PKCLS0301Energy Saving Lamp

User’s Manual This light device has been tested and found to comply with the limits for Consumer RF Lighting Device, pursuant to Part 18 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. 1 Use only on 120V/60Hz. 2 Never disassemble or modify-any changes could void the user’ authority to operate this device. 3 Not for use in totally enclosed recessed fixtures. 4 Risk of electric shock-do not use with where directly exposed to water. 5 This device is not intended for use with emergency exit fixtures or emergency exit lights. 6 This product may cause interference to radio equipment and should not be installed near maritime safety communications equipment or other critical navigation or communication equipment operating between 0.45-30MHz. 7 To prevent burns, do not touch the bulb during operation or immediately after switching off. 8 Not for use with dimmers, electronic timer or photocell devices or occupancy sensor.

Block Diagram 40

From: acibm [[email protected]] Sent: Wednesday, August 13, 2003 12:10 AM To: Eric Dobson; [email protected] Cc: Jason Chen; byron_kwo Subject: XIAMEN LONGSTAR LIGHTING CO., LTD. - FCC ID: PKCLS0301/04/05 Dear Eric Dobson: Pls see the words below, 1.SUBJECT: XIAMEN LONGSTAR LIGHTING CO., LTD. - FCC ID: PKCLS0301 REFERENCE: JOB 972CC3 Your question: 1. Nine (9) Models: Please identify any parts that are different from one model to another. And identify these part on the schematic. 2. Block Diagram must indicate frequencies on it. Please revise & resend." Our answer: 1.The application confirm the schematic and parts on each circuit board are identical. If you have some question as before, pls see the picture "photos". Our Engineer confirm that the parts mounted on the circuit cards are in agreement with the schematic really. They do not appear to be identical , because they have different point of view. 2.Pls check the Block Diagram and the schematic again.[See FILE1= d:\ftproot\timcoupload\cathrin-345--8-6-2003-01847\Longstar PKCLS0301.zip (731935) ] Our doubt: In your mail in Aug 09, you said,"We are reviewing your response. We will contact you if we have any questions." But after that, we can't received any message about this manner. 2.SUBJECT: XIAMEN LONGSTAR LIGHTING CO., LTD. - FCC ID: PKCLS0304 REFERENCE: JOB 1085CC3 In your mail , you said ,"Please provide us with a schematic showing that all part on all models are the same & also provide us with a statement for that also." Pls see the file[FILE2= d:\ftproot\timcoupload\cathrin-345--8-12-2003-23148\LongstarPKCLS0304.zip (748934) ], check the schematic part again. They all be we can provide. You advise us "If there are different parts on the circuit board, you must ask for a separate FCC ID for those lights". I'm very sorry to perplex you in this manner. But I don't know how can make this correct . I wish that you can in connection with the question over and above provide an advice to us. 3.SUBJECT: XIAMEN LONGSTAR LIGHTING CO., LTD. - FCC ID: PKCLS0305 REFERENCE: JOB 1090CC3 Your question: "Please submit a schematic that indicates any & all component differences between the different models of lights from 9 to 32 Watts" Our answer: Pls see the file [FILE1= d:\ftproot\timcoupload\cathrin-345--8-12-2003-23148\Longstar PKCLS0305.zip (740796) ], check the schematic part again. 4.The expenses about this manner will remit money by telegraph in Aug 21. If you have any questions, pls send message to us as soon as possible. Thank you very much and best regards. Very truly yours, Cathrin.yin Audix Technology(Shanghai)Co.,LTD

F IGURE 1 E NERGY S AVING L AMP (M/N: FE-BU-7/9W) G ENERAL A PPEARANCE F IGURE 2 E NERGY S AVING L AMP (M/N: FE-BU-11/15W) G ENERAL A PPEARANCE F IGURE 3 E NERGY S AVING L AMP (M/N: FE-BU-13W) G ENERAL A PPEARANCE F IGURE 4 E NERGY S AVING L AMP (M/N: FE-BU-18W) G ENERAL A PPEARANCE F IGURE 5 E NERGY S AVING L AMP (M/N: FE-BU-20W) G ENERAL A PPEARANCE F IGURE 6 E NERGY S AVING L AMP (M/N: FE-Z-13W) G ENERAL A PPEARANCE F IGURE 7 E NERGY S AVING L AMP (M/N: FE-Z-15W) G ENERAL A PPEARANCE

Label Location Information Refer to the below red arrow: (For example)

Label Drawing 1. For example: Note:The blue words will be replaced as follows for each model. Model (A) Label Model Label FE-BU-7W FE-BU-7W 120V 60Hz 115mA FE-BU-9W FE-BU-9W 120V 60Hz 150mA FE-BU-11W FE-BU-11W 120V 60Hz 180mA FE-BU-13W FE-BU-13W 120V 60Hz 210mA FE-BU-15W FE-BU-15W 120V 60Hz 230mA FE-BU-18W FE-BU-18W 120V 60Hz 280mA FE-BU-20W FE-BU-20W 120V 60Hz 335mA FE-Z-13W FE-Z-13W 120V 60Hz 210mA FE-Z-15W FE-Z-15W 120V 60Hz 230mA LISTED Energy Saving Lamp FCC ID: PKCLS0301 FE-BU-7W 7W 120V 60Hz 115mA

F IGURE 1 E NERGY S AVING L AMP (M/N: FE-BU-7/9W) C OVER R EMOVED 1 F IGURE 2 E NERGY S AVING L AMP (M/N: FE-BU-7/9W) C OVER REMOVED 2 F IGURE 3 E NERGY S AVING L AMP (M/N: FE-BU-7/9W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 4 ENERGY SAVING LAMP (M/N: FE-BU-7/9W) MAIN BOARD (SOLDERED SIDE) F IGURE 5 E NERGY S AVING L AMP (M/N: FE-BU-11/15W) C OVER R EMOVED 1 F IGURE 6 E NERGY S AVING L AMP (M/N: FE-BU-11/15W) C OVER REMOVED 2 F IGURE 7 E NERGY S AVING L AMP (M/N: FE-BU-11/15W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 8 ENERGY SAVING LAMP (M/N: FE-BU-11/15W) MAIN BOARD (SOLDERED SIDE) F IGURE 9 E NERGY S AVING L AMP (M/N: FE-BU-13W) C OVER R EMOVED 1 F IGURE 10 E NERGY S AVING L AMP (M/N: FE-BU-13W) C OVER REMOVED 2 F IGURE 11 E NERGY S AVING L AMP (M/N: FE-BU-13W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 12 E NERGY S AVING L AMP (M/N: FE-BU-13W) M AIN BOARD (SOLDERED SIDE) F IGURE 13 E NERGY S AVING L AMP (M/N: FE-BU-18W) C OVER R EMOVED 1 F IGURE 14 ENERGY SAVING LAMP (M/N: FE-BU-18W) COVER REMOVED 2 F IGURE 15 E NERGY S AVING L AMP (M/N: FE-BU-18W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 16 ENERGY SAVING LAMP (M/N: FE-BU-18W) MAIN BOARD (SOLDERED SIDE) F IGURE 17 E NERGY S AVING L AMP (M/N: FE-BU-20W) C OVER R EMOVED 1 F IGURE 18 ENERGY SAVING LAMP (M/N: FE-BU-20W) COVER REMOVED 2 F IGURE 19 E NERGY S AVING L AMP (M/N: FE-BU-20W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 20 ENERGY SAVING LAMP (M/N: FE-BU-20W) MAIN BOARD (SOLDERED SIDE) F IGURE 21 E NERGY S AVING L AMP (M/N: FE-Z-13W) C OVER R EMOVED 1 F IGURE 22 E NERGY S AVING L AMP (M/N: FE-Z-13W) C OVER REMOVED 2 F IGURE 23 E NERGY S AVING L AMP (M/N: FE-Z-13W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 24 E NERGY S AVING L AMP (M/N: FE-Z-13W) M AIN BOARD (SOLDERED SIDE) F IGURE 25 E NERGY S AVING L AMP (M/N: FE-Z-15W) C OVER R EMOVED 1 F IGURE 26 ENERGY SAVING LAMP (M/N: FE-Z-15W) COVER REMOVED 2 F IGURE 27 E NERGY S AVING L AMP (M/N: FE-Z-15W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 28 ENERGY SAVING LAMP (M/N: FE-Z-15W) MAIN BOARD (SOLDERED SIDE)

Schematics

Xiamen Longstar Lighting Co., Ltd. FCC ID: PKCLS0301 Page 1 of 38 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F03033 Application for FCC Certificate On Behalf of Xiamen Longstar Lighting Co., Ltd. Energy Saving Lamp FCC ID: PKCLS0301 Prepared For : Xiamen Longstar Lighting Co., Ltd. Chengnan Industrial Zone, Tongan, Xiamen, China 361100 Prepared By : Audix Technology (Shanghai) Co., Ltd. 3 F, 34 Bldg, 680 Guiping Rd, Caohejing Hi-Tech Park, Shanghai, China 200233 Tel : +86-21-64955500 Fax : +86-21-64955491 Report No. : ACI-F03033 Date of Test : Apr 03-May 21, 2003 Date of Report : Jun 20, 2003 Model No.: FE-BU-7W FE-BU-9W FE-BU-11W FE-BU-13W FE-BU-15W FE-BU-20W FE-BU-18W FE-Z-13W FE-Z-15W Xiamen Longstar Lighting Co., Ltd. FCC ID: PKCLS0301 Page 2 of 38 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F03033 TABLE OF CONTENTS Page 1 GENERAL INFORMATION.......................................................................................................... 4 1.1 Description of Equipment Under Test........................................................................................4 1.2 Description of Test Facility ........................................................................................................ 5 1.3 Measurement Uncertainty .......................................................................................................... 5 2 AC POWERLINE CONDUCTED EMISSION TEST ................................................................. 6 2.1 Test Equipment........................................................................................................................... 6 2.2 Block Diagram of Test Setup ..................................................................................................... 6 2.3 Conducted Emission Limits ....................................................................................................... 6 2.4 EUT Configuration on Test ........................................................................................................ 7 2.5 Operating Condition of EUT ...................................................................................................... 7 2.6 Test Procedures .......................................................................................................................... 7 2.7 Test Results ................................................................................................................................ 7 3 MAGNETIC FIELD EMISSION TEST ...................................................................................... 28 3.1 Test Equipment......................................................................................................................... 28 3.2 Block Diagram of Test Setup ................................................................................................... 28 3.3 Magnetic Field Emission Limit ................................................................................................ 28 3.4 EUT Configuration on Test ...................................................................................................... 28 3.5 Operating Condition of EUT .................................................................................................... 29 3.6 Test Procedures ........................................................................................................................ 29 3.7 Test Results .............................................................................................................................. 29 Xiamen Longstar Lighting Co., Ltd. FCC ID: PKCLS0301 Page 3 of 38 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F03033 TEST REPORT FOR FCC CERTIFICATE Applicant : Xiamen Longstar Lighting Co., Ltd. Manufacturer : Xiamen Longstar Lighting Co., Ltd. EUT Description : Energy Saving Lamp (A) Model No.: FE-BU-7W, FE-BU-9W, FE-BU-11W, FE-BU-13W, FE-BU-15W, FE-BU-18W, FE-BU-20W, FE-Z-13W, FE-Z-15W (B) Power Supply: 120V/60Hz Test Procedure Used: FCC RULES AND REGULATIONS PART 18 CONSUMER DEVICES (2002.10) AND MP-5/1986 The device described above is tested by Audix Technology (Shanghai) Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 18 RF Lighting Device limits both conducted emissions and field strength. The test results are contained in this test report and Audix Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT to be technically compliant with the FCC official limits. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shanghai) Co., Ltd. This report must not be used by the applicant to claim product endorsement by NVLAP or any agency of the U.S. Government. Date of Test : Apr 03-May 21, 2003 Prepared by : Test Engineer : CATHRIN YIN (Assistant) SOLON GONG (Engineer) Reviewer : Approved Signatory : SAMMY CHEN (Engineer) BYRON KWO (Assistant Manager) Xiamen Longstar Lighting Co., Ltd. FCC ID: PKCLS0301 Page 4 of 38 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F03033 1 GENERAL INFORMATION 1.1 Description of Equipment Under Test Description : Energy Saving Lamp Type of EUT : ; Production … Pre-product … Pro-type Model Number : FE-BU-7W, FE-BU-9W, FE-BU-11W, FE-BU-13W, FE-BU-15W, FE-BU-18W, FE-BU-20W, FE-Z-13W, FE-Z-15W, Applicant : Xiamen Longstar Lighting Co., Ltd. Chengnan Industrial Zone, Tongan, Xiamen, China 361100 Manufacturer : Xiamen Longstar Lighting Co., Ltd. Chengnan Industrial Zone, Tongan, Xiamen, China 361100 Test Model Apparent Power (V ̇ A) Real Power (W) FE-BU-7W 13.59 7.01 FE-BU-9W 14.33 7.43 FE-BU-11W 18.52 9.26 FE-BU-13W 21.91 13.31 FE-BU-15W 27.08 14.69 FE-BU-18W 27.68 15.19 FE-BU-20W 28.63 16.75 FE-Z-13W 21.19 12.24 FE-Z-15W 26.87 13.86 Xiamen Longstar Lighting Co., Ltd. FCC I…
