PI4TDKB2IPCBluetooth module PC Card II
Laird Connectivity, LLC
Click to zoom
Application Details
- Equipment Class
- DSS - Part 15 Spread Spectrum Transmitter
- Date of Grant
- Dec 02, 2003
- Application Purpose
- Original Equipment
- Date of Application
- Dec 02, 2003
- Equipment Note
- Bluetooth module PC Card II
- Frequency Range
- 2402.00000000 - 2480.00000000
- Company
- Laird Connectivity, LLC
- Country
- United States
Documents & Files
Document Text
Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Block Diagram
Block Diagram TDK Bluetooth PC Card II PCMCIA Interface OX950B PCMCIA to RS232 Bridge + CIS ROM 5V to 3.3V Regulator CSR BCO2 BluecoreIC 4/8/16 Meg Flash SPI Bus 16MHz 14.74 MHz Balun & Bandpass filter Bluetooth Module Section Antenna LED Indicators x 3
Contact Information
Applicant
Brian Petted(Technology Leader)
Technical Contact
TDK Systems Europe Ltd.Darrell Robertson
[email protected]+44 20 8938 1024
126 Colindale Avenue · London · United Kingdom
Non-Technical Contact
TDK Systems Europe Ltd.Darrell Robertson
[email protected]+44 20 8938 1024
Test Firm
7layers AGRobert Machulec
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 2.41 mW |
