PIDASMAX2350WiMAX terminal station

UGD-D00234 Rev A SSRM Module User Guide System Release 9.7 SSRM Module User Guide Page 2 Commercial in Confidence UWB-D00234 Rev A Acknowledgements Airspan Networks Inc. acknowledges the following trademarks used within this document: © Intel Corporation http://www.intel.com/ © Microsoft Corporation http://www.microsoft.com © SEQUANS COMMUNICATIONS http://www.sequans.com Copyright © Copyright by Airspan Networks Inc., 2012. All rights reserved worldwide. The information contained within this document is proprietary and is subject to all relevant copyright, patent and other laws protecting intellectual property, as well as any specific agreements protecting Airspan Networks Inc. rights in the aforesaid information. Neither this document nor the information contained herein may be published, reproduced or disclosed to third parties, in whole or in part, without the express, prior, written permission of Airspan Networks Inc. In addition, any use of this document or the information contained herein for the purposes other than those for which it is disclosed is strictly forbidden. Airspan Networks Inc. reserves the right, without prior notice or liability, to make changes in equipment design or specifications. Information supplied by Airspan Networks Inc. is believed to be accurate and reliable. However, no responsibility is assumed by Airspan Networks Inc. for the use thereof nor for the rights of third parties which may be effected in any way by the use of thereof. Any representation(s) in this document concerning performance of Airspan Networks Inc. product(s) are for informational purposes only and are not warranties of future performance, either expressed or implied. Airspan Networks Inc. standard limited warranty, stated in its sales contract or order confirmation form, is the only warranty offered by Airspan Networks Inc. in relation thereto. This document may contain flaws, omissions or typesetting errors; no warranty is granted nor liability assumed in relation thereto unless specifically undertaken in Airspan Networks Inc. sales contract or order confirmation. Information contained herein is periodically updated and changes will be incorporated into subsequent editions. If you have encountered an error, please notify Airspan Networks Inc. All specifications are subject to change without prior notice. Product performance figures quoted within this document are indicative and for information purposes only. SSRM Module User Guide Page 3 Commercial in Confidence UWB-D00234 Rev A Table of Contents Acknowledgements .......................................................................................................................... 2 Copyright .......................................................................................................................................... 2 Table of Contents ............................................................................................................................. 3 Summary of Figures ......................................................................................................................... 5 Summary of Tables .......................................................................................................................... 6 Warnings and Cautions .................................................................................................................... 7 Human Exposure to Radio Frequencies ...................................................................................... 7 Radio Interference ........................................................................................................................ 7 Modifications ................................................................................................................................. 7 General ......................................................................................................................................... 7 Disclaimer Statement ................................................................................................................... 7 DECLARATION OF CONFORMITY ................................................................................................. 8 FCC Notice ....................................................................................................................................... 9 Federal Communication Commission Notice ............................................................................... 9 Maximum Output TX Power ........................................................................................................... 10 Antenna Types............................................................................................................................ 10 SSRM Antenna Usage ............................................................................................................. 10 1 About this Guide ....................................................................................................................... 11 1.1 Purpose ................................................................................................................................. 11 1.2 Conventions .......................................................................................................................... 11 2 Overview .................................................................................................................................. 12 2.1 SSRM Frequency Ranges .................................................................................................... 12 2.1.1 Main Features ............................................................................................................... 12 2.2 WiMAX Management ............................................................................................................ 12 2.3 SSRM Block Diagram ...........................................................................................…

Text truncated - open the document above for the full version.

UGD-D00234 Rev A SSRM Module User Guide System Release 9.7 SSRM Module User Guide Page 2 Commercial in Confidence UWB-D00234 Rev A Acknowledgements Airspan Networks Inc. acknowledges the following trademarks used within this document: © Intel Corporation http://www.intel.com/ © Microsoft Corporation http://www.microsoft.com © SEQUANS COMMUNICATIONS http://www.sequans.com Copyright © Copyright by Airspan Networks Inc., 2012. All rights reserved worldwide. The information contained within this document is proprietary and is subject to all relevant copyright, patent and other laws protecting intellectual property, as well as any specific agreements protecting Airspan Networks Inc. rights in the aforesaid information. Neither this document nor the information contained herein may be published, reproduced or disclosed to third parties, in whole or in part, without the express, prior, written permission of Airspan Networks Inc. In addition, any use of this document or the information contained herein for the purposes other than those for which it is disclosed is strictly forbidden. Airspan Networks Inc. reserves the right, without prior notice or liability, to make changes in equipment design or specifications. Information supplied by Airspan Networks Inc. is believed to be accurate and reliable. However, no responsibility is assumed by Airspan Networks Inc. for the use thereof nor for the rights of third parties which may be effected in any way by the use of thereof. Any representation(s) in this document concerning performance of Airspan Networks Inc. product(s) are for informational purposes only and are not warranties of future performance, either expressed or implied. Airspan Networks Inc. standard limited warranty, stated in its sales contract or order confirmation form, is the only warranty offered by Airspan Networks Inc. in relation thereto. This document may contain flaws, omissions or typesetting errors; no warranty is granted nor liability assumed in relation thereto unless specifically undertaken in Airspan Networks Inc. sales contract or order confirmation. Information contained herein is periodically updated and changes will be incorporated into subsequent editions. If you have encountered an error, please notify Airspan Networks Inc. All specifications are subject to change without prior notice. Product performance figures quoted within this document are indicative and for information purposes only. SSRM Module User Guide Page 3 Commercial in Confidence UWB-D00234 Rev A Table of Contents Acknowledgements .......................................................................................................................... 2 Copyright .......................................................................................................................................... 2 Table of Contents ............................................................................................................................. 3 Summary of Figures ......................................................................................................................... 5 Summary of Tables .......................................................................................................................... 6 Warnings and Cautions .................................................................................................................... 7 Human Exposure to Radio Frequencies ...................................................................................... 7 Radio Interference ........................................................................................................................ 7 Modifications ................................................................................................................................. 7 General ......................................................................................................................................... 7 Disclaimer Statement ................................................................................................................... 7 DECLARATION OF CONFORMITY ................................................................................................. 8 FCC Notice ....................................................................................................................................... 9 Federal Communication Commission Notice ............................................................................... 9 Maximum Output TX Power ........................................................................................................... 10 Antenna Types............................................................................................................................ 10 SSRM Antenna Usage ............................................................................................................. 10 1 About this Guide ....................................................................................................................... 11 1.1 Purpose ................................................................................................................................. 11 1.2 Conventions .......................................................................................................................... 11 2 Overview .................................................................................................................................. 12 2.1 SSRM Frequency Ranges .................................................................................................... 12 2.1.1 Main Features ............................................................................................................... 12 2.2 WiMAX Management ............................................................................................................ 12 2.3 SSRM Block Diagram ...........................................................................................…

Text truncated - open the document above for the full version.

Airspan Networks Inc. 777 Yamato Rd Suite 310, Boca Raton, Florida, United States, 33431 FCC DFS DECLARATION LETTER FCC ID: PIDASMAX2350 Date: 2012.03.15 To whom it may concern: We, the undersigned, declare that the SSRM 2.3GHz hardware configuration is used for 2316.75 MHz and 2348.25 MHz as well as 3.5 MHz emission bandwidth only. The Frequency can not be modified by any method. Sincerely, Brian Roberts Engineering Dept. Airspan Networks Inc. Tel: +1 561 893 8686 Fax: +1 561 893 8671 e-mail: [email protected]

Airspan Networks Inc. 777 Yamato Rd Suite 310, Boca Raton, Florida, United States, 33431 FCC DECLARATION LETTER FCC ID: PIDASMAX2350 Date: 2012.03.15 To whom it may concern: By SSRM 2.3GHz hardware configuration, the maximum ratio of DL:UL is 31:16. That means it can not support the higher ratio then 31:16. The ratio can not be modified to higher ratio then 31:16 by any method. The device does not support mobile station FDD mode. Sincerely, Brian Roberts Engineering Dept. Airspan Networks Inc. Tel: +1 561 893 8686 Fax: +1 561 893 8671 e-mail: [email protected]

Airspan Networks Inc. 777 Yamato Rd Suite 310, Boca Raton, Florida, United States, 33431 FCC DECLARATION LETTER FCC ID: PIDASMAX2350 Date: 2012.04.03 To whom it may concern: We, the undersigned, declare that the SSRM 2.3GHz hardware configuration, used for 2316.75 MHz and 2348.25 MHz as well as 3.5 MHz emission bandwidth only. The Frequency can not be modified by any method. Sincerely, Brian Roberts Engineering Dept. Airspan Networks Inc. Tel: +1 561 893 8686 Fax: +1 561 893 8671 e-mail: [email protected]

Page 1 of 1 Modular Approval Request to FCC FCC ID:PIDASMAX2350 Items to be covered Answer from applicant 1. The modular transmitter must have its own RF shielding. The modular transmitter has its own RF shielding. The RF shielding consists of the metal shielding of the module cover. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over- modulation. Data from hosting PC to RF module pass thru SQN1210 chip which is used as a data buffer. 3. The modular transmitter must have its own power supply regulation. All power rails on system are regulated and/or filtered (pi filter) on board before entering the modular transmitter. As a module is inserted into a standard host slot the EUT is powered by the 5.4 VDC 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). Antenna in use is a unique Directional Panel Antenna 16dBi requiring professional installation only. As noted in the User manual. 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. The Tx module was tested in stand-alone configuration connected with 15 cm cable to evaluation board. The cable was decoupled with ferrite at approximately 2 cm to represent the actual in slot installation. As a module, the EUT must be inserted directly into a Mini PCIe slot. 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1”. The modular transmitter has its own FCC ID:PIDASMAX2350. If the FCC ID is not visible when the module is installed inside another device, user has the instructions to apply a FCC ID label on the other device (referred to in page 9 of the User manual). 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. There is no specific rule or operating requirements applicable to the transmitter with respect to user operation. 8. The modular transmitter must comply with any applicable RF exposure requirements. Modular transmitters approved under other Sections of Part 15, when necessary, may also need to address certain RF Exposure concerns, typically by providing specific installation and operating instructions for users, installers and other interested parties to ensure compliance. The modular transmitter complies with applicable RF exposure requirements as specified in FCC part 27 section 27.52. The EUT is a fixed device for use in Cisco products as stated in User manual page 9. Name and surname of applicant: Zion Levy Date: 13.03.2012 Signature:

Airspan Networks Inc. 777 Yamato Rd Suite 310, Boca Raton, Florida, United States, 33431 FCC ID: PIDASMAX2350 Date: 2012.03.15 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information accompanying this application as outlined below: Schematics Block Diagram BOM Tune up procedure Operational description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, Richard Tier Engineering Dept. Airspan Networks Inc. Tel: +1 561 893 8686 Fax: +1 561 893 8671 e-mail: [email protected]

Airspan Networks Inc. 777 Yamato Rd Suite 310, Boca Raton, Florida, United States, 33431 FCC MODULE APPROVAL REQUEST LETTER FCC ID: PIDASMAX2350 Date: 2012.04.05 To whom it may concern: We, the undersigned, request to change the module type to limited single-modular transmitter. Sincerely, Brian Roberts Engineering Dept. Airspan Networks Inc. Tel: +1 561 893 8686 Fax: +1 561 893 8671 e-mail: [email protected]

Page 1 of 1 Limited single-modular transmitter approval request FCC ID:PIDASMAX2350 Items to be covered Answer from applicant 1. The modular transmitter must have its own RF shielding. The modular transmitter has its own RF shielding. The RF shielding consists of the metal shielding of the module cover. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over- modulation. Data from hosting PC to RF module pass thru SQN1210 chip which is used as a data buffer. 3. The modular transmitter must have its own power supply regulation. All power rails on system are regulated and/or filtered (pi filter) on board before entering the modular transmitter. As a module is inserted into a standard Host slot the EUT is powered by the 5.4 VDC 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). Antenna in use is a unique Directional Panel Antenna 16dBi requiring professional installation only. As noted in the User manual. 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. The Tx module was tested in stand-alone configuration connected with 15 cm cable to evaluation board. The cable was decoupled with ferrite at approximately 2 cm to represent the actual in slot installation. As a module, the EUT must be inserted directly into a Mini PCIe slot. 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” The modular transmitter has its own FCC ID: PIDASMAX2350. If the FCC ID is not visible when the module is installed inside another device, user has the instructions to apply a FCC ID label on the other device (referred to in page 9 of the User manual) 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. There is no specific rule or operating requirements applicable to the transmitter with respect to user operation. 8. The modular transmitter must comply with any applicable RF exposure requirements. Modular transmitters approved under other Sections of Part 15, when necessary, may also need to address certain RF Exposure concerns, typically by providing specific installation and operating instructions for users, installers and other interested parties to ensure compliance. The modular transmitter complies with applicable RF exposure requirements as specified in FCC part 27 section 27.52. The EUT is a fixed device for use in Cisco products as stated in User manual page 9. Name and surname of applicant: Zion Levy Date: 5.04.2012 Signature:

Airspan Networks Inc. FCC ID:PIDASMAX2350 Page 1 of 3 EXTERNAL PHOTOGRAPHS This document contains 2 photographs Airspan Networks Inc. FCC ID:PIDASMAX2350 Page 2 of 3 Photograph No.1 SSRM 2.3 GHz module top view Airspan Networks Inc. FCC ID:PIDASMAX2350 Page 3 of 3 Photograph No.2 SSRM 2.3 GHz module bottom view

Airspan Networks Inc. FCC ID:PIDMMAX2350 Page 1 of 1 LABEL The label is affixed on the module as shown below. The label material is PVC with a permanent adhesive. SSRM 2.3 GHz module, label with FCC ID:PIDASMAX2350 location FCC ID:PIDASMAX2350

Airspan Networks Inc. FCC ID:PIDASMAX2350 Page 1 of 4 MODULE PHOTOGRAPHS This document contains 3 photographs Airspan Networks Inc. FCC ID:PIDASMAX2350 Page 2 of 4 Photograph No.1 SSRM 2.3 GHz module top view Airspan Networks Inc. FCC ID:PIDASMAX2350 Page 3 of 4 Photograph No.2 SSRM 2.3 GHz module bottom view Airspan Networks Inc. FCC ID:PIDASMAX2350 Page 4 of 4 Photograph No.3 SSRM 2.3 GHz module without shielding

2.3-2.7GHz Dual-Polarized Directional Panel Antenna for Cisco Directional Dual-Polarized Panel Antenna PCTEL, Inc. WEB: www.antenna.com Technical Data Maximum Power: 20 watts Polarization: Dual Linear, H/V or +/-45 ° slant Nominal Impedance: 50 ohms VSWR: 1.5 typical, 2.0 maximum Front to Back Ratio: > 27 dB Radome Material: UL-HB rated Chi Mei PW-978B ASA Thickness: 0.085” typical, 0.070” min Termination: 2 x Type N Female Panel Mount Connectors Mounting Method and Material: Fully adjustable pipe or wall mount constructed of nickel-zinc trivalent coated steel The 07-1160-01 directional panel antenna was designed to cover 2.3-2.7GHz frequencies for industrial wireless applications, obtaining maximum gain with an attractive, low profi le package. These models provide efficient and stable performance across the band and can be mounted indoors or outdoors. Features • ASA radome and PC board conform to the UL-HB flame retardant rating, allowing maximum installation flexibility. • Attractive, low profi le housing. Blends well with indoor and outdoor envi- ronments where aesthetic considerations are important. • Dual-polarized for higher throughput MIMO applications. • Private labeled with Cisco part numbers and descriptions. Frequency Range Nominal Gain 3 dB Horizontal Beamwidth 3 dB Vertical Beamwidth RF/Electrical Specifi cations Mechanical Specifications Dimensions Antenna Weight (Mass) Temperature Range FRONT VIEW 14.5” x 14.5” x 1.75” (340 x 340 x 30 mm) 3.5 lbs (1.6 kg) -40°C to +85°C 2.3-2.7GHz16 dBi - 2.3-2.36GHz 20° 20° 17 dBi - 2.36-2.4GHz 17.5 dBi - 2.5-2.7GHz MOUNT VIEW © 2012 PCTEL, Inc. Product specifi cations are subject to change without notice. • Fully adjustable mounting bracket for pipe or wall mount installations.

CAVITY DUAL BPF(DR TYPE) Rev. No.02,B Date : 2010. 04. 22. www.wevercomm.com #101-101, Daewoo Mirae, 1011-14, Gwonseon-Dong, Gwonseon-Gu, Suwon-Si, Gyeonggi-Do, KOREA Tel. +82-31-263-3567, Fax. +82-31-263-3569 CUSTOMER : SPECIFICATION SHEET ITEM : Cavity DR Dual BPF for 2.3GHz Part No : WVC-2.3GDB-3.5M01B SUPPLIER Written Checked Approved CAVITY DUAL BPF(DR TYPE) Rev. No.02,B Date : 2010. 04. 22. www.wevercomm.com #101-101, Daewoo Mirae, 1011-14, Gwonseon-Dong, Gwonseon-Gu, Suwon-Si, Gyeonggi-Do, KOREA Tel. +82-31-263-3567, Fax. +82-31-263-3569 ◈ INDEX – INDEX – REVISION HISTORY – APPLICATION, FEATURES – ELECTRICAL SPECIFICATION – ENVIRONMENTAL SPECIFICATION – MECHANICAL SPECIFICATION – OUTLINE DRAWING – SIMULATION DATA ----------------------- ----------------------- ----------------------- ----------------------- ----------------------- ----------------------- ----------------------- ----------------------- 2 2 3 3 3 3 4 5 ◈ REVISION HISTORY AUTHORS DATE REVISION NOTE Daniel Lim 2010. 03. 24. 00 First Draft Daniel Lim 2010. 03. 26. 01, A Changed Mechanical Spec. Bracket : Hole 4.5Pi -> 8Pi Distance Between hole 86.0mm -> 83.3mm Daniel Lim 2010. 04. 22. 02, B Added mark(Up and Down) CAVITY DUAL BPF(DR TYPE) Rev. No.02,B Date : 2010. 04. 22. www.wevercomm.com #101-101, Daewoo Mirae, 1011-14, Gwonseon-Dong, Gwonseon-Gu, Suwon-Si, Gyeonggi-Do, KOREA Tel. +82-31-263-3567, Fax. +82-31-263-3569 PART NO. : WVC-2.3GDB-3.5M01B ◈ APPLICATION > for use in 2.3GHz Band System ◈ FEATURE > High Reliability > RoHS Compliant ◈ ELECTRICAL SPECIFICATION ITEM SPECIFIATION Frequency Range 2315MHz ~ 2318.5MHz 2346.5MHz ~ 2350MHz Center Frequency Fc1 = 2316.75MHz Fc2 = 2348.25MHz Insertion Loss 2.7dB Max Ripple 1.0dB Max Attenuation 25dB Min @ 2320 MHz 20dB Min @ 2300 MHz 25dB Min @ 2345 MHz 20dB Min @ 2370 MHz Return Loss 18.0dB Min Average Input Power Handling 20W CW Max ◈ ENVIRONMENTAL SPECIFICATIONS ITEM SPECIFICATION Operating Temperature -40°C to +70°C Operating Humidity RH 20% ~ 98%, Waterproof IP67 ◈ MECHANICAL SPECIFICATIONS ITEM SPECIFICATION Dimension 148.0 x 106.0 x 85.0 (mm) , Excluded Bracket Mounting Points See Outline Drawing RF Connector All Port : N Female Connector Connector Position See Outline Drawing Finish Gray color epoxy coating CAVITY DUAL BPF(DR TYPE) Rev. No.02,B Date : 2010. 04. 22. www.wevercomm.com #101-101, Daewoo Mirae, 1011-14, Gwonseon-Dong, Gwonseon-Gu, Suwon-Si, Gyeonggi-Do, KOREA Tel. +82-31-263-3567, Fax. +82-31-263-3569 ◈ OUTLINE DRWAING INPUT OUTPUT xxxxxxxx Bar Code 148 32 42 106 85 12 157° 2 54.5 198 15 16 51 11.3583.3 4-Φ8.0 THRU UP DOWN CAVITY DUAL BPF(DR TYPE) Rev. No.02,B Date : 2010. 04. 22. www.wevercomm.com #101-101, Daewoo Mirae, 1011-14, Gwonseon-Dong, Gwonseon-Gu, Suwon-Si, Gyeonggi-Do, KOREA Tel. +82-31-263-3567, Fax. +82-31-263-3569 ◈ SIMULATION DATA Fc1(2316.75MHz) : Return Loss & Insertion Loss & Attenuation Fc2(2348.25MHz) : Return Loss & Insertion Loss & Attenuation

Airspan Networks Inc. FCC ID:PIDASMAX2350 Page 1 of 1 Environmental evaluation and exposure limit according to FCC CFR 47part 1, §1.1307, §1.1310 The transceiver is classified as fixed, the calculation was done to confirm a safe distance. Limit for power density for general population/uncontrolled exposure is 1 mW/cm 2 for 1500 -100000 MHz frequency range. The power density P (mW/cm 2 ) = P T / 4 r 2 , where P T is the transmitted power, which is equal to the peak transmitter output power plus maximum antenna gain. The maximum equivalent isotropically radiated power EIRP is P T = 26 dBm +16 dBi = 42 dBm = 15849 mW, where 26 dBm is the EUT peak output power, 16 dBi – antenna gain. The minimum safe distance “r”, where RF exposure does not exceed FCC permissible limit, is r = sqrt { P T / (Px4)} = sqrt {15849 / 12.56} = 35.5 cm. General public cannot be exposed to dangerous RF level.

Hermon Laboratories Ltd. Harakevet Industrial Zone, Binyamina 30500, Israel Tel. +972-4-6288001 Fax. +972-4-6288277 E-mail: [email protected] Page 1 of 72 Report ID: AIRRAD_FCC.22555_rev1.doc Date of Issue: 14-Mar-12 ELECTRICAL TESTING 0839.01 TEST REPORT ACCORDING TO: FCC 47CFR part 27 FOR: Airspan Networks Inc. Terminal station Model: SSRM 2.3GHz This report is in conformity with ISO/ IEC 17025. The "A2LA Accredited" symbol endorsement applies only to the tests and calibrations that are listed in the scope of Hermon Laboratories accreditation. The test results relate only to the items tested. This test report shall not be reproduced in any form except in full with the written approval of Hermon Laboratories Ltd. Report ID: AIRRAD_FCC.22555_rev1.doc Date of Issue: 14-Mar-12 Page 2 of 72 Table of contents 1 Applicant information ..................................................................................................................................................... 3 2 Equipment under test attributes .................................................................................................................................... 3 3 Manufacturer information .............................................................................................................................................. 3 4 Test details ...........…
