PLNHM-T002Part 15 Security/ Remote Control Transmitter

HYUNDAI MOBIS Page 1 of 1 HM-NARPT-0412-01 FCC ID: PLNHM-T002 External Photos

HYUNDAI MOBIS Page 1 of 1 HM-NARPT-0412-01 FCC ID: PLNHM-T002 Label Sample & Location 1. Label Sample 2. Label Location The Label will be attached on the bottom side of product

HYUNDAI MOBIS Page 1 of 1 HM-NARPT-0412-01 FCC ID: PLNHM-T002 Internal Photos

HYUNDAI MOBIS Page 1 of 1 HM-NARPT-0412-01 FCC ID: PLNHM-T002 <Operational Description> Primary Functon - Remote Door Lock & Unlock - Remote Panic Alarm 2.General Description - Receiver control vehicle door - Receiver has RF module (315MHz) - RF module use super-heterodyne circuit - Receiver control door relay,hazard relay - Receiver has EEPROM that save rolling code 3.System Configuration

TX DATA OUTPUT RF ENABLE OUTPUT BAT CR2032 C1 103 TP1 +B 1 TP2 GND 1 Q1 DTA114YUA D1 SML-311UT R1 102J SW1 LOCK C4 27p R2 473J C3 102 L1 56N C6 22p R3 201J C5 2.7p Q2 2SC4226 C2 103 TP5 5 1 IC1 HCS1370 RC0 1 RC1 2 RC2 3 RC3 4 RC4 5 RC5/LC 6 RC6/T0CKI 7 RB4/VIN 8 RB3/STEP 9 RB2 10 Vss 11 RB1 12 RB0/MCLR 13 Vdd 14 C7 OPEN C10 18p X1 SARCC315M00BXL3RO5 1 1 2 2 3 3 4 4 5 5 6 6 C13 10p C8 102 C12 OPEN SW2 UNLOCK SW3 PANIC L2 220N L3 150N C11 2.7p C9 12p R4102J R6 102J R5102J

HYUNDAI MOBIS Page 1 of 13 HM-NARPT-0412-01 FCC ID: PLNHM-T002 Certificate of Compliance Test Report No.: HM-NARPT-0412-01 FCC Reg.No: 899163 Applicant: BONTEC Co., Ltd. Applicant Address: # 27-31, Hanchun-Ri, Ducksan-Myun, Jinchun-Gun, Chung-Buk , Korea Device Under Test: Remote Keyless Entry (Transmitter) FCC ID: PLNHM-T002 Model No.: HM-T002 Date of Issue: Dec 06, 2004 Location of Testing: HYUNDAI MOBIS CO., LTD. # 80-09,Mabook-Ri,Guseong-Eup,Yongin-Shi,Gyunggi-Do, Korea Test Procedure: ANSI C63.4 / 2001 Test Specification: FCC Title 47, Part 15 Subpart C Equipment Class: Part 15 Security/Remote Control Transmitter Test Result: The above-mentioned device has been tested and passed. Other Aspects: Abbreviations: · OK, Pass = passed · Fail = failed · N/A = not applicable •This test report is not permitted to copy partly without our permission. •This test result is dependent on only equipment to be used. •This test result is based on a single evaluation of one sample of the above mentioned. • We certify that this test report has been based on the measurement standards that is traceable to the national or International standards. HYUNDAI MOBIS Page 2 of 13 HM-NARPT-0412-01 FCC ID: PLNHM-T002 >> CONTENTS << 1. GENERAL ...............................................................................................3 2. TEST SITE ..............................................................................................3 2.1 Location ................................................................................................3 2.2 List of Test and Measurement Instruments ...............................................4 2.3 Test Date ..............................................................................................4 2.4 Test Environment ...................................................................................4 3. DESCRIPTION OF The EQUIPMENT UNDER TEST ..................................5 3.1 Rating and Physical Characteristics ..........................................................5 3.2 Equipment Modifications ........................................................................5 3.3 Submitted Documents ............................................................................5 4. MEASUREMENT CONDITIONS ...............................................................6 4.1 Description of test configuration ..............................................................6 4.2 List of Peripherals ..................................................................................6 4.3 Type of used Cables ...............................................................................6 4.4 Uncertainty ...........................................................................................6 5. TEST AND MEASUREMENTS ...................................................................7 5.1 ANTENNA REQUIREMENT ...............................................................7 5.1.1 Regulation ......................................................................................7 5.1.2 Result .............................................................................................7 5.2 RADIATED EMISSIONS ...................................................................8 5.2.1 Regulation ......................................................................................8 5.2.2 Measurement Procedure ...................................................................8 5.2.3 Calculation of the filed strength limits by linear interpolation ...............9 5.2.4 Calculation of Average Correction Factor ............................................9 5.2.5 Test Results ....................................................................................9 Table 1: Measured values of the Field strength.................................................10 5.3 PERIODIC OPERATION CHARACTERISTICS .................................11 5.3.1 Periodic Operation .........................................................................11 5.3.2 Manually Operated Transmitter Deactivation ....................................11 5.3.3 Result ...........................................................................................11 5.4 OCCUPIED BANDWIDTH ...............................................................12 5.4.1 Regulation ....................................................................................12 5.4.2 Calculation of 20dB Bandwidth Limit ................................................12 5.4.3 Test Procedure ..............................................................................12 5.4.4 Test Results ...................................................................................12 Figure 1: Measured value of the Occupied bandwidth.......................................13 HYUNDAI MOBIS Page 3 of 13 HM-NARPT-0412-01 FCC ID: PLNHM-T002 1. GENERAL These tests were performed using the test procedure outlined in ANSI C63.4, 2001 for intentional radiators, and in accordance with the limits set forth in FCC Part 15.231 for periodic transmitter. The EUT (Equipment Under Test) has been shown to be capable of compliance with the applicable technical standards. We attest to the accuracy of data. All measurements reported herein were performed by HYUNDAI MOBIS Co., Ltd. and were made under Chief Engineer’s supervision. We assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. 2. TEST SITE HYUNDAI MOBIS Co., Ltd. 2.1 Location # 80-09,Mabook-Ri,Guseong-Eup,Yongin-Shi,Gyunggi-Do, Korea This test site is in compliance with ANSI C63.4 ;2001 for general requirements for the competence of testing and calibration laboratories. This laboratory is accredited by FCC (FCC REGISTRATION NO.:899163) HYUNDAI MOBIS Page 4 of 13 HM-NARPT-0412-01 FCC ID: PLNHM-T002 2.2 List of Test and Measurement Instruments Equipment Type Manufacturer Model No. Serial No. Cal. Due Date EMI Test Receiver Rohde&Schwarz ESIB 26 100…

Text truncated - open the document above for the full version.

HYUNDAI MOBIS Page 1 of 1 HM-NARPT-0412-01 FCC ID: PLNHM-T002 Test Set-up Photos
