PLNBONTEC-003Transmitter Keyless

C:\WINDOWS\TEMP\probonholdemail.doc TIMCO TIMCOTIMCO TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: tei@t imcoengr.com 30 April 2001 FCC SUBJECT: BONTEC CO., LTD. FCC ID: PLNBONTEC-003 To Whom It May Concern: In the original application the test laboratory did not include any data about the bandwidth of the emission and they did not include a statement about test the EUT in 3 orthogonal planes. They send the additional information and stated that it was tested in the 3 orthogonal planes. Sincerely, Eric Dobson

SK TECH CO., LTD. Page 1 of 2 SKT SKTOS-01044 FCC ID : XXXBONTEC-003 External Photographs of EUT SK TECH CO., LTD. Page 2 of 2 SKT SKTOS-01044 FCC ID : XXXBONTEC-003

SK TECH CO., LTD. Page 1 of 1 SKT SKTOS-01044 FCC ID : XXXBONTEC-003 FCC ID Sample Label & Location Information LABELLING REQUIREMENTS PER ∫∫∫∫ ∫∫∫∫∫∫∫∫ ∫∫∫∫2.928 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. FCC ID : PLNBONTEC-003 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

SK TECH CO., LTD. Page 1 of 3 SKT SKTOS-01044 FCC ID : XXXBONTEC-003 Internal Photographs of EUT SK TECH CO., LTD. Page 2 of 3 SKT SKTOS-01044 FCC ID : XXXBONTEC-003 SK TECH CO., LTD. Page 3 of 3 SKT SKTOS-01044 FCC ID : XXXBONTEC-003

SK TECH CO., LTD. Page 1 of 10 SKT SKTOS-01044 FCC ID : XXXBONTEC-003 Certificate of Compliance Test Report No.: SKTOS-01044 NVLAP CODE : 200220-0 Applicant: BONTECH CO., LTD Applicant Address: #27-31, Hanchun-Ri, Ducksan-Myun, Jinchun-Gun, Chungbuk, Korea Product: Transmitter keyless FCC ID: XXXBONTEC-003 Model No.: BONTEC-003 Receipt No.: SKE20010323-239 Date of receipt: Mar. 23, 2001 Date of Issue: Apr. 09, 2001 Testing location: SK TECH CO., LTD. 820-2, Wolmoon-Ri, Wabu-Up, Namyangju-Si, Kyunggi-Do, Korea Test Standards: ANSI C63.4 / 1992 Rule Parts: FCC part 15 Subpart C Equipment Class : Class B Digital Device Peripheral Test Result: The above mentioned product has been tested and passed. Prepared by:Y.H. Kang Tested by:K.H.Nam/Engineer Approved by: J.Y.Hyun /Lab.Manager Signature Date Signature Date Signature Date Other Aspects : Abbreviations : · OK, Pass = passed · Fail = failed · N/A = not applicable ☞ ☞☞ ☞ •This test report is not permitted to copy partly without our permission. •This test result is dependent on only equipment to be used. •This test result is based on a single evaluation of one sample of the above mentioned. •This test report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S Government. • We certify that this test report has been based on the measurement standards that is traceable to the national or International standards. NVLAP Lab. Code: 200220-0 SK TECH CO., LTD. Page 2 of 10 SKT SKTOS-01044 FCC ID : XXXBONTEC-003 SK TECH CO., LTD. Page 3 of 10 SKT SKTOS-01044 FCC ID : XXXBONTEC-003 》》 》》》》 》》 Contents 《《 《《《《 《《 Contents 2 List of Tables 2 List of Figures 2 List of Photographs 2 1. General 3 2. Test Site 3 2.1 Location 3 2.2 List of Test and Measurement Instruments 4 2.3 Test Date 4 2.4 Test Environment 4 3. Description of the tested samples 5 3.1 Rating and Physical characteristics 5 3.2 Submitted Documents 5 4. Measurement Conditions 6 4.1 Modes of Operation 6 4.2 List of Peripherals 6 4.3 Type of Used cables 6 4.4 Test Setup 6 4.5 Uncertainty 6 5. Emission Test 7 5.1 Radiated Emissions 7 》 》》 》List of Tables Table 1 List of test and measurement equipment 4 Table 2 Test Data, Radiated Emissions 8 SK TECH CO., LTD. Page 4 of 10 SKT SKTOS-01044 FCC ID : XXXBONTEC-003 1. General This equipment has been shown to be capable of compliance with the applicable technical standards and was tested in accordance with the measurement procedures as indicated in this report. We attest to the accuracy of data. All measurements reported herein were performed by SK Tech Co., Ltd. and were made under Chief Engineer’s supervision. We assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. 2. Test Site SK TECH Co., Ltd. 2.1 Location 820-2, Wolmoon Ri, Wabu-Up, Namyangju-Si, Kyunggi-Do, Korea The test site is in compliance with ANSI C63.4/1992 for measurement of radio interference. SK TECH CO., LTD. Page 5 of 10 SKT SKTOS-01044 FCC ID : XXXBONTEC-003 2.2 List of Test and Measurement Instruments Table 1 : List of Test and Measurement Equipment z Radiated Emissions Kind of Equipment Type S/N Calibrated until Field Strength Meter ESVS 10 825120/013 04.2001 Spectrum Analyzer R3361A 11730187 07.2001 Amplifier 8447F 3113A05153 05.2001 Log Periodic Antenna UHALP9107 91071238 04.2001 Biconical Antenna BBA9106 N/A 04.2001 Open Site Cable N/A N/A 07.2001 Antenna Mast 5907 N/A N/A Antenna & Turntable controller 5906 91X519 N/A Amp & Receiver connection cable N/A N/A 07.2001 Amp & Spectrum connection cable N/A N/A 07.2001 50Ω Switcher MP59B M93083 07.2001 2.3 Test Date Date of Application : Mar. 23, 2001 Date of Test : Apr . 03, 2001 2.4 Test Environment See each test item’s description. SK TECH CO., LTD. Page 6 of 10 SKT SKTOS-01044 FCC ID : XXXBONTEC-003 3. Description of the tested samples The EUT is Transmitter Keyless. 3.1 Rating and Physical Characteristics TRANSMITTER RECEIVER Operating Voltage 4.5 ~ 6 VDC 10 ~ 16 VDC Consumption Current Max 20mA Max 5mA Operating frequency 315MHz Power 10mW under - Sensitivity - -95dBm(typical) Operating temperature -30 ~ +80°C -30 ~ +80°C 3.2 Submitted Documents N/A SK TECH CO., LTD. Page 7 of 10 SKT SKTOS-01044 FCC ID : XXXBONTEC-003 4. Measurement Conditions Testing Input Voltage : DC 4.5V~6V 4.1 Modes of Operation The EUT was in the following operation mode during all testing; The EUT is in the mode of pushing the Lock / Unlock key button. 4.2 List of Peripherals Description Manufacturer Model Name Serial No. FCC ID Receiver Bontec N/A N/A N/A 4.3 Type of Used Cables Description Length Type of shield Manufacturer Remark N/A 4.4 Test Setup The test setup photographs showed the external supply connections and interfaces. 4.5 Uncertainty 1) Radiated disturbance Uc (Combined standard Uncertainty) = ±1.9dB Expanded uncertainty U = KUc K = 2 ∴ U = ±3.8dB 2) Conducted disturbance Uc = ±0.88dB U = KUc = 2xUc = ±1.8dB SK TECH CO., LTD. Page 8 of 10 SKT SKTOS-01044 FCC ID : XXXBONTEC-003 5. EMISSION Test 5.1 Radiated Emissions Result : Pass Preliminary measurements were made indoors at 1 meter using broadband antennas, broadband amplifier, and spectrum analyzer to determine the frequency producing the maximum EME. Appropriate precaution was taken to ensure that all EME from the EUT were maximized and investigated. The system configuration, clock speed, mode of operation or video resolution, turntable azimuth with respect to the antenna were noted for each frequency found. The spectrum was scanned from 30 to 300 MHz using biconical antenna and from 300 to 1000 MHz using log-periodic antenna. Above 1GHz, linearly polarized double ridge horn antennas were used. Final measurements were made outdoors at 3-meter test range using SCHWARZBECK dipole antennas. The test equipment was placed on a wooden table situated on a 4x4 meter area adjacent to the measurement area. Turntable was to protect from weather in the dome that made with FRP. Suff…

Text truncated - open the document above for the full version.

SK TECH CO., LTD. Page 1 of 1 SKT SKTOS-01044 FCC ID : XXXBONTEC-003 Test set up photos Photograph 1: Setup for Radiated Emissions
