PLE-GA-9700B15Watt Fast Charger



C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Gigastone Corp. FRN: 0022062988 Grantee code: PLE FCC ID: PLE-GA-9700B Contact Name: Kristie Chang Address: 4F., No. 166, Xinhu 2nd Rd., Neihu Dist., Taipei City 114, Taiwan (R.O.C.) Telephone No: +886-2-2658-2588 Fax No: / Email: [email protected] i. [Gigastone Corp.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Gigastone Corp.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. Gigastone Corp. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Date: 07.29.2024 Applicant’s Name: Kristie Chang Title: Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

CFR 47 §2.911 (d)(7) Agent Designation Attestation To: Federal Communications Commissio Date: 07-26-20234 FCC ID: PLE-GA-9700B FRN:0022062988 n 7435 Oakland Mills Road Columbia, MD 21046 Gigastone Corp.(“the applicant”) as required by section 2.911(d)(7), designates the following agent, located in the United States, for purposes of acting as the applicant’s agent for service of process. The applicant acknowledges that they will maintain an agent for no less than one year after the grantee has terminated all market ing and importation or the conclusion of any Commission- related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the agent information changes. U. S. Agent Information: James He Oasis Compliance, Inc. 3313 Verdi Dr, San Jose, CA 95111 [email protected] FRN: 0033464157 cell:2026028330 Sincerely yours, Kristie Chang Manager Gigastone Corp. Address: 4F., No. 166, Xinhu 2nd Rd., Neihu Dist., Taipei City 114, Taiwan (R.O.C.) Email: [email protected] Phone: +886-2-2658-2588

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Gigastone Corp. Address: 4F., No. 166, Xinhu 2nd Rd., Neihu Dist., Taipei City 114, Taiwan (R.O.C.) Product Name: 15Watt Fast Charger Model Number: GA-9700 FCC Identifier: PLE-GA-9700B We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take act ion on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Kristie Chang Date: 8/9/2024 Title: Manager Signature of applicant:

C5266091_X10_Ed.2 1/1 Gigastone Corp. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 8/9/2024 Subject: Request for Confidentiality FCC ID: PLE-GA-9700B To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name: Kristie Chang Title: Manager

Page 1 of 4 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Photographs of the EUT (External Photos) Model: GA-9700 Page 2 of 4 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Page 3 of 4 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Page 4 of 4 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected]

41.5X5.28mm 38.68mm

Page 1 of 4 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Photographs of the EUT (Internal Photos) Model: GA-9700 Page 2 of 4 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Coil Page 3 of 4 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected] Page 4 of 4 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: 0755-88850135-1439 Mobile: 131-4343-1439 (Wechat same number) Web: http://www.mtitest.cn E-mail: [email protected]

Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] Test Report Report No.: MTi240604006-01E2 Date of issue: 2024-07-24 Applicant: Gigastone Corp. Product: 15Watt Fast Charger Model(s): GA-9700 FCC ID: PLE-GA-9700B Shenzhen Microtest Co., Ltd. http:// Web: www.mtitest.cn Page 2 of 13 Report No.: MTi240604006-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] Instructions 1. This test report shall not be partially reproduced without the written consent of the laboratory. 2. The test results in this test report are only responsible for the samples submitted 3. This test report is invalid without the seal and signature of the laboratory. 4. This test report is invalid if transferred, altered, or tampered with in any form without authorization. 5. Any objection to this test report shall be submitted to the laboratory within 15 days from the date of receipt of the report. Page 3 of 13 Report No.: MTi240604006-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] Contents 1 General Description ........................................................................................................................ 5 1.1 Description of the EUT ....................................................................................................................................... 5 1.2 Description of test modes ................................................................................................................................... 5 1.3 Description of support units ................................................................................................................................ 6 2 Measurement uncertainty ............................................................................................................... 6 3 Test facilities and accreditations .................................................................................................... 7 3.1 Test laboratory .................................................................................................................................................... 7 4 List of test equipment ..................................................................................................................... 8 5 Test result ........................................................................................................................................ 9 5.2 Test setup ......................................................................................................................................................... 10 5.3 Test Procedures ................................................................................................................................................ 10 5.4 Information of test equipment ........................................................................................................................... 11 5.5 Test results ....................................................................................................................................................... 12 Photographs of the Test Setup ............................................................................................................ 13 Photographs of the EUT....................................................................................................................... 13 Page 4 of 13 Report No.: MTi240604006-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] Test Result Certification Applicant: Gigastone Corp. Address: 4F., No. 166, Xinhu 2nd Rd., Neihu Dist., Taipei City 114, Taiwan (R.O.C.) Manufacturer: Gigastone Corp. Address: 4F., No. 166, Xinhu 2nd Rd., Neihu Dist., Taipei City 114, Taiwan (R.O.C.) Product description Product name: 15Watt Fast Charger Trademark: GIGASTONE Model name: GA-9700 Series Model: N/A Standards: CFR 47 PART 1, § 1.1310 Test method: KDB 680106 D01 Wireless Power Transfer v04 Date of Test Date of test: 2024-06-29 to 2024-07-03 Test result: Pass Test Engineer : (Yanice.Xie) Reviewed By : (David Lee) Approved By : (Leon Chen) Page 5 of 13 Report No.: MTi240604006-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] 1 General Description 1.1 Description of the EUT Product name: 15Watt Fast Charger Model name: GA-9700 Series Model: N/A Model difference: N/A Electrical rating: Input:DC 5V/2A,9V/2A,12V/1.5A Output:DC 5V/1A~1.5A, 9V/1.67A, 12V/1.25A(Max 15Watt) Accessories: Cable:USB-A to Type-C 1.5m Hardware version: LZX37-1501-V1 Software version: XCUUO Test sample(s) number: MTi240604006-01S1001 RF specification: Operation frequency: 111-205kHz Modulation type: ASK Antenna type: Coil Antenna 1.2 Description of test modes All the test modes were carried out with the EUT in normal operation, the final test mode of the EUT was the worst test mode for emission test, which was shown in this report and defined as: No. Emission test modes Mode1 Wireless Output(5W) Mode2 Wireless Output(7.5W) Mode3 Wireless Output(10W) Mode4 Wireless Output(15W) Mode5 Stand by Page 6 of 13 Report No.: MTi240604006-01…

Text truncated - open the document above for the full version.

The test report is only used for customer scientific research, teaching, internal quality control and other purposes, and is for internal reference only. Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] Test Report Report No.: MTi240621004-01E1 Date of issue: 2024-07-24 Applicant: Gigastone Corp. Product name: 15Watt Fast Charger Model(s): GA-9700 FCC ID: PLE-GA-9700B Shenzhen Microtest Co., Ltd. http://www.mtitest.cn Page 2 of 24 Report No.: MTi240621004-01E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] Instructions 1. This test report shall not be partially reproduced without the written consent of the laboratory. 2. The test results in this test report are only responsible for the samples submitted 3. This test report is invalid without the seal and signature of the laboratory. 4. This test report is invalid if transferred, altered, or tampered with in any form without authorization. 5. Any objection to this test report shall be submitted to the laboratory within 15 days from the date of receipt of the report. Page 3 of 24 Report No.: MTi240621004-01E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] Table of contents 1 General Description ......................................................................................................................... 5 1.1 Description of the EUT ............................................................................................................................... 5 1.2 Description of test modes .......................................................................................................................... 5 1.3 Environmental Conditions .......................................................................................................................... 6 1.4 Description of support units ....................................................................................................................... 6 1.5 Measurement uncertainty .......................................................................................................................... 6 2 Summary of Test Result .................................................................................................................. 7 3 Test Facilities and accreditations ................................................................................................... 8 3.1 Test laboratory ........................................................................................................................................... 8 4 List of test equipment ...................................................................................................................... 9 5 Evaluation Results (Evaluation) .................................................................................................... 10 5.1 Antenna requirement ............................................................................................................................... 10 6 Radio Spectrum Matter Test Results (RF) .................................................................................... 11 6.1 Conducted Emission at AC power line .................................................................................................... 11 6.2 20dB Occupied Bandwidth ...................................................................................................................... 14 6.3 Emissions in frequency bands (below 30MHz)........................................................................................ 17 6.4 Emissions in frequency bands (30MHz - 1GHz)...................................................................................... 20 Photographs of the test setup ............................................................................................................. 23 Photographs of the EUT....................................................................................................................... 24 Page 4 of 24 Report No.: MTi240621004-01E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] Test Result Certification Applicant: Gigastone Corp. Address: 4F., No. 166, Xinhu 2nd Rd., Neihu Dist., Taipei City 114, Taiwan (R.O.C.) Manufacturer: Gigastone Corp. Address: 4F., No. 166, Xinhu 2nd Rd., Neihu Dist., Taipei City 114, Taiwan (R.O.C.) Product description Product name: 15Watt Fast Charger Trademark: GIGASTONE Model name: GA-9700 Series Model(s): N/A Standards: CFR 47 Part 15C Test Method: ANSI C63.10-2013 Date of Test Date of test: 2024-06-29 to 2024-07-03 Test result: Pass Test Engineer : (Yanice.Xie) Reviewed By : (David Lee) Approved By : (Leon Chen) Page 5 of 24 Report No.: MTi240621004-01E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] 1 General Description 1.1 Description of the EUT Product name: 15Watt Fast Charger Model name: GA-9700 Series Model(s): N/A Model difference: N/A Electrical rating: Input:DC 5V/2A,9V/2A,12V/1.5A Output:DC 5V/1A~1.5A, 9V/1.67A, 12V/1.25A(Max 15Watt) Accessories: Cable:USB-A to Type-C 1.5m Hardware version: LZX37-1501-V…

Text truncated - open the document above for the full version.

兴宁市沐坚旺电子科技有限公司 第 1 页共 3 页 SPECIFICATIONFORAPPROVAL 产品规格承认书 CUSTOMER ： (客户名称） CUSTOMERP/N: (客户型号) A11 DESCRIPTION/SPEC: (品名/规格)TXA11无线充发射线圈模组 PARTNUMBER: (产品编号) SAMPLEDATE: (送样日期) APPROVALSIGNATURE(供应商承认签章) 制作检查审核 谢新香梅路萍张志强 APPROVALSIGNATURE(客户承认签章) 日期 XingningMujianwangElectronicTechnologyCo.,Ltd Add：No.839GuanshanFourthRoad,NingxinStreet,XingningCity, GuangdongProvince,China Mobile:13528703607 E-mail：[email protected] 兴宁市沐坚旺电子科技有限公司 第 2 页共 3 页 变更记录 版本变更内容日期 A新版文件 2023/012/29 兴宁市沐坚旺电子科技有限公司 第 3 页 共 3 页 1. DIMENSIONS& MARKING(UNIT:mm): 备注： 1.1. High temperatureadhesivetape: Brown7mm wide； 1.2. Doublesided adhesivesize : 48*6*0.08mm 2. SCHEMATICS: 3.WINDINGINSTRUCTION& DESCTIPTION: 序号 No. 起头 S 收尾 F 圈数 TURNS 漆包线 WIRE 高温胶带 HIGH TEMPERATURE TAPE 绕线方式 WINDING DIRECTION L1SF 10 T 1 层 丙酮丝包线 0.08*105P 7mm TYP 反绕 4. ELECTRICALSPECIFICATIONS@25°C： 4.1. OCL ：S-F=6.5uH±10% @1 00 KHz/1V; 4.2.DCR：S-F =35m ΩMax 项目规格 A50.0±1.0 B42.0±1.0 C20.5±0.5 D5.3±0.5 E8±1.5 F 3.0±1.5 G 10.0 TYP H 2.8 MAX （不含离型纸厚度） I 1.0±0.1 （不含离型纸厚度） Φ0.08*105P*10TS

Page 1 of 2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] Photographs of the test setup Model: GA-9700 Conducted Emission at AC power line Radiated Emissions (below 30MHz) Page 2 of 2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755) 88850135-1349 Fax: (86-755) 88850136 Web: http://www.mtitest.cn E-mail: [email protected] Radiated Emissions (30MHz - 1GHz) MPE
