PINHACOEF311TAutomotive Security Transmitter

April 5, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: Hyundai Autonet Co., Ltd. FCC ID: PINHACOEF311T 731 Confirmation No.: TC100454 Request for Tech. Info.: 04/03/01 To Whom It May Concern:: Transmitted herewith, on behalf of Hyundai Autonet Co., Ltd., is an amendment provided in response to the request for technical information dated April 3, 2001. 1. Please find attached the Schematic Diagram. If you have any further questions, please do not hesitate to contact us. cc: Hyundai Autonet Co., Ltd.

© 2001 PCTEST Lab Car Alarm RF Remote Control Transmitter NVLAP Lab Code: 100431-0 Hyundai Autonet Co., Ltd. FCC ID: HACOEF311T © 2001 PCTEST Lab Car Alarm RF Remote Control Transmitter NVLAP Lab Code: 100431-0 Hyundai Autonet Co., Ltd. FCC ID: HACOEF311T

© 2001 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 & §§ 15.19 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) FCC ID: PINHACOEF311T

© 2001 PCTEST Lab Car Alarm RF Remote Control Transmitter NVLAP Lab Code: 100431-0 Hyundai Autonet Co., Ltd. FCC ID: HACOEF311T © 2001 PCTEST Lab Car Alarm RF Remote Control Transmitter NVLAP Lab Code: 100431-0 Hyundai Autonet Co., Ltd. FCC ID: HACOEF311T

© 2001 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 66606660--B Dobbin Road B Dobbin Road •• Columbia, MD 21045 Columbia, MD 21045 •• U.S.A. U.S.A. TEL (410) 290TEL (410) 290--6652 6652 •• FAX (410) 290 FAX (410) 290--66546654 http://www.pctestlab.comhttp://www.pctestlab.com CERTIFICATE OF COMPLIANCE Manufacturer: Hyundai Autonet Co., Ltd. Date(s) of Tests: March 5-6, 2001 San 136-1, Ami-Ri, Bubal-Eub, Test Report S/N: TX.210305116.PIN Icheon-Si, Kyoungki-Do, KOREA 467-701 Test Site: PCTEST Lab, MD U.S.A. Attn: Mr. Ki-Soo Kim, Quality Management Dept. System Quality Assurance Office FCC ID PINHACOEF311T APPLICANT HYUNDAI AUTONET CO., LTD. FCC Rule Part(s): § 15.231 Subpart C – Intentional Radiator Classification: Remote Control Transmitter (DSC) EUT Type: Car Alarm RF Remote Control Transmitter Freq. Range: 311MHz ~ 311MHz Oscillator(s): 311MHz Trade Name: HYUNDAI AUTONET CO., LTD. Model: HACOEF311T This device has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified is ANSI C63.4-1992. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Lab Code 100431-0 © 2001 PCTEST Engineering Laboratory, Inc. TX Certification TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT SCOPE 1 INTRODUCTION (SITE DESCRIPTION) 2 PRODUCTION INFORMATION 3 DESCRIPTION OF TESTS (CONDUCTED) 4 DESCRIPTION OF TESTS (RADIATED) 5 ANTENNA REQUIREMENT / BANDWIDTH MEASUREMENT 6 FREQUENCY MEASUREMENTS (SPURIOUS) 7 LIST OF SUPPORT EQUIPMENT 8 PLOTS OF EMISSION 9 SAMPLE CALCULATIONS 10 ACCURACY OF MEASUREMENT 11 LIST OF TEST EQUIPMENT 12 CONCLUSION 13 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL & LOCATION ATTACHMENT F: BLOCK DIAGRAM(S) / SCHEMATIC(S) ATTACHMENT G: TEST SETUP PHOTOGRAPHS ATTACHMENT H: EXTERNAL PHOTOGRAPHS ATTACHMENT I: INTERNAL PHOTOGRAPHS ATTACHMENT J: USER’S MANUAL Test Report S/N: TX.210305116.PIN FCC Part 15.231 Subpart C Dates of Tests: March 5-6, 2001 Transmitter Certification © 2001 PCTEST Lab Car Alarm RF Remote Control Transmitter 1 Hyundai Autonet Co., Ltd. FCC ID: HACOEF311T MEASUREMENT REPORT Scope - Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. Company Name: HYUNDAI AUTONET CO., LTD. Address: San 136-1, Ami-Ri, Bubal-Eub, Icheon-Si, Kyoungki-Do, KOREA 467-701 Attention: Mr. Ki-Soo Kim, Quality Management Dept. • FCC ID: PINHACOEF311T • Model: HACOEF311T • Trade Name: HYUNDAI AUTONET CO., LTD. • EUT Type: Car Alarm RF Remote Control Transmitter • Application Type: Transmitter Certification • Freq. Range: 311MHz ~ 311MHz • Oscillator(s): 311 MHz • FCC Rule Part(s): § 15.231 Subpart C – Intentional Radiator • Dates of Tests: March 5-6, 2001 • Place of Tests: PCTEST Lab, Columbia, MD U.S.A. • Test Report S/N: TX.210305116.PIN Test Report S/N: TX.210305116.PIN FCC Part 15.231 Subpart C Dates of Tests: March 5-6, 2001 Transmitter Certification © 2001 PCTEST Lab Car Alarm RF Remote Control Transmitter 2 Hyundai Autonet Co., Ltd. FCC ID: HACOEF311T 1.1 INTRODUCTION The measurement procedure described in American National Standard for Methods of Measurement of Radio- Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSI C63.4-1992) was used in determining radiated and conducted emissions emanating from HYUNDAI AUTONET CO., LTD. (Model: HACOEF311T) Car Alarm RF Remote Control Transmitter FCC ID: PINHACOEF311T. These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. 1.2 PCTEST Location The map at right shows the location of the PCTEST Lab, its proximity to the FCC Lab, the Columbia vicinity area, the Baltimore-Washington International (BWI) airport, and the city of Baltimore, and the Washington, D.C. area. (see Figure1). Figure 1. Map of the Greater Baltimore and Metropolitan Washington, D.C. area. Test Report S/N: TX.210305116.PIN FCC Part 15.231 Subpart C Dates of Tests: March 5-6, 2001 Transmitter Certification © 2001 PCTEST Lab Car Alarm RF Remote Control Transmitter 3 Hyundai Autonet Co., Ltd. FCC ID: HACOEF311T 2.1 Product Information 2.2 Equipment Description The Equipment Under Test (EUT) is the HYUNDAI AUTONET CO., LTD. (Model: HACOEF311T) Car Alarm RF Remote Control Transmitter FCC ID: PINHACOEF311T. The EUT is a one-channel wireless transmitter operating at 311MHz. * Tx Freq. Range: 311MHz ~ 311MHz * Oscillator(s): 311MHz * No. of Channels: 1 * Antenna: Built-in internal looped antenna on-board * Power Consumption: 3V DC * Rx Model No.: HACOEF311R Test Report S/N: TX.210305116.PIN FCC Part …
