PHYMAX09151Mobile Terminal

think dig High Tech Solutions GmbH

Click to zoom

Application Details

Equipment Class: DXT - Part 15 Low Power Transceiver, Rx Verified
Date of Grant: Oct 24, 2007
Application Purpose: Original Equipment
Date of Application: Oct 24, 2007
Equipment Note: Mobile Terminal
Frequency Range: 902.20000000 - 905.20000000
Company: think dig High Tech Solutions GmbH
Country: Austria

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

.Max. Users manual CAUTION: Any changes or modification not expressively appoved by the party responsible for compliance could avoid the user’s authority to operate the equipment ! © 2007-09-20 by Bachstraße 59, 5023 Salzburg – Austria - EU www.orderman.com Mistakes and typing errors excepted. Copying, including copying of extracts, is not permitted unless written permission has been given by think dig High Tech Solutions GmbH. P3.70-083 V2.0 ∑ Think dig takes no responsibility for damages or losses that result through use of these instructions. ∑ Think dig takes no responsibility for third party losses or claims that result from the use of the ORDERMAN “ Max. ∑ Changes to the content of these instructions are reserved and changes may be made without giving advan- ce notice. ∑ These instructions for use may not be part of a contract. ∑ Trade marks: All brands and product names are the trademarks or registered trademarks of their corre- sponding companies. User’s Manual Max Hand Held Terminal General Welcome to the world of the ORDERMAN “ Max ORDERMAN “ Max scope of delivery Safety advice “ ““ “ Technical data !"# Charging the battery Settings in ORDERMAN “ setup Changing menu cards $ $ %&'$ "() * $ $ %&'$ +,- ( General Welcome to the world of the ORDERMAN “ ““ “ Max Congratulations on purchasing the ORDERMAN “ Max. This document will help you to get to know your ORDERMAN “ Max and familiarize yourself with its functions. ORDERMAN “ ““ “ Max scope of delivery In addition to your ORDERMAN “ Max, you have received a rechargeable battery, an OR- DERMAN “ 7.5V mains adaptor plug, two ORDERMAN “ touch pens, two ORDERMAN “ A5 menu card transparencies and these instructions for use. Additional information on your software can be found in the cash system handbook. Safety advice General safety advice ∑ The ORDERMAN “ Max does not contain any parts that are suitable for servicing by the user and may therefore not be opened. The warranty claim will become void if the de- vice is opened. ∑ This ORDERMAN “ Max is optionally fitted with a Bluetooth “ interface for further wire- less connection. Never use the handset in areas in which Bluetooth “ can cause disrup- tion (aircraft, hospitals etc.). ∑ Only the ORDERMAN “ touch pen may be used for pen operation of the ORDERMAN “ Max. Pencils, ball point pens or other pointed objects lead to the touch surface being damaged. ∑ Do not under any circumstances short-circuit the handset charger contacts. ∑ A high mechanical load, for example twisting or allowing to fall from an excessive height onto a pointed object may damage the device. Rechargeable battery safety advice ∑ Only use the rechargeable battery model supplied. ∑ Do not expose the rechargeable battery to extreme heat. Never short-circuit the con- tacts – this could cause an explosion. User’s Manual Max Hand Held Terminal “ ““ “ " $ $" ! " # # "$ % & '(% ' ) # " " ) ' " " *+* # Technical data Display: Highly transflective and sunlight resistant graphics technology for 160 x160 pixels with adjustable LED back light Touch surface: Anti-glare surface over the entire display and menu card area, 5 pro- grammable on-screen buttons, adjustable LED backlight Radio (integrated): USA, Canada: 902.200 MHz – 905.200 MHz In accordance with FFC 47CFR Part 15 regulations bidirectional data transfer; Range in buildings: Up to 50 meters with an area coverage up to 7,800 m²; range outside: Up to 300 m Optional: Bluetooth “ V1.1 (class 2) Energy supply: Lithium ion rechargeable battery: 1,200mAh; charging time: approx. 4 hours in handset, approx. 60 min. in ORDERMAN “ MAX charging station (option) Power supply: Default values: 7.5V / 900mA; input values: 100V-240V / 50Hz-60Hz; max. Power consumption: 84mA / 19.4VA Operating time: Up to 18 hours continuousily Environment: Fall proof: 1.2 meters onto concrete Waterproof: IPX4 Operating temperature: -5° to +50°C Storage temperature: -10° to +60°C Dimensions: L x H x W: 180mm x 86mm x 24mm Weight: Handset: 220g; battery: 40g Options: ( not accomplished in US/Canada ) ORDERMAN “ Card swipe ORDERMAN “ Legic and ISO transponder reader ORDERMAN “ order card ORDERMAN “ order card and ORDERMAN “ card swipe Additional information on the options can be obtained from your specialist retailer. User’s Manual Max Hand Held Terminal !" Char…

Text truncated - open the document above for the full version.

Cover Letter(s)

Ersteller: U. Rodemeier Revision: 03 Erstelldatum: 03.08.01 Datum: 4.10.2006 Seite 1 von 1 Request for Confidentiality PHOENIX TESTLAB GmbH Date: October 15, 2007 Product Certification Königswinkel 10 D 32825 Blomberg RE: Certification Application FCC ID: PHYMAX09151 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rule, the applicant hereby requests confidential treatment of information accompanying this application as outlined below: • Schematics • Parts List • Block Diagram • Technical Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457, disclosure od this application and all accompanying documentation will not be made before the date of the GRANT for this application ́. Thank you for your attention in this matter. Applicant’s Company : Senton GmbH address : Auessere Fruehlingstrasse 45, D-94315 Straubing Signature : Johann Roidt Job Title and Dept. : Technical Director

External Photos

_________________________________________________________________________________ PHYMAX09151 _________________________________________________________________________________ PHYMAX09151 _________________________________________________________________________________ PHYMAX09151 _________________________________________________________________________________ PHYMAX09151 _________________________________________________________________________________ PHYMAX09151 _________________________________________________________________________________ PHYMAX09151

ID Label/Location Info

_________________________________________________________________________________ PHYMAX09151 Photo Label

Internal Photos

Test Report

Test Equipment List for Test Report No. 55416-070795-1 / Page 1 of 1 Page(s) EMI/EMC-Testcenter EMV-Prüfzentrum Test Equipment List with Calibration Data / Test date: September 2007 No. Type Inv.-No. Model Serial Number Manufacturer Calibration Organization Date of last calibration Date of next calibration 1 1. Test receiver 1028 ESHS 10 860043/016 Rohde & Schwarz Rohde & Schwarz 01/2006 07/2007 2. Test receiver 1025 ESVP 881120/024 Rohde & Schwarz Rohde & Schwarz 10/2006 10/2007 3. Spectrum analyzer 1078 R 3271 05050023 Advantest Rohde & Schwarz 03/2006 03/2008 4. Spectrum analyzer 1666 FSP 30 100063 Rohde & Schwarz Rohde & Schwarz 02/2006 08/2007 5. EMI test receiver 1569 ESMI 839379/013 839587/006 Rohde & Schwarz Rohde & Schwarz 12/2005 12/2007 Matrix RELAX consist: 1941 6. Preamplifier 1142 R14601 13120026 Advantest Rohde & Schwarz 11/2006 11/2007 7. Preamplifier 1651 CPA9231A1 3393 Schaffner Schaffner 02/2007 02/2008 8. Preamplifier 1684 AFS3-00100800-32-LN 847743 Miteq Senton GmbH 06/2006 06/2007 9. V-network 1060 ESH 3-Z5 862770/021 B1060 Rohde & Schwarz Senton GmbH 01/2007 01/2010 10. V-network 1218 ESH 3-Z5 830952/025 B1218 Rohde & Schwarz Senton GmbH 05/2005 05/2008 11. Trilog wide band antenna Chamber 2 1722 VULB 9163 9163-188 A1722 Schwarzbeck Schwarzbeck 10/2006 10/2007 12. Trilog wide band antenna Chamber 3 1802 VULB 9163 9163-214 A1802 Schwarzbeck Schwarzbeck 01/2006 07/2007 13. Biconical antenna EG 1 1518 HK 116 842204/001 Rohde & Schwarz Rohde & Schwarz 02/2007 02/2008 14. Log. per. antenna EG 1 1519 HL 223 841516/023 Rohde & Schwarz Rohde & Schwarz 01/2007 01/2008 15. Horn Antenna 1516 3115 9508-4553 Emco ARC-Seibersdorf 05/2005 05/2008 1 Accepted tolerance is ± 6 months.

Test Setup Photos

Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing PHYMAX09151 Test setup for conducted AC powerline emission measurement Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing PHYMAX09151 Test setup for radiated emission measurement (fully anechoic room) Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing PHYMAX09151 Test setup for radiated emission measurement (fully anechoic room) - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing PHYMAX09151 Test setup for radiated emission measurement (open field test site) Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing PHYMAX09151 Test setup for radiated emission measurement (open field test site) - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing PHYMAX09151 Test setup for radiated emission measurement (open field test site) - continued - Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing PHYMAX09151 Test setup for radiated emission measurement (open field test site) - continued -
