................................. 13 The RSU can successfully receive a signal at home, but not at work or at a friend’s house ...............................................13 The RSU cannot receive your service provider’s signal ..............14 The RSU’s lights blink in sequence .........................................14 You successfully completed the signal scan, but your Internet browser cannot connect to a web site ....................................16 The lights on the RSU blink more slowly than normal ...............16 You receive a dialog box indicating that you cannot connect to your service provider .......................................................16 LinkMonitor application cannot communicate with RSU when VPN is used ........................................................................17 RSU malfunctions after you write on the RSU or attach stickers to the RSU .........................................................................17 FCC information ................................................................... 19 iv 1 Welcome This document describes how to install and use your Expedience residential subscriber unit (RSU-2510) to obtain wireless high-speed Internet access. You can connect your RSU to a computer or to a small office/home office (SOHO) local area network (LAN) through a hub, switch, or router. BEFORE YOU BEGIN •Make sure your computer is equipped with an Ethernet network interface card (NIC). •The Ethernet cable that is supplied with your RSU plugs into any standard Ethernet NIC. The NIC is not provided with the RSU, but you can purchase a NIC at most computer and electronics stores. •Find an appropriate location for your RSU. •Make sure you are operating the RSU in a room near an outside window on the first or second floor of your home or office. •You need to locate the RSU close to a wall outlet. The RSU uses a standard power supply and can sit on a desktop or shelf. •Your RSU comes with a category-5 Ethernet cable. If you choose to place the RSU a good distance from your computer, you may need to purchase a longer Ethernet cable. If you purchase a cable, make sure the cable is a category-5 Ethernet cable with RJ-45 connectors on each end. •Locate the components shipped with your RSU device: •RSU device •Software CD-ROM •RSU Quick Start Guide •Power cable and power supply box •Ethernet cable 2 Figure 1 illustrates the RSU package contents. Table 1 lists the standard contents in your RSU package. Figure 1: RSU package contents Table 1: RSU package components ComponentPart number RSU package (vertical polarization)900-0015-1001 RSU device (vertical polarization)127-0015-1001 Power supply cord420-0015-1000 Power cord597-5120-0107 Quick Start Guide102-0015-0003 Installation software CD-ROM110-0002-0001 Ethernet cable597-6010-0001 RSU device …

Text truncated - open the document above for the full version.

NextNet Wireless, Inc Exhibit 13 9555 James Ave. South Suite 270 FCC ID: PHX-MMDS-CPE4 Bloomington, MN 55431 Page 1 of 5 11/28/2002 Exhibit 13 Correspondence NextNet Wireless, Inc Exhibit 13 9555 James Ave. South Suite 270 FCC ID: PHX-MMDS-CPE4 Bloomington, MN 55431 Page 2 of 5 11/28/2002 Request for Confidentiality 11/28/2002 NextNet Wireless, Inc. 9555 James Avenue South Suite 270 Bloomington, MN 55431 RE: Certification Application FCC ID: PHX-MMDS-CPE4 Please be advised that the following information is to be held confidential and behalf of NextNet Wireless, Inc.: • Exhibit 4 - Block Diagrams • Exhibit 5 – Schematics • Exhibit 10 – Parts list • Exhibit 12 - Technical Description The application contains technical information which NextNet Wireless, Inc. deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Tim Blom NextNet Wireless, Inc. NextNet Wireless, Inc Exhibit 13 9555 James Ave. South Suite 270 FCC ID: PHX-MMDS-CPE4 Bloomington, MN 55431 Page 3 of 5 11/28/2002 Modification Letter 11/28/2002 NextNet Wireless, Inc. 9555 James Avenue South Suite 270 Bloomington, MN 55431 RE: Certification Application FCC ID: PHX-MMDS-CPE4 Please be advised that the following information is a list of modifications that will be included in the production process for the above-referenced equipment. No modifications were performed during the measurement of this product for FCC compliance. Thank you for your attention to this matter. Tim Blom NextNet Wireless, Inc. NextNet Wireless, Inc Exhibit 13 9555 James Ave. South Suite 270 FCC ID: PHX-MMDS-CPE4 Bloomington, MN 55431 Page 4 of 5 11/28/2002 Warning Statements and Locations The following warning statement is located in the “Installing and using your CPE device” manual. NOTICE: This equipment has been tested and found to comply with the Radio Frequency Radiation Exposure Limits detailed below. A minimum of 20 centimeter (8 inches) separation between the CPE and the operator and all other persons should be maintained. NextNet Wireless, Inc Exhibit 13 9555 James Ave. South Suite 270 FCC ID: PHX-MMDS-CPE4 Bloomington, MN 55431 Page 5 of 5 11/28/2002 Manufacturer’s Letter 11/28/2002 NextNet Wireless, Inc. 9555 James Avenue South Suite 270 Bloomington, MN 55431 RE: Certification Application FCC ID: PHX-MMDS-CPE4 To Whom It May Concern: Please be advised that the manufacturer will ensure that the above-referenced model will be manufactured in accordance with the FCC Rules and Regulations. Thank you for your attention to this matter. Tim Blom NextNet Wireless, Inc.

Response to American TCB questions for FCC ID: PHX-MMDS-CPE4 Page 1 of 1 NextNet Wireless, Inc. 1/28/2003 2) This device contains an Ethernet port and is therefore considered a PC peripheral under Part 15 for the Digital Device emissions from the device. Therefore this device is also subject to both the radiated and conducted emissions under Part 15 with the device in an idle mode of (either a Certification or DoC at the discretion of the manufactuer). Please note that for this test the device must be configured as part of a minimum configuration (including a PC + 2 additional I/O connections) as specified by ANSI C63.4. Please explain whether the device is to be subject to a DoC or Certification for the PC peripheral requirements. Please note that the device does not contain DoC labeling information or a statement of compliance (2.1077) as required for DoC authorizations nor has the digital device data been presented as part of this application as would be required for a certification. The following DoC information is being added to the operating manual for this product: Declaration of Conformity Compliance Information - Class B computer peripheral. - This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Responsible Party: NextNet Wireless, Inc. 9555 James Ave. South Suite 270 Bloomington, MN 55431 952-929-4008 An additional label with DoC information and RF Exposure information is being added to the product, see attached Exhibit 1 - FCC Labeling Requirements and Information.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 December 24, 2002 RE: NextNet Wireless Inc. FCC ID: PHX-MMDS-CPE4 After a review of the submitted information, I have a few comments on the above referenced Application. 1) The block diagram should show the frequencies within the TX portion of the device (CFR 2.1033(a)(5)). Please provide an updated block diagram. 2) This device contains an Ethernet port and is therefore considered a PC peripheral under Part 15 for the Digital Device emissions from the device. Therefore this device is also subject to both the radiated and conducted emissions under Part 15 with the device in an idle mode of (either a Certification or DoC at the discretion of the manufactuer). Please note that for this test the device must be configured as part of a minimum configuration (including a PC + 2 additional I/O connections) as specified by ANSI C63.4. Please explain whether the device is to be subject to a DoC or Certification for the PC peripheral requirements. Please note that the device does not contain DoC labeling information or a statement of compliance (2.1077) as required for DoC authorizations nor has the digital device data been presented as part of this application as would be required for a certification. 3) The users manual should also include the required information specified by 15.105 and 15.21. 4) It is not clear if the device always contains one or two antennas. Please provide an additional photograph or information that shows the antenna(s) of the device and how they are integrated into the device. 5) Regarding the RF exposure measurements made, please comment on the measurement instrumentation. Note that diode detectors can underestimate field levels in high peak pulsed-signal fields due to diode saturation. Also, please provide information regarding the measurements uncertainty of the equipment used. 6) Licensed bands have typically required EIRP measurements for the fundamental to be made using a substitution method. Please comment. 7) Part 21. 908(d) and 74.936(f) state that out of band emissions are required to meet 60 dB. This test report uses 43 + 10 log(2). Note that 60 dB below the EIRP is slightly more stringent than -13 dBm calculated using 43 + 10 log(2). 8) Please comment on the 2 antennas. Are these considered to be phased-array or steered-beam antennas? Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

FCC ID: PHX-MMDS-CPE4 Page 1 of 3 Exhibit 3 External Photographs NextNet Wireless, Inc 11/28/2002 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 3 FCC ID: PHX-MMDS-CPE4 External Photographs Page 2 of 3 Front view NextNet Wireless, Inc 11/28/2002 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 3 FCC ID: PHX-MMDS-CPE4 External Photographs Page 3 of 3 NextNet Wireless, Inc 11/28/2002 9555 James Ave. South Suite 270 Bloomington, MN 55431 Back view

FCC ID: PHX-MMDS-CPE4 Page 1 of 1 Exhibit 1 FCC Labeling Requirements and Information NextNet Wireless, Inc 1/28/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 1 FCC ID: PHX-MMDS-CPE4 FCC Labeling Requirements and Information Page 2 of 2 1/28/2002 NextNet Wireless, Inc. 9555 James Avenue South Suite 270 Bloomington, MN 55431 RE: FCC Labeling Requirements FCC ID: PHX-MMDS-CPE4 The following label information is required by the FCC Rules and Regulations for certified devices and Class B personal computers and peripherals. Thank you for your attention to these matters. Sincerely, Tim Blom NextNet Wireless, Inc. NextNet Wireless, Inc 1/28/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 1 FCC ID: PHX-MMDS-CPE4 FCC Labeling Requirements and Information Page 3 of 3 ID Label / Location Information The FCC ID label will be attached to the Indoor CPE unit with a permanent adhesive. Label samples NextNet ® Wireless Inc., Minneapolis, MN 55431 USA FCC ID: PHX-MMDS-CPE4 Part Number: 900-0015-1XXX ||||| ||||||| ||||| ||||| |||||||||| |||||| ||||| ||||| ||||||| ||||| ||||| |||||||||| |||||| ||||| SN: 1234X123XAAX87654321 ||||||||||||| |||||||||||| |||||||||||||||||| ||||| ||||||||||||| |||||||||||| |||||||||||||||||| ||||| RSU-2510-BV 19.5Vdc 2.5A This device Complies With Part 15 of the FCC Rules. Vertically polarized antenna indoor CPE label NextNet ® Wireless Inc., Minneapolis, MN 55431 USA FCC ID: PHX-MMDS-CPE4 Part Number: 900-0015-2XXX ||||| ||||||| ||||| ||||| |||||||||| |||||| ||||| ||||| ||||||| ||||| ||||| |||||||||| |||||| ||||| SN: 1234X123XAAX87654321 ||||||||||||| |||||||||||| |||||||||||||||||| ||||| ||||||||||||| |||||||||||| |||||||||||||||||| ||||| RSU-2510-BH 19.5Vdc 2.5A This device Complies With Part 15 of the FCC Rules. Horizontally polarized antenna indoor CPE label To comply with FCC radio frequency exposure rules, 47CFR1.1307 and 1.1310, a minimum separation of 20 cm (8 inches) is required between this device and all persons. Declaration of Conformity label NextNet Wireless, Inc 1/28/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 1 FCC ID: PHX-MMDS-CPE4 FCC Labeling Requirements and Information Page 4 of 4 NextNet Wireless, Inc 1/28/2003 9555 James Ave. South Suite 270 Bloomington, MN 55431 Photo showing label locations on indoor CPE unit

FCC ID: PHX-MMDS-CPE4 Page 1 of 10 Exhibit 9 Internal Photographs NextNet Wireless, Inc 11/28/2002 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 9 FCC ID: PHX-MMDS-CPE4 Internal Photographs Page 2 of 10 RF Board component side (no shields) NextNet Wireless, Inc 11/28/2002 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 9 FCC ID: PHX-MMDS-CPE4 Internal Photographs Page 3 of 10 RF Board component side (with shields) NextNet Wireless, Inc 11/28/2002 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 9 FCC ID: PHX-MMDS-CPE4 Internal Photographs Page 4 of 10 PC Board back side NextNet Wireless, Inc 11/28/2002 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 9 FCC ID: PHX-MMDS-CPE4 Internal Photographs Page 5 of 10 Antenna Plate (antenna side) NextNet Wireless, Inc 11/28/2002 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 9 FCC ID: PHX-MMDS-CPE4 Internal Photographs Page 6 of 10 Antenna Plate (back side) NextNet Wireless, Inc 11/28/2002 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 9 FCC ID: PHX-MMDS-CPE4 Internal Photographs Page 7 of 10 Vertically Polarized Antenna NextNet Wireless, Inc 11/28/2002 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 9 FCC ID: PHX-MMDS-CPE4 Internal Photographs Page 8 of 10 Vertically Polarized Antenna (copper side) NextNet Wireless, Inc 11/28/2002 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 9 FCC ID: PHX-MMDS-CPE4 Internal Photographs Page 9 of 10 Horizontally Polarized Antenna NextNet Wireless, Inc 11/28/2002 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 9 FCC ID: PHX-MMDS-CPE4 Internal Photographs Page 10 of 10 NextNet Wireless, Inc 11/28/2002 9555 James Ave. South Suite 270 Bloomington, MN 55431 Horizontally Polarized Antenna (copper side)

Exhibit 11 FCC ID: PHX-MMDS-CPE4 Radio Frequency Exposure Page 1 of 7 Exhibit 11 RF Exposure Information NextNet Wireless, Inc 11/28/2002 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 11 FCC ID: PHX-MMDS-CPE4 Radio Frequency Exposure Page 2 of 7 Radio Frequency Radiation Exposure Evaluation Rule Part Number: 1.1307, 1.1310, 2.1091 1.1307 Actions that may have a significant environmental effect, for which Environmental Assessments (EAs) must be prepared. TABLE 1—TRANSMITTERS, FACILITIES AND OPERATIONS SUBJECT TO ROUTINE ENVIRONMENTAL EVALUATION Multipoint Distribution Service (subpart K of part 21). Non-building-mounted antennas: height above ground level to lowest point of antenna < 10 m and power > 1640 W EIRP Building-mounted antennas: power > 1640 W EIRP MDS licensees are required to attach a label to subscriber transceiver or transverter antennas that: (1) provides adequate notice regarding potential radio frequency safety hazards, e.g., information regarding the safe minimum separation distance required between users and transceiver antennas; and (2) references the applicable FCC-adopted limits for radio frequency exposure specified in § 1.1310. Experimental, auxiliary, and special broadcast and other program distributional services (part 74). Subpart I: non-building-mounted antennas: height above ground level to lowest point of antenna < 10 m and power > 1640 W EIRP Building-mounted antennas: power > 1640 W EIRP ITFS licensees are required to attach a label to subscriber transceiver or transverter antennas that: (1) provides adequate notice regarding potential radio frequency safety hazards, e.g., information regarding the safe minimum separation distance required between users and transceiver antennas; and (2) references the applicable FCC-adopted limits for radio frequency exposure specified in § 1.1310. 1.1310 Radio frequency radiation exposure limits. TABLE 1—LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) (A) Limits for Occupational/Controlled Exposures 1500–100,000 ..................... ...................... ......................... 5 6 (B) Limits for General Population/Uncontrolled Exposure 1500–100,000 ..................... ..................... ...................... 1.0 30 f = frequency in MHz NextNet Wireless, Inc 11/28/2002 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 11 FCC ID: PHX-MMDS-CPE4 Radio Frequency Exposure Page 3 of 7 Radio Frequency Radiation Exposure Evaluation § 2.1091 Radio Frequency radiation exposure evaluation: mobile devices. (a) Requirements of this section are a consequence of Commission responsibilities under the National Environ-mental Policy Act to evaluate the environmental significance of its actions. See subpart I of part 1 of this chapter, in particular § 1.1307(b). (b) For purposes of this section, a mobile device is defined as a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter’s radiating structure(s) and the body of the user or nearby persons. In this context, the term ‘‘fixed location’’ means that the device is physically secured at one location and is not able to be easily moved to another location. Transmitting devices designed to be used by consumers or workers that can be easily relocated, such as wireless devices associated with a personal computer, are considered to be mobile devices if they meet the 20 centimeter separation requirement. (d) The limits to be used for evaluation are specified in § 1.1310 of this chapter. All unlicensed personal communications service (PCS) devices and unlicensed NII devices shall be subject to the limits for general population/un-controlled exposure. (1) For purposes of analyzing mobile transmitting devices under the occupational/ controlled criteria specified in § 1.1310 of this chapter, time-averaging provisions of the guidelines may be used in conjunction with typical maximum duty factors to determine maximum likely exposure levels. (2) Time-averaging provisions may not be used in determining typical exposure levels for devices intended for use by consumers in general population uncontrolled environments as defined in § 1.1310 of this chapter. However, ‘‘source-based’’ time-averaging based on an inherent property or duty- cycle of a device is allowed. An example of this is the determination of exposure from a device that uses digital technology such as a time-division multiple-access (TDMA) scheme for transmission of a signal. In general, maximum average power levels must be used to determine compliance. Calculations: The information contained in 1.1307(b)(1) Table 1 indicates that an RF Exposure label be attached to the transmitting antenna for equipment operating in the MDS and ITFS bands that exceed 1640 Watts EIRP. The NextNet Wireless Expedience system operates at a maximum of 2 watts (33dBm) average power while transmitting. The Customer Premise Equipment (CPE) has a maximum transmit duty cycle of 14.29 % and is based on a TDM frame. NextNet Wireless, Inc 11/28/2002 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 11 FCC ID: PHX-MMDS-CPE4 Radio Frequency Exposure Page 4 of 7 Radio Frequency Radiation Exposure Evaluation The vertically polarized antenna for the transmitting signal has 13 dBi of gain. Therefore the maximum radiated transmit power would be: 14.29 % Transmit duty cycle: Pmax = Ptx + G(antenna) - 10*log(duty cycle) Pmax = 33 + 13 - 10*log(.1429) Pmax = 33 + 13 – 8.45 Pmax = 37.55 dBim = 5.688 Watts EIRP < 1640 Watts EIRP The horizontally polarized antenna for the transmitting signal has 11 dBi of gain. Therefore the maximum transmitting power would be: 14.29 % Transmit duty cycle: Pmax = Ptx + G(antenna) - 10*log(duty cycle) Pmax = 33 + 12.2 - 10*…

Text truncated - open the document above for the full version.

FCC ID: PHX-MMDS-CPE4 Page 1 of 5 Exhibit 2 Attestation Statement Cover Letters NextNet Wireless, Inc 11/28/2002 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 2 FCC ID: PHX-MMDS-CPE4 Attestation Statement Page 2 of 5 The measurements performed on the test sample for this FCC product Certification were performed by me or by personnel under my direction. Tim Blom Principal Engineer NextNet Wireless, Inc 11/28/2002 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 2 FCC ID: PHX-MMDS-CPE4 Attestation Statement Page 3 of 5 Cover Letters Gentlemen: This report is being submitted to the Federal Communications Commission for the Certification of equipment pursuant to 2000 Title 47 CFR parts 1, 2, 21, and 74 dated 9-24-2002 Edition. FCC Rule Part Description Response 0.457dii Records not routinely available for public inspection See exhibit 13 0.459 Requests that materials or information submitted to the Commission be withheld from public inspection. See exhibit 13 2.1033(c)1 The full name and mailing address of the manufacturer of the device and the applicant for certification. NextNet Wireless, Inc. 9555 James Avenue South, Suite 270 Bloomington, MN 55431 2.1033(c)2 FCC identifier. PHX-MMDS-CPE4 2.1033(c)3 A copy of the installation and operating instructions. See information located within exhibit 8 2.1033(c)4 Type or types of emission. 21.905(b): OFDM / 5M80W7D 74.936(a): OFDM / 5M80W7D 2.1033(c)5 Frequency range. 2500 – 2686 MHz 2.1033(c)6 21.909(g)2 74.939(g)2 Range of operating power values or specific operating power levels, and description of any means provided for variation of operating power. 0.001 Watts – 2 Watts Power is adjusted by system based on signal level received at the base station site. 2.1033(c)7 Maximum power rating as defined in the applicable part(s) of the rules. 21.909(n): 18 dBW EIRP 74.939(p): 18 dBW EIRP 2.1033(c)8 The dc voltages applied to and dc currents into the several elements of the final radio frequency amplifying device for normal operation over the power range. See block diagram in exhibit 4 2.1033(c)9 Tune-up procedure over the power range, or at specific operating power levels. See tune-up information in exhibit 12 2.1033(c)10 A schematic diagram and a description of all circuitry and devices provided for determining and stabilizing frequency, for suppression of spurious radiation, for limiting modulation, and for limiting power. See schematics in exhibit 5. See circuit descriptions in exhibit 12. 2.1033(c)11 A photograph or drawing of the equipment identification plate or label showing the information to be placed thereon. See exhibit 1 NextNet Wireless, Inc 11/28/2002 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 2 FCC ID: PHX-MMDS-CPE4 Attestation Statement Page 4 of 5 2.1033(c)12 Photographs (8”x10”) of the equipment of sufficient clarity to reveal equipment construction and layout, including meters, if any, and labels for controls and meters and sufficient views of the internal construction to define component placement and chassis assembly. Insofar as these requirements are met by photographs or drawings contained in instruction manuals supplied with the certification request, additional photographs are necessary only to complete the required showing. See photographs in Exhibit 9 2.1033(c)13 For equipment employing digital modulation techniques, a detailed description of the modulation system to be used, including the response characteristics (frequency, phase and amplitude) of any filters provided, and a description of the modulating wavetrain, shall be submitted for the maximum rated conditions under which the equipment will be operated. See Exhibit 12 2.1033(c)14 The data required by §§ 2.1046 through 2.1057, inclusive, measured in accordance with the procedures set out in § 2.1041 See Test Report measurements in Exhibit 6 2.1033(c)15 The application for certification of an external radio frequency power amplifier under part 97 of this chapter need not be accompanied by the data required by paragraph (b)(14) of this section. In lieu thereof, measurements shall be submitted to show compliance with the technical specifications in subpart C of part 97 of this chapter and such information as required by § 2.1060 of this part. Not applicable 2.1033(c)16 An application for certification of an AM broadcast stereophonic exciter-generator intended for interfacing with existing certified, or formerly type accepted or notified transmitters must include measurements made on a complete stereophonic transmitter. The instruction book must include complete specifications and circuit requirements for interconnecting with existing transmitters. The instruction book must also provide a full description of the equipment and measurement procedures to monitor modulation and to verify that the combination of stereo exciter-generator and transmitter meet the emission limitations of § 73.44. Not applicable 2.1033(c)17 A single application may be filed for a composite system that incorporates devices subject to certification under multiple rule parts, however, the appropriate fee must be included for each device. Not applicable NextNet Wireless, Inc 11/28/2002 9555 James Ave. South Suite 270 Bloomington, MN 55431 Exhibit 2 FCC ID: PHX-MMDS-CPE4 Attestation Statement Page 5 of 5 NextNet Wireless, Inc 11/28/2002 9555 James Ave. South Suite 270 Bloomington, MN 55431 Test Report Summary CFR Rule Part Requirement Test Result 2.1046 21.909(n) 74.939(p) RF Output Power Pass 2.1047 21.905(b) 74.936(a) Modulation Characteristics Pass 2.1049 21.908(d) 74.936(e) Occupied Bandwidth Pass 2.1051 Spurious Emissions at Antenna Terminals Pass 2.1053 Field Strength of Spurious Radiation Pass 2.105…

Text truncated - open the document above for the full version.
