PKCLS0304PART 18 CONSUMER DEVICE

User’s Manual This light device has been tested and found to comply with the limits for Consumer RF Lighting Device, pursuant to Part 18 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. 1 Use only on 120V/60Hz. 2 Never disassemble or modify-any changes could void the user’ authority to operate this device. 3 Not for use in totally enclosed recessed fixtures. 4 Risk of electric shock-do not use with where directly exposed to water. 5 This device is not intended for use with emergency exit fixtures or emergency exit lights. 6 This product may cause interference to radio equipment and should not be installed near maritime safety communications equipment or other critical navigation or communication equipment operating between 0.45-30MHz. 7 To prevent burns, do not touch the bulb during operation or immediately after switching off. 8 Not for use with dimmers, electronic timer or photocell devices or occupancy sensor.

Block Diagram 40

From: acibm [[email protected]] Sent: Wednesday, August 13, 2003 12:10 AM To: Eric Dobson; [email protected] Cc: Jason Chen; byron_kwo Subject: XIAMEN LONGSTAR LIGHTING CO., LTD. - FCC ID: PKCLS0301/04/05 Dear Eric Dobson: Pls see the words below, 1.SUBJECT: XIAMEN LONGSTAR LIGHTING CO., LTD. - FCC ID: PKCLS0301 REFERENCE: JOB 972CC3 Your question: 1. Nine (9) Models: Please identify any parts that are different from one model to another. And identify these part on the schematic. 2. Block Diagram must indicate frequencies on it. Please revise & resend." Our answer: 1.The application confirm the schematic and parts on each circuit board are identical. If you have some question as before, pls see the picture "photos". Our Engineer confirm that the parts mounted on the circuit cards are in agreement with the schematic really. They do not appear to be identical , because they have different point of view. 2.Pls check the Block Diagram and the schematic again.[See FILE1= d:\ftproot\timcoupload\cathrin-345--8-6-2003-01847\Longstar PKCLS0301.zip (731935) ] Our doubt: In your mail in Aug 09, you said,"We are reviewing your response. We will contact you if we have any questions." But after that, we can't received any message about this manner. 2.SUBJECT: XIAMEN LONGSTAR LIGHTING CO., LTD. - FCC ID: PKCLS0304 REFERENCE: JOB 1085CC3 In your mail , you said ,"Please provide us with a schematic showing that all part on all models are the same & also provide us with a statement for that also." Pls see the file[FILE2= d:\ftproot\timcoupload\cathrin-345--8-12-2003-23148\LongstarPKCLS0304.zip (748934) ], check the schematic part again. They all be we can provide. You advise us "If there are different parts on the circuit board, you must ask for a separate FCC ID for those lights". I'm very sorry to perplex you in this manner. But I don't know how can make this correct . I wish that you can in connection with the question over and above provide an advice to us. 3.SUBJECT: XIAMEN LONGSTAR LIGHTING CO., LTD. - FCC ID: PKCLS0305 REFERENCE: JOB 1090CC3 Your question: "Please submit a schematic that indicates any & all component differences between the different models of lights from 9 to 32 Watts" Our answer: Pls see the file [FILE1= d:\ftproot\timcoupload\cathrin-345--8-12-2003-23148\Longstar PKCLS0305.zip (740796) ], check the schematic part again. 4.The expenses about this manner will remit money by telegraph in Aug 21. If you have any questions, pls send message to us as soon as possible. Thank you very much and best regards. Very truly yours, Cathrin.yin Audix Technology(Shanghai)Co.,LTD

F IGURE 1 E NERGY S AVING L AMP (M/N: FE-Z-3/5W) G ENERAL A PPEARANCE F IGURE 2 E NERGY S AVING L AMP (M/N: FE-Z-7W) G ENERAL A PPEARANCE F IGURE 3 E NERGY S AVING L AMP (M/N: FE-ZM-4W) G ENERAL A PPEARANCE F IGURE 4 E NERGY S AVING L AMP (M/N: FE-RSF-15W) G ENERAL A PPEARANCE F IGURE 5 E NERGY S AVING L AMP (M/N: FE-RSF-18W) G ENERAL A PPEARANCE F IGURE 6 E NERGY S AVING L AMP (M/N: FE-RSF-20W) G ENERAL A PPEARANCE F IGURE 7 E NERGY S AVING L AMP (M/N: FE-RSF-23W) G ENERAL A PPEARANCE F IGURE 8 E NERGY S AVING L AMP (M/N: FE-RSF-26W) G ENERAL A PPEARANCE F IGURE 9 E NERGY S AVING L AMP (M/N: FE-RSF-30W) G ENERAL A PPEARANCE F IGURE 10 E NERGY S AVING L AMP (M/N: FE-RSH-15W) G ENERAL A PPEARANCE F IGURE 11 E NERGY S AVING L AMP (M/N: FE-RSH-18W) G ENERAL A PPEARANCE F IGURE 12 E NERGY S AVING L AMP (M/N: FE-RSH-20W) G ENERAL A PPEARANCE F IGURE 13 E NERGY S AVING L AMP (M/N: FE-RSH-23W) G ENERAL A PPEARANCE F IGURE 14 E NERGY S AVING L AMP (M/N: FE-RSH-26W) G ENERAL A PPEARANCE F IGURE 15 E NERGY S AVING L AMP (M/N: FE-RSH-30W) G ENERAL A PPEARANCE F IGURE 16 E NERGY S AVING L AMP (M/N: FE-US-15W) G ENERAL A PPEARANCE F IGURE 17 E NERGY S AVING L AMP (M/N: FE-US-18W) G ENERAL A PPEARANCE F IGURE 18 E NERGY S AVING L AMP (M/N: FE-US-20W) G ENERAL A PPEARANCE F IGURE 19 E NERGY S AVING L AMP (M/N: FE-US-23W) G ENERAL A PPEARANCE F IGURE 20 E NERGY S AVING L AMP (M/N: FE-US-26W) G ENERAL A PPEARANCE F IGURE 21 E NERGY S AVING L AMP (M/N: FE-US-30W) G ENERAL A PPEARANCE F IGURE 22 E NERGY S AVING L AMP (M/N: FE- III -32W) G ENERAL A PPEARANCE F IGURE 23 E NERGY S AVING L AMP (M/N: FE- III -36W) G ENERAL A PPEARANCE F IGURE 24 E NERGY S AVING L AMP (M/N: FE- III -40W) G ENERAL A PPEARANCE F IGURE 25 E NERGY S AVING L AMP (M/N: FE- III -45W) G ENERAL A PPEARANCE F IGURE 26 E NERGY S AVING L AMP (M/N: FE- III -50W) G ENERAL A PPEARANCE F IGURE 27 E NERGY S AVING L AMP (M/N: FE- III S-32W) G ENERAL A PPEARANCE F IGURE 28 E NERGY S AVING L AMP (M/N: FE- III S-36W) G ENERAL A PPEARANCE F IGURE 29 E NERGY S AVING L AMP (M/N: FE- III S-40W) G ENERAL A PPEARANCE F IGURE 30 E NERGY S AVING L AMP (M/N: FE- III S-45W) G ENERAL A PPEARANCE F IGURE 31 E NERGY S AVING L AMP (M/N: FE- III S-50W) G ENERAL A PPEARANCE F IGURE 32 E NERGY S AVING L AMP (M/N: FE- III S-55W) G ENERAL A PPEARANCE

Label Location Information Refer to the below red arrow: (For example)

Label Drawing 1. For example: Note:The blue words will be replaced as follows for each model. Model (A) Label Model Label FE-Z-3W FE-Z-3W 120V 60Hz 50mA FE-Z-5W FE-Z-5W 120V 60Hz 80mA FE-Z-7W FE-Z-7W 120V 60Hz 115mA FE-ZM-4W FE-ZM-4W 120V 60Hz 75mA FE-RSF-15W FE-RSF-15W 120V 60Hz 230mA FE-RSF-18W FE-RSF-18W 120V 60Hz 280mA FE-RSF-20W FE-RSF-20W 120V 60Hz 320mA FE-RSF-23 W FE-RSF-23 W 120V 60Hz 360mA FE-RSF-26 W FE-RSF-26 W 120V 60Hz 400mA FE-RSF-30W FE-RSF-30W 120V 60Hz 460mA FE-RSH-15W FE-RSH-15W 120V 60Hz 230mA FE-RSH-18W FE-RSH-18W 120V 60Hz 280 mA FE-RSH-20W FE-RSH-20W 120V 60Hz 320 mA FE-RSH-23W FE-RSH-23W 120V 60Hz 360mA FE-RSH-26W FE-RSH-26W 120V 60Hz 400mA FE-RSH-30W FE-RSH-30W 120V 60Hz 460mA FE-US-15W FE-US-15W 120V 60Hz 230mA FE-US-18W FE-US-18W 120V 60Hz 280mA FE-US-20W FE-US-20W 120V 60Hz 320mA FE-US-23W FE-US-23W 120V 60Hz 360mA FE-US-26W FE-US-26W 120V 60Hz 400mA FE-US-30W FE-US-30W 120V 60Hz 460mA FE- III -32W FE- III -32W 120V 60Hz 520mA FE- III -36W FE- III -36W 120V 60Hz 540mA FE- III -40W FE- III -40W 120V 60Hz 600mA FE- III -45W FE- III -45W 120V 60Hz 680mA FE- III -50W FE- III -50W 120V 60Hz 760mA FE- III S-32W FE- III S-32W 120V 60Hz 520mA FE- III S-36W FE- III S-36W 120V 60Hz 540mA FE- III S-40W FE- III S-40W 120V 60Hz 600mA FE- III S-45W FE- III S-45W 120V 60Hz 680mA FE- III S-50W FE- III S-50W 120V 60Hz 760 mA FE- III S-55W FE- III S-55W 120V 60Hz 840mA LISTED Energy Saving Lamp FCC ID: PKCLS0304 FE-Z-3W 3W 120V 60Hz 50mA

Interpretation Common ground Different M/N FE-Z-3W FE-Z-5W FE-Z-7W FE-ZM-4W FE-RSF-15W FE-RSF-18W FE-RSF-20W FE-RSF-23W FE-RSF-26W FE-RSF-30W FE-RSH-15W FE-RSH-18W FE-RSH-20W FE-RSH-23W FE-RSH-26W FE-RSH-30W FE-US-15W FE-US-18W FE-US-20W FE-US-23W FE-US-26W FE-US-30W FE-III-32W FE-III-36W FE-III-40W FE-III-45W FE-III-50W FE-IIIS-32W FE-IIIS-36W FE-IIIS-40W FE-IIIS-50W FE-IIIS-55W They’re all tested. Only the blue script part is recorded. F IGURE 1 E NERGY S AVING L AMP (M/N: FE-Z-3/5W) C OVER R EMOVED 1 F IGURE 2 ENERGY SAVING LAMP (M/N: FE-Z-3/5W) COVER REMOVED 2 F IGURE 3 E NERGY S AVING L AMP (M/N: FE-Z-3/5W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 4 ENERGY SAVING LAMP (M/N: FE-Z-3/5W) MAIN BOARD (SOLDERED SIDE) F IGURE 5 E NERGY S AVING L AMP (M/N: FE-Z-7W) C OVER R EMOVED 1 F IGURE 6 E NERGY S AVING L AMP (M/N: FE-Z-7W) C OVER REMOVED 2 F IGURE 7 E NERGY S AVING L AMP (M/N: FE-Z-7W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 8 E NERGY S AVING L AMP (M/N: FE-Z-7W) M AIN BOARD (SOLDERED SIDE) F IGURE 9 E NERGY S AVING L AMP (M/N: FE-ZM-4W) C OVER R EMOVED 1 F IGURE 10 ENERGY SAVING LAMP (M/N: FE-ZM-4W) COVER REMOVED 2 F IGURE 11 E NERGY S AVING L AMP (M/N: FE-ZM-4W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 12 ENERGY SAVING LAMP (M/N: FE-ZM-4W) MAIN BOARD (SOLDERED SIDE) F IGURE 13 E NERGY S AVING L AMP (M/N: FE-RSF-15W) C OVER R EMOVED F IGURE 14 ENERGY SAVING LAMP (M/N: FE-RSF-15W) MAIN BOARD (COMPONENT SIDE) F IGURE 15 E NERGY S AVING L AMP (M/N: FE-RSF-15W) M AIN B OARD (S OLDERED S IDE ) F IGURE 16 ENERGY SAVING LAMP (M/N: FE-RSF-20W) COVER REMOVED 1 F IGURE 17 E NERGY S AVING L AMP (M/N: FE-RSF-20W) C OVER R EMOVED 2 F IGURE 18 ENERGY SAVING LAMP (M/N: FE-RSF-20W) MAIN BOARD (COMPONENT SIDE) F IGURE 19 E NERGY S AVING L AMP (M/N: FE-RSF-20W) M AIN B OARD (S OLDERED S IDE ) F IGURE 20 ENERGY SAVING LAMP (M/N: FE-RSF-30W) COVER REMOVED 1 F IGURE 21 E NERGY S AVING L AMP (M/N: FE-RSF-30W) C OVER R EMOVED 2 F IGURE 22 ENERGY SAVING LAMP (M/N: FE-RSF-30W) MAIN BOARD (COMPONENT SIDE) F IGURE 23 E NERGY S AVING L AMP (M/N: FE-RSF-30W) M AIN B OARD (S OLDERED S IDE ) F IGURE 24 ENERGY SAVING LAMP (M/N: FE-RSH-15W) COVER REMOVED 1 F IGURE 25 E NERGY S AVING L AMP (M/N: FE-RSH-15W) C OVER R EMOVED 2 F IGURE 26 ENERGY SAVING LAMP (M/N: FE-RSH-15W) MAIN BOARD (COMPONENT SIDE) F IGURE 27 E NERGY S AVING L AMP (M/N: FE-RSH-15W) M AIN B OARD (S OLDERED S IDE ) F IGURE 28 ENERGY SAVING LAMP (M/N: FE-RSH-20W) COVER REMOVED 1 F IGURE 29 E NERGY S AVING L AMP (M/N: FE-RSH-20W) C OVER R EMOVED 2 F IGURE 30 E NERGY S AVING L AMP (M/N: FE-RSH-20W) M AIN BOARD (COMPONENT SIDE) F IGURE 31 E NERGY S AVING L AMP (M/N: FE-RSH-20W) M AIN B OARD (S OLDERED S IDE ) FIGURE 32 E NERGY S AVING L AMP (M/N: FE-RSH-30W) C OVER REMOVED 1 F IGURE 33 E NERGY S AVING L AMP (M/N: FE-RSH-30W) C OVER R EMOVED 2 F IGURE 34 ENERGY SAVING LAMP (M/N: FE-RSH-30W) MAIN BOARD (COMPONENT SIDE) F IGURE 35 E NERGY S AVING L AMP (M/N: FE-RSH-30W) M AIN B OARD (S OLDERED S IDE ) F IGURE 36 ENERGY SAVING LAMP (M/N: FE-US-15W) COVER REMOVED F IGURE 37 E NERGY S AVING L AMP (M/N: FE-US-15W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 38 ENERGY SAVING LAMP (M/N: FE-US-15W) MAIN BOARD (SOLDERED SIDE) F IGURE 39 E NERGY S AVING L AMP (M/N: FE-US-20W) C OVER R EMOVED F IGURE 40 ENERGY SAVING LAMP (M/N: FE-US-20W) MAIN BOARD (COMPONENT SIDE) F IGURE 41 E NERGY S AVING L AMP (M/N: FE-US-20W) M AIN B OARD (S OLDERED S IDE ) F IGURE 42 ENERGY SAVING LAMP (M/N: FE-US-30W) COVER REMOVED F IGURE 43 E NERGY S AVING L AMP (M/N: FE-US-30W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 44 ENERGY SAVING LAMP (M/N: FE-US-30W) MAIN BOARD (SOLDERED SIDE) F IGURE 45 E NERGY S AVING L AMP (M/N: FE-III-32W) C OVER REMOVED F IGURE 46 ENERGY SAVING LAMP (M/N: FE-III-32W) M AIN BOARD (COMPONENT SIDE) F IGURE 47 ENERGY SAVING LAMP (M/N: FE-III-32W) M AIN B OARD (S OLDERED S IDE ) F IGURE 48 ENERGY SAVING LAMP (M/N: FE-III-40W) C OVER REMOVED F IGURE 49 E NERGY S AVING L AMP (M/N: FE-III-40W) M AIN BOARD (COMPONENT SIDE) F IGURE 50 E NERGY SAVING LAMP (M/N: FE-III-40W) M AIN B OARD (S OLDERED S IDE ) F IGURE 51 E NERGY S AVING L AMP (M/N: FE-III-50W) C OVER REMOVED F IGURE 52 E NERGY SAVING LAMP (M/N: FE-III-50W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 53 E NERGY S AVING L AMP (M/N: FE-III-50W) M AIN BOARD (SOLDERED SIDE) F IGURE 54 E NERGY SAVING LAMP (M/N: FE-IIIS-32W) C OVER R EMOVED F IGURE 55 E NERGY S AVING L AMP (M/N: FE-IIIS-32W) M AIN BOARD (COMPONENT SIDE) F IGURE 56 ENERGY SAVING LAMP (M/N: FE-IIIS-32W) M AIN BOARD (SOLDERED SIDE) F IGURE 57 E NERGY S AVING L AMP (M/N: FE-IIIS-40W) C OVER REMOVED F IGURE 58 ENERGY SAVING LAMP (M/N: FE-IIIS-40W) M AIN BOARD (COMPONENT SIDE) F IGURE 59 E NERGY S AVING L AMP (M/N: FE-IIIS-40W) M AIN BOARD (SOLDERED SIDE) F IGURE 60 ENERGY SAVING LAMP (M/N: FE-IIIS-55W) C OVER REMOVED F IGURE 61 E NERGY S AVING L AMP (M/N: FE-IIIS-55W) M AIN BOARD (COMPONENT SIDE) F IGURE 62 ENERGY SAVING LAMP (M/N: FE-IIIS-55W) M AIN BOARD (SOLDERED SIDE)

Schematics APPENDIX F ORM OF C OMPONENTS RATINGS COMPONENTS MODEL FE-ZM-4W FE-Z-3W FE-Z-5W FE-Z-7W 1 LAMP CAP E26 E26 E12 E12 E12 2 ELECTRICAL WIRE UL1569 1C*22AWG 1C*22AWG 1C*22AWG 1C*22AWG 3 PLASTIC PIECE PBT /GE 420SEO Ø32mm Ø32mm Ø32mm Ø32mm 4 CRYSTAL REVERBERATOR H=52.5mm,D=50mm Ø30mm H=57mm,D=35mm Ø31.0mm H=57mm,D=35mm Ø31.0mm H=57mm,D=35mm Ø31.0mm 5 LAMP TUBE 4W/Ø9.5 3W/Ø9.5 5W/Ø9.5 5W/Ø9.5 TOP SPIRAL Ø1.0mm Ø1.0mm Ø1.0mm Ø1.0mm 6 FILAMENT CASING PIPE 7 FUSE CASING PIPE Ø4.0mm Ø4.0mm Ø4.0mm Ø4.0mm 8 FU FUSE 1A/250VAC 1A/ 250VAC 1A/250VAC 1A/250VAC 9 PCB PCB BOARD WLD-60B WLD-60B WLD-60B WLD-60B 10 B RING MAGNET PCB T9*5*3 FR-9*5*4 FR-9*5*4 FR-9*5*4 11 D1-D4 DIODE FR-9*5*4 1A/1000V 1A/1000V 1A/ 1000V 1A/1000V 12 D5 DIODE 1N4007 1A/1000V 1A /1000V 1A/1000V 1A/1000V 13 D6 DIODE FR104 －－－－ －－－－ －－－－ －－－－ 14 D7 DIODE FR104 －－－－ －－－－ －－－－ －－－－ 15 D8, D9 DIODE FR104 －－－－ －－－－ －－－－ －－－－ RATINGS COMPONENTS MODEL FE-ZM-4W FE-Z-3W FE-Z-5W FE-Z-7W 16 DB3 TYIGGER DIODE DB3 DB3 DB3 DB3 DB3 17 R1, R2 RESISTOR 220K Ω 1/4W 220K Ω 1/4W 220K Ω 1/4W 220K Ω 1/4W 18 R3, R5 RESISTOR 10 Ω 1/4W 6.8 Ω 1/4W 10 Ω 1/4W 10 Ω 1/4W 19 R4, R6 RESISTOR －－－－ －－－－ －－－－ －－－－ 20 C0 CAPACITOR CL21 －－－－ －－－－ －－－－ －－－－ 21 C1 CAPACITOR CD11 4.7uF/200V 4.7uF/200V 4.7uF/ 200V 6.8uF/200V 22 C2 CAPACITOR CBB11 0.47nF/1200V 0.68nF/1200V 1nF/ 1200V 1.5nF/1200V 23 C3 CAPACITOR CL11 22nF/100V 22nF/100V 22nF/ 100V 22nF/100V 24 C4 CAPACITOR CL11 22nF/250V 22nF/250V 22nF/ 250V 22nF/250V 25 C5 CAPACITOR CBB11 1.5nF/1200V 1. 5nF/1200V 1.5nF/ 1200V 2.2nF/1200V 26 C6 CAPACITOR CBB11 1nF/1200V 1. 5nF/1200V 2.2nF/ 1200V 2.2nF/1200V 27 L MAGNETIC EE10 EE10 EE10 EE10 INDUCTANCE 28 L0 INDUCTANCE Ø6*8mm Ø6*8mm Ø6*8mm Ø6*8mm 29 T1, T2 TRANSISTOR 2482S 2482S 2482S 2482S RATINGS COMPONENTS MODEL FE-RSF-15W FE-RSF-18W FE-RSF-20W FE-RSF-23W FE-RSF-26W FE-RSF-30W 1 LAMP CAP E26 E26 E26 E26 E26 E26 E26 2 ELECTRICAL WIRE UL1569 1C*22AG 1C *22AG 1C*22AG 1C*22AG 1C*22AG 1C*22AG 3 PLASTIC PIECE PBT /GE 420SEO Ø42mm Ø42mm Ø42mm Ø48mm Ø48mm Ø48mm 4 CRYSTAL REVERBERATOR H=96 Ø49.4mm H=96 Ø49.4mm H=96 Ø49.4mm H=126 Ø57.5mm H=126 Ø57.5mm H=126 Ø57.5mm 5 LAMP TUBE H=37 Ø96mm H=37 Ø96mm H=37 Ø96mm H=46 Ø126mm H=46 Ø126mm H=46 Ø126mm TOP SPIRAL 15/Ø10.5 18/Ø10.5 20/Ø10.5 23/Ø12 26/Ø12 30/Ø12 6 FILAMENT CASING PIPE Ø1.0mm Ø1.0mm Ø1.0mm Ø1.0mm Ø1.0mm Ø1.0mm 7 FUSE CASING PIPE 8 FU FUSE Ø4.0mm Ø4.0mm Ø4.0mm Ø4.0mm Ø4.0mm Ø4.0mm 9 PCB PCB BOARD 2A/250VAC 2A/250VAC 2A /250VAC 2A/250VAC 2A/250VAC 2A/250VAC 10 B RING MAGNET PCB WLD-RS01 WLD-RS01 WLD-RS01 WLD-RS02 WLD-RS02 WLD-RS02 11 D1-D4 DIODE FR-9*5*4 FR-9*5*4 FR-9*5*4 FR-9*5*4 FR-9*5*4 FR-9*5*4 FR-9*5*4 12 D5 DIODE 1N4007 1A/1000V 1A/1000V 1A /1000V 1A/1000V 1A /1000V 1A/1000V 13 D6 DIODE FR104 1A/1000V 1A/1000V 1A /1000V 1A/1000V 1A /1000V 1A/1000V 14 D7 DIODE FR104 1A/1000V 1A/1000V 1A/1000V －－－－ －－－－ －－－－ 15 D8, D9 DIODE FR104 1A/1000V 1A/1000V －－－－ 1A/1000V 1A/ 1000V 1A/1000V RATINGS COMPONENTS MODEL FE-RSF-15W FE-RSF-18W FE-RSF-20W FE-RSF-23W FE-RSF-26W FE-RSF-30W 16 DB3 TRIGGER DIODE DB3 DB3 DB3 DB3 DB3 DB3 DB3 17 R1 RESISTOR －－－－ －－－－ －－－－ －－－－ 220K Ω 1/4W －－－－ 18 R2 RESISTOR 220K Ω 1/4W 220K Ω 1/4W 220K Ω 1/4W 220K Ω 1/4W 220K Ω 1/4W 220K Ω 1/4W 19 R7, R8 RESISTOR 220K Ω 1/4W 220K Ω 1/4W 220K Ω 1/4W 220K Ω 1/4W －－－－ 220K Ω 1/4W 20 R3, R5 RESISTOR 10 Ω 1/4W 10 Ω 1/4W 15 Ω 1/4W 20 Ω 1/4W 15 Ω 1/4W 20 Ω 1/4W 21 R4, R6 RESISTOR 1 Ω 1/4W 1 Ω 1/4W 1 Ω 1/4W 1 Ω 1/4W 1 Ω 1/4W 0.5 Ω 1/4W 22 C0 CAPACITOR CL21 100nF/250V 100nF/250V 220nF/250V 220nF/250V 330nF/250V 330nF/250V 23 C1 CAPACITOR CD11 22uF/200V 22uF/200V 22uF/200V 33uF/200V 33uF/200V 47uF/200V 24 C2 CAPACITOR CBB11 1nF/1200V 1nF/1200V 0. 47nF/1200V 1nF/1200V 0. 68nF/1200V 0.68nF/1200V 25 C3 CAPACITOR CL11 22nF/100V 22nF/100V 22nF/100V 22nF/100V 22nF/100V 22nF/100V 26 C4 CAPACITOR CL11 47nF/250V 47nF/250V 47nF/250V 47nF/250V 47nF/250V 47nF/250V 27 C5 CAPACITOR CBB11 4.0nF/1200V 4.0nF/1200V 3.3nF/ 1200V 4.7nF/1200V 4.7nF /1200V 4.7nF/1200V 28 C6 CAPACITOR CBB11 2.2nF/ 1200V 2.2nF/1200V 2. 7nF/1200V 4nF/1200V 4nF/1200V 4nF/1200V 29 L MAGNETIC EE16 EE16 EE16 EE19 EE19 EE19 INDUCTANCE 30 L0 INDUCTANCE Ø8*10mm Ø8*10mm Ø8*10mm Ø8*10mm Ø8*10mm Ø8*10mm 31 T1, T2 TRANSISTOR 13003 13003 13003 3DD128F 3DD128F 3DD128F RATINGS COMPONENTS MODEL FE-RSH-15W FE-RSH-18W FE-RSH-20W FE-RSH-23W FE-RSH-26W FE-RSH-30W 1 LAMP CAP E26 E26 E26 E26 E26 E26 E26 2 ELECTRICAL WIRE UL1569 1C*22AG 1C *22AG 1C*22AG 1C*22AG 1C*22AG 1C*22AG 3 PLASTIC PIECE PBT /GE 420SEO Ø42mm Ø42mm Ø42mm Ø48mm Ø48mm Ø48mm 4 CRYSTAL REVERBERATOR H=96 Ø49.4mm H=96 Ø49.4mm H=96 Ø49.4mm H=126 Ø57.5mm H=126 Ø57.5mm H=126 Ø57.5mm 5 LAMP TUBE 15/Ø10.5 18/Ø 10.5 20/Ø10.5 23/Ø 12 26/Ø12 30/Ø12 TOP SPIRAL Ø1.0mm Ø1.0mm Ø1.0mm Ø1.0mm Ø1.0mm Ø1.0mm 6 FILAMENT CASING PIPE 7 FUSE CASING PIPE Ø4.0mm Ø4.0mm Ø4.0mm Ø4.0mm Ø4.0mm Ø4.0mm 8 FU FUSE 2A/250VAC 2A/250VAC 2A/ 250VAC 2A/250VAC 2A/250VAC 2A/250VAC 9 PCB PCB BOARD WLD-RS01 WLD-RS01 WLD-RS01 WLD-RS02 WLD-RS02 WLD-RS02 10 B RING MAGNET PCB FR-9*5*4 FR-9*5*4 FR-9*5*4 FR-9*5*4 FR-9*5*4 FR-9*5*4 11 D1-D4 DIODE FR-9*5*4 1A/1000V 1A/1000V 1A/1000V 1A/1000V 1A/1000V 1A/1000V 12 D5 DIODE 1N4007 1A/1000V 1A/1000V 1A /1000V 1A/1000V 1A /1000V 1A/1000V 13 D6 DIODE FR104 1A/1000V 1A/1000V 1A /1000V 1A/1000V 1A /1000V 1A/1000V 14 D7 DIODE FR104 1A/1000V 1A/1000V 1A/1000V －－－－ －－－－ －－－－ 15 D8, D9 DIODE FR104 1A/1000V 1A/1000V －－－－ 1A/1000V 1A/ 1000V 1A/1000V RATINGS COMPONENTS MODEL FE-RSH-15W FE-RSH-18W FE-RSH-20W FE-RSH-23W FE-RSH-26W FE-RSH-30W 16 DB3 TRIGGER DIODE DB3 DB3 DB3 DB3 DB3 DB3 DB3 17 R1 RESISTOR －－－－ －－－－ －－－－ －－－－ 220K Ω 1/4W －－－－ 18 R2 RESISTOR 220K Ω 1/4W 220K Ω 1/4W 220K Ω 1/4W 220K Ω 1/4W 220K Ω 1/4W 220K Ω 1/4W 19 R7, R8 RESISTOR 220K Ω 1/4W 220K Ω 1/4W 220K Ω 1/4W 220K Ω 1/4W －－－－ 220K Ω 1/4W 20 R3, R5 RESISTOR 10 Ω 1/4W 10 Ω 1/4W 15 Ω 1/4W 20 Ω 1/4W 15 Ω 1/4W 20 Ω 1/4W 21 R4, R6 RESISTOR 1 Ω 1/4W 1 Ω 1/4W 1 Ω 1/4W 1 Ω 1/4W 1 Ω 1/4W 0.5 Ω 1/4W 22 C0 CAPACITOR CL21 100nF/250V 100nF/250V 220nF/250V 220nF/250V 330nF/250V 330nF/250V 23 C1 CAPACITOR CD11 22uF/200V …

Text truncated - open the document above for the full version.

Xiamen Longstar Lighting Co., Ltd. FCC ID: PKCLS0304 Page 1 of 38 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F03044 Application for FCC Certificate On Behalf of Xiamen Longstar Lighting Co., Ltd. Energy Saving Lamp FCC ID: PKCLS0304 Prepared For : Xiamen Longstar Lighting Co., Ltd. Chengnan Industrial Zone, Tongan, Xiamen, China 361100 Prepared By : Audix Technology (Shanghai) Co., Ltd. 3 F, 34 Bldg, 680 Guiping Rd, Caohejing Hi-Tech Park, Shanghai, China 200233 Tel : +86-21-64955500 Fax : +86-21-64955491 Report No. : ACI-F03044 Date of Test : Apr 01-Jun 09, 2003 Date of Report : Jun 20, 2003 Model No.: FE-Z-3W FE-Z-5W FE-Z-7W FE-ZM-4W FE-RSF-15W FE-RSF-18W FE-RSF-20W FE-RSF-23W FE-RSF-26W FE-RSF-30W FE-RSH-15W FE-RSH-18W FE-RSH-20W FE-RSH-23W FE-RSH-26W FE-RSH-30W FE-US-15W FE-US-18W FE-US-20W FE-US-23W FE-US-26W FE-US-30W FE-III-32W FE-III-36W FE-III-40W FE-III-45W FE-III-50W FE-IIIS-32W FE-IIIS-36W FE-IIIS-40W FE-IIIS-45W FE-IIIS-50W FE-IIIS-55W Xiamen Longstar Lighting Co., Ltd. FCC ID: PKCLS0304 Page 2 of 38 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F03044 TABLE OF CONTENTS Page 1 GENERAL INFORMATION.......................................................................................................... 4 1.1 Description of Equipment Under Test........................................................................................4 1.2 Description of Test Facility ........................................................................................................ 5 1.3 Measurement Uncertainty .......................................................................................................... 5 2 AC POWERLINE CONDUCTED EMISSION TEST ................................................................. 6 2.1 Test Equipment........................................................................................................................... 6 2.2 Block Diagram of Test Setup ..................................................................................................... 6 2.3 Conducted Emission Limits ....................................................................................................... 6 2.4 EUT Configuration on Test ........................................................................................................ 7 2.5 Operating Condition of EUT ...................................................................................................... 7 2.6 Test Procedures .......................................................................................................................... 7 2.7 Test Results ................................................................................................................................ 7 3 MAGNETIC FIELD EMISSION TEST ...................................................................................... 18 3.1 Test Equipment......................................................................................................................... 18 3.2 Block Diagram of Test Setup ................................................................................................... 18 3.3 Magnetic Field Emission Limit ................................................................................................ 18 3.4 EUT Configuration on Test ...................................................................................................... 18 3.5 Operating Condition of EUT .................................................................................................... 19 3.6 Test Procedures ........................................................................................................................ 19 3.7 Test Results .............................................................................................................................. 19 Xiamen Longstar Lighting Co., Ltd. FCC ID: PKCLS0304 Page 3 of 38 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F03044 TEST REPORT FOR FCC CERTIFICATE Applicant : Xiamen Longstar Lighting Co., Ltd. Manufacturer : Xiamen Longstar Lighting Co., Ltd. EUT Description : Energy Saving Lamp (A) Model No.: FE-Z-3W, FE-Z-5W, FE-Z-7W, FE-ZM-4W, FE-RSF-15W, FE-RSF-18W, FE-RSF-20W, FE-RSF-23W, FE-RSF-26W, FE-RSF-30W, FE-RSH-15W, FE-RSH-18W, FE-RSH-20W, FE-RSH-23W, FE-RSH-26W, FE-RSH-30W, FE-US-15W, FE-US-18W, FE-US-20W, FE-US-23W, FE-US-26W, FE-US-30W, FE-III-32W, FE-III-36W, FE-III-40W, FE-III-45W, FE-III-50W, FE-IIIS-32W,, FE-IIIS-36W, FE-IIIS-40W, FE-IIIS-45W, FE-IIIS-50W, FE-IIIS-55W, (B) Power Supply: 120V/60Hz Test Procedure Used: FCC RULES AND REGULATIONS PART 18 CONSUMER DEVICES (2002.10) AND MP-5/1986 The device described above is tested by Audix Technology (Shanghai) Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 18 RF Lighting Device limits both conducted emissions and field strength. The test results are contained in this test report and Audix Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT to be technically compliant with the FCC official limits. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shanghai) Co., Ltd. This report must not be used by the applicant to claim product endorsement by NVLAP or any agency of the U.S. Government. Date of Test : Apr 01-Jun 09, 2003 Prepared by : Test Engineer : CATHRIN YIN (Assistant) SOLON GONG (Engineer) Reviewer : Approved Signatory : SAMMY CHEN (Engineer) BYRON KWO (Assistant Manager) Xiamen Longstar Lighting Co., Ltd. FCC ID: PKCLS0304 Page 4 of 38 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F03044 1 GENERAL INFORMATION 1.1 Description of Equipment Under Test Description : Energy Saving Lamp Type of EUT : ; Production … Pre-product … Pro-type Model Number : FE-Z-3W, FE-Z-5W, FE-Z-7…

Text truncated - open the document above for the full version.

Test Set-Up Photos 1. Conducted Emission Test (M/N: FE-Z SERIES) (M/N: FE-ZM-4W) (M/N: FE-RSF SERIES) (M/N: FE-RSH SERIES) (M/N: FE-US SERIES) (M/N: FE-III SERIES) (M/N: FE-IIIS SERIES) 2. Field strength Test (M/N: FE-Z SERIES) (M/N: FE-ZM-4W) (M/N: FE-RSF SERIES) (M/N: FE-RSH SERIES) (M/N: FE-US SERIES) (M/N: FE- III SERIES) (M/N: FE-IIIS SERIES)
