PIDAIRSPAN-BSRBase Station Radio

Connecting the World with Wireless Access Solutions WipLL WipLLWipLL WipLL Wireless IP-Based Local Loop System Hardware Installation Manual For Release 4.2A Revision Record: WipLL Hardware Installation Manual for Release 4.0 Pub. Rev. Date Update Description - Nov-00 First edition and printing. (Marconi) - Mar-01 WipLL Release 1.4 (Marconi) - Apr-01 WipLL Release 2.0 (Marconi) - Jul-01 WipLL Release 2.2 (Marconi) - Nov-01 WipLL Release 2.6 (Marconi) - Jun-02 WipLL Release 3.0A (Marconi) 01 Feb-03 WipLL Release 4.0. Author: InterDoc. Updating Airspan template and content (connector pinouts; cable crimping, and general) 02 May-03 WipLL Release 4.2F. Author: InterDoc. Adding graphics, deleting BSR with serial port. 03 Jul-03 WipLL Release 4.2A. Author: InterDoc. Updating Chapter 1 for Transparent Bridging; 5.8 GHz; 2.8 GHz. Publication No. 02030311-03 Airspan Ltd. Cambridge House Oxford Road Uxbridge Middlesex UB8 1UN Tel: (44)-895 467100 Web site: http//www.airspan.com  Copyright by Airspan Networks LTD., 2003. All rights reserved worldwide. The information contained in this document is proprietary and is subject to all relevant copyright, patent and other laws protecting intellectual property, as well as any specific agreement protecting Airspan Networks LTD. rights in the aforesaid information. Neither this document nor the information contained herein may be published, reproduced or disclosed to third parties, in whole or in part, without the express, prior, written permission of Airspan Networks LTD. In addition, any use of this document or the information contained herein for any purposes other than those for which it was disclosed is strictly forbidden. Airspan Networks LTD. reserves the right, without prior notice or liability, to make changes in equipment design or specifications. Information supplied by Airspan Networks LTD. is believed to be accurate and reliable. However, no responsibility is assumed by Airspan Networks LTD. for the use thereof nor for the rights of third parties which may be effected in any way by the use thereof. Any representation(s) in this document concerning performance of Airspan Networks LTD. product(s) are for informational purposes only and are not warranties of future performance, either express or implied. Airspan Networks LTD. standard limited warranty, stated in its sales contract or order confirmation form, is the only warranty offered by Airspan Networks LTD. in relation thereto. This document may contain flaws, omissions or typesetting errors; no warranty is granted nor liability assumed in relation thereto unless specifically undertaken in Airspan Networks LTD. sales contract or order confirmation. Information contained herein is periodically updated and changes will be incorporated into subsequent editions. If you have encountered an error, please notify Airspan Networks LTD. All specifications are subject to change without prior notice. Hardware Installation Manual Contents 02030311-03 Airspan Networks Ltd. i Contents About this Manual................................................................................................. vii Purpose ........................................................................................................ vii Targeted Audience ....................................................................................... vii Organization of this manual.......................................................................... vii Technical support ........................................................................................ viii 1. Introduction .............................................................................................. 1-1 1.1. Main Features ..................................................................................... 1-2 1.2. Customer Benefits............................................................................... 1-3 1.3. System Architecture ............................................................................ 1-4 1.3.1. Base Station ......................................................................... 1-5 1.3.2. Subscriber Site ..................................................................... 1-8 1.3.3. Network Operations Center ................................................ 1-11 1.4. Applications ....................................................................................... 1-12 1.4.1. Broadband Data Access ..................................................... 1-12 1.4.2. High Speed Internet Access ............................................... 1-13 1.4.3. Voice over IP ...................................................................... 1-14 1.4.4. Repeater Solution ............................................................... 1-15 2. Safety Guidelines ..................................................................................... 2-1 2.1. General Safety Guidelines .................................................................. 2-2 2.2. Electrical Safety Guidelines................................................................. 2-2 2.2.1. Handling Electrostatic Devices ............................................. 2-3 2.2.2. Grounding............................................................................. 2-4 2.3. Lightening Protection........................................................................... 2-4 Contents Hardware Installation Manual ii Airspan Networks Ltd. 02030311-03 2.4. Preventing Radio Interference............................................................. 2-5 2.5. Cabling ................................................................................................ 2-6 2.5.1. Cable Labeling...................................................................... 2-7 3. Unpacking and Required Tools .............................................................. 3-1 3.1. Unpacking and Verifying Contents ...................................................... 3-1 3.1.1. Base Station Equipment ...…

Text truncated - open the document above for the full version.

17-Dec-02 R.E. IF RxIF Rx IF IF TxTx Tx VTCXOVTCXO To PLL RSSI Rx 5725 - 5850 MHz PLL PLL T/R 5.376GHz-5.499GHz 20MHz 356MHz 20dB Gain Control 20dB Gain Control (LO) 350MHz 350MHz 6MHz 6MHz (LO)

1 Hamelacha street, Lod, 71293, Israel tel. +972 8977 7000 FAX: +972 8977 7080 American TCB 6731 Whittier Ave Suite C110 McLean, VA 22101 USA September 22, 2003 Subject: Request for confidentiality for frequency hopping transceiver, model name BSR-5.8, FCC ID:PIDAIRSPAN-BSR Dear Gentlemen, We apply to you with request to withhold Airspan Networks (Israel) Ltd. trade secrets in Application for Certification for FCC ID: PIDAIRSPAN-BSR. These trade secrets can be found in the BSR-5.8/SPR-5.8 schematic diagrams (5 pages of this Application). Many thanks in advance. Sincerely yours Zion Levi Compliances & Testing Engineer Airspan Networks (Israel) Ltd.

HERMON LABORATORIES October 21, 2003 American TCB 6731 Whittier Ave Suite C110 McLean, VA 22101 Attn: Mr. T. Johnson, Examining Engineer RE: your e-mail dated October 9, 2003; Airspan Networks Ltd. FCC ID: PIDAIRSPAN-BSR, ATCB000794 Dear Mr. Johnson, Please find below the answers to your questions. 1) A frequency hopping list sample was added to the product technical description. A revised file “WipLL-5.8_technical_description_rev1” was uploaded on October 21, 2003. 2) A revised file “WipLL-5.8_technical_description_rev1” includes a 1.33 Mbit/s rate for Hybrid mode. 3) Actually 62 channels are used in the device. A missed channel F62 was added to revised file “WipLL- 5.8_technical_description_rev1”; revised test report AIRRAD_FCC.15529_rev2 (pages 9, 11, 133) was uploaded on October 21, 2003. 4) According to the Airspan statement the product is intended for point-to-multipoint operations, hence, reduced limits were used throughout the testing. Many thanks for your continuous help and patience. Sincerely, Marina Cherniavsky, certification engineer Hermon Laboratories

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 October 9, 2003 RE: Airspan Networks FCC ID: PIDAIRSPAN-BSR After a review of the submitted information, I have a few comments on the above referenced Application. 1) Please provide a sample frequency hopping list that shows compliance with the pseudo-random hopping requirements (one for frequency hopping mode and one for hybrid mode). Note that both frequency hopping and hybrid modes requires pseudo-random hopping. 2) The test report lists a 1.33 Mbit/s rate for hybrid modes that is not listed in the operational description. Please explain. 3) Plot A13 appears to show 62 channels instead of 61. Please explain. Is the frequency list given in the operational description missing a channel? Note that 61 channels are listed in Table 1 and the frequency list of the operational description, and various placed throughout the test report. Please explain. 4) Please explain the use of the 25.0 and 18.0 dBm limits given in section 4.4 of the report. These limits for the conducted power are typically 30 dBm. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

BSR general view

FCC ID:PIDAIRSPAN Date: August 2003 Project number:15528, 15529 Page 1 of 1 LABEL The label shown below is affixed on the bottom of the BSR-5.8 radio unit. The label material is PVC with a permanent adhesive. The FCC part 15, §15.105 statement is placed in Hardware installation Manual, page 2-5. Label placement

BSR with cover removed BSR antenna BSR PCBs, first side BSR PCBs, second side RF PCB for BSR and SPR, first side RF PCB for BSR and SPR, second side

Technical Note WipLL 5.8 GHz Wireless IP-Based Local Loop System Hopping Algorithms and Compliance with FCC 15.247 (a) (1) Connecting the World with Wireless Access Solutions Revision Record: Hopping Compliance Pub/ Rev Date Update Description 01 Jul-03 Airspan. Author: InterDoc 02 Jul-03 Airspan. Author: InterDoc. Updating of frequency tables; average time of occupancy for Hopping and Hybrid modes. 03 Oct-03 Airspan. Author: InterDoc. Adding of pseudo-random frequencies; 1.33 Mbps. Publication No. 13070311-03  Copyright by Airspan Networks LTD., 2003. All rights reserved worldwide. The information contained in this document is proprietary and is subject to all relevant copyright, patent and other laws protecting intellectual property, as well as any specific agreement protecting Airspan Networks LTD. rights in the aforesaid information. Neither this document nor the information contained herein may be published, reproduced or disclosed to third parties, in whole or in part, without the express, prior, written permission of Airspan Networks LTD. In addition, any use of this document or the information contained herein for any purposes other than those for which it was disclosed is strictly forbidden. Airspan Networks LTD. reserves the right, without prior notice or liability, to make changes in equipment design or specifications. Information supplied by Airspan Networks LTD. is believed to be accurate and reliable. However, no responsibility is assumed by Airspan Networks LTD. for the use thereof nor for the rights of third parties which may be effected in any way by the use thereof. Any representation(s) in this document concerning performance of Airspan Networks LTD. product(s) are for informational purposes only and are not warranties of future performance, either express or implied. Airspan Networks LTD. standard limited warranty, stated in its sales contract or order confirmation form, is the only warranty offered by Airspan Networks LTD. in relation thereto. This document may contain flaws, omissions or typesetting errors; no warranty is granted nor liability assumed in relation thereto unless specifically undertaken in Airspan Networks LTD. sales contract or order confirmation. Information contained herein is periodically updated and changes will be incorporated into subsequent editions. If you have encountered an error, please notify Airspan Networks LTD. All specifications are subject to change without prior notice. Frequency Hopping Compliance Contents 13070311-03 Airspan Networks Ltd. iii Contents 1. Introduction 4 2. Hopping and Hybrid System Algorithms 4 3. Hopping Time 4 4. Number of Channels 4 5. Resolution 4 6. Channel Distribution 4 7. Receiver Synchronization 4 8. Frequency Hopping and Hybrid Modes 6 8.1. Frequency Hopping Mode 6 8.2. Hybrid Mode 7 9. Receiver and Transmitter Compliance 8 9.1. Receiver Compliance with 15.247 (a) (1) / 2.1033 (a) (10) 8 9.2. Transmitter Compliance with 15.247 (g), 15.247 (h) 8 Frequency Hopping Compliance Technical Note 13070311-03 Airspan Networks Ltd. 4 1. Introduction This document provides a description of the Frequency Hopping and Hybrid systems for WipLL 5.8 GHz products. The Frequency Hopping system is for 1 Mbps, 2 Mbps and 3 Mbps; the Hybrid system (HS) is for 1.33 Mbps and 4 Mbps. 2. Hopping and Hybrid System Algorithms n The hopping algorithm is defined by a table of n frequencies, where n is greater or equal to 75 when the system is configured for 1 Mbps, 2 Mbps and 3 Mbps, and where n is greater or equal to 62 when the system is configured for 1.33 Mbps and 4 Mbps. The hopping sequence follows cyclically the frequencies in the table, remaining in each frequency for a constant period. The frequencies in the table are all in the 5.726 to 5.849 range, with at least 1 MHz between any two frequencies in the table for systems configured for 1 Mbps, 2 Mbps, and 3 Mbps; and at least 2 MHz for systems configured for 1.33 Mbps and 4 Mbps. The order of frequencies in the table is pseudorandom. n In Section 7, “Receiver Synchronization”, two modes (1 MHz-channel spacing and 2 MHz-channel spacing) are described in Table 1. 3. Hopping Time The hopping time in a given is constant (typically WipLL uses 50 msec). 4. Number of Channels The number of channels is determined by the table size n frequencies, depending on transmission speed configured for the WipLL system: n For 1 Mbps, 2 Mbps, and 3 Mbps, n is equal to at least 75 (WipLL uses n = 79) n For 1.33 Mbps and 4 Mbps, n is equal to at least 62 5. Resolution The minimum difference between any two channels is: n 1 MHz for 1 Mbps, 2 Mbps, and 3 Mbps n 2 MHz for 1.33 Mbps and 4 Mbps 6. Channel Distribution Since any used channel is included once in the table, all the channels are equally used, each channel occupying 1/n of the time. 7. Receiver Synchronization The system receiver input bandwidth filter matches the hopping channel bandwidth and synchronizes with the corresponding transmitter on the hopping sequence. Frequency Hopping Compliance Technical Note 13070311-03 Airspan Networks Ltd. 5 Table 1: Frequency Hopping System (1, 2 and 3 Mbps) and Hybrid System (4 Mbps) 15.247 Spec. Requirement WipLL Capability Comply Spread Spectrum FHSS or DSSS FHSS Yes • Minimum channel separation at 1, 2, and 3 Mbps • -20 dB bandwidth (1 MHz) • -20 dB bandwidth (1 MHz • Yes • Minimum channel separation at 4 Mbps • -20 dB bandwidth • 2 MHz • Yes List of Freq. Pseudo-random ordered list Pseudo-random ordered list Yes Use of Freq. Equal use of frequencies: 5.726 to 5.849 Constant hop period (50 msec) each frequency used once in a table Yes • Number of Frequencies at 1, 2, and 3 Mbps • Min. 75 • 79 • Yes • Number of frequencies at 1.33 Mbps and 4 Mbps •  15 non-overlapping channels with total span  123 MHz • 62 • Yes • Occupied BW per hop at 1, 2, and 3 Mbps • < 1 MHz at –20 dB • < 1 MHz at –20 dB • Yes • Occupied BW per hop at 1.33 Mbps and 4 Mbps • > 1 MHz • 1 MHz < BW < 2 MHz at –20 dB • Yes Average …

Text truncated - open the document above for the full version.

Raytron Ltd. Microwave, antenna and array technology 61b Bilu st., Ra’anana 43581 Telephone: 052.510.367 Fax: 09.771.5299 E- Mail Address: [email protected] Specification for: SPR Subscriber Antenna 5.8Ghz Raytron P/N: 5803-SV Airspan P/N: 901-000-26 Raytron Ltd. Microwave, antenna and array technology 1 SPR subscriber Antenna 5.8GHz Raytron P/N: 5803-SV Antenna Type: Flat Printed Antenna. Specifications: Electrical: Freq. Range (Mhz) : 5725-5875 Gain (dBi) : 16min -3dB Beam Width E-Plane (Deg) : 12 ± 1º -3dB Beam Width H-Plane (Deg) : 21 ± 2º Polarization : Linear Vertical VSWR Max : 1:1.6 Impedance (Ω) : 50 Power Handling (Watt) : 20 Sidelobes Level (dB) : -12 Front-to-back Ratio (dB) : 25 Sidelobe in the Invisible Range (120-240) (dB) : -17 Mechanical Dimensions WxH (mm) : 116x190 Input RF Interface : OSX male connector Environmental: Operating Temperature : -30 ÷ +70 Lightning Protection : Radiating elements- DC grounded Flammability UL (Std. 94) : UL 94V-0 Raytron Ltd. Microwave, antenna and array technology 2 Raytron Ltd. Microwave, antenna and array technology 3 Comparison table BSR and SPR antennas characteristics Frequency Beam Width MHz Product Matrix (XxY) (HxV) Gain dBi Pol Raytron P/N Notes BSR 1x4 60x15 11 Ver 5803BV Diversity 5725-5875 SPR 5x3 21x12 16 Ver 5803SV

Environmental evaluation and exposure limit according to FCC CFR 47part 1, §1.1307, §1.1310 The BSR-5.8 transceiver is classified as mobile. Limit for power density for general population/uncontrolled exposure is 1 mW/cm 2 . P T The power density P (mW/cm 2 ) = ------------- , where 4π r 2 P T is the maximum equivalent isotropically radiated power (EIRP). PT is equal to transmitter maximum output power 25 dBm plus maximum antenna gain 11 dBi, the maximum equivalent isotropically radiated power (e.i.r.p.) is 36 dBm = 4000 mW, and the power density at 20 cm (minimum safe distance, required for mobile devices), calculated as follows: 4000 / 4π 20 2 = 0.79 mW/cm 2 < 1 mW/cm 2 was found below the limit. Hence, no safety hazard exists for human being.

This report is in conformity with ISO/IEC 17025. The A2LA logo endorsement applies only to the test methods and the standards that are listed in the scope of Hermon Laboratories accreditation. The test results relate only to the items tested. This test report must not be reproduced in any form except in full with the approval of Hermon Laboratories Ltd. Page 1 of 148 Document ID: AIRRAD_FCC.15529_rev2.doc Date of Issue: October 2003 HERMON LABORATORIES Electrical Hermon Laboratories Ltd. P.O.Box 23 Binyamina 30500, Israel Tel.+972 46288001 Fax.+972 46288277 e-mail: [email protected] RADIO TEST REPORT according to 47CFR Part 15, §15.247 and subpart B for Airspan Networks (Israel) Ltd. EQUIPMENT UNDER TEST: Base station radio unit Model: BSR 5.8 GHz TDD Page 2 of 148 Document ID: AIRRAD_FCC.15529_rev2.doc Date of Issue: October 2003 HERMON LABORATORIES Hermon Laboratories Ltd. P.O.Box 23 Binyamina 30500, Israel Tel.+972 46288001 Fax.+972 46288277 e-mail: [email protected] Contents 1 Project information.............................................................................................................................3 2 Summary of tests...............................................................................................................................4 3 EUT description.................................................................................................................................6 3.1 GENERAL DESCRIPTION........................................................................................................................................................6 3.2 EUT TEST CONFIGURATION..................................................................................................................................................6 3.3 TRANSMITTER DESCRIPTION.................................................................................................................................................8 4 Test results......................................................................................................................................10 4.1 OCCUPIED BANDWIDTH OF HOPPING CHANNELS AND CHANNEL CARRIER FREQUENCIES SEPARATION ACCORDING TO § 15.247(A)(1)...................................................................................................................................................................10 4.2 NUMBER OF HOPPING CHANNELS ACCORDING TO § 15.247(A)(1)........................................................................................11 4.3 AVERAGE TIME OF HOPPING FREQUENCY OCCUPANCY ACCORDING TO § 15.247(A)(1), (F)...................................................12 4.4 MAXIMUM PEAK OUTPUT POWER TEST ACCORDING TO §15.247 (B)(1), (B)(2), (B)(3)..........................................................13 4.5 OUT OF BAND CONDUCTED EMISSIONS TEST ACCORDING TO §15.247(C).............................................................................14 4.6 RADIATED EMISSIONS WHICH FALL IN RESTRICTED BANDS TEST ACCORDING TO §15.247(C) AND § 15.205, §15.209(A).......15 4.7 PEAK POWER SPECTRAL DENSITY OF A HYBRID SYSTEMS ACCORDING TO § 15.247(D).........................................................18 4.8 CONDUCTED EMISSIONS TEST ACCORDING TO §15.107, 15.207.........................................................................................19 4.9 UNINTENTIONAL RADIATED EMISSIONS TEST ACCORDING TO §15.109..................................................................................20 Appendix A Plots....................................................................................................................................21 Appendix B Test setup photographs.......................................................................................................132 Appendix C Example of hopping frequency.............................................................................................132 Appendix D Test equipment used for tests..............................................................................................134 Appendix E General information............................................................................................................136 TEST FACILITY DESCRIPTION.......................................................................................................................................................148 ABBREVIATIONS AND ACRONYMS.................................................................................................................................................148 SPECIFICATION REFERENCES......................................................................................................................................................148 Page 3 of 148 Document ID: AIRRAD_FCC.15529_rev2.doc Date of Issue: October 2003 HERMON LABORATORIES Hermon Laboratories Ltd. P.O.Box 23 Binyamina 30500, Israel Tel.+972 46288001 Fax.+972 46288277 e-mail: [email protected] 1 Project information EUT attributes Test item Base station radio unit Type (Model) BSR 5.8 GHz TDD Software revision of radio unit 2.59 Hardware revision of the unit A0 Equipment FCC code DSS Applicant information Applicant’s responsible person Mr. Zion Levi, compliance & testing engineer Applicant/Manufacturer Airspan Networks (Israel) Ltd. Address 1, Hamelacha street City Lod Postal code 71293 Country Israel Telephone number +972 8 9777 046 Telefax number +972 8 9777 080 Test details Project number 15529 Location Hermon Laboratories Receipt date June 15, 2003 Test started June 15, 2003 Test completed July 8, 2003 Purpose of test Apparatus compliance verification in accordance with emission requirements Test specifications 47CFR Part 15, §15.247 and subpart B Page 4 of 148 Document ID: AIRRAD_FCC.15529_rev2.doc Date of Issue: October 2003 HERMON LABORATORIES Hermon Laboratories Ltd. P.O.Box 23 Binyamina 30500, Israel Tel.+972 46288001 Fax.+972 46288277 e-mail: [email protected] 2 Summary of tests The test…

Text truncated - open the document above for the full version.

BSR testing Photograph 1 Setup for conducted measurements Photograph 2 Spurious emission measurement setup in anechoic chamber, biconilog antenna in vertical polarization Photograph 3 Spurious emission measurement setup at OATS, double ridged guide antenna in vertical polarization Photograph 4 Spurious emission measurement setup at OATS, BSR view Photograph 5 Conducted emission at AC line measurement setup
