PKNCM-198NOptical 2.4GHz Wireless Mouse

PID #: 111585/86-109283 Rev. 140429 Optical 2.4GHz Wireless Mouse Model #: OM4750W, OM6750W CM-198 User Manual 2 3 All brand name and trademarks are the property of their respective companies Mac and Mac OS X are registered trademarks of Apple Inc. Windows, Windows XP, Windows Vista, Windows 7 and Windows 8 are registered trademarks of Microsoft Corporation in the United States and/or other countries. USER’S RECORD: To provide quality customer service and technical support, it is suggested that you keep the following information as well as your store receipt and this user’s manual. Date of Purchase: ________________________________ Model Number: ________________________________ Product Rev Number (located below the UPC on the package): ____________________ FCC RADIATION NORM: FCC This equipment has been tested and found to comply with limits for Class B digital device pursuant to Part 15 of Federal Communications Commission (FCC) rules. FCC Compliance Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. FCC Statement This device complies with FCC radiation exposure limits set forth for an uncontrolled environment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 4 CAUTION! Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment 5 PACKAGE CONTENTS: Your new Wireless Optical Mouse will ship with the following items. - Optical Wireless Mouse - Nano Receiver - 2 AAA Batteries - User Manual - Warranty Information SYSTEM REQUIREMENTS: Please be sure that you meet all of the system requirements below to avoid difficulties during installation Compatible with: PCs, Mac ® computers, and Chromebook™ notebook computers Works with: - Windows ® XP, Windows ® Vista ,Windows ® 7 and Windows ® 8 operating systems - Mac OS X ® 10.3 and above - An available USB port 6 INSTALLING BATTERIES: To properly install batteries into your Mouse, please follow the instructions below: 1. Open the Battery Compartment Cover. 2. Install two AA Batteries into your Mouse following the battery orientation guide in the battery bay and then close the Battery Compartment Cover back onto your Mouse. 3. Turn on the switch on the bottom, and your mouse is now ready to use. 7 INSTALLATION: For All Operating Systems 1. Make sure you have successfully installed the Batteries into your Mouse, refer to the Installing Batteries section in this manual if necessary. 2. Turn on your computer, plug the enclosed Nano Receiver into an available USB port on your computer. (TIP: If you are not able to find an available USB port on your computer, please refer to the user’s manual of your computer for more help.) 3. Your mouse will connect to the receiver automatically within 30 seconds. MOUSE DESCRIPTION: Scroll Wheel Page Backward Page Forward DPI Switch Button Left Click Right Click 8 CHANGING THE SPEED OF YOUR MOUSE: To the speed of the cursor or the scroll button features on your computer, please follow the instructions below: NOTE: The screenshots show in this section are for demonstration only and your screen may look slightly different but with similar options. For Windows ® Open the “Control Panel”, and double-click the “Mouse” icon to open the mouse properties screen, and then select the “Pointer Options”. After you have made your changes; select “Apply”, and then “OK”. For Mac ® Open the “System Preferences”. At the System Preferences screen, click the “Keyboard & Mouse” icon to open the Keyboard & Mouse screen, and then select the “Mouse” tab and make your changes. Windows ® Mac ® 9 WARRANTY INFORMATION: WARRANTY INFORMATION: Gear Head, LLC warrants that this product shall be free from defects in materials and workmanship for the reasonable lifetime of the product. If the product is defective, Gear Head, LLC’s sole obligation under this warranty shall be at its election, subject to the terms of this warranty, to repair or replace any parts deemed defective. This warranty is for the exclusive benefit of the original purchaser and is not assignable or transferable. THIS WARRANTY IS MADE IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, AND ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO THE TERMS OF THIS WARRANTY, UNLESS OTHERWISE PROHIBITED BY LAW. Exclusions To the fullest extent permitted by law, Gear Head, LLC expressly disclaims and excludes from this warranty any liability for damages, including but not limited to general, special, indirect, incidental, consequential, aggravated, punitive or exemplary damages, and economic loss (even if Gear Head™ is informed of their possibility), third party claims against you, including for an…

Text truncated - open the document above for the full version.

RV-0000000 Project No.: 1407C004 Page 2 of 6 RV-0000000 Project No.: 1407C004 Page 3 of 6

ODEHOORFDWLRQ

RV-0000000 Project No.: 1407C004 Page 4 of 6 RV-0000000 Project No.: 1407C004 Page 5 of 6 RV-0000000 Project No.: 1407C004 Page 6 of 6

Report No.: NEI-FCCP-1-1407C004 Page 1 of 54 FCC&IC Radio Test Report FCC ID: PKNCM-198N This report concerns (check one): Original Grant Class II Change Project No. : 1407C004 Equipment : Optical 2.4GHz Wireless Mouse Model Name : CM-198;OM4750W;OM6750W Applicant : ZhuoHeng Electronic Co.,Ltd Address : No.8 ,Lane 5 , ShangNan Road .The 5th Industrial Area,NanCe, HuMen Town ,DongGuan City,China. Date of Receipt : Jun. 30, 2014 Date of Test : Jun. 30, 2014 ~ Jul. 16, 2014 Issued Date : Jul. 17, 2014 Tested by : BTL Inc. Testing Engineer : (David Mao) Technical Manager : (Leo Hung) Authorized Signatory : (Steven Lu) BTL INC. No.3, Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, China. TEL: +86-769-8318-3000 FAX: +86-769-8319-6000 Report No.: NEI-FCCP-1-1407C004 Page 2 of 54 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. BTL’s reports must not be used by the client to claim product endorsement by the authorities or an y agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and BTL-self, extracts from the test report shall not be reproduced except in full with BTL’s authorized written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Report No.: NEI-FCCP-1-1407C004 Page 3 of 54 Table of Contents Page 1 . CERTIFICATION 6 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 3 . GENERAL INFORMATION 9 3.1 GENERAL DESCRIPTION OF EUT 9 3.2 DESCRIPTION OF TEST MODES 10 3.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 3.4 DESCRIPTION OF SUPPORT UNITS 11 4 . EMC EMISSION TEST 12 4.1 RADIATED EMISSION MEASUREMENT 12 4.1.1 RADIATED EMISSION LIMITS 12 4.1.2 TEST PROCEDURE 13 4.1.3 DEVIATION FROM TEST STANDARD 13 4.1.4 TEST SETUP 14 4.1.5 EUT OPERATING CONDITIONS 15 4.1.6 EUT TEST CONDITIONS 15 4.1.7 TEST RESULTS (BELOW 30MHz) 15 4.1.8 TEST RESULTS (BETWEEN 30 – 1000 MHz) 15 4.1.9 TEST RESULTS (ABOVE 1000 MHz) 16 5 . BANDWIDTH TEST 17 5.1 TEST PROCEDURE 17 5.2 DEVIATION FROM STANDARD 17 5.3 TEST SETUP 17 5.4 EUT OPERATION CONDITIONS 17 5.5 EUT TEST CONDITIONS 17 5.6 TEST RESULTS 17 6 . ANTENNA CONDUCTED SPURIOUS EMISSION 18 6.1 APPLIED PROCEDURES / LIMIT 18 6.2 TEST PROCEDURE 18 6.3 DEVIATION FROM STANDARD 18 6.4 TEST SETUP 18 6.5 EUT OPERATION CONDITIONS 19 6.6 EUT TEST CONDITIONS 19 6.7 TEST RESULTS 19 7 . MEASUREMENT INSTRUMENTS LIST AND SETTING 20 Report No.: NEI-FCCP-1-1407C004 Page 4 of 54 Table of Contents Page 8 . EUT TEST PHOTO 21 ATTACHMENT A - RADIATED EMISSION (9KHZ to 30MHZ) 24 ATTACHMENT B - RADIATED EMISSION (30MHZ TO 1000MHZ) 26 ATTACHMENT C - RADIATED EMISSION (ABOVE 1000MHZ) 33 ATTACHMENT D - BANDWIDTH 46 ATTACHMENT E - ANTENNA CONDUCTED SPURIOUS EMISSION 49 Report No.: NEI-FCCP-1-1407C004 Page 5 of 54 REPORT ISSUED HISTORY Issued No. Description Issued Date NEI-FCCP-1-1407C004 Original Issue. Jul. 17, 2014 Report No.: NEI-FCCP-1-1407C004 Page 6 of 54 1. CERTIFICATION Equipment : Optical 2.4GHz Wireless Mouse Brand Name : N/A Model Name : CM-198;OM4750W;OM6750W Applicant : ZhuoHeng Electronic Co.,Ltd Manufacturer : YiBang Electronic Technology Co.,Ltd Address : No.8 ,Lane 5 , ShangNan Road .The 5th Industrial Area,NanCe, HuMen Town ,DongGuan City,China. Factory : YiBang Electronic Technology Co.,Ltd Address : No.8 ,Lane 5 , ShangNan Road .The 5th Industrial Area,NanCe, HuMen Town ,DongGuan City,China. Date of Test : Jun. 30, 2014 ~ Jul. 16, 2014 Test Sample : Engineering Sample Standard(s) : FCC Part15, Subpart C(15.249)/ ANSI C63.4-2009 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1407C004) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical standard(s). Report No.: NEI-FCCP-1-1407C004 Page 7 of 54 2. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC Part15, Subpart C (15.249) StandardSection Test Item Judgment Remark FCC 15.207 Conducted Emission N/A 15.209 15.249 Radiated Spurious Emission PASS NOTE: (1)”N/A” denotes test is not applicable in this test report. Report No.: NEI-FCCP-1-1407C004 Page 8 of 54 2.1 TEST FACILITY The test facilities used to collect the test data in this report is DG-C02/DG-CB03 at the location of No.3,Jinshagang 1st Road, ShiXia, Dalang Town,Dong Guan, China.523792 BTL's test firm number for FCC: 319330 2.2 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2: The reported uncertainty of measurement y ± U,where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2,providing a level of confidence of approximately 95 %. A. Conducted Measur…

Text truncated - open the document above for the full version.

Report No.: NEI-FCCP-1-1407C004 Page 23 of 56 8. EUT TEST PHOTO Radiated Measurement Photos 9K~30MHz Report No.: NEI-FCCP-1-1407C004 Page 24 of 56 Radiated Measurement Photos 30~1000MHz Report No.: NEI-FCCP-1-1407C004 Page 25 of 56 Radiated Measurement Photos Above 1GHz
