PIDCRM3650WiMAX terminal station

UGD-D00658 Rev A CRM Module User Guide CRM Module User Guide Page 2 Commercial in Confidence UWB-D00658 Rev A Acknowledgements Airspan Networks Inc. acknowledges the following trademarks used within this document: © Intel Corporation http://www.intel.com/ © Microsoft Corporation http://www.microsoft.com © SEQUANS COMMUNICATIONS http://www.sequans.com Copyright © Copyright by Airspan Networks Inc., 2012. All rights reserved worldwide. The information contained within this document is proprietary and is subject to all relevant copyright, patent and other laws protecting intellectual property, as well as any specific agreements protecting Airspan Networks Inc. rights in the aforesaid information. Neither this document nor the information contained herein may be published, reproduced or disclosed to third parties, in whole or in part, without the express, prior, written permission of Airspan Networks Inc. In addition, any use of this document or the information contained herein for the purposes other than those for which it is disclosed is strictly forbidden. Airspan Networks Inc. reserves the right, without prior notice or liability, to make changes in equipment design or specifications. Information supplied by Airspan Networks Inc. is believed to be accurate and reliable. However, no responsibility is assumed by Airspan Networks Inc. for the use thereof nor for the rights of third parties which may be effected in any way by the use of thereof. Any representation(s) in this document concerning performance of Airspan Networks Inc. product(s) are for informational purposes only and are not warranties of future performance, either expressed or implied. Airspan Networks Inc. standard limited warranty, stated in its sales contract or order confirmation form, is the only warranty offered by Airspan Networks Inc. in relation thereto. This document may contain flaws, omissions or typesetting errors; no warranty is granted nor liability assumed in relation thereto unless specifically undertaken in Airspan Networks Inc. sales contract or order confirmation. Information contained herein is periodically updated and changes will be incorporated into subsequent editions. If you have encountered an error, please notify Airspan Networks Inc. All specifications are subject to change without prior notice. Product performance figures quoted within this document are indicative and for information purposes only. CRM Module User Guide Page 3 Commercial in Confidence UWB-D00658 Rev A Table of Contents Acknowledgements .................................................................................................................... 2 Copyright .................................................................................................................................... 2 Table of Contents ....................................................................................................................... 3 Summary of Figures ................................................................................................................... 5 Summary of Tables .................................................................................................................... 6 Warnings and Cautions .............................................................................................................. 7 Human Exposure to Radio Frequencies ...................................................................................... 7 Radio Interference ........................................................................................................................ 7 Modifications ................................................................................................................................ 7 General......................................................................................................................................... 7 Disclaimer Statement ................................................................................................................... 7 DECLARATION OF CONFORMITY .......................................................................................... 8 FCC Notice ............................................................................................................................... 10 Federal Communication Commission Notice ............................................................................. 10 Limitations - TBD ........................................................................................................................ 10 Labeling Requirement ................................................................................................................ 10 Maximum Output TX Power ..................................................................................................... 11 Antenna Types ........................................................................................................................... 11 CRM Antenna Usage ............................................................................................................... 11 1 About this Guide ................................................................................................................ 12 1.1 Purpose ................................................................................................................................ 12 1.2 Conventions .......................................................................................................................... 12 2 Overview ............................................................................................................................ 13 2.1.1 Main Features ............................................................................................................... 13 2.2 WiMAX Management ............................................................................................................ 13 3 Installation Prerequisites ..............................…

Text truncated - open the document above for the full version.

Airspan Networks Inc. 777 Yamato Rd Suite 310, Boca Raton, Florida, United States, 33431 FCC DECLARATION LETTER FCC ID:PIDCRM3650 Date: 2012.10.31 To whom it may concern: We, the undersigned, declare that the CRM 3.65GHz hardware configuration, used for operation frequencies of 3650 MHz - 3700 MHz only. The Frequency range is restricted by SW. Sincerely, Richard Tier Engineering Dept. Airspan Networks Inc. Tel: +1 561 893 8686 Fax: +1 561 893 8671 e-mail: [email protected]

Airspan Networks Inc. 777 Yamato Rd Suite 310, Boca Raton, Florida, United States, 33431 FCC DECLARATION LETTER FCC ID:PIDCRM3650 Date: 2012.10.31 To whom it may concern: By CRM 3.65 GHz hardware configuration, the maximum ratio of DL: UL is 31:16. That means it can not support the higher ratio then 31:16. The ratio can not be modified to higher ratio then 31:16 by any method. The device does not support mobile station FDD mode. Sincerely, Brian Roberts Engineering Dept. Airspan Networks Inc. Tel: +1 561 893 8686 Fax: +1 561 893 8671 e-mail: [email protected]

1 February 4, 2013 Federal Communication Commission Office of Engineering and Technology USA RE: FCC ID:PIDCRM3650 Form 731 CN: EA388942 Subject: CRN 43322 Dear Mr. Uganzenwoko, Please find attached our response according to your questions. 1. You attested that the DL:UL cannot be more than 31:16; but most USA wireless carriers adopt 29:18. Please explain if this can be used with most mobile users. Response: Our module is supporting any standard DL/UL split. The 29:18 is the most popular, and we support it. The split 31:16 is the longest downlink and the shortest uplink supported. Full coexistence with any other mobile device is supported. 2. Please provide more detail information on the Bandwidth been monitored versus the Bandwidth been occupied for all modes of operation, give examples of frequency ranges. Response: The unit, as WiMAX device, is a slave of a Base Station. The unit is searching for BS in predefined frequency and bandwidth. During that period no transmission is done, only Rx. A BS (as FCC certified device) has certain configuration of working frequency and bandwidth. Once the MS unit synchronized to BS, it starts transmission. For example, MS unit has configuration of Freq.=3670 MHz, and BW=10 MHz. The MS seeks for BS at that configuration. The BS should have the identical configuration of his radio. After MS gets synchronized with BS, it starts Tx. There are no such terms like “monitored and occupied bandwidth”. There is a configured set of parameters and actual (coordinated with the base station) configuration. Name of authorized person: Zion Levy Position: Compliances & Integration Engineer

Airspan Networks Inc. 777 Yamato Rd Suite 310, Boca Raton, Florida, United States, 33431 FCC DECLARATION LETTER FCC ID: PIDCRM3650 Date: 2013.02.07 To whom it may concern: By CRM 3.65GHz hardware configuration, the ratios of DL: UL are: (32:15), (29:18), (26:21), (23:24) and (14:33). That means it can not support the higher ratio then 31:16. The ratio can not be modified to higher ratio then (31:16) by any method. The device does not support mobile station FDD mode. Sincerely, Brian Roberts Engineering Dept. Airspan Networks Inc. Tel: +1 561 893 8686 Fax: +1 561 893 8671 e-mail: [email protected]

1 February 7, 2013 Federal Communication Commission Office of Engineering and Technology USA RE: FCC ID:PIDCRM3650 Form 731 CN: EA388942 Subject: CRN 43400 Dear Mr. Uganzenwoko, Please find attached our response according to your question. 1. If your module supports any DL:UL split including 29:18 which suggests more down link symbols greater than 16,then the attestation statement might be misleading. Please change the attestation statement to reflect actual DU:UL split the device can support. Response: Revised attestation statement file “UL_DL_statement_letter_23805_rev1” was uploaded on 2/07/2012 Name of authorized person: Zion Levy Position: Compliances & Integration Engineer

1 February 7, 2013 Federal Communication Commission Office of Engineering and Technology USA RE: FCC ID:PIDCRM3650 Form 731 CN: EA388942 Subject: CRN 43400 Dear Mr. Uganzenwoko, Please find attached our response according to your question. 1. If your module supports any DL:UL split including 29:18 which suggests more down link symbols greater than 16,then the attestation statement might be misleading. Please change the attestation statement to reflect actual DU:UL split the device can support. Response: Revised attestation statement file “UL_DL_statement_letter_23805_rev1” was uploaded on 2/07/2013. Name of authorized person: Zion Levy Position: Compliances & Integration Engineer

Airspan Networks Inc. 777 Yamato Rd Suite 310, Boca Raton, Florida, United States, 33431 FCC DECLARATION LETTER FCC ID: PIDCRM3650 Date: 2013.02.12 To whom it may concern: By CRM 3.65GHz hardware configuration, the ratios of DL: UL are: (31:16), (29:18), (26:21), (23:24) and (14:33). That means it can not support the higher ratio then 31:16. The ratio can not be modified to higher ratio then (31:16) by any method. The device does not support mobile station FDD mode. Sincerely, Brian Roberts Engineering Dept. Airspan Networks Inc. Tel: +1 561 893 8686 Fax: +1 561 893 8671 e-mail: [email protected]

1 February 12, 2013 Federal Communication Commission Office of Engineering and Technology USA RE: FCC ID:PIDCRM3650 Form 731 CN: EA388942 Subject: CRN 43399, 43400 Dear Mr. Uganzenwoko, Please find attached our corrected response according to your question. 1. If your module supports any DL:UL split including 29:18 which suggests more down link symbols greater than 16,then the attestation statement might be misleading. Please change the attestation statement to reflect actual DU:UL split the device can support. Response: Please use adjusted attestation statement file “UL_DL_statement_letter_23805_rev2” uploaded on 2/12/2013. The typo “32:15” was done in the ratios of DL:UL instead of “31:16” in file “UL_DL_statement_letter_23805_rev1” uploaded on 2/07/2013. Name of authorized person: Zion Levy Position: Compliances & Integration Engineer

Airspan Networks Inc. 777 Yamato Rd Suite 310, Boca Raton, Florida, United States, 33431 FCC DECLARATION LETTER FCC ID: PIDCRM3650 Date: 2013.02.17 To whom it may concern: By CRM 3.65GHz hardware configuration, the ratios of DL: UL are: (31:16), (29:18), (26:21), (23:24) and (14:33). That means it can not support the higher ratio then (31:16), meaning 31 downlink symbols and 16 uplink symbols. The ratio can not be modified to higher ratio then (31:16) by any method. The device does not support mobile station FDD mode. Sincerely, Brian Roberts Engineering Dept. Airspan Networks Inc. Tel: +1 561 893 8686 Fax: +1 561 893 8671 e-mail: [email protected]

1 February 17, 2013 Federal Communication Commission Office of Engineering and Technology USA RE: FCC ID:PIDCRM3650 Form 731 CN: EA388942 Subject: CRN 43399, 43400 Dear Mr. Uganzenwoko, Please find attached our corrected response according to your question. 1. The attestation statement still has not specifically define the maximum DL symbols the system can support in a set of UL:DL of 31:16 suggest maximum of 16 symbols in DL. However, I have approved the application, please correct your attestation to reflect actual maximum UL:DL it can support. Response: By CRM 3.65GHz hardware configuration, the ratios of DL:UL are: (31:16), (29:18), (26:21), (23:24) and (14:33). That means it can not support the higher ratio than (31:16), meaning 31 downlink symbols and 16 uplink symbols. The ratio can not be modified to higher ratio than (31:16) by any method. The device does not support mobile station FDD mode. Adjusted file UL_DL_statement_letter_23805_rev3 uploaded on 2/17/2013. Name of authorized person: Zion Levy Position: Compliances & Integration Engineer

Page 1 of 2 Limited single modular transmitter approval request FCC ID:PIDCRM3650 Items to be covered Answer from applicant 1. The modular transmitter must have its own RF shielding. The modular transmitter has its own RF shielding. The RF shielding consists of the metal shielding of the module cover. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. Data from hosting PC to RF module pass thru SQN1210 chip which is used as a data buffer. 3. The modular transmitter must have its own power supply regulation. All power rails on system are regulated and/or filtered (pi filter) on board before entering the modular transmitter. As a module is inserted into a standard Host slot the EUT is powered by the 5.4 VDC 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). Antennas in use are a unique Directional Panel Antenna 19.5 dBi and Monopole 5.6 dBi requiring professional installation only. As noted in the User manual. 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. The Tx module was tested in stand-alone configuration connected with 15 cm cable to evaluation board. The cable was decoupled with ferrite at approximately 2 cm to represent the actual in slot installation. As a module, the EUT must be inserted directly into a Mini PCIe slot. 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. The modular transmitter has its own FCC ID:PIDCRM3650. If the FCC ID is not visible when the module is installed inside another device, user has the instructions to apply a FCC ID label on the other device (referred to in page 10 of the User manual). Page 2 of 2 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. There is no specific rule or operating requirements applicable to the transmitter with respect to user operation. 8. The modular transmitter must comply with any applicable RF exposure requirements. Modular transmitters approved under other Sections of Part 15, when necessary, may also need to address certain RF Exposure concerns, typically by providing specific installation and operating instructions for users, installers and other interested parties to ensure compliance. The modular transmitter complies with any applicable RF exposure requirements as specified in FCC part 90 section 90.1335. The EUT is a fixed device for use in Airspan products as stated in User manual page 10. Name of authorized person: Zion Levy Position: Compliances & Integration Engineer Airspan Networks Inc. Date: October 28, 2012

Airspan Networks Inc. 777 Yamato Rd Suite 310, Boca Raton, Florida, United States, 33431 FCC ID:PIDCRM3650 Date: 2012.10.29 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information accompanying this application as outlined below: Schematics BOM Tune up procedure Operational description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentation will not be made before the date of the grant for this application. Sincerely, Brian Roberts Engineering Dept. Airspan Networks Inc. Tel: +1 561 893 8686 Fax: +1 561 893 8671 e-mail: [email protected]

Airspan Networks Inc. FCC ID:PIDCRM3650 Page 1 of 3 EXTERNAL PHOTOGRAPHS This document contains 2 photographs Airspan Networks Inc. FCC ID:PIDCRM3650 Page 2 of 3 Photograph No.1 CRM 3.65GHz module top view Airspan Networks Inc. FCC ID:PIDCRM3650 Page 3 of 3 Photograph No.2 CRM 3.65GHz module rear side view

Airspan Networks Inc. FCC ID:PIDCRM3650 Page 1 of 1 LABEL The label is affixed on the module as shown below. The label material is PVC with a permanent adhesive. CRM 3.65GHz module, label with FCC ID:PIDCRM3650 location Label with FCC ID:PIDCRM3650 will be placed here.

Airspan Networks Inc. FCC ID:PIDCRM3650 Page 1 of 3 INTERNAL PHOTOGRAPHS This document contains 2 photographs Airspan Networks Inc. FCC ID:PIDCRM3650 Page 2 of 3 Photograph No.1 CRM 3.65GHz module without shielding Airspan Networks Inc. FCC ID:PIDCRM3650 Page 3 of 3 Photograph No.2 CRM 3.65GHz module rear side view

TECHNICAL DATA SHEET Page 1 of 9 Direct Mount LPT Style Antenna W1982 1390-1435/3300-3800 MHz Series : ANTENNA Issue: 1148 I n t h e e f f o r t t o i m p r o v e o u r p r o d u c t s , w e r e s e r v e t h e r i g h t t o m a k e c h a n g e s j u d g e d t o b e n e c e s s a r y. C O N F I D E N T I A L A N D P R O P R I E T A R Y I N F O R M A T I O N T h i s d o c u m e n t c o n t a i n s c o n f i d e n t i a l a n d p r o p r i e t a r y i n f o r m a t i o n o f P u l s e E l e c t r o n i c s, I n c . ( P u l s e ) a n d is p r o t e c t e d b y c o p y r i g h t , t r a d e s e c r e t a n d o t h e r s t a t e a n d f e d e r a l l a w s. Its r e c e i p t o r p o s s e s s i o n d o e s n o t c o n v e y a n y r i g h t s t o r e p r o d u c e, d i s c l o s e its c o n t e n t s , o r t o m a n u f a c t u r e , u s e o r s e l l a n y t h i n g it m a y d e s c r i b e. R e p r o d u c t i o n , d i s c l o s u r e o r u s e w i t h o u t s p e c i f i c w r i t t e n a u t h o r i z a t i o n o f P u l s e is s t r i c t l y f o r b i d d e n All dimensions are in inches (mm) TECHNICAL DATA SHEET Page 2 of 9 Direct Mount LPT Style Antenna W1982 1390-1435/3300-3800 MHz Series : ANTENNA Issue: 1148 I n t h e e f f o r t t o i m p r o v e o u r p r o d u c t s , w e r e s e r v e t h e r i g h t t o m a k e c h a n g e s j u d g e d t o b e n e c e s s a r y. C O N F I D E N T I A L A N D P R O P R I E T A R Y I N F O R M A T I O N T h i s d o c u m e n t c o n t a i n s c o n f i d e n t i a l a n d p r o p r i e t a r y i n f o r m a t i o n o f P u l s e E l e c t r o n i c s, I n c . ( P u l s e ) a n d is p r o t e c t e d b y c o p y r i g h t , t r a d e s e c r e t a n d o t h e r s t a t e a n d f e d e r a l l a w s. Its r e c e i p t o r p o s s e s s i o n d o e s n o t c o n v e y a n y r i g h t s t o r e p r o d u c e, d i s c l o s e its c o n t e n t s , o r t o m a n u f a c t u r e , u s e o r s e l l a n y t h i n g it m a y d e s c r i b e. R e p r o d u c t i o n , d i s c l o s u r e o r u s e w i t h o u t s p e c i f i c w r i t t e n a u t h o r i z a t i o n o f P u l s e is s t r i c t l y f o r b i d d e n ELECTRICAL SPECIFICATIONS Antenna type Monopole (All electrical performance measured with antenna centered on 12” x 12” Ground plane) Frequency 1390-1435/3300-3800 MHz Nominal Impedance 50  VSWR 2:1 Max Peak Gain 1390-1435 MHz: 3.6 dBi Peak Gain 3300-3800 MHz: 5.6 dBi Avg Gain @15° EL 1390-1435 MHz: 1.0 dBi ±1.0dB Avg Gain @15° EL 3300-3800 MHz: 4.0 dBi ±1.0dB Efficiency 1390-1435/3300-3800 MHz: 60 % Min Polarization: Vertical -3 dB beamwidth Horizontal Plane : OMNI Vertical Plane 1390-1435 MHz: 53 ° Avg Vertical Plane 3300-3800 MHz: 31 ° Avg Power withstanding 10 W Connector type MCX jack TECHNICAL DATA SHEET Page 3 of 9 Direct Mount LPT Style Antenna W1982 1390-1435/3300-3800 MHz Series : ANTENNA Issue: 1148 I n t h e e f f o r t t o i m p r o v e o u r p r o d u c t s , w e r e s e r v e t h e r i g h t t o m a k e c h a n g e s j u d g e d t o b e n e c e s s a r y. C O N F I D E N T I A L A N D P R O P R I E T A R Y I N F O R M A T I O N T h i s d o c u m e n t c o n t a i n s c o n f i d e n t i a l a n d p r o p r i e t a r y i n f o r m a t i o n o f P u l s e E l e c t r o n i c s, I n c . ( P u l s e ) a n d is p r o t e c t e d b y c o p y r i g h t , t r a d e s e c r e t a n d o t h e r s t a t e a n d f e d e r a l l a w s. Its r e c e i p t o r p o s s e s s i o n d o e s n o t c o n v e y a n y r i g h t s t o r e p r o d u c e, d i s c l o s e its c o n t e n t s , o r t o m a n u f a c t u r e , u s e o r s e l l a n y t h i n g it m a y d e s c r i b e. R e p r o d u c t i o n , d i s c l o s u r e o r u s e w i t h o u t s p e c i f i c w r i t t e n a u t h o r i z a t i o n o f P u l s e is s t r i c t l y f o r b i d d e n MECHANICAL SPECIFICATIONS Plastic radome PC/Polyester blend, Makroblend EL 703 Bayer Material Science .110 thick min Flammability UL94 V-0 Color Cisco Gray Ingress Protection IP67 Weight 91 g Wind-loading 165 Mph Overall length 3.04 INCHES Installation torque 6-9 Ft/lbs Installation tool Recommended strap wrench, similar to McMaster Carr P/N: 5448A31 ENVIRONMENTAL SPECIFICATIONS Operating temperature -40to +85 ° C TECHNICAL DATA SHEET Page 4 of 9 Direct Mount LPT Style Antenna W1982 1390-1435/3300-3800 MHz Series : ANTENNA Issue: 1148 I n t h e e f f o r t t o i m p r o v e o u r p r o d u c t s , w e r e s e r v e t h e r i g h t t o m a k e c h a n g e s j u d g e d t o b e n e c e s s a r y. C O N F I D E N T I A L A N D P R O P R I E T A R Y I N F O R M A T I O N T h i s d o c u m e n t c o n t a i n s c o n f i d e n t i a l a n d p r o p r i e t a r y i n f o r m a t i o n o f P u l s e E l e c t r o n i c s, I n c . ( P u l s e ) a n d is p r o t e c t e d b y c o p y r i g h t , t r a d e s e c r e t a n d o t h e r s t a t e a n d f e d e r a l l a w s. Its r e c e i p t o r p o s s e s s i o n d o e s n o t c o n v e y a n y r i g h t s t o r e p r o d u c e, d i s c l o s e its c o n t e n t s , o r t o m a n u f a c t u r e , u s e o r s e l l a n y t h i n g it m a y d e s c r i b e. R e p r o d u c t i o n , d i s c l o s u r e o r u s e w i t h o u t s p e c i f i c w r i t t e n a u t h o r i z a t i o n o f P u l s e is s t r i c t l y f o r b i d d e n Charts - All radiation patterns, gain, VSWR measured with Antenna mounted on center of 12” x 12” Ground plane Vertical Plane -35 -30 -25 -20 -15 -10 -5 0 5 0 30 60 90 120 150 180 210 240 270 300 330 W1962 E-Plane 139014101440 -3.8 3.8 53 1390: Avg (dBi) = Peak (dBi) = Avg -3 (deg) = -4.2 3.3 53 1410: Avg (dBi) = Peak (dBi) = Avg -3 (deg) = -4.2 3.4 53 1440: Avg (dBi) = Peak (dBi) = Avg -3 (deg) = Vertical Plane -35 -30 -25 -20 -15 -10 -5 0 5 0 30 60 90 120 150 180 210 240 270 300 330 W1962 E-Plane 330033503400 34503500 -6.8 5.0 32 3300: Avg (dBi) = Peak (dBi) = Avg -3 (deg) = -6.7 5.1 32 3350: Avg (dBi) = Peak (dBi) = Avg -3 (deg) = -…

Text truncated - open the document above for the full version.

3.3-3.8GHz Dual-Polarized Directional Panel Antenna for Cisco Directional Dual-Polarized Panel Antenna PCTEL, Inc. WEB: www.antenna.com Technical Data Maximum Power: 20 watts Polarization: Dual Linear, H/V or +/-45 ° slant Nominal Impedance: 50 ohms VSWR: 1.5 typical, 2.0 maximum Front to Back Ratio: > 27 dB Radome Material: UL-HB rated Chi Mei PW-978B ASA Thickness: 0.085” typical, 0.070” min Termination: 2 x Type N Female Panel Mount Connectors Mounting Method and Material: Fully adjustable pipe or wall mount constructed of nickel-zinc trivalent coated steel The 07-1161-01 directional panel antenna was designed to cover 3.3-3.8GHz frequencies for industrial wireless applications, obtaining maximum gain with an attractive, low profi le package. These models provide efficient and stable performance across the band and can be mounted indoors or outdoors. Features • ASA radome and PC board conform to the UL-HB flame retardant rating, allowing maximum installation flexibility. • Attractive, low profi le housing. Blends well with indoor and outdoor envi- ronments where aesthetic considerations are important. • Dual-polarized for higher throughput MIMO applications. • Private labeled with Cisco part numbers and descriptions. Frequency Range Nominal Gain 3 dB Horizontal Beamwidth 3 dB Vertical Beamwidth RF/Electrical Specifi cations Mechanical Specifi cations Dimensions Antenna Weight (Mass) Temperature Range FRONT VIEW 14.5” x 14.5” x 1.75” (340 x 340 x 30 mm) 3.5 lbs (1.6 kg) -40°C to +85°C 3.3-3.8GHz18.5 dBi ±1 dB 17° 17° MOUNT VIEW © 2011 PCTEL, Inc. Product specifi cations are subject to change without notice. • Fully adjustable mounting bracket for pipe or wall mount installations.

Airspan Interference Detection in Unrestricted FCC Band Guidance regarding contention based protocol for devices operating in the 3650-3700 MHz Band under Part 90Z. Airspan Interference Detection in Unrestricted FCC Band Page 2 1 Document Overview This document identifies several questions / information to help determine the contention based protocol capability of a device that may operate in the 3650 – 3700 MHz under part 90Z of our rules. These questions are intended to be used as a guide by the applicant to describe how their system meets the requirements for 3650-3700 contention based protocol. This device is WiMAX fixed remote terminal station. The base station enables fixed remote terminal station and ensures CBP implementation. In order to start any transmission of WiMAX fixed remote terminal station, it first has to be synchronized with the transmission of the base station. In order to be synchronized with the base station, the terminal station has to detect the preamble transmitted by the base station every frame and to decode the DL and UL MAP messages which are broadcasted by the base station. It then has to verify that the base station identity (BSID), which is broadcasted by the BS matched the BSID that the terminal station is configured to work with. The UL MAP messages contains transmission allocations for the terminals station, therefore, without synchronization to the base station transmission, without validation of the BSID and without decoding of the UL MAP, terminal station is not able to transmit. This device is WiMAX fixed remote terminal station intended for operation with Base station FCC ID: PIDMMAX3605 or Base station FCC ID: O2J-365AS (Airspan’s BS). Answers to FCC Technical questions in KDB 552295 for devices operating in the 3650-3700 MHz Band under Part 90Z. Airspan Interference Detection in Unrestricted FCC Band Page 3 2 Unrestricted Certification under Part 90Z (3650-3700 Band) In order to ensure that a device complies with the requirements of unrestricted contention based protocol, the following information should be provided in the application. 2.1 Unrestricted Protocol Description 2.1.1 Address the key requirements for operation using unrestricted contention based protocol. Please note that this requires recognizing other systems (both similar to yours and different from yours) that operate on a co-channel. Indicate the strategy for sharing the spectrum in…
