PIDSYN2500Base station of LTE fixed cellular system

UGD-D01001 Rev A AirSynergy 2000 Installation Guide AirSynergy 2000 Installation Guide Page 2 Commercial in Confidence UGD-D01001 Rev A1 Copyright © Copyright by Airspan Networks Inc., 2013. All rights reserved worldwide. The information contained within this document is proprietary and is subject to all relevant copyright, patent and other laws protecting intellectual property, as well as any specific agreements protecting Airspan Networks Inc. rights in the aforesaid information. Neither this document nor the information contained herein may be published, reproduced or disclosed to third parties, in whole or in part, without the express, prior, written permission of Airspan Networks Inc. In addition, any use of this document or the information contained herein for the purposes other than those for which it is disclosed is strictly forbidden. Airspan Networks Inc. reserves the right, without prior notice or liability, to make changes in equipment design or specifications. Information supplied by Airspan Networks Inc. is believed to be accurate and reliable. However, no responsibility is assumed by Airspan Networks Inc. for the use thereof nor for the rights of third parties which may be effected in any way by the use of thereof. Any representation(s) in this document concerning performance of Airspan Networks Inc. product(s) are for informational purposes only and are not warranties of future performance, either expressed or implied. Airspan Networks Inc. standard limited warranty, stated in its sales contract or order confirmation form, is the only warranty offered by Airspan Networks Inc. in relation thereto. This document may contain flaws, omissions or typesetting errors; no warranty is granted nor liability assumed in relation thereto unless specifically undertaken in Airspan Networks Inc. sales contract or order confirmation. Information contained herein is periodically updated and changes will be incorporated into subsequent editions. If you have encountered an error, please notify Airspan Networks Inc. All specifications are subject to change without prior notice. Product performance figures quoted within this document are indicative and for information purposes only. AirSynergy 2000 Installation Guide Page 3 Commercial in Confidence UGD-D01001 Rev A1 Table of Contents Copyright .......................................................................................................................................... 2 Table of Contents ............................................................................................................................. 3 Summary of Figures ......................................................................................................................... 5 Summary of Tables .......................................................................................................................... 7 Warnings and Cautions .................................................................................................................... 8 Human Exposure to Radio Frequencies ...................................................................................... 8 Radio Interference ........................................................................................................................ 8 Avoiding Radio Interference ......................................................................................................... 8 Modifications ................................................................................................................................. 8 General ......................................................................................................................................... 8 Safety ............................................................................................................................................ 8 Warning of Hazardous Voltages ............................................................................................... 9 Adherence to European Directive 1999/519/EC .......................................................................... 9 Warning Symbols.......................................................................................................................... 9 Service Information ....................................................................................................................... 9 UL Information ............................................................................................................................ 10 Lightning Protection .................................................................................................................... 10 DECLARATION OF CONFORMITY ............................................................................................... 11 FCC Notice ..................................................................................................................................... 12 Federal Communication Commission Notice ............................................................................. 12 GPS Compliance ........................................................................................................................ 12 Maximum Output TX Power ........................................................................................................... 13 Power Consumption ................................................................................................................... 13 Antenna Types............................................................................................................................ 13 Switched Beam Antenna ............................................................................................................ 13 Front Mount Sector Antenna ...................................................................................................... 14 AirSynergy Antenna Usage Options .................................................…

Text truncated - open the document above for the full version.

194 7.64 194 7.64 1405.51 1154.53 1054.13 130 5.12 130 5.12 903.54 MOUNTED VIA 6 OFF 4.5 HOLES ALTERNATIVE MOUNTED VIA 4 OFF M4 x 10 STUDS 13.7 0.54 399 15.71 N(M) CONNECTORS ON 750mm LEADS BASE VIEW SIDE VIEW SAT edit Elevation edit Polar Plot edit Provisional performance patterns available. Cobham Antenna Systems, Microwave Antennas - Newmarket For further information please contact: Cobham Antenna Systems, Microwave Antennas Lambda House, Cheveley, Newmarket, Suffolk. CB8 9RG, UK Tel +44 (0) 1638 732177 Fax +44 (0) 1638 731999 [email protected] European Antennas Limited trading as Cobham Antenna Systems, Microwave Antennas European Antennas Limited has a policy of continuous development and stress that the information provided is a guide only and does not consitute an offer or contract or part thereof. Whilst every effort is made to ensure the accuracy of the information contained in this datasheet, no responsibilty can be accepted for any errors or omissions. The copyright of antenna designs and images is copyright protected and owned by European Antennas Limited. ©European Antennas Limited. Azimuth Polar Plot (similar product) Elevation Polar Plot (similar product) www.cobham.com/antennasystems EUROPEAN ANTENNAS LTD.

Alpha Wireless Ltd, Email: [email protected] Web: www.alphawireless.ie These specifications are subject to change without notice AW3008 +/-45° Polarized 90° Sector Antennas 2300-2700MHz Quad Port Fixed Tilt The AW3008 is a broadband dual polarised Quad Port Basestation Antenna which is designed for MIMO applications. Emphasis has been placed on rugged mechanical construction, styling, small dimensions plus superior electrical performance. This antenna is designed to meet the most stringent environmental conditions. Features: Excellent Radiation Patterns Low Upper Sidelobes plus Null Fill Wide Bandwidth with stable gain across the band Low PIM Design UV Stabilised Radome with Stainless steel Brackets Applications: WiMAX Sector antennas, 4x2 and 4x4 MIMO Electrical Specifications: Frequency Range: 2300 MHz - 2700 MHz //2300 MHz - 2700 MHz Gain: 17.0 dBi Return Loss: > 15dB Polarisation: +/-45° Slant Isolation >30dB Front to Back Ratio: >30dB Horizontal 3dB BW: 90° Vertical 3dB BW: 7° Upper Sidelobe Suppression: >18dB Electrical Downtilt: 4° (2° & 8° options also available) Power Handling: 150W Mechanical Specifications: Connectors: 4 x N Type Female Connector Location: Bottom Dimensions (LxWxD): 1100 x 260 x 55 mm Weight: 10Kg Radome: UV Stabilised Styrosun Environmental Ratings: Rated Wind Velocity 200 km/h (125mph) Lightening Protection: DC Grounded Temperature -40ºC to +70ºC Alpha Wireless Ltd, Email: [email protected] Web: www.alphawireless.ie These specifications are subject to change without notice AW3008 (Cont) Mounting Options: Standard (Included) Pipe Mount with 2 Stainless Steel Bands Adjustable (Optional) Mounting Kit (CL-V-103, CL-V-104 ) Typical Radiation Patterns: Azimuth Pattern Elevation Pattern Antenna Outline:

Alpha Wireless Ltd, Email: [email protected] Web: www.alphawireless.ie These specifications are subject to change without notice AW3007 +/-45° Polarized 65° Sector Antennas 2300-2700MHz Quad Port Fixed Tilt The AW3007 is a broadband dual polarised Quad Port Basestation Antenna which is designed for MIMO applications. Emphasis has been placed on rugged mechanical construction, styling, small dimensions plus superior electrical performance. This antenna is designed to meet the most stringent environmental conditions. Features: Excellent Radiation Patterns Low Upper Sidelobes plus Null Fill Wide Bandwidth with stable gain across the band Low PIM Design UV Stabilised Radome with Stainless steel Brackets Applications: WiMAX Sector antennas, 4x2 and 4x4 MIMO Electrical Specifications: Frequency Range: 2300 MHz - 2700 MHz //2300 MHz - 2700 MHz Gain: 18.0 dBi Return Loss: > 15dB Polarisation: +/-45° Slant Isolation >30dB Front to Back Ratio: >30dB Horizontal 3dB BW: 65° Vertical 3dB BW: 7° Upper Sidelobe Suppression: >18dB Electrical Downtilt: 4° (2° & 8° options also available) Power Handling: 150W Mechanical Specifications: Connectors: 4 x N Type Female Connector Location: Bottom Dimensions (LxWxD): 1100 x 260 x 55 mm Weight: 10Kg Radome: UV Stabilised Styrosun Environmental Ratings: Rated Wind Velocity 200 km/h (125mph) Lightening Protection: DC Grounded Temperature -40ºC to +70ºC Alpha Wireless Ltd, Email: [email protected] Web: www.alphawireless.ie These specifications are subject to change without notice AW3007 (Cont) Mounting Options: Standard (Included) Pipe Mount with 2 Stainless Steel Bands Adjustable (Optional) Mounting Kit (CL-V-103, CL-V-104 ) Typical Radiation Patterns: Azimuth Pattern Elevation Pattern Antenna Outline:

RF_160, Issue 03 Declaration of Authorization We Name: Airspan Networks Inc. Address: 777 Yamato Rd, Suite 310 City: Boca Raton, Florida 33431 Country: USA. Declare that: Name Representative of agent: ............. (1) Agent Company name: Hermon Laboratories Ltd. . Address: Harakevet Industrial Zone .. City: Binyamina 30500 .. Country Israel . is authorized to apply for Certification of the following product(s): Product description:  Base station of LTE fixed cellular system . Type designation:  Synergy 2000 2.5 GHz (B41). Trademark:  Airspan . on our behalf. Date: March 16, 2014.. City: Boca Raton .. Name: Zion Levy .. (2) Function: Compliances & Integration Engineer ............................... Signature: . Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 16-Jul-10 RF_501, Issue 6 Page 1 of 1 Company Name: Airspan Networks Inc. Address : 777 Yamato Rd, Suite 310 City: Boca Raton, Florida Country: United States To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: PIDSYN2500 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: This device is a new concept of LTE products and contains a trade secret of the company Planned Release Date STC: 180 days from the grant date (notes 2, 3, 4, 5) Date: March 16 , 2014 Name and signature of applicant: Zion Levi Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

March 16, 2014 To: Telefication B.V. Attn: Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Application for certification of a base station of LTE fixed cellular system operating in 2501 – 2685 MHz band, FCC ID:PIDSYN2500 Dear Gentlemen, Please find attached our application for certification of a base station of LTE fixed cellular system operating in 2501 – 2685 MHz band, FCC ID:PIDSYN2500, prepared in accordance with FCC Rules, parts 2 and 27. The product testing and this application for certification were performed by Hermon Laboratories, which is listed by FCC (Registration Numbers 90623, 90624). The FCC Designation Number is US1003. Hermon Labs responsible person is Mr. Michael Nikishin, tel: 011 972 4626 8440, fax:011 972 4628 8277, e-mail: [email protected]. We hope this application satisfies your requirements. Please send an invoice to Hermon Labs. Sincerely, Zion Levi Compliances & Integration Engineer Airspan Networks Inc.

Company name: Airspan Networks Inc. Address: 777 Yamato Road Suite 310 Boca Raton FL 33431 USA FCC ID:PIDSYN2500 “Synergy 2000 2.5 GHz (B41)” statement DC voltages/currents supplied to elements of the final radio frequency amplifying device for normal operation over the power range: 28 V/ 1 A. Name of authorized person: Zion Levy Position: Compliances & Integration Engineer Date:March 5, 2014 Airspan Networks Inc. Tel: +1 561 893-8670; Fax: +1 561 893-8671, www.airspan.com

Airspan Networks Inc. FCC ID:PIDSYN2500 Page 1 of 1 Environmental evaluation and exposure limit according to FCC CFR 47part 1, §1.1307, §1.1310 The transceiver is classified as fixed, the calculation was done to confirm a safe distance. Limit for power density for general population/uncontrolled exposure is 1 mW/cm 2 for 1500 -100000 MHz frequency range. The power density P (mW/cm 2 ) = P T / 4 r 2 , where P T is the transmitted power, which is equal to the peak transmitter output power plus maximum antenna gain. The maximum equivalent isotropically radiated power EIRP is P T = 33.65 dBm +18 dBi = 51.65 dBm = 146218 mW, where 33.65 dBm is the EUT maximum output power, 18 dBi – antenna gain. The minimum safe distance “r”, where RF exposure does not exceed FCC permissible limit, is r = sqrt { P T / (Px4)} = sqrt {146218 / 12.56} = 107.9 cm ≈ 108 cm. A warning about a safe distance is contained in the user manual.

Airspan Networks Inc. FCC ID:PIDSYN2500 Page 1 of 8 EXTERNAL PHOTOGRAPHS This document contains 7 photographs Airspan Networks Inc. FCC ID:PIDSYN2500 Page 2 of 8 Photograph No.1 “Synergy 2000 2.5 GHz (B41)” base station general view Airspan Networks Inc. FCC ID:PIDSYN2500 Page 3 of 8 Photograph No.2 “Synergy 2000 2.5 GHz (B41)” base station top panel view Airspan Networks Inc. FCC ID:PIDSYN2500 Page 4 of 8 Photograph No.3 “Synergy 2000 2.5 GHz (B41)” base station rear side view Airspan Networks Inc. FCC ID:PIDSYN2500 Page 5 of 8 Photograph No.4 “Synergy 2000 2.5 GHz (B41)” base station bottom panel view Airspan Networks Inc. FCC ID:PIDSYN2500 Page 6 of 8 Photograph No.5 “Synergy 2000 2.5 GHz (B41)” base station side view Airspan Networks Inc. FCC ID:PIDSYN2500 Page 7 of 8 Photograph No.6 “Synergy 2000 2.5 GHz (B41)” base station second side view Airspan Networks Inc. FCC ID:PIDSYN2500 Page 8 of 8 Photograph No.7 “Synergy 2000 2.5 GHz (B41)” base station bottom view

Airspan Networks Inc. FCC ID:PIDSYN2500 Page 1 of 1 LABEL The label is affixed on the bottom side of the base radio unit as shown below. The label material is PVC with a permanent adhesive. “Synergy 2000 2.5 GHz” bottom panel, label with FCC ID:PIDSYN2500 location FCC ID:PIDSYN2500

Airspan Networks Inc. FCC ID:PIDSYN2500 Page 1 of 13 INTERNAL PHOTOGRAPHS This document contains 12 photographs Airspan Networks Inc. FCC ID:PIDSYN2500 Page 2 of 13 Photograph No.1 “Synergy 2000 2.5 GHz (B41)” base station internal view Airspan Networks Inc. FCC ID:PIDSYN2500 Page 3 of 13 Photograph No.2 “Synergy 2000 2.5 GHz (B41)” base station internal view with filter and power supply removed Airspan Networks Inc. FCC ID:PIDSYN2500 Page 4 of 13 Photograph No.3 “Synergy 2000 2.5 GHz (B41)” base station internal view without flat cable Airspan Networks Inc. FCC ID:PIDSYN2500 Page 5 of 13 Photograph No.4 SDR-Qc, Digital and RF card front view Airspan Networks Inc. FCC ID:PIDSYN2500 Page 6 of 13 Photograph No.5 SDR-Qc, Digital and RF card second side view Airspan Networks Inc. FCC ID:PIDSYN2500 Page 7 of 13 Photograph No.6 Base station assembled FEM device Airspan Networks Inc. FCC ID:PIDSYN2500 Page 8 of 13 Photograph No.7 FEM device PCA on mechanical base plate Airspan Networks Inc. FCC ID:PIDSYN2500 Page 9 of 13 Photograph No.8 FEM device PCA front view Airspan Networks Inc. FCC ID:PIDSYN2500 Page 10 of 13 Photograph No.9 FEM device PCA second side view Airspan Networks Inc. FCC ID:PIDSYN2500 Page 11 of 13 Photograph No.10 Base station assembled power supply module Airspan Networks Inc. FCC ID:PIDSYN2500 Page 12 of 13 Photograph No.11 Power supply PCB front view Airspan Networks Inc. FCC ID:PIDSYN2500 Page 13 of 13 Photograph No.12 Power supply PCB second side view

FCC ID: PIDSYN2500 Technical Note LTE Band 41 Synergy 2000- Band 41 Connecting the World with Wireless Access Solutions Revision RecordSynergy 2000- Band 41 Pub/ Rev Date Update Description 01 March 05 Publication No. 28080512-01  Copyright by Airspan Networks LTD., 2003. All rights reserved worldwide. The information contained in this document is proprietary and is subject to all relevant copyright, patent and other laws protecting intellectual property, as well as any specific agreement protecting Airspan Networks LTD. rights in the aforesaid information. Neither this document nor the information contained herein may be published, reproduced or disclosed to third parties, in whole or in part, without the express, prior, written permission of Airspan Networks LTD. In addition, any use of this document or the information contained herein for any purposes other than those for which it was disclosed is strictly forbidden. Airspan Networks LTD. reserves the right, without prior notice or liability, to make changes in equipment design or specifications. Information supplied by Airspan Networks LTD. is believed to be accurate and reliable. However, no responsibility is assumed by Airspan Networks LTD. for the use thereof nor for the rights of third parties which may be effected in any way by the use thereof. Any representation(s) in this document concerning performance of Airspan Networks LTD. product(s) are for informational purposes only and are not warranties of future performance, either express or implied. Airspan Networks LTD. standard limited warranty, stated in its sales contract or order confirmation form, is the only warranty offered by Airspan Networks LTD. in relation thereto. This document may contain flaws, omissions or typesetting errors; no warranty is granted nor liability assumed in relation thereto unless specifically undertaken in Airspan Networks LTD. sales contract or order confirmation. Information contained herein is periodically updated and changes will be incorporated into subsequent editions. If you have encountered an error, please notify Airspan Networks LTD. All specifications are subject to change without prior notice. LTE Synergy 2000 Technical Note 28080511-01 Airspan Networks Ltd. 3 1. Scope This document provides a description of the LTE Synergy product. 2. Synergy (Base Station) A Base station radio, Synergy 2000- Band 41 TDD LTE, is part of a LTE broadband fixed cellular wireless access system. The system provides a radio link between an end-user (a subscriber) and a network to give high-speed data access. The Synergy’s’ transceiver/receiver (up to 64 QAM modulation, data rate up to 150 Mbps) uses OFDM and operating in TDD mode, equipped with a 18 dBi external antenna. The maximum total RF output power (not including antenna gain) is 33.65 dBm and it can be reduced by software. The Synergy is installed outdoors and typically is mounted on a pole. The Subscriber transmits and receives traffic to and from the base station respectively. The transceiver provides subscribers with "always-on" Internet, high speed data only, or data and voice (VoIP) services and is configured with a unique base station reference number, preventing the LTE UE from relocating to another subscriber premises without authorization. . 2.1. EUT (Synergy 2000) test configuration The EUT ports and lines description is given in the table below. Port type Port description Connector type QuantityCable length (m) Indoor /outdoor Connected to DC 48 VDC DC Connector 1 100 Outdoor DC P.S Data Ethernet RJ 45 1 100 Outdoor Eth. Switch

Company name: Airspan Networks Inc. Address: 777 Yamato Road Suite 310 Boca Raton FL 33431 USA FCC ID:PIDSYN2500 Synergy 2000 2.5 GHz (B41) tune up procedure Each Synergy radio has been tested by an automatic testing station (which is calibrated weekly for accuracy), which calibrates the unit prior to testing. Each Synergy contains 2 transmitters therefore each in turn is calibrated by the station for RF output power accuracy. The calibration is then verified by transmitting on the RF output power approved for each frequency checking that it does not exceed the maximum allowed by the FCC. For each frequency there is an internal software limit value that prevents the User from exceeding that RF output power setting. In the event the RF output power is higher than specified in the System Description, the Synergy radio doesn’t pass and acquires a Fail status. The Synergy boards with Fail statuses are rejected for final assembly of the product. The NMS management program also has internal specific FCC output limits that further checks and verifies maximum RF power output and prevents transmition above the FCC limits. Name of authorized person: Zion Levy Position: Compliances & Integration Engineer Date:March 5, 2014 Airspan Networks Inc. Tel: +1 561 893-8670; Fax: +1 561 893-8671, www.airspan.com

Hermon Laboratories Ltd. Harakevet Industrial Zone, Binyamina 30500, Israel Tel. +972-4-6288001 Fax. +972-4-6288277 E-mail: [email protected] Page 1 of 110 Report ID: AIRRAD_FCC.25543_rev1.docx Date of Issue: 20-Mar-14 ELECTRICAL TESTING 0839.01 TEST REPORT ACCORDING TO: FCC 47CFR part 27 FOR: Airspan Networks Inc. LTE Base Station Model: Synergy 2000 2.5 GHz (B41) FCC ID:PIDSYN2500 This report is in conformity with ISO/ IEC 17025. The "A2LA Accredited" symbol endorsement applies only to the tests and calibrations that are listed in the scope of Hermon Laboratories accreditation. The test results relate only to the items tested. This test report shall not be reproduced in any form except in full with the written approval of Hermon Laboratories Ltd. Report ID: AIRRAD_FCC.25543_rev1.docx Date of Issue: 20-Mar-14 Page 2 of 110 Table of contents 1 Applicant information ..................................................................................................................................................... 3 2 Equipment under test attributes .................................................................................................................................... 3 3 Manufacturer information .............................................................................................................................................. 3 4 Test details .................................................................................................................................................................... 3 5 Tests summary .............................................................................................................................................................. 4 6 EUT description ............................................................................................................................................................. 5 6.1 General information ....................................................................................................................................................... 5 6.2 Ports and lines .............................................................................................................................................................. 5 6.3 Support and test equipment .......................................................................................................................................... 5 6.4 Changes made in the EUT ............................................................................................................................................ 5 6.5 Test configuration .......................................................................................................................................................... 6 6.6 Transmitter characteristics ............................................................................................................................................ 7 7 Transmitter tests according to 47CFR part 27 ............................................................................................................... 8 7.1 Occupied bandwidth test ............................................................................................................................................... 8 7.2 Peak output power test ................................................................................................................................................ 16 7.3 Band edge emissions at RF connector test ................................................................................................................. 30 7.4 Spurious emissions at RF antenna connector test ...................................................................................................... 41 7.5 Radiated spurious emission measurements ................................................................................................................ 74 7.6 Frequency stability test ................................................................................................................................................ 88 8 APPENDIX A Test equipment and ancillaries used for tests ....................................................................................... 97 9 APPENDIX B Measurement uncertainties ................................................................................................................... 99 10 APPENDIX C Test facility description ....................................................................................................................... 100 11 APPENDIX D Specification references ..................................................................................................................... 100 12 APPENDIX E Test equipment correction factors ....................................................................................................... 101 13 APPENDIX F Abbreviations and acronyms ............................................................................................................... 110 Report ID: AIRRAD_FCC.25543_rev1.docx Date of Issue: 20-Mar-14 Page 3 of 110 1 Applicant information Client name: Airspan Networks Inc. Address: 777 Yamato, Road Suite 310 Boca Raton, FL 33431, USA Telephone: +1 561 893 8670 Fax: +1 561 893 8671 E-mail: [email protected] Contact name: Mr. Zion Levi 2 Equipment under test attributes Product name: LTE Base Station Product type: Transceiver Model(s): Synergy 2000 2.5 GHz (B41) Serial number: 70F1E1173BD0 Hardware version: C8 Software release: 14.12.50.57 Receipt date 23-Feb-14 3 Manufacturer information Manufacturer name: Airspan Networks Inc. Address: 777 Yamato, Road Suite 310 Boca Raton, FL 33431, USA Telephone: +1 561 893 8670 Fax: +1 561 893 8671 E-Mail: [email protected] Contact name: Mr. Zion Levi 4 Test details Project ID: 25543 Location: Hermon Laboratories Ltd. Harakevet Industrial Zone, Binyamina 30500, Israel Test started: 25-Feb-14 Test completed:…
